2000 HONDA ODYSSEY Owners Manual

Changing a Fla t Tir e
3. Open the tailgate.
Remove the cargo net.
4. The tools and jack are behind a cover in the cargo area on the
driver's side. Remove the cover by
turning the handle counterclockwise, then pulling out
the cover. 5. Take the tools out of the storage
compartment.
6. Turn the jack's end bracket counterclockwise to loosen it, then
remove the jack.
7. The spare tire is stored under the
floor between the first and second row of seats. If the front seats areadjusted to the rear-most position,
move the seats forward slightly and adjust the seat-backs to an
upright position (see page 100).
Lift up the center table (see page
117).
Takin g Car e o f th e Unexpecte d
COVER

Changing a Fla t Tir e
8. Open either of the rear sliding
doors. Pull the floor carpet up by
lifting up on the edge, then raise
the floor lid by pulling up on the handle. To keep the floor carpetand lid out of the way, pull out the
hook on the back of the floor lid and attach it into the seat-back
handle on the driver's seat.9. On EX model
Remove the spare tire basket.
10. Unscrew the wing bolt and take the spare tire out of its well. After
you have removed the spare tire, screw this wing bolt back into
place.
11. On EX model
If you are changing a rear tire,
close the sliding door. Then turnoff the sliding door MAIN switch.
12. Loosen the five wheel nuts 1/2 turn with the wheel wrench.
CONTINUED
Takin g Car e o f th e Unexpecte d
HOOK
WHEE L NUT S
HANDL E
SPARE TIR E
BASKE T
SPAR E TIR E
WIN G BOL T

Changing a Fla t Tir e
13. Locate the jacking point nearest
the tire you need to change. It is
pointed to by a mark molded
into the underside of the body.Place the jack under the jacking
point. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Makesure the jacking point tab is
resting in the jack notch. 14. Use the extension and wheel
wrench as shown to raise the
vehicle until the flat tire is off the
ground.
15. Remove the wheel nuts and flattire. Temporarily place the flat tireon the ground with the outside
surface of the wheel facing up.
You could scratch the wheel if you put it face down.
Takin g Car e o f th e Unexpecte d
JACKIN
G POIN T EXTENSIO
N
WHEE L
WRENC H

Changing a Fla t Tir e
On LX model
Do not attempt to forcibly pry the
wheel cover off with a screwdriver or other tool. The wheel cover cannot
be removed without first removing
the wheel nuts. 16. Before mounting the spare tire,
wipe any dirt off the mounting
surface of the wheel and hub with
a clean cloth. Wipe the hub
carefully, it may be hot from
driving.
17. Put on the spare tire. Put the wheel nuts back on finger-tight,
then tighten them in a crisscross
pattern with the wheel wrenchuntil the wheel is firmly against
the hub. Do not try to tighten
them fully.
CONTINUED
Takin g Car e o f th e Unexpecte d
BRAKE HU B
WHEE L
COVE R

Changing a Fla t Tir e
18. Lower the vehicle to the ground
and remove the jack.19. Tighten the wheel nuts securely in
the same crisscross pattern. Have
the wheel nut torque checked at
the nearest automotive service
facility.
Tighten the wheel nuts to:8 0 lbf .
f t (10 8 N .
m , 1 1 kgf .
m )
20. Put the flat tire in the supplied
vinyl bag. This bag is stored in therear compartment on the driver'sside panel in the third row. Knot
the top of the vinyl bag.
Takin g Car e o f th e Unexpecte d

Changing a Fla t Tir e
21. Storing the flat tire behind the third
seat
When the third seat is not folded,
the flat tire is secured behind the
third seat.
On EX model
Turn on the sliding door MAIN switch so you can open the door.
Remove the bracket and the wing
bolt from the spare tire lid by unscrewing the bracket mounting
bolt. 22. You will find a u-shaped slit on the
carpet behind the seat bottom of
the third seat. Pull up the carpet at
the slit and remove the plastic screw with a coin.
CONTINUED
Takin g Car e o f th e Unexpecte d
WIN
G BOL T
BRACKE T
BRACKE T MOUNTIN G BOL T BRACKE
T
MOUNTIN GBOLT
PLASTI C
SCRE W
BRACKE T

Changing a Flat Tire
Adjust th
e seat-back of the third
seat to the upright position (see
page 101). Install the bracket and
the bracket mounting bolt to the attachment point as shown, and
tighten the bolt. Make sure the
bracket is securely locked.
23. Storing the Flat Tire on the Floor

When the third seat is folded, the
flat tire is secured to the floor on
top of the folded seat. Pull up thecarpet on the attachment point and
remove the plastic screw asdescribed in the previous
procedure.
Remove the wing bolt from the
bracket that is attached to the spare tire lid.
Takin g Car e o f th e Unexpecte d

BRACKE T

TIR E MOUNTIN G
WIN
G BOL T

Install the flat tire on the bracket

with the inside of the wheel facing

toward you. Put the tire mounting

wing bolt in the attachment point

through one of the five wheel nut
holes and the bracket as shown.

Poke holes in the vinyl bag. Secure

the flat tire by tightening the wing

bolt.

Changin
g a Fla t Tir e

TIR E MOUNTIN G WIN G BOL T
ATTACHMEN T POIN T
Place the flat tire face down on the attachment point. Put the tire
mounting wing bolt in the attachment point through one of
the five wheel nut holes as shown. Poke holes in the vinyl bag. Secure
the flat tire by tightening the wing
bolt.
24. Store the jack in its holder. Turn
the jack's end bracket clockwise to
lock it in place. Store the tools.
Replace the cover.

25. Close the tailgate.

26. Store the plastic screw in the spare

tire well.
On LX model

Store
th
e wheel cover in the spare
tire well. Make sure it will not get scratched or damaged.

On EX model

Store th
e spare tire basket in the
spare tire well. 27. Unclip the hook from the seat

back handle on the driver's seat
and lower the floor lid and the
carpet.
Make sure to adjust the front
seats properly before you start
driving (see page 100).

Takin g Car e
o
f th e Unexpecte d
Loose items can fly around the
interior in a crash and could
seriously injure the occupants.
Store the wheel, jack and tools
securely before driving.
