6-63
Maxi Fuses Description
1 Cooling Fans
2 Crank
3 Power Seats, Rear Defog,
Trunk Release
4 HVAC Controls, Hazard Flasher,
CHMSL, Body Control Module,
Stoplamp, Power Mirrors
5 HVAC Controls, Compass Mirror,
Cruise Control, PRNDL Lamp,
Powertrain Control Module (PCM)Maxi Fuses Description
6 Cooling Fans
7 Body Control Module, Cigar
Lighter, Accessory Power Outlet,
Trunk CD Changer, Audio
Systems, Keyless Entry System,
I/P Cluster, HVAC Controls
8 Turn Signals, Air Bag System,
I/P Cluster, Body Control Module,
Windshield Wipers
Mini Relays Description
9 Cooling Fans
10 Cooling Fans
11 Crank
12 Cooling Fans
13 Ignition Main
14 Blank
Micro Relays Description
15 Air Conditioning Compressor
16 Horn
17 Fog Lamps
18 Blank
19 Fuel Pump

6-64
Mini Fuses Description
20 Blank
21 Generator
22 Powertrain Control Module
23 Air Conditioning Compressor
24 Blank
25 Fuel Injectors, Electronic Ignition
26 Transmission Solenoid
27 Horn
28 Fuel Injector, Electronic Ignition
29 Oxygen Sensor
30 PCM Devices/Engine
Emissions Sensors
31 Fog Lamps
32 Headlamp (Passenger Side)
33 Trunk Release
34 Parking LampMini Fuses Description
35 Fuel Pump
36 Headlamp (Driver Side)
37 ABS
38 Spare
39 Spare
40 Spare
41 Spare
42 Spare
43 Spare
Diodes Description

Air Conditioning
Compressor Diode
44 Fuse Puller

6-65
California Emissions Underhood Fuse Block
(If Equipped)
If your vehicle is equipped with this fuse block, it is
located next to the main fuse block on the passenger's
side of the engine compartment.
A. California Emissions Fuse Block
B. Main Underhood Fuse BlockWhen the cover is removed, you'll see the following fuses:
Fuse Description
AIR PUMP Air Pump
ABS VALVE ABS
ABS MOTOR ABS
RELAY
AIR PUMPAir Pump

6-66
Replacement Bulbs
Center High-Mounted Stop Lamp (CHMSL) 1141. .
Fog Lamp 893. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Parking/Turn Signal 4157 NAK. . . . . . . . . . . . .
Headlamp
High Beam 9005. . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Beam 9006. . . . . . . . . . . . . . . . . . . . . . . . . . . .
License Plate Lamp 194. . . . . . . . . . . . . . . . . . . . . . .
Sidemarker (Front/Rear) 194. . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal (Rear) 3057. . . . . . . . . . . . . . .
Cornering 3156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº
in the Index for more information.
Automatic Transaxle
After Complete Overhaul 10.0 quarts (9.5 L). . . . . . .
Pan Removal
and Replacement 7.4 quarts (7.0 L). . . . . . . . . . . . .
When draining/replacing the converter, more fluid
may be needed.Cooling System Including Reservoir
10.0 quarts (9.5 L)
A/C Refrigerant1.9 lbs. (0.85 kg) . . . . . . . . . . . . . . .
Engine Crankcase (Oil and Filter Change)
6.0 quarts (5.7 L)
Fuel Tank17 gallons (64 L) . . . . . . . . . . . . . . . . . . . .
NOTE: All capacities are approximate. When adding, be
sure to fill to the appropriate level, as recommended in
this manual. Recheck fluid level after filling.
Engine Specifications
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 212 cubic inches (3.5 L). . . . . . . . . . . .
Compression Ratio 9.3:1. . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 180
F (82
C) . . . . . . . . . . .
Horsepower 215. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-67
Normal Maintenance
Replacement Parts
Air Cleaner FilterAC1096C . . . . . . . . . . . . . . . . . . .
Passenger Compartment Air Filter10406026 . . . .
Battery19000678 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil Filter25177917 . . . . . . . . . . . . . . . . . . . .
PCV ValveAC Type CV892C . . . . . . . . . . . . . . . . . . .
Cooling System Pressure Cap10296465 . . . . . . . . .
Spark PlugsType PTR5C
-13/12556183 . . . . . . . . . . .
Gap: 0.050 inches (.127 cm)
Windshield Wiper Blade Replacement
Length 22 inches (56 cm). . . . . . . . . . . . . . . . . . . . .
Type Pin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Wheelbase 109.0 inches (270 cm). . . . . . . . . . . . . . . .
Front Tread Width 61.5 inches (156 cm). . . . . . . . . . .
Rear Tread Width 61.5 inches (156 cm). . . . . . . . . . . .
Length 195.9 inches (498 cm). . . . . . . . . . . . . . . . . . .
Width 73.8 inches (187 cm). . . . . . . . . . . . . . . . . . . . .
Height 56.4 inches (143 cm). . . . . . . . . . . . . . . . . . . . .

7-
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-5 Scheduled Maintenance
7
-15 Part B: Owner Checks and Services7
-20 Part C: Periodic Maintenance Inspections
7
-22 Part D: Recommended Fluids and Lubricants
7
-23 Part E: Maintenance Record

7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet, or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
Maintenance Requirements
Maintenance intervals, checks, inspections and
recommended fluids and lubricants as prescribed in this
manual are necessary to keep your vehicle in good
working condition. Any damage caused by failure to
follow recommended maintenance may not be covered
by warranty.

7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you want to get the service information, see
ªService and Owner Publicationsº in the Index.ªPart B: Owner Checks and Servicesº tells you what
should be checked and when. It also explains what you
can easily do to help keep your vehicle in good condition.
ªPart C: Periodic Maintenance Inspectionsº explains
important inspections that your dealer's service department
or another qualified service center should perform.
ªPart D: Recommended Fluids and Lubricantsº lists
some recommended products necessary to help keep
your vehicle properly maintained. These products, or
their equivalents, should be used whether you do the
work yourself or have it done.
ªPart E: Maintenance Recordº is a place for you to
record and keep track of the maintenance performed on
your vehicle. Keep your maintenance receipts. They may
be needed to qualify your vehicle for warranty repairs.
