2000 SUBARU IMPREZA Owners Manual

Instruments and controls3-3
–
CONTINUED –
p ushing the knob and keep the knob p ushed for more
than 2 sec ond s.
NOTE If the connection between the combination meter and battery is bro-
ken for any reason such as vehicle maintenance or fuse replace-ment, the data recorded on the trip meter will be lost. Tachometer (if equipped)
CAUTION
Do not operate the engine with the pointer of the tachometer in
the red zone. In this range, fuel injection will be cut by the enginecontrol module to protect the engine from overrevving. The en-gine will resume running normally after the engine speed is re-duced below the red zone.
The tac hometer shows the eng ine sp eed in thousand s of revolutions p er
minute. Fuel gauge
The fuel g aug e shows the ap p roximate amount of fuel remaining in the
tank.
The g aug e d oes not return to “E ” even thoug h the ig nition switc h is in the
“ ACC ” or “LOCK ” p osition.
The g aug e may move slig htly d uring b raking , turning or ac c eleration d ue
to fuel movement in the tank.

3-4

Temperature gauge
CAUTION
If the pointer exceeds the normal operating range, safely stop the
vehicle as soon as possible.
See “ In case of emergency ” in this manual.
HG0297
Normal operating range
The temp erature g aug e shows eng ine c oolant temp erat ure when the
ig nition switc h is in the “ON ” p osition.
The c oolant temp erature will vary in ac c ord anc e wit h the outsid e temp er-
ature and d riving c ond itions.
We rec ommend that you d rive mod erately until the p o inter of the temp er-
ature g aug e reac hes near the mid d le of the rang e. E ng ine op eration is
op timum with the eng ine c oolant at this temp erature rang e and hig h rev-
ving op eration when the eng ine is not warmed up eno ug h should b e
avoid ed .

Instruments and controls3-5
–
CONTINUED –
Warning and indicator lights
Several of the warning and ind ic ator lig hts c ome on
momentarily and
then g o out when the ig nition switc h is initially t urned to the “ON ” p osi-
tion. This p ermits c hec king the op eration of the b u lb s.
Ap p ly the p arking b rake and turn the ig nition switc h to the “ON ” p osition.
The following lig hts c ome on:
Seat b elt warning lig ht
SRS airb ag system warning lig ht
Charg e warning lig ht
Oil p ressure warning lig ht
Brake system warning lig ht
CHECK ENGINE warning lig ht/Malfunc tion ind ic ator la mp
ABS warning lig ht (if eq uip p ed )
AT OIL TEMPerature warning lig ht (if eq uip p ed )
If any lig hts fail to c ome on, it ind ic ates a b urne d -out b ulb or a malfunc -
tion of the c orresp ond ing system.
Consult your authorized SUBARU d ealer for rep air. Seat belt warning light and chime
When the ig nition switc h is turned to the “ON ” p osition, the seat b elt
warning lig ht will c ome on and the remind er c hime will sound to remind
d river to fasten the seat b elt.
The seat b elt warning lig ht will remain on for ab ou t six sec ond s and turn
off automatic ally after six sec ond s.
The seat b elt remind er c hime will turn off when the d river’s sid e seat b elt
is b uc kled or it will turn off automatic ally after six sec ond s.
SRS airbag system warning light AIRBAG
When the ig nition switc h is turned to the “ON ” p osition, the SRS airb ag
warning lig ht will c ome on for ab out six sec ond s an d g o out. This shows
the SRS airb ag is in normal op eration.
If this lig ht c omes on while d riving or d oes not g o out after the eng ine
starts, it may ind ic ate that the SRS airb ag system is not working p rop erly.
Contac t your nearest SUBARU d ealer immed iately.

