MA003±06
MA±4
± MAINTENANCEUNDER HOOD
47 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTES
Maintenance items may vary from country to country. Check the owner's manual supplement in which
the maintenance schedule is shown.
Every service item in the periodic maintenance schedule must be performed.
Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).
Maintenance service after the last period should be performed at the same interval as before unless
otherwise noted.
Failure to do even one item an cause the engine to run poorly and increase exhaust emissions.
2. WINDSHIELD WASHER FLUID
Check that there is sufficient fluid in the tank.
3. ENGINE COOLANT LEVEL
Check that the coolant level is between the ºFULLº and ºLOWº lines on the see±through reservoir.
4. RADIATOR AND HOSES
(a) Check that the front of the radiator is clean and not blocked with leaves, dirt or bugs.
(b) Check the hoses for cracks, kinks, rot or loose connections.
5. BATTERY ELECTROLYTE LEVEL
Check that the electrolyte level of all battery cells is between the upper and lower level lines on the case.
6. BRAKE FLUID LEVEL
Check that the brake fluid levels are near the upper level line on the see±through reservoirs.
7. ENGINE DRIVE BELT
Check drive belt for fraying, cracks, wear or oiliness.
8. ENGINE OIL LEVEL
Check the level on the dipstick with the engine turned off.
9. POWER STEERING FLUID LEVEL
Check the level on the dipstick.
The level should be in the ºHOTº or ºCOLDºrange depending on the fluid temperature.
10. AUTOMATIC TRANSMISSION FLUID LEVEL
(a) Park the vehicle on a level surface.
(b) With the engine idling and the parking brake applied, shift the selector into all positions from ºPº to ºLº,
and then shift into ºPº position.
(c) Pull out the dipstick and wipe off the fluid with a clean rag. Re±insert the dipstick and check that the
fluid level is in the HOT range.
(d) Do this check with the fluid at normal driving temperature (70 ± 80°C, 158 ± 176°F).
HINT:
Wait until the engine cools down (approx. 30 min.) before checking the fluid level after extended driving at
high speeds, in hot weather, in heavy traffic or pulling a trailer.
11. EXHAUST SYSTEM
If any change in the sound of the exhaust or smell of the exhaust fumes is noticed, have the cause located
and corrected.
MA01S±01
± MAINTENANCECHASSIS
MA±7
50 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
CHASSIS
INSPECTION
1. INSPECT STEERING LINKAGE
(a) Check the steering wheel freeplay.
(See page SR±8)
(b) Check the steering linkage for looseness or damage.
Check that:
Tie rod ends do not have excessive play.
Dust seals and boots are not damaged.
Boot clamps are not loose.
2. INSPECT SRS AIRBAG
(DRIVER'S SIDE: See page RS±15)
(PASSENGER'S SIDE: See page RS±29)
3. INSPECT STEERING GEAR HOUSING OIL
Check the steering gear housing for oil leakage.
4. INSPECT LOWER BALL JOINTS AND DUST COVERS
(a) Jack up the front of the vehicle and support it with stands.
(b) Make sure the front wheels are in a straight±ahead posi-
tion, and depress the brake pedal.
(c) Jack up the lower suspension arm until there is about half
a load on the front coil spring.
(d) Inspect the dust cover for damage.
5. CHECK AUTOMATIC TRANSMISSION AND
DIFFERENTIAL
Visually check the automatic transmission and differential for oil
leakage.
If leakage is found, check for the cause and repair it.
6. REPLACE AUTOMATIC TRANSMISSION FLUID
(See page DI±318)
7. REPLACE DIFFERENTIAL OIL
(See page SA±61)
PP0N7±06
PP±62
± PREPARATIONAUTOMATIC TRANSMISSION
11 4 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
LUBRICANT
ItemCapacityClassification
Automatic transmission fluid
Dry fill
Drain and refill
8.4 liters (8.9 US qts, 7.4 Imp. qts)
1.9 liters (2.0 US qts, 1.7 Imp. qts)ATF TYPE T±IV
