2000 LEXUS GS400 dimensions

B02135
Plate type lift
HINT :Attachment
AB
Left and right set position Place the vehicle over the center of the lift.
Front and rear set position
Align the attachment upper end (B) with the
Attachment dimensions
85 mm (3.35 in.)
70 mm (2.76 in.)
200 mm (7.87 in.) 100 mm (3.94 in.)C


Align the cushion gum ends of the plate
with the attachment lower ends (A, C).


When using attachments, place the one for
front side vertically and the one for rear side
horizontally to the vehicle.
rocker flange rear side notch.
± INTRODUCTIONREPAIR INSTRUCTIONS
IN±9
9 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)

B01974
40 mm
Contact
Plate
20 mm37 mmWooden
Block
(kgf/cm2) =Ram diameter (cm)
100 kgf
2x 3.14 (p)
2
(psi) =Ram diameter (in.)
221 lbf
2x 3.14 (p)
2
(kPa) = (kgf/cm2) x 98.1
(kPa) = (psi) x 6.9
B01975
SST
ST±12
± STARTING (2JZ±GE)STARTER
1630 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(f) Temporarily tighten the terminal nuts.
(g) Tighten the terminal nut
(1) Put a wooden block on the contact plate and press
it down with a hand press.
Dimensions of wooden block:
20 x 37 x 40 mm (0.79 x 1.46 x 1.57 in.)
Press force:
981 N (100 kgf, 221 lbf)
NOTICE:

Check the diameter of the hand press ram. Then
calculate the gauge pressure of the press when
981 N (100 kgf, 221 lbf) of force is applied.
Gauge pressure:

If the contact plate is not pressed down with the spe-
cified pressure, the contact plate may tilt due to coil
deformation or the tightening of the nut.
(2) Using SST, tighten the nuts to the specified torque.
SST 09810±38140
Torque: 17 N´m (173 kgf´cm, 13 ft´lbf)
NOTICE:
If the nut is over tightened, it may cause cracks on the in-
side of the insulator.

H02586Weight
y
x y
R04211
Inner Diam.
Tires
(3 or More)Width
H0257810 m (33 ft) or more
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±23
2254 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(f) Cover steering wheel pad with cardboard box or tires.

Covering method using cardboard box:
Cover the steering wheel pad with the cardboard
box and weight the cardboard box down in 4 places
with at least 190 N (20 kg, 44 lb).
Size of cardboard box:
Must exceed the following dimensions:
x=460 mm (18.11 in.)
When dimension of the cardboard box exceeds the di-
ameter of the disc wheel with tire which the steering
wheel pad is tied to±
x=460 mm (18.11 in.) + width of tire
y= 650 mm (25.59 in.)
NOTICE:
If a cardboard box smaller than the specified size is used,
the cardboard box will be broken by the shock from the air-
bag deployment.

Covering method using tires:
Place at least 3 tires without disc wheel on top of the
disc wheel with tire to which the steering wheel pad
is tied.
Tire size: Must exceed the following dimensions±
Width: 185 mm (7.87 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Do not use tires with disc wheels.
NOTICE:
The tires may be marked by the airbag deployment, so use
the redundant tires.
(g) Deploy the airbag.
(1) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the battery negative
(±) terminal.
(2) Check that no one is within 10 m (33 ft) area around
the disc wheel which the steering wheel pad is tied
to.
(3) Press the SST activation switch and deploy the air-
bag.
HINT:
The airbag deploys simultaneously as the LED of the SST ac-
tivation switch lights up.

AB0163
Wire Harness
Diameter
Stripped Wire Harness Section
H02596
AB0158
SSTBattery RS±34
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
2265 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(b) Fix the front passenger airbag assembly.
(1) Use a service±purpose wire harness tie down the
front passenger airbag assembly.
Wire harness: Stripped wire harness section
1.25 mm
2
or more (0.0019 in2 or more)
HINT:
To calculate the square of the stripped wire harness section:
Square = 3.14 x (Diameter)
2
divided by 4
CAUTION:
If a wire harness which is too thin or some other thing is
used to tie down the front passenger airbag assembly it
may be snapped by the shock when the airbag is deployed.
This is highly dangerous. Always use a wire harness for ve-
hicle use which is at least 1.25 mm
2 (0.0019 in2).
(2) Wind the wire harness around the mount brackets.
(3) Position the front passenger airbag assembly in-
side the tire with the airbag deployment side facing
inside.
Tire size: Must exceed the following dimensions±
Width 185 mm (7.28 in.)
Inner diameter 360 mm (14.17 in.)
CAUTION:

Make sure the wire harness is tight. It is very danger-
ous when a loose wire harness results in the front
passenger airbag assembly coming free due to the
shock from the airbag deploying.

Always tie down the front passenger airbag assembly
with the airbag deployment side facing inside.
NOTICE:
The tire will be marked by the airbag deployment, so use
the spare tire.
(c) Check functioning of SST.
(See page RS±17)
SST 09082±00700, 09082±00760
(d) Install the SST.
Connect the SST connector to the front passenger airbag
assembly connector.
SST 09082±00700, 09082±00760
NOTICE:
To avoid damage to the SST connector and wire harness,
do not lock the secondary lock of the twin lock.

AB0163
Wire Harness
Diameter
Stripped Wire Harness Section
H00549
H00548
H02607
RS±46
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY
2277 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
(c) Using a service±purpose wire harness, tie down the side
airbag assembly to the tire.
Wire harness: Stripped wire harness section
1.25 mm
2
or more (0.0019 in2. or more)
CAUTION:
If a wire harness which is too thin or some other thing is
used to tie down the side airbag assembly, it may be
snapped by the shock when the airbag is deployed. This is
highly dangerous. Always use a wire harness for vehicle
use which is at least 1.25 mm
2 (0.0019 in2.).
HINT:
To calculate the square of the stripped wire harness section±
Square = 3.14 x (Diameter)
2 divided by 4
(1) Install the 2 nuts to the side airbag assembly.
(2) Wind the wire harness around the stud bolts of the
side airbag assembly as shown in the illustration.
(3) Position the side airbag assembly inside the tire
with the airbag deployment direction facing inside.
Tire size: Must exceed the following dimensions±
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:

Make sure the wire harness is tight. It is very danger-
ous when a loose wire harness results in the side air-
bag assembly coming free due to the shock from the
airbag deploying.
