2000 YAMAHA YZF-R6 Owners Manual

OPERATION AND IMPORTANT RIDING POINTS
5-5
5
EAU01128
Engine break-inThere is never a more important period
in the life of your motorcycle than the
period between zero and 1,600 km. For
this reason we ask that you carefully
read the following material. Because
the engine is brand new, you must not
put an excessive load on it for the first
1,600 km. The various parts in the en-
gine wear and polish themselves to the
correct operating clearances. During
this period, prolonged full throttle oper-
ation, or any condition which might re-
sult in excessive heating of the engine,
must be avoided.
EAU01329
0 ~ 1,000 km
Avoid operation above 5,000 r/min.
1,000 ~ 1,600 km
Avoid cruising speeds in excess of
6,000 r/min.
EC000052
CAUTION:@ After 1,000 km of operation, be sure
to replace the engine oil and oil fil-
ter. @1,600 km and beyond
Proceed with normal riding.
EC000053
CAUTION:@ l
Never let engine speeds enter
the red zone.
l
If any engine trouble should oc-
cur during the break-in period,
consult a Yamaha dealer imme-
diately.
@
EAU00460
ParkingWhen parking the motorcycle, stop the
engine and remove the ignition key.
EW000058
WARNING
@ The exhaust system is hot. Park the
motorcycle in a place where pedes-
trians or children are not likely to
touch the motorcycle. Do not park
the motorcycle on a slope or soft
ground; the motorcycle may over-
turn. @
E_5eb_Operation.fm Page 5 Thursday, November 18, 1999 4:05 PM

6
PERIODIC MAINTENANCE AND MINOR REPAIR
Tool kit................................................................... 6-1
Periodic maintenance and lubrication ................... 6-3
Cowling and panel removal and installation.......... 6-6
Cowlings A and B ................................................. 6-6
Panel C ................................................................. 6-8
Spark plug inspection ........................................... 6-9
Engine oil ............................................................ 6-10
Cooling system ................................................... 6-13
Changing the coolant .......................................... 6-14
Air filter ............................................................... 6-17
Air intake duct ..................................................... 6-19
Carburetor adjustment ........................................ 6-20
Idle speed adjustment ........................................ 6-20
Throttle cable free play inspection ...................... 6-21
Valve clearance adjustment ................................ 6-21
Tires .................................................................... 6-21
Wheels ................................................................ 6-24
Clutch lever free play adjustment........................ 6-25
Brake light switch adjustment ............................. 6-25
Checking the front and rear brake pads.............. 6-26
Inspecting the brake fluid level............................ 6-27
Brake fluid replacement ...................................... 6-28
Drive chain slack check ...................................... 6-28Drive chain slack adjustment ............................. 6-29
Drive chain lubrication........................................ 6-29
Cable inspection and lubrication ........................ 6-30
Throttle cable and grip lubrication ...................... 6-30
Brake pedal lubrication....................................... 6-30
Brake and clutch lever lubrication ...................... 6-31
Sidestand lubrication.......................................... 6-31
Rear suspension lubrication............................... 6-31
Front fork inspection ........................................... 6-32
Steering inspection ............................................ 6-32
Wheel bearings .................................................. 6-33
Battery................................................................ 6-33
Fuse replacement .............................................. 6-34
Headlight bulb replacement ............................... 6-35
Tail/brake light bulb replacement ........................ 6-36
Turn signal light bulb replacement...................... 6-36
Supporting the motorcycle ................................. 6-37
Front wheel removal ........................................... 6-37
Front wheel installation ...................................... 6-38
Rear wheel removal ........................................... 6-39
Rear wheel installation ....................................... 6-40
Troubleshooting .................................................. 6-40
Troubleshooting chart ......................................... 6-41
E_5eb_PeriodicTOC.fm Page 1 Thursday, November 18, 1999 4:06 PM

