2000 LEXUS GS400 fuel pressure

AC2810
AC0W6±01
AC2811
N11084
Wrong Okay
HI LO HILO
± AIR CONDITIONINGAIR CONDITIONING SYSTEM
AC±1
2686 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
AIR CONDITIONING SYSTEM
PRECAUTION
1. DO NOT HANDLE REFRIGERANT IN AN ENCLOSED
AREA OR NEAR AN OPEN FLAME
2. ALWAYS WEAR EYE PROTECTION
3. BE CAREFUL NOT TO GET LIQUID REFRIGERANT IN
YOUR EYES OR ON YOUR SKIN
If liquid refrigerant gets in your eyes or on your skin.
(a) Wash the area with lots of cool water.
CAUTION:
Do not rub your eyes or skin.
(b) Apply clean petroleum jelly to the skin.
(c) Go immediately to a physician or hospital for professional
treatment.
4. NEVER HEAT CONTAINER OR EXPOSE IT TO NAKED
FLAME
5. BE CAREFUL NOT TO DROP CONTAINER AND NOT
TO APPLY PHYSICAL SHOCKS TO IT
6. DO NOT OPERATE COMPRESSOR WITHOUT
ENOUGH REFRIGERANT IN REFRIGERANT SYSTEM
If there is not enough refrigerant in the refrigerant system oil lu-
brication will be insufficient and compressor burnout may occur,
so take care to avoid this, necessary care should be taken.
7. DO NOT OPEN HIGH PRESSURE MANIFOLD VALVE
WHILE COMPRESSOR IS OPERATING
If the high pressure valves opened, refrigerant flows in the re-
verse direction and could cause the charging cylinder to rup-
ture, so open and close the only low pressure valve.
8. BE CAREFUL NOT TO OVERCHARGE SYSTEM WITH
REFRIGERANT
If refrigerant is overcharged, it causes problems such as insuffi-
cient cooling, poor fuel economy, engine overheating etc.

I01360
Fuel Tank

Fuel Main
Sender Gauge
Fuel Tank

Fuel Sub
Sender Gauge
Occupant Detection Sensor
(Passenger seat belt
warning sensor)
Engine Oil Level
Warning Sensor Engine Oil Level
Warning Sensor
Park/ Neutral
Position Switch
Low Oil Pressure
Warning Switch
Park/ Neutral
Position Switch
Low Oil Pressure
Warning Switch
GS300GS400 Light Failure Sensor
± BODY ELECTRICALCOMBINATION METER
BE±81
2382 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

I04253

Meter Circuit Plate ± 2
Combination Meter ECU
SLIP Indicator
TRAC OFF Indicator
Window Washer Level Warning
ABS Warning
VSC Warning
Brake Fluid Level Warning
ECT SNOW Indicator
Low Oil Pressure Warning
ECT PWR Indicator
Discharge Warning
CRUISE MAIN Indicator
Seat Belt Warning
Rear Light Indicator
Headlight Leveling Indicator
SRS Warning
Open Door Warning
Fog Light IndicatorA/T 2 Indicaor
Engine Oil Level Indicator
Malfunction Indicator
Fuel Level Indicator
Headlight Indicator (USA)
Taillight Indicator (CANADA) ODO/
TRIP
Display
PanelIG+
SLIP
TRC OFF
WASHER
ABS
VSC
BRAKE
ECT SNOW
OIL P
ECT PWR
CHARGE
CRUISE
SEAT BELT
Rr LIGHT
HEAD LVL
AIRBAG
SRS +B
DOOR
FR FOG
COM1
SEG30
TEST1
TEST2
TEST3
GroundCHECK
ENG
IG+
FUEL
IG+
BEAM±
BEAM+ SRS +BTAIL A/T R
A/T L
A/T N
A/T D
OIL LVLDIM+
A/T 2
A/T 3
A/T 4F12
A/T PF11
F10
F9
F8
F5
F4
F2
F1
C7
C5
C3
D12
D8 E11
E10
E9
E8
E7
E6
J1
J33
D6
D4Hi±Beam Indicator
D2 E20
E19
E18
E17
E16
E15
E14
E13
E12
E3
E1 E5
E4A/T 3 Indicaor
A/T 4 Indicaor
A/T P Indicaor
A/T R Indicaor
A/T L Indicaor
A/T N Indicaor
A/T D Indicaor
T1
T2
T3
T4
~~
D10 BE±88
± BODY ELECTRICALCOMBINATION METER
2389 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

