2000 HONDA PRELUDE Owner's Manual (in English)

Powe
r Window s

The master control panel also con-tains these extra features:
AUT O — To open the driver's
window fully, push the window switch firmly down and release it.
The window automatically goes all the way down. To stop the window
from going all the way down, pull
back on the window switch briefly.
To open the driver's window only partially, push the window switchdown lightly and hold it. The window
will stop as soon as you release the
switch.

The AUTO function only works to lower the driver's window. To raise
the window, you must pull back on
the window switch and hold it until
the window reaches the desired
position.
The MAIN switch controls power to
the passenger's window. With thisswitch off, the passenger's window
cannot be raised or lowered. The
MAIN switch does not affect the driver's window. Keep the MAIN
switch off when you have children in
the car so they do not injure them- selves by operating the window
unintentionally.
The power window system has a key- off delay function. The windows will
still operate for up to ten minutes
after you turn off the ignition.
Opening either door cancels the
delay function. You must turn the
ignition ON (II) again before you can
raise or lower the windows.
Instrument s an d Control s

Closing a power window on
someone's hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.

Moonroo
f

Use the switch on the dashboard to
open and close the moonroof. The
ignition switch must be ON (II). Push and hold the switch to
open the moonroof. Release the
switch when the moonroof reaches
the desired position. To close the moonroof, press and hold the
switch.
The moonroof has a key-off delay.
You can still open and close the
moonroof for up to ten minutes after
you turn off the ignition. The key-off delay cancels as soon as you open
either door. You must then turn the
ignition ON (II) for the moonroof to
operate.
If you try to open the moonroof in
below-freezing temperatures, or when it is covered with snow or ice, you can
damage the moonroof panel or motor.

Instrument s an d Control s

MOONROO
F
SWITC H
Closin
g the moonroof on
someone's hands or fingers can
cause serious injury.
Make sure passengers are
clear of the moonroof before
closing it.
NOTIC
E

Mirror
s
Keep the inside and outside mirrors
clean and adjusted for best visibility.
Be sure to adjust the mirrors before
you start driving.
The inside mirror has day and night positions. The night position reduces
glare from headlights behind you. Flip the tab on the bottom edge of
the mirror to select the day or night
position. Adjustin
g th e Powe r Mirror s
Adjust the outside mirrors with the adjustment switch on the driver's
door armrest:
1. Turn the ignition switch ON (II).
2. Move the selector switch to L (driver's side) or R (passenger's

side).
3. Push the appropriate edge of the
adjustment switch to move the

mirror right, left, up or down.

4.
When you finish, mov
e the
selector switch to the center (off)
position. This turns off the adjustment switch so you can't
move a mirror out of position by accidentally bumping the switch.

Instrument s an d Control s

TA
B SELECTO
R SWITC H

Mirrors
, Parkin g Brake

Available on all Canadian models

The outside mirrors are heated to re- move fog and frost. With the ignitionswitch ON (II), turn on the heaters
by pressing the button. The light in
the button comes on as a reminder. Press the button again to turn the
heaters off. Parkin
g Brak e
To apply the parking brake, pull the lever up fully. To release it, pull upslightly, push the button, and lower
the lever. The parking brake light on
the instrument panel should go out
when the parking brake is fully
released (see page 55).

Instruments an d Control s
Driving the car with the parking brake
applied can damage the rear brakes

and axles.

HEATE
D MIRRO R

BUTTO N
PARKIN
G BRAK E LEVE R NOTIC
E

Digita
l Cloc k

The digital clock displays the time with the ignition switch ON (II). To set the clock:
1. Turn the ignition switch ON (II) to display the time.
2. Swing down the front cover of the wide button under the clock
display. You will see HOUR, MIN,
and RESET buttons.
3. Press and hold the HOUR button until the hour advances to the
desired hour.
4. Press and hold the MIN (minute) button until the numbers advance
to the desired minutes.
You can use the RESET button to
quickly set the time to the nearest
hour. If the displayed time is before
the half hour, pressing RESET
button sets the clock back to the previous hour. If the displayed timeis after the half hour, pressing the
RESET button sets the clock for-
ward to the beginning of the next
hour.
For example:
1:06 would RESET to 1:00. 1:52 would RESET to 2:00.

Instrument s
an d Control s
HOU
R
MI
N RESE T

Beverag
e Holde r

The front beverage holder is located on the center console.
The partition in the beverage holder can be moved forward or backward.
If you want to use the beverage
holder, slide the partition forward
until it clicks. To put small items in
the beverage holder, slide the partition completely backward.
Be careful when you are using the
beverage holder. A spilled liquid that is very hot can scald you or your
passengers. Spilled liquids can alsodamage the upholstery, carpeting,
and electrical components in the
interior.

CONTINUED

Instrument s an d Control s

PARTITIO
N

Beverag
e Holder , Consol e Compartment

The rear seat also has a beverage holder in the armrest on the driver's
side.
Consol
e Compartment

To open the console compartment, pull up on the lower lever and lift the

lid.

To close, lower the lid and push it down until it latches.
You can put small items in the tray
located in the console compartment
lid. To use the tray, pull up on the
upper lever and lift up the armrest
pad.

Instrument s an d Control s
LEVE
R

CONSOLE

COMPART -

MEN T
LEVE
R

Coi
n Box , Accessor y Powe r Socke t

Coi n Bo x

The coin box is located next to the beverage holder. Open the lid by
lifting it up.
To remove the coin box for emptying,
lift the coin box up by pushing up on
the middle edge of the coin box on
the console guide. Never use thecoin box for smoking materials. Accessor
y Powe r Socke t
To use the accessory power socket, pull down the cover. The ignitionswitch must be in ACCESSORY (I)

or ON (II).

This socket is intended to supply power for 12 volt DC accessoriesthat are rated 120 watts or less (10

amps).

It will not power an automotive type
cigarette lighter element.
Instrument s an d Control s

ACCESSOR
Y
POWE R
SOCKE T
