2000 CHEVROLET CAMARO Owners Manual

2-16 Remote Keyless Entry Transmitter Locking
If all the doors are closed, locking the vehicle with the
remote keyless entry transmitter will immediately arm
the system. The horn will chirp twice and the parking
lamps will flash, confirming that the system is armed.
If any door is open when the LOCK button is pressed,
the system goes into an armed wait mode, waiting for
the doors to close. Once they are closed, the system
will arm, the horn will chirp twice and the parking
lamps will flash. If the hatch is open or ajar at the time
the system is arming, the horn will only chirp once.
Power Door Lock Switch Locking
If any door is open when the power door lock switch
is pressed, the system goes into an armed wait mode,
waiting for the doors to close. Once they are closed,
the system will arm and the parking lamps will flash.
If both doors are closed when the power door lock
switch is pressed, the system assumes you are inside
the vehicle, so it will not arm. Locking the doors by
using the manual door locks will not arm the system.
Passive Arming
If the ignition was just turned off and a door was
opened, the system will arm six seconds after both doors
are closed, whether or not you lock them. In all other
cases, the system will wait 30 seconds after both doors
are closed before arming, allowing you time to get into
the vehicle and put the key in the ignition. The parking
lamps will flash when the system arms.
The vehicle is shipped from the factory with this
feature turned off, To turn this feature on, see
ªFeature Customizationº in the Index.
Disarming the System
There are two ways to disarm the system:

Press the UNLOCK button on the remote keyless
entry transmitter. If the horn chirps two or three
times when you unlock the vehicle, the alarm
sounded in your absence. Two chirps means that
the shock sensor was set off and three chirps means
that a door or the hatch was opened.

Turn the ignition key to RUN.
For more information on customizing the features
mentioned here, see ªFeature Customizationº in
the Index.

2-17
PASS-Key
II
Your vehicle is equipped
with the PASS
-Key II
(Personalized Automotive
Security System)
theft
-deterrent system.
PASS
-Key II is a passive
theft
-deterrent system.
It works when you insert
or remove the key from
the ignition.
PASS
-Key II uses a resistor pellet in the ignition key
that matches a decoder in your vehicle.
When the PASS
-Key II system senses that someone is
using the wrong key, it shuts down the vehicle's starter and
fuel systems. For about three minutes, the starter won't
work and fuel won't go to the engine. If someone tries to
start your vehicle again or uses another key during this time,
the vehicle will not start. This discourages someone from
randomly trying different keys with different resistor pellets
in an attempt to make a match.
The ignition key must be clean and dry before it's
inserted in the ignition or the engine may not start.
If the engine does not start and the SECURITY light
stays on when you try to start the vehicle, the key may be
dirty or wet. Turn the ignition off.Clean and dry the key. Wait about three minutes and try
again. The SECURITY light may remain on during this
time. If the starter still won't work, and the key appears
to be clean and dry, wait about three minutes and try
another ignition key. At this time, you may also want to
check the fuses (see ªFuses and Circuit Breakersº in the
Index). If the starter won't work with the other key, your
vehicle needs service. If your vehicle does start, the first
ignition key may be faulty. See your dealer or a
locksmith who can service the PASS
-Key II.
If you accidentally use a key that has a damaged or
missing resistor pellet, the starter won't work. The
SECURITY light will flash. But you don't have to
wait three minutes before trying another ignition key.
See your dealer or a locksmith who can service the
PASS
-Key II to have a new key made.
If you're ever driving and the SECURITY light comes on
and stays on, you will be able to restart your engine if you
turn it off. Your PASS
-Key II system, however, is not
working properly and must be serviced by your dealer.
Your vehicle is not protected by the PASS
-Key II system.
If you lose or damage a PASS
-Key II ignition key, see
your dealer or a locksmith who can service PASS
-Key II to
have a new key made. In an emergency, call the Chevrolet
Roadside Assistance Center at 1
-800-CHEV-USA
or
1
-800-243-8872 (In Canada call 1-800-268-6800).

2-18
Feature Customization (If Equipped)
Your vehicle's content theft-deterrent/alarm system, locks and lighting systems can be programmed with several
different features. The features you can program depend upon the options that came with your vehicle. The following
chart show the features that can be programmed. To determine which features your vehicle is equipped with, follow
the steps listed for entering the programming mode.

2-19 Entering Programming Mode
To program any feature, your vehicle must be in the
programming mode. Follow these steps:
1. Put your key in the ignition.
2. Turn the ignition to RUN to disarm the content
theft
-deterrent/alarm system.
3. Turn the ignition to OFF.
4. Remove the RADIO fuse. This fuse is in the
main fuse block, located on the left side of your
instrument panel. When the main fuse block is open,
the RADIO fuse is located in the lower right corner
side of the fuse panel. See ªFuses and Circuit
Breakersº in the Index.
5. Turn the ignition towards you to ACC.
6. Count the number of chimes you hear. You will
hear one to two chimes depending on the features
your vehicle is equipped with. Refer to the chart
shown previously.
You can now program your choices.
To exit the programming mode, follow the steps
listed under ªLeaving Programming Modeº later in
this section.
Exit Lighting and Delayed Illumination
With Exit Lighting, your interior lamps will come on
for up to 25 seconds when the key is removed from
the ignition.
With Delayed Illumination, your interior lamps will
come on and stay on for up to 25 seconds when
entering your vehicle and up to five seconds when
leaving your vehicle.
Programmable Modes
Your vehicle can be programmed to one of the
following modes:
Mode 1: Both Off
Mode 2: Delayed Illumination Only
Mode 3: Exit Lighting Only
Mode 4: Both On
Vehicles are delivered programmed in Mode 4.