3-6

Charge warning light
If this lig ht c omes on when the eng ine is running , it may ind ic ate that the
c harg ing system is not working p rop erly.
If the lig ht c omes on while d riving or d oes not g o out after the eng ine
starts, stop the eng ine at the first safe op p ortuni ty and c hec k the alterna-
tor b elt. If the b elt is loose, b roken or if the b e lt is in g ood c ond ition b ut
the lig ht remains on, c ontac t your nearest SUBARU d ealer immed iately.
Oil pressure warning light
CAUTION
Do not operate the engine with the oil pressure warning light on. This may cause serious engine damage.
If this lig ht c omes on when the eng ine is running , it may ind ic ate that the
eng ine oil p ressure is low and the lub ric ating syst em is not working p rop -
erly.
If the lig ht c omes on while d riving or d oes not g o out after the eng ine
starts, stop the eng ine at the first safe op p ortuni ty and c hec k the eng ine
oil level. If the oil level is low, ad d oil immed ia tely. If the eng ine oil is at
the p rop er level b ut the lig ht remains on, c ontac t your nearest SUBARU
d ealer immed iately. Brake system warning light
WARNING
Driving with the brake system warning light on is dangerous.
This indicates your brake system may not be working properly. If the light remains on, have the brakes inspected by a SUBARU
dealer immediately. If at all in doubt about whether the brakes are operating prop-
erly, do not drive the vehicle. Have your vehicle towed to the
nearest SUBARU dealer for repair.
(Canada)
BRAKE (US)

Instruments and controls3-7
–
CONTINUED –
This lig ht has the following two func tions:
Parking brake warning
The lig ht c omes on with the p arking b rake ap p lied w hile the ig nition
switc h is in the “ON ” p osition. It g oes out when the p arking b rake is
fully released . Brake fluid level warning
This lig ht c omes on when the b rake fluid level d rop s to near the “MIN ”
level of the b rake fluid reservoir with the ig nitio n switc h in the “ON ”
p osition and with the p arking b rake fully released .
If the b rake system warning lig ht should c ome on wh ile d riving with
the p arking b rake lever fully released , it c ould b e an ind ic ation of
leaking of b rake fluid or worn b rake p ad s. In suc h a c ase, have your
vehic le c hec ked b y a SUBARU d ealer immed iately.
CHECK ENGINE warning light/ Malfunction indicator lamp
CAUTION
If the CHECK ENGINE light comes on while you are driving, have
your vehicle checked/repaired by your SUBARU dealer as soonas possible. Continued vehicle operation without having the
emission control system checked and repaired as necessarycould cause serious damage, which may not be covered by your
vehicle’ s warranty.
If this lig ht c omes on stead ily or b links while the eng ine is running , it may
ind ic ate that there is a p rob lem or p otential p rob l em somewhere in the
emission c ontrol system.
If the light comes on steadily:
If the lig ht c omes on stead ily while d riving or d oe s not g o out after the
eng ine starts, an emission c ontrol system malfunc ti on has b een d e-
tec ted .
You should have your vehic le c hec ked b y an authoriz ed SUBARU
d ealer immed iately.

3-8NOTE This light also comes on when the fuel filler cap is not tightened until it clicks. If you have recently refueled your vehicle, the
cause of the CHECK ENGINE warning light/malfunction indicatorlamp coming on could be a loose or missing fuel filler cap.Remove the cap and retighten it until it clicks. Make sure nothing
is interfering with the sealing of the cap. Tightening the cap will
not make the CHECK ENGINE warning light turn off immediately.It may take several driving trips. If the light does not go out, take
your vehicle to your authorized SUBARU dealer immediately.
If the light is blinking:
If the lig ht is b linking while d riving , an eng ine m isfire c ond ition has
b een d etec ted whic h may d amag e the emission c ontrol system.
To p revent serious d amag e to the emission c ontrol s ystem, you
should d o the following : Red uc e vehic le sp eed .
Avoid hard ac c eleration.
Avoid steep up hill g rad es.
Red uc e the amount of c arg o, if p ossib le.
Stop towing a trailer as soon as p ossib le.
The CHECK ENGINE warning lig ht may stop b linking an d c ome on
stead ily after several d riving trip s. You should ha ve your vehic le
c hec ked b y an authorized SUBARU d ealer immed iately.
ABS warning light (for vehicles with ABS)
The ABS warning lig ht c omes on when the ig nition sw itc h is turned to the
“ ON ” p osition and g oes out after ab out two sec ond s.
This is an ind ic ation that the ABS system is workin g p rop erly.
If the warning lig ht b ehaves as follows, the ABS sy stem may not work
p rop erly. The warning lig ht d oes not c ome on when the ig nitio n switc h is turned
to the “ON ” p osition.
The warning lig ht c omes on when the ig nition switc h is turned to the
“ ON ” p osition, b ut it d oes not g o out even when the veh ic le sp eed
(U.S.)
(Canada)
ABS

