2000 CHEVROLET CAMARO Owners Manual

6-62
Main Fuse Block
Fuse Usage
STOP/HAZARD Hazard Flashers, Brake
Switch Assembly
TURN B/U Traction Control/Second
-Gear
Start Switch, Back
-Up Lamp
Switch, Turn Flasher, Daytime
Running Lamps (DRL) Module
STG WHL
CNTRLSteering Wheel ControlsFuse Usage
RADIO ACCY Delco Monsoon Radio Amplifier,
Remote CD Player (Trunk)
TAIL LPS Daytime Running Lamps (DRL)
Module, Headlamp Switch
HVAC HVAC Selector Switch,
Rear Defogger Switch/Timer
PWR ACCY Parking Lamp Relay, Hatch
Release Relay, Power Mirror
Switch, Radio, Shock Sensor,
Instrument Cluster
COURTESY Body Control Module (BCM)
GAUGESBody Control Module (BCM),
Brake
-Transmission Shift Interlock
(BTSI), Instrument Cluster,
Daytime Running Lamps
(DRL) Module
AIR BAG Air Bag System
CIG/ACCY Cigarette Lighter, Data Link
Connector (DLC)
DEFOG/SEATS Rear Defogger Switch/Timer,
Power Seats

6-63
Fuse Usage
IGN Aftermarket Use Only
STG WHL
CNTRLSteering Wheel
Controls Illumination
WIPER/WASH Wiper Motor Assembly,
Wiper/Washer Switch
BATT Aftermarket Use Only
WINDOWSPower Windows Switch (RH, LH),
Express
-Down Module,
Convertible Top Switch
IP DIMMER Door Illumination Lamp (LH, RH),
Headlamp Switch, Fog Lamp
Switch, Instrument Cluster,
HVAC Control Assembly, PRNDL
Illumination Lamp, Ashtray Lamp,
Radio, Rear Window Defogger
Switch/Timer, Traction Control
(ASR)/Second
-Gear Start Switch,
Convertible Top Switch
ACCY Aftermarket Use Only
RADIO Body Control Module (BCM),
Radio, Amplifier, Steering Wheel
Controls
-RadioUnderhood Electrical Center
Fuse and Relay Center 1
Fuse Usage
ABS BAT SOL Anti
-Lock Brake System
TCS BAT Traction Control System and ETC
COOL FAN Cooling Fan Control
PCM BAT Powertrain Control Module (PCM)
FUEL PUMP Fuel Pump

6-64
Fuse Usage
AIR PUMP Air Pump Relay and Bleed Valve
LH HDLP DR Left Headlamp Door and Module
RH HDLP DR Right Headlamp Door and Module
HORN Horn Relay
ABS BAT
-1 Anti-Lock Brake System Module
H/L DR HORN Horn and Headlamp Doors
ABS BAT
-2 Anti-Lock Brake and Traction
Control System (ASR)
COOL FAN Cooling Fan Relays
Relay Description
FOG LAMP Fog Lamps
HORN Horn
FAN #3 Cooling Fans
FAN #2 Cooling Fans
FAN #1 Cooling Fans
Fuse and Relay Center 2
Fuse Usage
INJ
-2 Fuel Injectors (Not Used for V6)
(LH Injectors for V8 and
Ignition Module)
INJ
-1 Fuel Injectors (All for V6)
(RH Injectors for V8 and
Ignition Module)

6-65
Fuse Usage
ENG SEN Mass Air Flow, Heated Oxygen
Sensor, Skip Shift Solenoid
(V8 Only), Reverse Lockout
Solenoid, Brake Switch
STRTR Powertrain Control Module (PCM)
and Clutch Pedal Switch
ABS IGN Anti
-Lock Brake System Module
PCM IGN Powertrain Control Module (PCM)
ETC Electronic Throttle Control
(V6 Only)
ENG CTRL Ignition Module (V6 Only),
Automatic Transmission and
Charcoal Canister Purge Solenoid
A/C CRUISE Air Conditioning Compressor
Relay, Cruise Control Switches
and ModuleFuse Usage
ENG CTRL Engine Controls, Fuel Pump,
Powertrain Control Module (PCM),
A.I.R. and Cooling Fans
I/P
-1 HVAC Blower Control and Relay
IGN Ignition Switch, Relay and Starter
Enable Relay
I/P
-2 Instrument Panel Fuse Center
Relay Description
Blank Not Used
AIR PUMP Air Pump
A/C COMP Air Conditioning Compressor
FUEL PUMP Fuel Pump
STARTER Starter
IGN Engine Controls, Cruise Control,
Air Conditioning

