2000 CHEVROLET CAMARO Owners Manual

2-88
Emissions Inspection and Maintenance Programs
Some state/provincial and local governments have or may
begin programs to inspect the emission control equipment
on your vehicle. Failure to pass this inspection could
prevent you from getting a vehicle registration.
Here are some things you need to know in order to help
your vehicle pass an inspection:
Your vehicle will not pass this inspection if the
SERVICE ENGINE SOON or CHECK ENGINE light
is on or not working properly.
Your vehicle will not pass this inspection if the OBD
(on
-board diagnostic) system determines that critical
emission control systems have not been completely
diagnosed by the system. The vehicle would be
considered not ready for inspection. This can happen
if you have recently replaced your battery or if your
battery has run down. The diagnostic system is designed
to evaluate critical emission control systems during
normal driving. This may take several days of routine
driving. If you have done this and your vehicle still
does not pass the inspection for lack of OBD system
readiness, see your dealer or qualified service center
to prepare the vehicle for inspection.
Oil Pressure Gage
3800 V6 Engine 5.7L V8 Engine
This gage tells you if there could be a problem
with your engine oil pressure. The gage shows the
engine oil pressure in psi (pounds per square inch)
or kPa (kilopascals) when the engine is running.

2-89
On the 3800 V6 engine, the oil pressure should be
20 to 120 psi (140 to 827 kPa). On the 5.7L V8 engine,
oil pressure should be 20 to 80 psi (140 to 550 kPa).
In certain situations such as long, extended idles on hot
days, it could read as low as 6 psi (40 kPa) and still
be considered normal. It may vary with engine speed,
outside temperature and oil viscosity, but readings above
the red area show the normal operating range. Readings
in the red area tell you that the engine is low on oil,
or that you might have some other oil problem.
See ªEngine Oilº in the Index.
CAUTION:
Don't keep driving if the oil pressure is low. If you
do, your engine can become so hot that it catches fire.
You or others could be burned. Check your oil as
soon as possible and have your vehicle serviced.
NOTICE:
Damage to your engine from neglected oil problems
can be costly and is not covered by your warranty.

2-90 Low Oil Light
This warning light
should come on briefly
while you are starting your
engine. If the light doesn't
come on, have it repaired.
If the light stays on after starting your engine, your
engine oil level may be too low. You may need to add
oil. See ªEngine Oilº in the Index.
NOTICE:
The oil level monitoring system only checks the
oil level when you are starting your engine. It
does not keep monitoring the level once the
engine is running. Also, the oil level check only
works when the engine has been turned off long
enough for the oil to drain back into the oil pan.
Oil Change Light
This OIL CHANGE light
should come on briefly as
a bulb check when you
start the engine. If the OIL
CHANGE light doesn't
come on, have it serviced.
If the OIL CHANGE light comes on and stays on for
60 seconds after you start the engine, have the oil changed.
For additional information, see ªEngine Oil, When to
Changeº in the Index. After changing the engine oil, the
system must be reset. See ªHow to Reset the Oil Change
Lightº in the Index.

2-91 Service Vehicle Light
This warning light
should come on in your
instrument panel cluster for
a three
-second bulb check
when you first start your
vehicle. If the light doesn't
come on, have it serviced.
This light will stay on steady if you have certain
non
-emission related vehicle problems. These problems
may not be obvious and may affect vehicle performance
or durability. Consult a qualified dealership for
necessary repairs to maintain top vehicle performance.
Check Gages Light
This warning light
will come on briefly
when you start
the engine.
If the light comes on and stays on while you are driving,
check your gages to see if they are in the warning areas.
Hatch Ajar Light
This warning light should
come on in your instrument
panel cluster for a
three
-second bulb check
when you first start your
vehicle. If the light doesn't
come on, have it serviced.
This light will stay on steady if your hatch is open or
ajar and the ignition key is in RUN.

2-92 Fuel Gage
Your fuel gage tells you
about how much fuel
you have left when the
ignition is on.
When the indicator nears E (empty), you still have a
little fuel left, but you should get more soon.
Here are four things that some owners ask about. All
these things are normal and do not indicate that anything
is wrong with the fuel gage.

At the gas station, the gas pump shuts off before the
gage reads F (full).

It takes more (or less) fuel to fill up than the gage reads.
For example, the gage reads half full, but it took more
(or less) than half of the tank's capacity to fill it.