6-1
6
EAU00462
6-PERIODIC MAINTENANCE AND MINOR REPAIR
EAU00464
Periodic inspection, adjustment and lu-
brication will keep your motorcycle in
the safest and most efficient condition
possible. Safety is an obligation of the
motorcycle owner. The maintenance
and lubrication schedule chart should
be considered strictly as a guide to
general maintenance and lubrication
intervals. YOU MUST TAKE INTO
CONSIDERATION THAT WEATHER,
TERRAIN, GEOGRAPHICAL LOCA-
TIONS, AND A VARIETY OF INDIVID-
UAL USES ALL TEND TO DEMAND
THAT EACH OWNER ALTER THIS
TIME SCHEDULE TO SHORTER IN-
TERVALS TO MATCH THE ENVI-
RONMENT. The most important points
of motorcycle inspection, adjustment,
and lubrication are explained in the fol-
lowing pages.
EW000060
WARNING
@ If you are not familiar with motor-
cycle service, this work should be
done by a Yamaha dealer. @
EAU01296
CAUTION:@ Do not test this motorcycle on a dy-
namometer for an extended period
of time as discoloration to the fiber
constructed muffler may occur from
the heat. @
EAU01129
Tool kitThe tool kit is located inside the storage
compartment. (See page 3-17 for com-
partment opening procedures.) The
tools provided in the owner’s tool kit are
to assist you in the performance of pe-
riodic maintenance. However, some
other tools such as a torque wrench are
also necessary to perform the mainte-
nance correctly.
The service information included in this
manual is intended to provide you, the
owner, with the necessary information
for completing some of your own pre-
ventive maintenance and minor re-
pairs.1. Tool kit
E_5eb_Periodic.fm Page 1 Thursday, November 18, 1999 4:06 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-2
6
NOTE:@ If you do not have necessary tools re-
quired during a service operation, take
your motorcycle to a Yamaha dealer for
service. @
EW000062
WARNING
@ Modifications to this motorcycle not
approved by Yamaha may cause
loss of performance, excessive
emissions, and render it unsafe for
use. Consult a Yamaha dealer be-
fore attempting any changes. @
E_5eb_Periodic.fm Page 2 Thursday, November 18, 1999 4:06 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-3
6
EAU00473
PERIODIC MAINTENANCE AND LUBRICATION
CP-01ENO. ITEM CHECKS AND MAINTENANCE JOBSINITIAL
(1,000 km)EVERY
6,000 km
or
6 months
(whichever
comes first)12,000 km
or
12 months
(whichever
comes first)
1
*Fuel line• Check fuel hoses for cracks or damage.
• Replace if necessary.ÖÖ
2*Fuel filter• Check condition.
• Replace if necessary.Ö
3 Spark plugs• Check condition.
• Clean, regap or replace if necessary.ÖÖÖ
4*Valves• Check valve clearance.
• Adjust if necessary.Every 42,000 km or 42 months
(whichever comes first)
5 Air filter• Replace if necessary.ÖÖ
6Clutch• Check operation.
• Adjust or replace cable.ÖÖÖ
7*Front brake• Check operation, fluid level and vehicle for fluid leakage.
(See NOTE on page 6-5.)
• Correct accordingly.
• Replace brake pads if necessary.ÖÖÖ
8*Rear brake• Check operation, fluid level and vehicle for fluid leakage.
(See NOTE on page 6-5.)
• Correct accordingly.
• Replace brake pads if necessary.ÖÖÖ
9*Wheels• Check balance, runout and for damage.
• Rebalance or replace if necessary.ÖÖ
E_5eb_Periodic.fm Page 3 Thursday, November 18, 1999 4:06 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-4
6
10
*Tires• Check tread depth and for damage.
• Replace if necessary.
• Check air pressure.
• Correct if necessary.ÖÖ
11*Wheel bearings• Check bearing for looseness or damage.
• Replace if necessary. ÖÖ
12*Swingarm• Check swingarm pivoting point for play.
• Correct if necessary.
• Lubricate with lithium soap base grease every 24,000 km
or 24 months (whichever comes first).ÖÖ
13 Drive chain• Check chain slack.
• Adjust if necessary. Make sure that the rear wheel is properly
aligned.
• Clean and lubricate. Every 1,000 km and after washing the
motorcycle or riding in the rain
14*Steering bearings• Check bearing play and steering for roughness.
• Correct accordingly.
• Lubricate with lithium soap base grease every 24,000 km
or 24 months (whichever comes first).ÖÖ
15*Chassis fasteners• Make sure that all nuts, bolts and screws are properly tightened.
• Tighten if necessary.ÖÖ
16 Sidestand• Check operation.
• Lubricate and repair if necessary.ÖÖ
17*Sidestand switch• Check operation.
• Replace if necessary.ÖÖÖ
18*Front fork• Check operation and for oil leakage.
• Correct accordingly.ÖÖ
19*Rear shock absorber
assembly• Check operation and shock absorber for oil leakage.
• Replace shock absorber assembly if necessary. ÖÖ NO. ITEM CHECKS AND MAINTENANCE JOBSINITIAL
(1,000 km)EVERY
6,000 km
or
6 months
(whichever
comes first)12,000 km
or
12 months
(whichever
comes first)
E_5eb_Periodic.fm Page 4 Thursday, November 18, 1999 4:06 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-5
6
* Since these items require special tools, data and technical skills, they should be serviced by a Yamaha dealer.
EAU02970*
NOTE:@ l
The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
l
Hydraulic brake system
• When disassembling the master cylinder or caliper cylinder, always replace the brake fluid. Check the brake fluid level
regularly and fill as required.
• Replace the oil seals on the inner parts of the master cylinder and caliper cylinder every two years.
• Replace the brake hoses every four years or if cracked or damaged.
@20
*Rear suspension relay
arm and connecting arm
pivoting points• Check operation.
• Correct if necessary.ÖÖ
21*Carburetors• Check engine idling speed, synchronization and starter operation.
• Adjust if necessary.ÖÖÖ
22 Engine oil• Check oil level and vehicle for oil leakage.
• Correct if necessary.
• Change. (Warm engine before draining.)ÖÖÖ
23 Engine oil filter cartridge•Replace.ÖÖ
24*Cooling system• Check coolant level and vehicle for coolant leakage.
• Correct if necessary.
• Change coolant every 24,000 km or 24 months (whichever comes
first).ÖÖ NO. ITEM CHECKS AND MAINTENANCE JOBSINITIAL
(1,000 km)EVERY
6,000 km
or
6 months
(whichever
comes first)12,000 km
or
12 months
(whichever
comes first)
E_5eb_Periodic.fm Page 5 Thursday, November 18, 1999 4:06 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-6
6
EAU01139
Cowling and panel removal
and installationThe cowlings and panels illustrated
need to be removed to perform some
of the maintenance described in this
chapter. Refer to this section each time
a cowling or panel has to be removed
or reinstalled.
EAU01602
Cowlings A and BTo remove
1. Remove the screws.
1. Cowling A (right side)
Cowling B (left side)
2. Panel C
1. Screw (´ 5)
1. Screw (´ 6)
E_5eb_Periodic.fm Page 6 Thursday, November 18, 1999 4:06 PM