I04079
Connector ºCº Connector ºDº
Connector ºFº Connector ºEº
Connector ºGº
1 131 13
1 201 12
± BODY ELECTRICALCOMBINATION METER
BE±93
2394 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
2. INSPECT COMBINATION METER CIRCUIT PLATE
Warning light circuit plate:
(a) Remove meter cover.
(b) Disconnect connectors ºCº, ºDº, ºEº, ºFº and ºGº from the
meter circuit plate and inspect the connectors on the wire
harness side as shown in the table.
Tester connectionCheck indicator lightSpecified condition
D10 (+) ± D12 (±)Fuel level warning lightContinuity
D6 (+) ± D8 (±)Headlight indiactor light (USA)
Taillight indiactor light (CANADA)Continuity
D2 (+) ± D4 (±)Hi±beam indicator lightContinuity
C3 (+) ± C7 (±)Engine oil level warning lightContinuity
C3 (+) ± C5 (±)Malfunction indicator lightContinuity
E19 (±) ± E20 (+)Slip warning lightContinuity
E18 (±) ± E20 (+)TRAC OFF indicator lightContinuity
E17 (±) ± E20 (+)Window washer level warning lightContinuity
E16 (±) ± E20 (+)ABS warning lightContinuity
E15 (±) ± E20 (+)VSC OFF indicator lightContinuity
E14 (±) ± E20 (+)Brake warning lightContinuity
E13 (±) ± E20 (+)ECT SNOW indicator lightContinuity
E12 (±) ± E20 (+)Low oil pressure warning lightContinuity
E11 (±) ± E20 (+)ECT PWR indicator lightContinuity
E10 (±) ± E20 (+)Discharge warning lightContinuity
E9 (±) ± E20 (+)CRUISE MAIN indicator lightContinuity
E8 (±) ± E20 (+)Seat belt warning lightContinuity
E7 (±) ± E20 (+)Rear Lights warning lightContinuity
E6 (±) ± E20 (+)Headlight leveling indiactorContinuity
E4 (+) ± E5 (±)SRS warning lightContinuity
E3 (±) ± E4 (+)Open door warning lightContinuity
F4 (±) ± F12 (+)A/T shift indicator light (L)Continuity
F11 (±) ± F12 (+)A/T shift indicator light (2)Continuity
F10 (±) ± F12 (+)A/T shift indicator light (3)Continuity
F8 (±) ± F12 (+)A/T shift indicator light (P)Continuity

I04091
F
E1
2
1/2
I04094
A
D
C
B
I01277
Battery Ignition
SwitchWarning Light
Wire Harness Side
1 BE±98
± BODY ELECTRICALCOMBINATION METER
2399 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
13. INSPECT FUEL SUB SENDER GAUGE RESISTANCE
Measure the resistance between terminals 1 and 2 for each
float position.
Float position mm (in.)Resistance (W)
F: Approx. 9.5 (0.37) ± 3 (0.12)Approx. 2.0 ± 1.0
1/2: Approx. 110.5 (4.35) ± 3 (0.12)Approx. 33.0 ± 3.0
E: Approx. 206.5 (8.13) ± 3 (0.12)Approx. 61.3 ± 1.0
If resistance value is not as specified, replace the sub sender
gauge.
14. INSPECT ENGINE COOLANT TEMPERATURE RE-
CEIVER GAUGE OPERATION (See page DI±754)
15. INSPECT ENGINE COOLANT TEMPERATURE RE-
CEIVER GAUGE RESISTANCE
Measure the resistance between terminals with fixing pointer to
the stopper.
Tester connectionResistance (W)
A ± B140 ± 185
C ± D130 ± 175
If resistance value is not as specified, replace the receiver
gauge.
HINT:
This circuit includes the diode.
If resistance value is not as specified, replace the receiver
gauge.
16. INSPECT LOW OIL PRESSURE WARNING LIGHT
(a) Disconnect the connector from the warning switch and
ground terminal on the wire harness side connector.
(b) Turn the ignition switch ON and check that the warning
light lights up.
If the warning light does not light up, test the bulb.

EC04V±06
B08612
PCV Valve VSV for EVAP
Front TWC
EVAP Service Port
Fill Check LineCutoff ValveCharcoal Canister
Air Inlet Line
Vapor Pressure Sensor
Fuel Tank Cap
VSV for Vapor
Pressure Sensor
Purge Line
EVAP Line
Vent Line
Air Drain Hose
Rear TWC
EC±2
± EMISSION CONTROL (2JZ±GE)PARTS LAYOUT AND SCHEMATIC DRAWING
1453 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
PARTS LAYOUT AND SCHEMATIC DRAWING
LOCATION

EC04W±06
B08613
VSV for Vapor Pressure Sensor
Purge Line
Air Inlet LineAir Drain Hose
EVAP Line
Fuel Tank Charcoal Canister VSV for EVAPVapor Pressure Sensor
PCV Valve
Front TWC Front TWC
Vent Line
Fuel Tank
Cap
EVAP
Service
Port
Rear TWC
± EMISSION CONTROL (2JZ±GE)PARTS LAYOUT AND SCHEMATIC DRAWING
EC±3
1454 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
DRAWING

EC0BD±02
B02709
Gasket
Vacuum
Valve Pressure
Valve
B06544
Vacuum
Gauge
B01982
LEXUS Hand±Held Tester
DLC 3
B06548Battery
± EMISSION CONTROL (2JZ±GE)EVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
EC±7
1458 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSPECTION
1. INSPECT LINES AND CONNECTORS
Visually check for loose connections, sharp bends or damage.
2. INSPECT FUEL TANK FILLER PIPE
Visually check for deformation, cracks or fuel leakage.
3. VISUALLY INSPECT FUEL TANK CAP
Check if the cap and/or gasket are deformed or damaged.
If necessary, repair or replace the cap.
4. INSPECT EVAP SYSTEM LINE
(a) Warm up the engine and stop the engine.
Allow the engine to warm up to normal operating tempera-
ture.
(b) Install a vacuum gauge (EVAP control system test equip-
ment vacuum gauge) to the EVAP service port on the
purge line.
(c) LEXUS Hand±Held Tester:
Forced driving of the VSV for the EVAP.
(1) Connect a LEXUS hand±held tester to the DLC3.
(2) Start the engine.
(3) Push the LEXUS hand±held tester main switch ON.
(4) Use the ACTIVE TEST mode on the LEXUS hand±
held tester to operate the VSV for the EVAP.
(d) If you have no LEXUS Hand±Held Tester:
Forced driving of the VSV for the EVAP.
(1) Disconnect the VSV connector for the EVAP.
(2) Connect the positive (+) and negative (±) leads from
the battery to the VSV terminals for the EVAP.
(3) Start the engine.
