2000 TOYOTA CAMRY Keyless

I00229
0.75 ± 0.1 sec.
1.25 ± 0.1 sec.
ON
OFF
Blinking Pattern Security only: DI±830
± DIAGNOSTICSTHEFT DETERRENT SYSTEM
1065 Author: Date:
4. CANCELLATION OF THEFT DETERRENT OPERA-
TION OR MODE
The theft deterrent operation of mode can be cancelled when
any of the following conditions is met.
No.ConditionCancel of OperationCancel of Mode
1Unlock front doors with the keyEffectiveEffective
2Unlock doors with remote keyless entryEffectiveEffective
3Insert key into ignition key cylinder and turn
it to ACC or ON positionEffectiveEffective
4About 1 minute passes after theft deterrent
operation beginsAutomatic stop *1±
5Unlock the luggage compartment door with
the key or keyless entry.UneffectiveEffective
6Unlock the luggage compartment door with
the keyless entry.UneffectiveEffective
7
If the system receives panic signal again or
unlock signal when the system is activated
by panic signal
Effective *2Uneffective
6If the system receives unlock signal when
the system is activated by panic signalEffectiveEffective
*1: The system is set to the theft deterrent mode again in
about 2 seconds after the operation stops, if all doors are
closed.
*2: The alarm caused by the panic signal malces the sys-
tem in the previous condition.
5. INDICATOR LIGHT (LED)
The indicator light functions as shown below according to the
system condition in the theft deterrent mode. It remains OFF in
the initial state.
System ConditionIndicator Light
During set preparation timeON
When the mode is set*OFF
When alarm is activatedON
When the system is temporally cancelled*OFF
*: The indicator flashes with the output from the immobiliser.
6. KEEPING POWER SUPPLY FUNCTION IN CASE OF
DOME FUSE OPEN
Even if the dome fuse blows open on the theft deterrent mode,
the system will keep working on the theft deterrent mode.

DI±836
± DIAGNOSTICSTHEFT DETERRENT SYSTEM
1071 Author: Date:
+B1 e Body ground
(T4±12 eBody ground)R eW±BAlways10 ± 14 V
IG e E
(T4±13 e T3±7)B±R e W±BIgnition switch is turned to ºONº position10 ± 14 V
LSWD e ELRWB
Door unlock detection switch ºONº
(Driver's door)Below 1 WLSWD e E
(T4±14 e T3±7)L±R e W±BDoor unlock detection switch ºOFFº
(Driver's door)1 MW or higher
LSWP e EYWB
Door unlock detection switch ºONº
(Passenger's door)Below 1 WLSWP e E
(T4±15 e T3±7)Y e W±BDoor unlock detection switch ºOFFº
(Passenger's door)1 MW or higher
LSWR e ELYWB
Door unlock detection switch ºONº
(Rear door)Below 1 WLSWR e E
(T4±16 e T3±7)L±Y e W±BDoor unlock detection switch ºOFFº
(Rear door)1 MW or higher
PANI e ELGWBIt is receiving panic signal from remote keyless entryBelow 1 WPANI e E
(T4±18 e T3±7)LG e W±BExcept above mention1 MW or hegher
+B2 e Body ground
(T3±1 e Body ground)L±W e Body
groundAlways10 ± 14 V
IND e E
(T3±6 e T3±7)R±Y eW±BDuring set preparation3 ± 5 V
E e Body ground
(T3±7 e Body ground)W±B e Body
groundAlways10 ± 14 V
SH e E
(T3±9 e T3±7)W±L e W±BAlways10 ± 14 V
HEAD e E
(T3±10 e T3±7)R±B e W±BLight control switch ºHEADº10 ± 14 V
TA I L e E
(T3±11 e T3±7)G±R e W±BLight control switch ºTAILº or ºHEADº10 ± 14 V
HORN e E
(T3±12 e T3±7)G±B e W±BHorn switch ºOFFº10 ± 14 V

Toyota Supports ASE CertificationPage 1 of 2
EL008±98Title:
PROGRAMMING OEM WIRELESS
DOOR LOCK REMOTE TRANSMITTERS
Models:
'97 ± '99 Camry
Technical Service
BULLETIN
December 4, 1998

