2000 LEXUS GS400 stop start

F02832
± BRAKEHYDRAULIC BRAKE BOOSTER
BR±47
2155 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(r) Inspect the left rear ABS solenoid.
(1) Turn the selector switch to ºLHº position.
(2) Depress the brake pedal several times and release
the brake pedal when the pump begins rotating.
Wait until the pump stops.
(3) Turn the ignition switch OFF.
(4) Depress the brake pedal with a force of 343 N (35
kgf, 77 lbf), record the fluid surface in the reservoir
tank of the hydraulic brake booster.
(5) Press the MAIN push switch for 10 sec., and check
that the fluid surface in the reservoir tank of the hy-
draulic brake booster does not rise up at this time.
If the fluid surface level rises up, replace the hydraulic brake
booster.
NOTICE:
Do not press MAIN push switch for more than 10 sec. When
operating the switch continuously, do it an interval of more
than 20 seconds.
(6) Start the engine and run it at idle.
(7) Depress the brake pedal.
(8) Release the parking brake pedal and shift the shift
lever to ºLº position.
(9) Once, release the brake pedal. After depressing the
brake pedal with stable force, then push and hold
MAIN push switch.
(10) Check that the left rear wheel rotates.
If the left rear wheel stops, replace the hydraulic brake booster.
(s) Stop the engine and lower the vehicle.
(t) Remove the ºSHEET Gº (SST) and disconnect the actua-
tor checker (SST) and sub±wire harness S (SST) from the
hydraulic brake booster.
(u) Connect the 2 connectors to the actuator.
(v) Clear the DTC (See page DI±389).

B01900
CO0AD±03
B00922
ECT
Switch
Connector
B02072
B02073
Ammeter
Battery(+)
(±)
CO±24
± COOLING (2JZ±GE)ELECTRIC COOLING FAN
1562 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
ELECTRIC COOLING FAN
ON±VEHICLE INSPECTION
1. CHECK COOLING FAN OPERATION WITH LOW
TEMPERATURE (Below 83°C (181°F))
(a) Turn the ignition switch ON.
(b) Check that the cooling fan stops.
If not, check the cooling fan relay and ECT switch, and check
for a separated connector or severed wire between the cooling
fan relay and ECT switch.
(c) Disconnect the ECT switch connector.
(d) Check that the cooling fan rotates.
If not, check the fuses, radiator fan main relay, cooling fan relay,
cooling fan, and check for a short circuit between the cooling
fan relay and ECT switch.
(e) Reconnect the ECT switch connector.
2. CHECK COOLING FAN OPERATION WITH HIGH
TEMPERATURE (Above 93°C (199°F))
(a) Start the engine, and raise coolant temperature to above
93°C (199°F).
HINT:
Coolant temperature is the detected value by the ECT switch
on the radiator lower tank.
(b) Check that the cooling fan rotates.
If not, replace the ECT switch.
3. INSPECT COOLING FANS
(a) Disconnect the cooling fan connector.
(b) Connect battery and ammeter to the cooling fan connec-
tor.
(c) Check that the cooling fan rotates smoothly, and check
the reading on the ammeter.
Standard amperage: 8.5 ± 11.5 A at 20°C (68°F)
(d) Reconnect the cooling fan connector.

EC0BD±02
B02709
Gasket
Vacuum
Valve Pressure
Valve
B06544
Vacuum
Gauge
B01982
LEXUS Hand±Held Tester
DLC 3
B06548Battery
± EMISSION CONTROL (2JZ±GE)EVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
EC±7
1458 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSPECTION
1. INSPECT LINES AND CONNECTORS
Visually check for loose connections, sharp bends or damage.
2. INSPECT FUEL TANK FILLER PIPE
Visually check for deformation, cracks or fuel leakage.
3. VISUALLY INSPECT FUEL TANK CAP
Check if the cap and/or gasket are deformed or damaged.
If necessary, repair or replace the cap.
4. INSPECT EVAP SYSTEM LINE
(a) Warm up the engine and stop the engine.
Allow the engine to warm up to normal operating tempera-
ture.
(b) Install a vacuum gauge (EVAP control system test equip-
ment vacuum gauge) to the EVAP service port on the
purge line.
(c) LEXUS Hand±Held Tester:
Forced driving of the VSV for the EVAP.
(1) Connect a LEXUS hand±held tester to the DLC3.
(2) Start the engine.
(3) Push the LEXUS hand±held tester main switch ON.
(4) Use the ACTIVE TEST mode on the LEXUS hand±
held tester to operate the VSV for the EVAP.
(d) If you have no LEXUS Hand±Held Tester:
Forced driving of the VSV for the EVAP.
(1) Disconnect the VSV connector for the EVAP.
(2) Connect the positive (+) and negative (±) leads from
the battery to the VSV terminals for the EVAP.
(3) Start the engine.

