2000 Citroen C5 Injection

Downloaded from www.Manualslib.com manuals search engine 114
INJECTION
STANDARD
W vu 15.05 Petrol Utility vehicles :
Diesel All Types
• new models 01/10/88

• existing models 01/10/89

10/94
Z US 83 Petrol Private vehicles : Current
 Adoption of U.S. standard
Diesel • certain non-EEC
European countries
• certain Export countries
EMISSION STANDARDS
PSA
A-S RPEngines ApplicableVehicles
ECE
R 15.05
US 83 E.E.C.
APPLICATION NOTES
CHARACTERISTICS
With oxygen sensor
and catalytic converter
for petrol vehicles Brussels directives 88/76 and
88/436
 Utility vehicle limits
= private vehicle limits of
Brussels directive 88/436
7 classes of limits by
vehicle weight

Downloaded from www.Manualslib.com manuals search engine 115
INJECTION
STANDARD
Y US 87 Diesel Private vehicles : Current
Adoption of U.S. standard With catalytic
• certain non-EEC converter and EGR
European countries
• certain Export countries
Y2 US 93 Petrol Private vehicles : Current
Adoption of U.S. standard
Diesel • certain Export countries
X1 US 84 Petrol Utility vehicles : Current
Adoption of U.S. standard
Diesel • certain non-EEC standard for light utility
European countries vehicles
• certain Export countries
X2 US 87 Petrol Utility vehicles : Current
Adoption of U.S. standard
Diesel • certain non-EEC standard for light utility
European countries vehicles
• certain Export countries
EMISSION STANDARDS
PSA
A-S RPEngines ApplicableVehicles
US 87
US 93
US 84
LDT
US 87
LDTE.E.C.
APPLICATION NOTES
CHARACTERISTICS

Downloaded from www.Manualslib.com manuals search engine 116
INJECTION
STANDARD
X3 US 90 Petrol Private vehicles : Current
 Adoption of the U.S.
Diesel • certain non-EEC standard for light utility vehicles
European countries
• certain Export countries
L1 CEE Petrol Private vehicles : Brussels directive
19.5 Diesel < 1.4 litres 07/92
89/458
• new models
 01/07/93 Possible alternative to
• existing models
 31/12/94 emission standard L from
1992 to 1994
L CEE Petrol Private vehicles : EU Brussels Directive
19.5 Diesel All Types 93/59 (91/441)
• new models 07/92

• existing models 01/93
• new models  01/96
• existing models
 01/97
EMISSION STANDARDS
PSA
A-S RPEngines ApplicableVehicles
US 90
LDT
EURO 1
(EURO
93)
EURO 1
(EURO
93)E.E.C.
APPLICATION NOTES
CHARACTERISTICS
With oxygen sensor and
catalytic converter for
petrol vehicles.
With catalytic converter
and EGR for diesel
vehicles.

Downloaded from www.Manualslib.com manuals search engine 117
INJECTION
STANDARD
W2 CEE Petrol Utility vehicles : Brussels Directive 93/59
W2 Diesel < 3.5 tonnes
• new models 01/10/93
 3 classes depending on
• existing models 01/10/94
vehicle weight :
Class 1 : Class 1 < 1250 kg
• new models
 01/97 Class 2 : 1250/1700 kg
• existing models
 10/97 Class 3 > 1700 kg
Class 2/3 :
• new models
 01/98
• existing models
 10/98
L3 CEE Petrol Private vehicles : Brussels Directive 94/12
95 Diesel < 6 seats and
< 2.5 tonnes
 EURO 93 standard made
• new models 01/96
 stricter
• existing models 01/97

All Types EMISSION STANDARDS
PSA
A-S RPEngines ApplicableVehicles
EURO 1
(EURO
93)
EURO 2
(EURO
96)E.E.C.
APPLICATION NOTES
CHARACTERISTICS
With oxygen sensor and
catalytic converter for
petrol vehicles
With oxygen sensor and
reinforced catalytic converter
for petrol vehicles.
With catalytic converter
and EGR for diesel
vehicles.