Instruments and controls3-9
–
CONTINUED –
exc eed s ap p roximately 8 mp h (12 km/h).
The warning lig ht c omes on d uring d riving .
When the warning lig ht is on, the ABS func tion shut s d own; however, the
c onventional b rake system c ontinues to op erate norm ally. If this oc c urs,
have the ABS system rep aired at the first availab le op p ortunity b y your
SUBARU d ealer. NOTE
If the warning light behavior is as shown below, the ABS system may be considered normal. The warning light comes on right after the engine is started but
goes out immediately, remaining off. The warning light remains on after the engine has been started,
but it goes out when the vehicle speed reaches about 8 mph (12km/h). The warning light comes on during driving, but it goes out
immediately and remains off.
When d riving with an insuffic ient b attery voltag e s uc h as when the en-
g ine is jump started , the ABS warning lig ht may c om e on. This is d ue to
the low b attery voltag e and d oes not ind ic ate a mal func tion. When the
b attery b ec omes fully c harg ed , the lig ht will g o ou t.
AT OIL TEMPerature warning light
(for AT vehicles)
This lig ht c omes on when the ig nition switc h is tur ned to the “ON ” p osi-
tion and g oes out after ab out two sec ond s. If this lig ht c omes on when
the eng ine is running , it may ind ic ate that the aut omatic transmission
fluid temp erature is too hot.
Even if the lig ht c omes on while d riving , it is unn ec essary to stop the ve-
hic le. But avoid d riving up steep g rad es or d riving in stop and g o traffic .
Automatic transmission control system warning
If the lig ht flashes after the eng ine starts, it ma y ind ic ate that the auto-
matic transmission c ontrol system is not working p r op erly. Contac t
your nearest SUBARU d ealer for servic e immed iately.

3-10
Door open warning lights
The d oor op en warning lig ht c omes on if any d oor or the rear g ate (for
wag on and OUTBACK SPORT) is not fully c losed .
Always make sure this lig ht is out b efore you start to d rive.
Front-wheel drive warning light
(for AWD AT vehicles)
This lig ht c omes on when All Wheel Drive is d iseng a g ed and the d rive
mec hanism is switc hed to Front Wheel Drive for mai ntenanc e or similar
p urp oses. Turn signal indicator lights
These lig hts show the op eration of the turn sig nal or lane c hang e sig nal.
If the ind ic ator lig hts d o not b link or b link rap id ly, the turn sig nal b ulb
may b e b urned out. Rep lac e the b ulb as soon as p oss ib le. Refer to “Re-
p lac ing b ulb s ” sec tion in c hap ter 10.
High beam indicator
This lig ht shows that the head lig hts are in the hig h b eam mod e.
This ind ic ator lig ht also c omes on when op erating h ead lig ht flasher.
Low fuel warning light
The low fuel warning lig ht c omes on when the tank i s nearly emp ty
(ab out 2.3 U.S. g al., 9.0 liters, 1.9 Imp . g al.). I t only op erates when the
ig nition switc h is in the “ON ” p osition.
NOTE This light does not go out unless the tank is replenished up to an internal fuel quantity of about 3.6 U.S. gal. (14 liters, 3.0 Imp. gal.).