V07268
VIBRATION METHOD: When vibration seems to be the major cause.
CONNECTORS
WIRE HARNESS
PARTS AND SENSOR1
Slightly shake the connector vertically and horizontally.
Slightly shake the wire harness vertically and horizontally.
The connector joint, fulcrum of the vibration, and body
through portion are the major areas to be checked thorough-
ly.
Apply slight vibration with a finger to the part of the sensor
considered to be the problem cause and check that the mal-
function occurs.Shake Slightly
Swing Slightly
Vibrate Slightly
HINT:
Applying strong vibration to relays may result in open relays.
± INTRODUCTIONHOW TO TROUBLESHOOT ECU CONTROLLED
SYSTEMSIN±25
25 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
3. SYMPTOM SIMULATION
The most difficult case in troubleshooting is when there are no problem symptoms occurring. In such cases,
a thorough customer problem analysis must be carried out, then simulate the same or similar conditions and
environment in which the problem occurred in the customer's vehicle. No matter how much experience a
technician has, or how skilled he may be, if he proceeds to troubleshoot without confirming the problem
symptoms he will tend to overlook something important in the repair operation and make a wrong guess
somewhere, which will only lead to a standstill. For example, for a problem which only occurs when the en-
gine is cold, or for a problem which occurs due to vibration caused by the road during driving, etc., the prob-
lem can never be determined so long as the symptoms are confirmed with the engine hot condition or the
vehicle at a standstill. Since vibration, heat or water penetration (moisture) is likely cause for problem which
is difficult to reproduce, the symptom simulation tests introduced here are effective measures in that the ex-
ternal causes are applied to the vehicle in a stopped condition.
Important Points in the Symptom Simulation Test:
In the symptom simulation test, the problem symptoms should of course be confirmed, but the problem area
or parts must also be found out. To do this, narrow down the possible problem circuits according to the symp-
toms before starting this test and connect a tester beforehand. After that, carry out the symptom simulation
test, judging whether the circuit being tested is defective or normal and also confirming the problem symp-
toms at the same time. Refer to the problem symptoms table for each system to narrow down the possible
causes of the symptom.