6-66
Replacement Bulbs
Back-Up3155 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stoplamp921 . . . . . . . . . . .
Front Parking and Turn Signal3157 K . . . . . . . . .
Headlamps
Low Beam 4703. . . . . . . . . . . . . . . . . . . . . . . . . . . .
High Beam 4701. . . . . . . . . . . . . . . . . . . . . . . . . . .
Sidemarker Lamps194 . . . . . . . . . . . . . . . . . . . . . .
Taillamps Only194 . . . . . . . . . . . . . . . . . . . . . . . . . .
Tail/Stop/Turn Lamps3057 . . . . . . . . . . . . . . . . . . .
Capacities and Specifications
The following approximate capacities are given in English
and metric conversions. Please refer to ªRecommended
Fluids and Lubricantsº in the Index for more information.
Air Conditioning
See the refrigerant . . . . . . . . . . .
information label under the hood.
Automatic Transmission
Drain and Refill 5.0 quarts (4.7 L). . . . . . . . . . . . . . . Overhaul
3800 V6 8.8 quarts (8.3 L). . . . . . . . . . . . . . . . . . . . .
5.7L V8 10.8 quarts (10.2 L). . . . . . . . . . . . . . . . . . .
Cooling System
3800 V6
With Manual Transmission 11.6 quarts (11.0 L). . . .
With Automatic Transmission 11.4 quarts (10.8 L). .
5.7L V8
With Manual Transmission 11.9 quarts (11.3 L). . . .
With Automatic Transmission 11.8 quarts (11.2 L). .
Crankcase
With Oil and Filter Change
3800 V6 4.5 quarts (4.2 L). . . . . . . . . . . . . . . . . . . . .
5.7L V8 5.5 quarts (5.2 L). . . . . . . . . . . . . . . . . . . . .
Fuel Tank16.8 gallons (63.6 L) . . . . . . . . . . . . . . . . .
Manual Transmission
Five
-Speed 3.4 quarts (3.2 L). . . . . . . . . . . . . . . . . . .
Six
-Speed 4.0 quarts (3.8 L). . . . . . . . . . . . . . . . . . .
Rear Axle Lubricant1.75 quarts (1.7 L) . . . . . . . . . .
All capacities are approximate. When adding, be sure to
fill to the approximate level, as recommended in this
manual. Recheck fluid level after filling.

6-67 Engine Specifications
Type
VIN Engine Code K V6. . . . . . . . . . . . . . . . . . . . . .
VIN Engine Code G V8. . . . . . . . . . . . . . . . . . . . . .
Fuel DeliveryFuel Injection . . . . . . . . . . . . . . . . . . .
Valve ArrangementIn
-Head . . . . . . . . . . . . . . . . . . .
Displacement
3800 V6 231 cubic inches (3791 cc). . . . . . . . . . . . .
5.7L V8 346 cubic inches (5665 cc). . . . . . . . . . . . .
Firing Order
3800 V6 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 1
-8-7-2-6-5-4-3 . . . . . . . . . . . . . . . . . . . . .
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
Thermostat Temperature Specification
3800 V6 195
F (91
C) . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 180
F (82
C) . . . . . . . . . . . . . . . . . . . . . . .
Normal Maintenance
Replacement Parts
Engine Air Cleaner/FilterA917C . . . . . . . . . . . . . . .
Battery75
-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil Filter
3800 V6 PF47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 PF44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fuel Filter
3800 V6 G627. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 GF578. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PCV Valve
3800 V6 CV892C. . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7L V8 CV948C. . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator CapRC24 . . . . . . . . . . . . . . . . . . . . . . . . . .
Spark Plug
3800 V6 41
-921 (0.060 inch gap) . . . . . . . . . . . . . . .
5.7L V8 41
-952 (0.060 inch gap) . . . . . . . . . . . . . . .
Windshield Wiper Blade Replacement
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 24.0 inches (60.1 cm). . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Length193.5 inches (491.5 cm) . . . . . . . . . . . . . . . . .
Width74.1 inches (188.3 cm) . . . . . . . . . . . . . . . . . . .
Height
Coupe 51.3 inches (130.3 cm). . . . . . . . . . . . . . . . .
Convertible 52.0 inches (131.2 cm). . . . . . . . . . . . .
Wheelbase101.1 inches (256.6 cm) . . . . . . . . . . . . . .
Tread
Front 60.7 inches (154.2 cm). . . . . . . . . . . . . . . . . .
Rear 60.6 inches (154.0 cm). . . . . . . . . . . . . . . . . . .

7-
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-5 Scheduled Maintenance
7
-17 Part B: Owner Checks and Services7
-21 Part C: Periodic Maintenance Inspections
7
-23 Part D: Recommended Fluids and Lubricants
7
-25 Part E: Maintenance Record

7-2
Have you purchased the GM Protection Plan?
The Plan supplements your new vehicle warranties.
See your Warranty and Owner Assistance booklet,
or your dealer for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
Maintenance Requirements
Maintenance intervals, checks, inspections and
recommended fluids and lubricants as prescribed in
this manual are necessary to keep your vehicle in good
working condition. Any damage caused by failure to
follow recommended maintenance may not be covered
by warranty.