The gage pointer may move while cornering, braking
or speeding up.

The gage may not indicate E (empty) when the
ignition is turned off.
Low Fuel Light
If your fuel is low, your vehicle's CHECK GAGES light
on your instrument panel cluster will come on.
Reduced Engine Power Light
(V6 Engine Only)
The REDUCED ENG PWR
warning light should come
on in your instrument panel
cluster for a three
-second
bulb check when you first
start your vehicle.
If the light doesn't come on, have it serviced.
If the REDUCED ENG PWR warning light comes on,
a noticeable reduction in the vehicle's performance may
occur. The vehicle may be driven at a reduced speed
while the REDUCED ENG PWR light is on, but
acceleration and speed may be reduced. Anytime this
warning light stays on, the vehicle should be taken to
an authorized Chevrolet dealer as soon as possible for
diagnosis and repair.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-3 Cooling
3
-3 Heating
3
-4 Defogging and Defrosting
3
-4 Rear Window Defogger
3
-5 Ventilation System
3
-6 Audio Systems
3
-6 Setting the Clock for Systems without
Automatic Tone Control
3
-6 Setting the Clock for Systems with
Automatic Tone Control
3
-6AM-FM Stereo with Cassette Tape Player
3
-9 Monsoon
AM-FM Stereo with Cassette
Tape Player and Automatic Tone Control
(If Equipped)3
-15 Monsoon AM-FM Stereo with Compact
Disc Player and Automatic Tone Control
(If Equipped)
3
-19 Trunk-Mounted CD Changer (If Equipped)
3
-22 Theft-Deterrent Feature (If Equipped)
3
-25 Audio Steering Wheel Controls (If Equipped)
3
-26 Understanding Radio Reception
3
-26 Tips About Your Audio System
3
-27 Care of Your Cassette Tape Player
3
-28 Care of Your Compact Discs
3
-28 Care of Your Compact Disc Player
3
-28 Fixed Mast Antenna

3-2
Comfort Controls
With this system you can control the heating, air
conditioning and ventilation in your vehicle.
Your vehicle also has the flow
-through ventilation
system described later in this section.
Fan Control Knob
Turn this knob to select the force of air you want.
Temperature Control Knob
Turn the knob to change the temperature of the air
flowing from the system. Turn it toward the red area
(clockwise) for warmer air and toward the blue area
(counterclockwise) for cooler air.
Air Control Knob
OFF: The system is off.
MAX: This setting provides maximum cooling for
quick cool
-down on very hot days. It recirculates
most of the air inside your vehicle. If it is used for long
periods of time, the air may become dry. This setting
directs air through the upper air vents.
A/C: Use A/C for normal cooling on hot days. This
setting cools outside air and directs it through the upper
air vents.
The air conditioner compressor operates in MAX,
A/C, bi
-level, blend and defrost when the outside
temperature is above freezing. When the air conditioner
is on, you may sometimes notice slight changes in your
vehicle's engine speed and power due to the operation of
the compressor.

3-3
BI-LEVEL: Air is directed through the upper air
vents and the heater ducts.
VENT: Air flows through the upper air vents.
HEATER: This setting directs most of the air
through the heater ducts and some of the air through
the windshield defroster vents.
BLEND: Air is directed through the windshield
defroster vents and the heater ducts.
DEFROST: This setting directs most of the air
through the windshield defroster vents and some of the
air through the heater ducts.
Cooling
The air conditioner works best if you keep your windows
closed. On very hot days, open the windows just long
enough for the hot air to escape.
1. Turn the air control knob to A/C for normal cooling.
For faster cooling turn the knob to MAX.
2. Turn the temperature control knob to a
comfortable setting.
3. Turn the fan control knob to the desired speed.
Heating
The heater works best if you keep your windows closed
while using it.
1. Turn the air control knob to heater.
2. Turn the fan control knob to the desired speed.
3. Turn the temperature control knob to a
comfortable setting.
If your vehicle is equipped with an engine coolant heater,
you can use it in cold weather (around 20
F/
-8
C or
lower) to improve heater performance on initial start up.
See ªEngine Coolant Heaterº in the Index.
Bi
-Level Heating
You may want to use bi
-level heating on cool, but
sunny days. This setting directs cool air toward your
body and warmer air toward your feet.
1. Turn the air control knob to bi
-level.
2. Turn the temperature control knob to a
comfortable setting.
3. Turn the fan control knob to the desired speed.