B00319
Recommended Viscosity (SAE):
TEMPERATURE RANGE ANTICIPATED BEFORE NEXT OIL CHANGE °F
°C±20
±29 0
±1820
±740
460
1680
27100
38 10W±30
5W±30 PREFERRED
LU05G±04
B01610
Oil PressureOil Pressure SwitchGauge
Union Bolt
P12478
Adhesive
± LUBRICATION (2JZ±GE)OIL AND FILTER
LU±1
1573 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
OIL AND FILTER
INSPECTION
1. CHECK OIL QUALITY
Check the oil for deterioration, entry of water, discoloring or thin-
ning.
If oil quality is visibly poor, replace the oil.
Oil grade:
API grade SJ, Energy±Conserving or ILSAC multi-
grade engine oil. SAE 5W±30 is the best choice for
your vehicle, for good fuel economy, and good start-
ing in cold weather.
2. CHECK ENGINE OIL LEVEL
After warming up the engine and then 5 minutes after the en-
gine stop, oil level should be between the low level and full level
marks of the dipstick.
If low, check for leakage and add oil up to the full level mark.
NOTICE:
Do not fill with engine oil above the full level mark.
3. REMOVE OIL PRESSURE SWITCH, AND INSTALL OIL
PRESSURE GAUGE
(a) Disconnect the oil pressure switch connector.
(b) Using SST, remove the oil pressure switch.
SST 09816±30010
(c) Install an oil pressure gauge.
4. WARM UP ENGINE
Allow the engine to warm up to normal operating temperature.
5. CHECK OIL PRESSURE
Oil pressure:
At idle49 kPa (0.5 kgf/cm2, 7 psi) or more
At 3,000 rpm324 kPa (3.3 kgf/cm2, 47 psi) or more
6. REMOVE OIL PRESSURE GAUGE AND REINSTALL
OIL PRESSURE SWITCH
(a) Remove the oil pressure gauge.
(b) Tighten the union bolt.
Torque: 90 N´m (900 kgf´cm, 66 ft´lbf)
(c) Apply adhesive to 2 or 3 threads of the oil pressure switch.
Adhesive:
Part No.08833±00080, THREE BOND 1344,
LOCTITE 242 or equivalent
(d) Using SST, install the oil pressure switch.
SST 09816±30010
Torque: 15 N´m (150 kgf´cm, 11 ft´lbf)
(e) Connect the oil pressure switch connector.
7. START ENGINE AND CHECK FOR LEAKS

SS0CN±02
SS±60
± SERVICE SPECIFICATIONSBODY ELECTRICAL
216 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
BODY ELECTRICAL
SERVICE DATA
DAYTIME RUNNING LIGHT RELAY (MAIN) (Wire Harness Side)
1 ± Ground (Ignition switch position LOCK or ACC)No voltage
1 ± Ground (Ignition switch position ON or START)Battery positive voltage
5 ± Ground (Engine Stop)No voltage
5 ± Ground (Engine Running)Battery positive voltage
7 ± Ground (Constant)Battery positive voltage
9 ± Ground (Constant)Battery positive voltage
AUTOMATIC LIGHT CONTROL SENSOR
(Connector disconnected)
4 ± Ground (Ignition switch position LOCK or ACC)No voltage
4 ± Ground (Ignition switch position ON)5.2 ± 9.0 V
(Connector connected)
1 ± Ground (Ignition switch position LOCK or ACC)No voltage
1 ± Ground (Ignition switch position ON)9.5 V or more
HEADLIGHT BEAM LEVEL CONTROL ECU
(Connector disconnected)
A1 ± A5 (Ignition switch position OFF)26 ± 30 W
A1 ± A6 (Ignition switch position OFF)26 ± 30 W
A1 ± A7 (Ignition switch position OFF)26 ± 30 W
A1 ± A8 (Ignition switch position OFF)26 ± 30 W
A4 ± B4 (Ignition switch position ON and light control switch HEAD)Below 1.5 V
B1 ± B3 (Ignition switch position OFF)3.5 k ± 6.5 kW
B5 ± B7 (Ignition switch position OFF)3.5 k ± 6.5 kW
(Connector disconnected)
B2 ± B3 (Ignition switch position ON)Approx. 2.5 V
B6 ± B7 (Ignition switch position ON)Approx. 2.5 V
B1 ± B3 (Ignition switch position ON)5V
B5 ± B7 (Ignition switch position ON)5V
TURN SIGNAL FLASHER
1 ± Ground (Ignition switch position LOCK or ACC)No voltage
1 ± Ground (Ignition switch position ON)Battery positive voltage
4 ± Ground (Constant)Battery positive voltage
LIGHT FAILURE RELAY (Wire Harness Side)
5 ± Ground (Light control switch position OFF)No voltage
5 ± Ground (Light control switch position TAIL or HEAD)Battery positive voltage
8 ± Ground (Ignition switch position LOCK or ACC)No voltage
8 ± Ground (Ignition switch position ON)Battery positive voltage
9 ± Ground (Stop light switch position OFF)No voltage
9 ± Ground (Stop light switch position ON)Battery positive voltage
10 ± Ground (Stop light switch position OFF)No voltage
10 ± Ground (Stop light switch position ON)Battery positive voltage
SPEEDOMETER (ON±VEHICLE)
USA:

