GM Vehicle Care/Appearance Materials
PART NUMBERSIZEDESCRIPTIONUSAGE
99495423 in. x 25 in.Polishing Cloth ± Wax TreatedExterior polishing cloth
105017216 oz. (0.473 L)Tar and Road Oil RemoverRemoves tar, road oil and asphalt
105017316 oz. (0.473 L)Chrome Cleaner and PolishUse on chrome, stainless steel, nickel, copper and brass
105017416 oz. (0.473 L)White Sidewall Tire CleanerRemoves soil and black marks from whitewalls
105021432 oz. (0.946 L)Vinyl CleanerCleans vinyl tops, upholstery and convertible tops
105042723 oz. (0.680 L)Glass CleanerRemoves dirt, grime, smoke and fingerprints
1052918**8 oz. (0.237 L)Armor All ProtectantProtects leather, wood, acrylics, Plexiglas, plastic,
rubber and vinyl
105292516 oz. (0.473 L)Multi-Purpose
Interior CleanerCleans carpets, seats, interior trim, door panels
and floor mats
105292916 oz. (0.473 L)Wheel CleanerSpray on and rinse with water
10529308 oz. (0.237 L)Capture Dry Spot RemoverAttracts, absorbs and removes soils on fabric
123457212.5 sq. ft.Synthetic ChamoisShines vehicle without scratching
1234572512 oz. (0.354 L)Silicone Tire ShineSpray on tire shine
12377964*16 oz. (0.473 L)Finish EnhancerRemoves dust, fingerprints and surface contaminants
12377966*16 oz. (0.473 L)Cleaner WaxRemoves light scratches and oxidation and protects finish
12377984*16 oz. (0.473 L)Surface CleanerRemoves contaminants, blemishes and swirl marks
See your General Motors Parts Department for these products. * For exterior use only.
See ªRecommended Fluids and Lubricantsº in the Index. ** Not recommended for use on instrument panels.
Page 306 of 328
6-55
Vehicle Identification Number (VIN)
This is the legal identifier for your vehicle. It appears on
a plate in the front corner of the instrument panel, on the
driver's side. You can see it if you look through the
windshield from outside your vehicle. The VIN also
appears on the Vehicle Certification and Service Parts
labels and the certificates of title and registration.
Engine Identification
The 8th character in your VIN is the engine code.
This code will help you identify your engine,
specifications and replacement parts.
Service Parts Identification Label
You'll find this label behind the passenger's side
access panel in the trunk (the panel that covers the
trunk
-mounted CD changer). It's very helpful if you
ever need to order parts. On this label is:
your VIN,
the model designation,
paint information and
a list of all production options and
special equipment.
Be sure that this label is not removed from the vehicle.
Page 307 of 328

6-56
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle
unless you check with your dealer first. Some
electrical equipment can damage your vehicle
and the damage wouldn't be covered by your
warranty. Some add
-on electrical equipment
can keep other components from working as
they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Headlamp Wiring
The headlamp wiring has several fuses which are
powered by a MaxiFuse. An electrical overload will
cause the lamps to go on and off, or in some cases to
remain off. If this happens, have the headlamp wiring
checked right away.
Windshield Wiper Fuses
If the windshield wiper motor overheats due to heavy
snow or ice, the wipers will stop until the motor cools.
If the overload is caused by some electrical problem, be
sure to have it fixed.
Power Windows and Other Power Options
Circuit breakers protect the power windows and other
power accessories. When the current load is too heavy,
the circuit breaker opens and closes, protecting the
circuit until the problem is fixed or goes away.
Page 308 of 328

6-57 Power Distribution Fuse Block
This fuse block is attached to the engine compartment
relay center located on top of the battery. Simply lift the
lid to open. If you have any questions about the power
distribution fuse block, consult your dealer.
Please note that if a power loss has occurred, such as
disconnecting the battery or removing the Maxi Fuses in
the power distribution fuse block, there are steps that
must be followed to calibrate the electronic throttle
control (ETC). If these steps are not done, the engine
will not run properly. For information regarding these
steps, see ªBatteryº earlier in this section.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses and circuit
breakers. This greatly reduces the chance of fires caused
by electrical problems.
Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical size
and rating.
If you ever have a problem on the road and don't have
a spare fuse, you can borrow one that has the same
amperage. Pick some feature of your vehicle that you
can get along without
-- like the radio or cigarette
lighter
-- and use its fuse, if it is the correct amperage.
Replace it as soon as you can.
There are two fuse blocks in your vehicle: the
instrument panel fuse block and the engine
compartment relay center.
Page 309 of 328
6-58
Instrument Panel Fuse Block (Driver's Side)
The fuse block is located below the steering wheel on
the driver's side. Using a screwdriver, loosen the two
trim fasteners under the trim panel and pull the trim
panel away from the instrument panel to access.
Fuse Usage
1 RH and LH Front Side Door
Window Regulator Motor, LH
Front Side Door Window Switch
2 Stoplamp Switch, Cruise Control
Release Switch
3 Automatic Transmission Range
Switch, Automatic Transmission
Control Indicator, Power Steering
Control Module, Hazard Warning
Switch, Automatic Transmission
Winter Mode Switch, Transmission
Control Module (TCM)
Page 310 of 328

