2000 LEXUS GS400 stop start

I04029
Fuses
Relays 1. AM1 H±Fuse
2. WASHER Fuse
3. FOG Fuse
4. TAIL Fuse
B. Taillight Control Relay A. Fog Light Relay
C. Body ECU No.2
Driver Side Instrument Panel Junction Block
5. SRS±ACC Fuse
6. GAUGE Fuse
7. FUEL OPN Fuse
8. D FR DOOR Fuse
9. PANEL Fuse
10. HTR Fuse
11. SRS±B Fuse
12. P/SEAT (D) Fuse
13. RAD NO.2 Fuse
14. WIP Fuse
15. OBD Fuse
16. STOP Fuse
17. CIG Fuse
18. ECU±IG Fuse
19. STARTER Fuse
20. IGN Fuse
21. D FR DOOR Fuse
2
21 34 5
678 9
10 11 12 13
14 15 16 17
18 19 20AB
C 1
± BODY ELECTRICALPOWER SOURCE
BE±19
2320 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

27 Noise NOISE PRODUCED BY VIBRATION OR SHOCK WHILE DRIVING
No
Ye s Is speaker properly installed?
Noise is produced from static eletricity accumulating in the vehicle body. With vehicles stationary lightly tap each system.
Is noise produced?Install properly.
Each system faulty. Is speaker properly installed?
No
No Ye s
Ye s
28 Noise NOISE PRODUCED WHEN ENGINE STARTS
NoYe s Whistling noise which becomes high±pitched when
accelerator strongly depressed, disappears shortly
after engine stops.Generator noise.
A/C noise.
Fuel gauge noise.
Horn noise.
Ignition noise.
Turn signal noise.
Washer noise.
Engine coolant temp. gauge noise.
Wiper noise. Whining noise occurs when A/C is operating.
Scratching noise occurs during sudden acceleration, driving on rough
roads or when ignition switch is turned ON.
Clicking sound is heard when horn button is pressed, then
released. Whirring/grating sound is heard when pushed
continuously.
Murmuring sound stops when engine stops.
Tick±tack noise occurs in co±ordination with blinking
offlasher.
Noise occurs during window washer operation.
Scratching noise occurs while engine is running,
and continues a while even after engine stops.
Scraping noise in line with wiper beat.
Other type of noiseYe s
Ye s
Ye s
Ye s
Ye s
Ye s
Ye s
Ye s No
No
No
No
No
No
No
No
± BODY ELECTRICALAUDIO SYSTEM
BE±215
2516 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

I04038
I04039
BE±42
± BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
2343 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)8 ± Ground
Headlight dimmer switch HIGH beam or FLASHContinuity
1 ± GroundIgnition switch LOCK or ACCNo voltage
1 ± GroundIgnition switch ON or STARTBattery positive voltage
5 ± GroundEngine StopNo voltage
5 ± GroundEngine RunningBattery positive voltage
7 ± GroundConstantBattery positive voltage
9 ± GroundConstantBattery positive voltage
If circuit is specified, try replacing the relay with a new one.
If circuit is not as specified, inspect the circuits connected to oth-
er parts.
16. INSPECT AUTOMATIC LIGHT CONTROL
AUTO ON:
(a) Turn the ignition switch ON.
(b) Turn the light control switch to AUTO.
(c) Gradually cover the top of the sensor.
(d) Check the accessory lights and the headlights should turn
ON.
17. INSPECT AUTOMATIC LIGHT CONTROL
AUTO OFF:
(a) Gradually expose the sensor.
(b) Check the headlights and the accessory lights should turn
OFF.
18. INSPECT LIGHT±OFF CONDITION
(a) Turn the ignition switch ON.
(b) Gradually cover the top of the sensor.
Lights auto ON:
(c) Check that the lights go off under the following conditions.
(1) Light control switch is OFF.
(2) The area surrounding the sensor gets bright.
(3) The driver's door is opened with the ignition switch
OFF.