B01875
Fuel
Pump
Connector
B01998
New
Gasket
New
Gasket
FI1654
SST
Fulcrum Length
30 cm
± SFI (2JZ±GE)SFI SYSTEM
SF±3
1469 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
8. FUEL SYSTEM
(a) When disconnecting the high pressure fuel line, a large
amount of gasoline will spill out, so observe these proce-
dures:
(1) Disconnect the fuel pump connector.
(2) Start the engine. After the engine has stopped on
its own, turn the ignition switch OFF.
(3) Put a container under the connection.
(4) Slowly loosen the connection.
(5) Disconnect the connection.
(6) Plug the connection with a rubber plug.
(7) Reconnect the fuel pump connector.
(b) When connecting the flare nut or union bolt on the high
pressure pipe union, observe these procedures:
(1) Union Bolt Type:
Always use a new gasket.
(2) Union Bolt Type:
Tighten the union bolt by hand.
(3) Union Bolt Type:
Tighten the union bolt to the specified torque.
Torque: 29 N´m (300 kgf´cm, 22 ft´lbf)
(4) Flare Nut Type:
Apply a light coat of engine oil to the flare and tight-
en the flare nut by hand.
(5) Flare Nut Type:
Using SST, tighten the flare nut to the specified
torque.
SST 09631±22020
NOTICE:
Do not rotate the fuel pipe, when tightening the flare nut.
Torque:
30 N´m (310 kgf´cm, 22 ft´lbf) for using SST
38 N´m (387 kgf´cm, 28 ft´lbf)
HINT:
Use a torque wrench with a fulcrum length of 30 cm (11.81 in.).

B01982
LEXUS
Hand±Held
Tester
B01879
Ohmmeter54
B01880
5
4 Battery
± SFI (2JZ±GE)FUEL PUMP
SF±7
1473 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(f) Connect a LEXUS hand±held tester to the DLC3.
(See step 1 in check fuel pump operation (a) to (e))
(g) Measure the fuel pressure.
Fuel pressure:
304 ± 343 kPa (3.1 ± 3.5 kgf/cm
2, 44 ± 50 psi)
If pressure is high, replace the fuel pressure regulator.
If pressure is low, check the fuel hoses and connections, fuel
pump, fuel filter and fuel pressure regulator.
(h) Disconnect the LEXUS hand±held tester from the DLC3.
(i) Start the engine.
(j) Measure the fuel pressure at idle.
Fuel pressure:
304 ± 343 kPa (3.1 ± 3.5 kgf/cm
2, 44 ± 50 psi)
(k) Stop the engine.
(l) Check that the fuel pressure remains as specified for 5
minutes after the engine has stopped.
Fuel pressure: 147 kPa (1.5 kgf/cm
2, 21 psi) or more
If pressure is not as specified, check the fuel pump, pressure
regulator and/or injectors.
(m) After checking fuel pressure, disconnect the negative (±)
terminal cable from the battery and carefully remove SST
to prevent gasoline from splashing.
SST 09268±45014
(n) Reconnect the fuel inlet hose to the fuel pipe support with
2 new gaskets and the union bolt.
Torque: 29 N´m (300 kgf´cm, 21 ft´lbf)
(o) Reconnect the negative (±) terminal cable to the battery.
(p) Check for fuel leaks.
3. INSPECT FUEL PUMP
(a) Remove the rear seat cushion.
(b) Remove the 3 cap nuts and floor service hole cover.
(c) Disconnect the fuel pump & sender gauge connector.
(d) Using an ohmmeter, measure the resistance between ter-
minals 4 and 5.
Resistance: 0.2 ± 3.0 W at 20°C (68°F)
If the resistance is not as specified, replace the fuel pump.
(e) Inspect the fuel pump operation.
Connect the positive (+) lead from the battery to terminal
4 of the connector, and the negative (±) lead to terminal
5. Check that the fuel pump operates.
NOTICE:

These tests must be done quickly (within 10 seconds)
to prevent the coil burning out.

Keep the fuel pump as far away from the battery as
possible.

Always do the switching at the battery side.