6-59
Fuse Usage
4 RH and LH Rear Seat Cushion
Heater Relay, Rear Sunshade
Motor, Accessory Power Outlet
5 Transmission Control Module
6 Radio Speaker Amplifier
7 RH and LH Rear Side Door
Window Regulator Motor
8 Headlamp Switch, Turn Signal
Switch, Horn Relay, CD Changer,
Multifunction Relay
9 Windshield Wiper Motor and
Relay, Windshield Wiper and
Windshield Washer Switch
10 Body Control Module (BCM),
Heater Water Auxiliary Pump,
Fan Control Relays, Auxiliary
Water Pump Relay
11 Heater and A/C Control, RH and
LH Outside Rearview Mirrors
12 Hazard Warning Switch,
Instrument Cluster, Data Link
Connector (DLC), Stoplamp
Switch, Gage Cluster,
Heater and A/C Control.Fuse Usage
13 Remote Control Outside Rearview
Mirror Switch, A/C Compressor
Relay, Coolant Fan Test
Connector, A/C Load Switch
14 Cellular Telephone, RH and LH
Windshield Washer Nozzles,
Driver and Passenger Heated Seat
Switch, Heater and A/C Control,
Heated Outside Rearview Mirror
and Rear Window Defogger Relay
15 Rear Suspension Leveling Air
Compressor Relay, Instrument
Cluster, Gage Cluster, Cruise
Control Switch, Headlamp Switch,
Multifunction Relay, Passenger
and Driver Heated Seat Relay,
BCM, Sunroof Actuator,
Automatic Level Control Sensor,
RH and LH Heated Rear Seat
Switch, RH and LH Heated Rear
Seat Cushion Relay, Driver Seat
Adjuster Memory Module, LH
Front Side Door Window Switch,
Inside Rearview Mirror
Page 311 of 328

6-60
Fuse Usage
16 Cigarette Lighter
(Front and Console)
17 Horn #1 and #2
18 Fuel Pump
19 Electronic Brake/Traction
Control Module
20 Passenger and Driver Heated
Seat Relay
21 Daytime Running Lamp (DRL)
Relay, LH High
-Beam
Headlamp Relay
22 Headlamp Switch,
LH Low
-Beam Headlamp
23 LH Parking Lamp and Turn Signal
Lamps, LH Rear Sidemarker
Lamp, Multifunction Relay, LH
Stoplamp and Taillamp
24 Lifting Magnet, BCM,
Gage Cluster
25 Sunroof ActuatorFuse Usage
26 Headlamp Switch, RH and LH
Front Sidemarker Lamp, Middle
Taillamp, RH and LH Rear
License Plate Lamp, Radio,
Automatic Transmission Control
Indicator, Heater and A/C Control
27 Automatic Level Control Sensor,
Rear Suspension Leveling Air
Compressor and Relay
28 Door Lock Relay
29 Multifunction Relay,
OnStar
System
30 RH Parking Lamp and Turn Signal
Lamp, RH Rear Sidemarker
Lamp, RH Stoplamp and Taillamp
31 RH Low
-Beam Headlamp Turn
Signal Switch
32 RH High
-Beam Headlamp Relay
33 Blower Controller,
A/C Compressor Relay
34 Heated Rear Window
Defogger Relay
35 Passenger Seat Adjuster
Switch, Driver Seat Adjuster
Memory Module
Page 312 of 328
6-61
Relay Box
The relay box is located on the lower part of the
instrument panel, to the right of the steering column.Relay Usage
I Daytime Running Lamps
II Automatic Level Control
III Rear Window Defogger,
Heated Mirrors
IV Hazard Warning Flashers
V High
-Beam Headlamps II (RH)
VI Horn
VII Parking Lamps and
Turn Signal Lamps
VIII Low
-Beam Headlamps
IX Not Used
X Not Used
XI High
-Beam Headlamps I (LH)