I04084
A
D
CB BE±96
± BODY ELECTRICALCOMBINATION METER
2397 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
6. INSPECT SPEEDOMETER ON±VEHICLE
Using a speedometer tester, inspect the speedometer for allow-
able indication error and check the operation of the odometer.
HINT:
Tire wear and tire over or under inflation will increase the indica-
tion error.
USA (mph)CANADA (km/h)
Standard indication Allowable range Standard indication Allowable range
20 18 ± 24 20 17 ± 24
40 38 ± 44 40 38 ± 46
60 56 ± 66 60 57.5 ± 67
80 78 ± 88 80 77 ± 88
100 98 ± 110 100 96 ± 109
120 118 ± 132 120 115 ± 130
140 134 ± 151.5
160 153 ± 173
If error is excessive, replace the speedometer.
7. INSPECT SPEEDOMETER RESISTANCE
Measure the resistance between terminals with fixing pointer to
the stopper.
Tester connectionResistance (W)
A ± B140 ± 185
C ± D130 ± 175
If resistance value is not as the specified, replace the meter.
8. INSPECT TACHOMETER/
ON±VEHICLE
(a) Connect a tune±up test tachometer, and start the engine.
NOTICE:

Reversing the connection of the tachometer will dam-
age the transistors and diodes inside.

When removing or installing the tachometer, be care-
ful not to drop or subject it to heavy shocks.
(b) Compare the tester and tachometer indications.
DC 13.5 V 25 °C at (77°F)
Standard indicationAllowable range
700630 ± 770
1,000900 ± 1,100
2,0001,850 ± 2,150
3,0002,800 ± 3,200
4,0003,800 ± 4,200
5,0004,800 ± 5,200
6,0005,750 ± 6,250
7,0006,700 ± 7,300

I01278
I01279
Battery Ignition
SwitchWarning Light
I04095
OFF
ON
I04096
± BODY ELECTRICALCOMBINATION METER
BE±99
2400 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
17. INSPECT LOW OIL PRESSURE SWITCH CONTINUITY
(a) Disconnect the connector from the switch.
(b) Check that continuity exists between terminal and ground
with the engine stopped.
(c) Check that no continuity exists between terminal and
ground with the engine running.
HINT:
Oil pressure should be over 24.5 kPa (0.25 kgf/cm
2, 3.55 psi).
If operation is not as specified, replace the switch.
18. INSPECT BRAKE WARNING LIGHT
(a) Disconnect the connector from the brake fluid warning
switch.
(b) Release the parking brake pedal.
(c) Connect the terminals on the wire harness side of the lev-
el warning switch connector.
(d) Start the engine, check that the warning light lights up.
If the warning light does not light up, test the bulb or wire har-
ness.
19. INSPECT BRAKE FLUID LEVEL WARNING SWITCH
CONTINUITY
(a) Remove the reservoir tank cap and strainer.
(b) Disconnect the connector.
(c) Check that no continuity exists between the terminals with
the switch OFF (float up).
(d) Use siphon, etc. to take fluid out of the reservoir tank.
(e) Check that continuity exists between the terminals with
the switch ON (float down)
(f) Pour the fluid back in the reservoir tank.
If operation is not as specified, replace the switch.
20. INSPECT BRAKE FLUID LEVEL WARNING SWITCH
CIRCUIT (See page DI±835)
21. INSPECT PARKING BRAKE SWITCH CONTINUITY
(a) Check that continuity exists between the terminal and
switch body with the switch ON (switch pin released).
(b) Check that no continuity exists between the terminal and
switch body with the switch OFF (switch pin pushed in).
If operation is not as specified, replace the switch or inspect
ground point.
22. INSPECT PARKING BRAKE SWITCH CIRCUIT
(See page DI±796)

I04097
Battery Ignition
SwitchWarning Light
Wire Harness Side
I04098
Wire Harness Side
I04099
BatteryIgnition
SwitchWarning Light
Wire Harness Side BE±100
± BODY ELECTRICALCOMBINATION METER
2401 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
23. INSPECT REAR LIGHTS WARNING LIGHT
(See page DI±841)
(a) Disconnect the connector from the light failure sensor and
ground terminal 3 on the wire harness side connector.
(b) Start the engine, check that the warning light lights up.
If the warning light does not light up, inspect the bulb or wire har-
ness.
24. INSPECT LIGHT FAILURE SENSOR CIRCUIT
Disconnect connector from the light failure sensor and inspect
the connectors on the wire harness side as follows.
Tester connectionConditionSpecified condition
1 ± GroundConstantContinuity *
2 ± GroundConstantContinuity *
6 ± GroundConstantContinuity *
7 ± GroundConstantContinuity *
11 ± GroundConstantContinuity
12 ± GroundConstantContinuity *
5 ± GroundLight control switch OFFNo voltage
5 ± GroundLight control switch in TAIL or HEADBattery positive voltage
8 ± GroundIgnition switch in LOCK or ACCNo voltage
8 ± GroundIgnition switch ONBattery positive voltage
9, 10 ± GroundStop light switch OFFNo voltage
9, 10 ± GroundStop light switch ONBattery positive voltage
*: There is resistance because this circuit is grounded through
the bulb.
If circuit is as specified, replace the relay.
If circuit is not as specified, wiring diagram and inspect the cir-
cuits connected to other parts.
25. INSPECT ENGINE OIL LEVEL WARNING LIGHT
(a) Disconnect the connector from the switch.
(b) Run the engine.
(c) Turn the ignition switch ON, check that the warning light
lights up approximatery 40 seconds later.
If the warning light does not light up, inspect bulb or wire har-
ness.