2-20
To change the mode, do the following:
1. Turn the courtesy lamps on by turning the instrument
panel brightness control all the way up.
2. Count the number of chimes you hear. The number of
chimes tells you which mode your vehicle is set for.
3. Turn the courtesy lamp switch off.
4. Turn the courtesy lamp switch from on to off until
you hear the number of chimes that corresponds to
the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
Last Door Closed Locking and
Lockout Prevention
These features are designed to help prevent your keys
from being locked in your vehicle.
Programmable Modes
Your vehicle can be programmed to one of the
following modes:
Mode 1: Both Off (Doors will lock/unlock when you
press the power door lock switch.)Mode 2: Lockout Prevention Only (If you leave your
keys in the ignition and leave through the driver's door,
you won't be able to lock the doors with the power door
lock switch.)
Mode 3: Last Door Closed Locking Only (If the power
door lock switch is used to lock the vehicle while any
door is open, you will hear three chimes. The doors will
not lock until after all doors are closed.)
Mode 4: Both On (This combines Mode 2 and 3.)
Vehicles are delivered programmed in Mode 2.
To change the mode, do the following:
1. Press the power door LOCK switch on the door.
2. Count the number of chimes you hear. The
number of chimes tells you which mode your
vehicle is set for.
3. Press the power door LOCK switch again on the
door until you hear the number of chimes that
correspond to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-21 Remote Keyless Entry Verification
This feature provides feedback when the vehicle receives
a command from the remote keyless entry transmitter.
Programmable Modes
Your vehicle can be programmed to one of the
following modes:
Mode 1: All Off (The headlamps will not flash and
the horn will not sound to provide you feedback that a
lock/unlock command has been received by the remote
keyless entry transmitter.)
Mode 2: Horn and Lamps/Lamps (Your horn will
sound briefly and your parking lamps will flash when
you press LOCK on the remote keyless entry
transmitter. Only your parking lamps will flash when
you press UNLOCK.)
Mode 3: Horn and Lamps (Your horn will sound briefly
and your parking lamps will flash every time you push
LOCK or UNLOCK.)
Mode 4: Lamps (Your parking lamps will flash every
time you press LOCK or UNLOCK.)Mode 5: Lamps/Horn and Lamps/Lamps (Your lamps
will flash upon the first press on LOCK, your lamps
will flash and your horn will sound upon the second
press on LOCK and your lamps will flash upon any
press on UNLOCK.)
Vehicles are delivered programmed in Mode 5.
To change the mode, do the following:
1. Press the UNLOCK button on the remote keyless
entry transmitter.
2. Count the number of chimes you hear. The
number of chimes tells you which mode your
vehicle is set for.
3. Press the UNLOCK button again on the remote
keyless entry transmitter until you hear the number
of chimes that correspond to the mode selection
you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-22 Theft-Deterrent Arming Method
With this feature, you can program your vehicle to arm
the content theft
-deterrent/alarm system using the
remote keyless entry transmitter, the power door lock
switch or by passive arming.
Programmable Modes
Your vehicle can be programmed to one of the
following modes:
Mode 1: Alarm System Off (The system will not arm.)
Mode 2: Remote Keyless Entry Transmitter Lock
(When you lock your doors using the LOCK button
on the remote keyless entry transmitter, the system will
arm itself.)
Mode 3: Remote Keyless Entry Transmitter/Power
Door Lock Switch (If you use either the LOCK button
on the remote keyless entry transmitter or the power
door lock switch to lock the doors, the system will
arm itself.)Mode 4: Passive Arming and Remote Keyless
Entry Transmitter/Power Door Lock Switch Arming
(The system will arm itself after all doors are closed,
plus arming per Mode 3.)
Vehicles are delivered programmed in Mode 3.
To change the mode, do the following:
1. Press the unlock switch on the door.
2. Count the number of chimes you hear. The
number of chimes tells you which mode your
vehicle is set for.
3. Press the unlock switch again on the door until
you hear the number of chimes that correspond to
the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-23 Theft-Deterrent Arming Verification
With this feature, you can program your vehicle to
give verification when the theft
-deterrent system has
been armed.
Programmable Modes
Your vehicle can be programmed to one of the
following modes:
Mode 1: All Off (No horn chirps or parking lamp flash.)
Mode 2: Horn and Lamps (Your parking lamps will
flash and your horn will chirp twice to verify the system
is armed using any arming method.)
Mode 3: Horn and Lamps/Lamps (If you use the
remote keyless entry transmitter to arm the system,
your parking lamps will flash and your horn will chirp
twice to verify that the system is armed. If it only chirps
once, the hatch is open or unlatched. If you use either
the power door lock switch or passive arming, only your
parking lamps will flash for verification.)Mode 4: Lamps (When your vehicle arms, only your
parking lamps will flash for verification.)
Vehicles are delivered programmed in Mode 3.
To change the mode, do the following:
1. Press the LOCK button on the remote keyless
entry transmitter.
2. Count the number of chimes you hear. The
number of chimes tells you which mode your
vehicle is set for.
3. Press the LOCK button again on the remote
keyless entry transmitter until you hear the number
of chimes that corresponds to the mode selection
you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