This bulletin describes procedures used to program the three button remote transmitter to
vehicles that are equipped with Wireless Door Lock Control. The following information
applies
only to the Factory Wireless Door Lock Control, not dealer or port installed
options that also utilize remotes, such as VIP Keyless Entry/RS3000 or any aftermarket
system.
Verification of
Factory Wireless Door Lock Control can easily be performed by identifying
the TDS status monitor, functioning remote, or model grade.
The Remote Transmitter has LOCK,
UNLOCK, and PANIC features.The TDS Status Monitor is located in
the Tachometer.
Transmitter Identification TDS Status Montior Indentification
NOTE:
When a new remote is programmed, all previous codes are erased. Because of this,
all remotes should be entered during the same programming session, otherwise a
remote may no longer be registered and operate the vehicle.
For Customer Satisfaction, request that any existing remote be furnished when
programming a new or replacement unit.
1997 ± 1999 Camrys:
1997 ± 1998 All XLE (standard equipment) and some LE (optional)
1999 All XLE only
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
ELECTRICAL
Introduction
Applicable
Vehicles
Warranty
Information

Toyota Supports ASE CertificationPage 1 of 6
EL008-02Title:
WIRELESS TRANSMITTER &
PROGRAMMING GUIDE
Models:
All Applicable
Technical Service
BULLETIN
December 20, 2002

TSB REVISION NOTICE:
February 28, 2003: In Wireless Transmitter Identification section (pages 5 and 6),
Figures 5, 9, 10, 12, and 13 updated to include 2003 model year; Figure 11 updated
to include 1999 and 2003 model year.
January 17, 2003: 2003 model year added to Solara in the Application Chart on
page 3.
The information contained in this TSB supercedes TSB EL010±01, dated October 26,
2001. The previous TSB, EL010±01, should be discarded.
Difficulties during Remote Keyless Entry Transmitter Programming can arise due to
confusion between Toyota Factory Wireless systems and Toyota Port/Dealer installed
systems. This bulletin will assist in identifying the system/correct remote transmitters for
each vehicle, and provide the location of the most accurate programming procedure for
each system.
All applicable Toyota vehicles.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
The following table contains all of the necessary information to correctly identify the type
of system installed, and where to go to get programming procedures for each vehicle.
NOTE:
Should a vehicle having both VIP and Factory systems available (as identified in the
following table) be brought in without any remotes (or one non±working remote), use
the following tips to help determine which type of wireless system (O.E. or PIO/DIO)
the vehicle has.
Look at the Trim Level of the vehicle. Higher±grade vehicles will tend to have O.E.
systems, while entry±grade vehicles will tend to have VIP. For example, the 2001
Camry XLE has Factory RKE, but the LE and CE grades have VIP.
Look for a ªStatus Monitorº with a glass breakage sensor and an LED externally
installed into the dashboard or on the center console. Most VIP systems will have
this.
Locate the ECU (refer to the applicable vehicle VIP Manual installation instructions
for location). Once located, refer to the part label.
Attempt to perform the factory wireless programming procedure to get a response
from the vehicle. Select the ªconfirmation modeº and see if any ªLock/Unlockº
response is received, if so, the vehicle has a factory system.
ELECTRICAL
Introduction
Applicable
Vehicles
Warranty
Information
System
Identification

OBSOLETE
PLEASE SEE EL008±02
Toyota Supports ASE CertificationPage 1 of 5
EL010-01Title:
WIRELESS TRANSMITTER &
PROGRAMMING GUIDE
Models:
All Applicable
Technical Service
BULLETIN
October 26, 2001

Difficulties during Remote Keyless Entry Transmitter Programming can arise due to
confusion between Toyota Factory Wireless systems and Toyota Port/Dealer installed
systems. This bulletin will assist in identifying the system/correct remote transmitters for
each vehicle, and provide the location of the most accurate programming procedure for
each system.
All applicable Toyota vehicles.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty±±±±
The following table contains all of the necessary information to correctly identify the type
of system installed, and where to go to get programming procedures for each vehicle.
NOTE:
Should a vehicle having both VIP and Factory systems available (as identified in the
following table) be brought in without any remotes (or one non±working remote), use
the following tips to help determine which type of wireless system (O.E. or PIO/DIO)
the vehicle has.
Look at the Trim Level of the vehicle. Higher±grade vehicles will tend to have O.E.
systems, while entry±grade vehicles will tend to have VIP. For example, the 2001
Camry XLE has Factory RKE, but the LE and CE grades have VIP.
Look for a ªStatus Monitorº with a glass breakage sensor and an LED externally
installed into the dashboard or on the center console. Most VIP systems will have
this.
Locate the ECU (refer to the applicable vehicle VIP Manual installation instructions
for location). Once located, refer to the part label.
Attempt to perform the factory wireless programming procedure to get a response
from the vehicle. Select the ªconfirmation modeº and see if any ªLock/Unlockº
response is received, if so, the vehicle has a factory system.
ELECTRICAL
Introduction
Applicable
Vehicles
Warranty
Information
System
Identification