± BRAKETROUBLESHOOTING
BR±3
2111 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) Noise from brakes
1. Pad (Cracked or distorted)
2. Installation bolt (Loose)
3. Disc (Scored)
4. Pad support plate (Loose)
5. Sliding pin (Worn)
6. Pad (Dirty)
7. Pad (Glazed)
8. Tension or return spring (Faulty)
9. Anti±squeal shim (Damaged)
10.Shoe hold±down spring (Damaged)BR±15
BR±24
BR±15
BR±24
BR±18
BR±27
BR±18
BR±18
BR±15
BR±24
BR±15
BR±24
BR±33
BR±18
BR±27
BR±33
Noise from hydraulic brake booster
(Abnormal pump motor operation noise)Accumulator bracket clearance (Out or adjustment)BR±56
Brake warning light lights up*1
(Parking brake pedal released)
1. Brake fluid level
2. Hydraulic brake booster power supply system (Faulty)BR±38
Brake warning light lights up and brake warning buzzer sounds*2Hydraulic brake booster power supply system (Faulty)BR±38
ABS warning light lights up*31. Anti±lock brake system (Faulty)
2. Hydraulic brake booster power supply system (Faulty)
BR±38
*1, *3: The light may stay on for about 60 seconds after the engine has been started. It is normal if it goes
out after a while.
*
2, *3: Depressing the brake pedal repeatedly may turn on the warning light and buzzer. It is normal if the
light goes out and the buzzer stops sounding after a few seconds.
*
3: While ABS warning light is ON, both VSC warning light and VSC OFF indicator light come on.

F02830
F02831
BR±46
± BRAKEHYDRAULIC BRAKE BOOSTER
2154 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(p) Inspect the rear TRAC & VSC solenoid.
(1) Release the parking brake pedal and shift the shift
lever to ºLº position.
(2) Push and hold the ºSA3º switch and ºSTRº switch
simultaneously.
NOTICE:

Do not keep the ºSTRº switch pushed down for more
than 10 seconds.

Do not keep the ºSA3º switch pushed down for more
than 5 seconds.

When operating it continuously, set the interval of
more than 20 seconds.
(3) Check that the rear wheels stop.
If the rear wheels rotate, replace the hydraulic brake booster.
(4) Release the ºSA3º switch and ºSTRº switch simulta-
neously.
(5) Check that the rear wheels rotate.
If the rear wheels stop, replace the hydraulic brake booster.
(q) Inspect the right rear ABS solenoid.
(1) Turn the selector switch to ºRHº position.
(2) Depress the brake pedal several times and release
the brake pedal when the pump begins rotating.
Wait until the pump stops.
(3) Turn the ignition switch OFF.
(4) Depress the brake pedal with a force of 343 N (35
kgf, 77 lbf), record the fluid surface in the reservoir
tank of the hydraulic brake booster.
(5) Press the MAIN push switch for 10 sec., and check
that the fluid surface in the reservoir tank of the hy-
draulic brake booster does not rise up at this time.
If the fluid surface level rises up, replace the hydraulic brake
booster.
NOTICE:
Do not press MAIN push switch for more than 10 sec. When
operating the switch continuously, do it an interval of more
than 20 seconds.
(6) Start the engine and run it at idle.
(7) Depress the brake pedal.
(8) Release the parking brake pedal and shift the shift
lever to ºLº position.
(9) Once, release the brake pedal. After depressing the
brake pedal with stable force, then push and hold
MAIN push switch.
(10) Check that the right rear wheel rotates.
If the right rear wheel stops, replace the hydraulic brake boost-
er.