Downloaded from www.Manualslib.com manuals search engine 118
INJECTION
STANDARD
W3 CEE Petrol Utility vehicles : Brussels Directive 96/69
95 Diesel < 3.5 tonnes
Gaz Class 1 :
 3 classes depending on
• new models 01/97
 vehicle weight :
• existing models 10/97
 Class 1 < 1250 kg
Class 2/3 : Class 2 : 1250/1700 kg
• new models 01/98
 Class 3 : 1700 kg
• existing models 10/98

L4 CEE Petrol Private vehicles : Brussels Directive 98/69
2000 Diesel All Types
 EURO 2 standard (L3)
Gaz • new models
 01/2000 made stricter
• existing models
 01/2001  Fiscal incentives
EMISSION STANDARDS
PSA
A-S RPEngines ApplicableVehicles
EURO 2
(EURO
96)
EURO 3
(EURO
2000)E.E.C.
APPLICATION NOTES
CHARACTERISTICS
With oxygen sensor and
reinforced catalytic
converter for petrol
vehicles.
With catalytic converter
and EGR for diesel
vehicles.
With 2 oxygen sensors
and catalytic converter
for petrol vehicles. With
catalytic converter and
EGR for diesel vehicles.
With EOBD on-board
diagnosis.

Downloaded from www.Manualslib.com manuals search engine 119
INJECTION
STANDARD
W3 Petrol Utility vehicles : Brussels Directive 98/69
Diesel < 3.5 tonnes
 EURO 2 standard (L3)
Gaz
made stricter
Class 1 : Fiscal incentives
• new models
 01/2000 3 classes depending on
• existing models
 01/2001 vehicle weight :
Class 2/3 :
Class 1 < 1305 kg
• new models  01/2001Class 2 : 1305/1760 kg
• existing models  01/2002Class 3 : 1760 kg
IF / L5 Petrol Private vehicles : Brussels Directive 98/69
All Types
 EURO 3 standard (L4)
• new models
 01/2001 made stricter
• existing models
 01/2003  Fiscal incentives
EMISSION STANDARDS
PSA
A-S RPEngines ApplicableVehicles
EURO 3
(EURO
2000)
EURO 4E.E.C.
APPLICATION NOTES
CHARACTERISTICS
With 2 oxygen sensors
and catalytic converter
for petrol vehicles.
With catalytic converter
and EGR for diesel
vehicles.
With EOBD on-board
diagnosis.
With 2 oxygen sensors
and catalytic converter
for petrol vehicles.
With EOBD on-board
diagnosis.

Downloaded from www.Manualslib.com manuals search engine 120
INJECTION
PROHIBITED OPERATIONS: HDi DIRECT INJECTION SYSTEM
Engines : RHY - RHZ - 4HX
Cleaning.
- The use of high pressure cleaners is prohibited.
- Do not use compressed air.
Fuel supply circuit.
- Required fuel : diesel.
Electric circuit.
- Swapping injection ECUs Between two vehicles will render it impossible to start either vehicle.
- It is forbidden to supply a diesel injector with 12 volts.
High pressure fuel pump.
Do not separate the following components from the high pressure fuel pump (5):
- Sealing ring (b)(no replacement parts).
- High pressure outlet connector (a)(will cause a malfunction).
PS : HDi = High pressure diesel injection.
B1HP19LC

Downloaded from www.Manualslib.com manuals search engine 121
INJECTION
PROHIBITED OPERATIONS: HDi DIRECT INJECTION SYSTEM
Engines : RHY - RHZ - 4HX
Diesel injectors.
WARNING: Diesel and ultrasonic cleaners are prohibited.
Do not separate the following components from the diesel injector carrier (2):
- Diesel injector(e) (no replacement parts).
- Electromagnetic element(c)(no replacement parts).
Do not alter the position of the nut(d)(malfunction).
Do not separate the connector(f)from a diesel injector.
It is forbidden to clean the carbon deposits from the diesel injector nozzle.
B1HP19NC
