2000 CADILLAC SEVILLE Owners Manual

2-85
SERVICE ELECTRICAL SYS - 106: This message
will display if an electrical problem has occurred within
the Powertrain Control Module (PCM) or the ignition
switch. Have your vehicle serviced by your dealership.
SERVICE FUEL SYSTEM
- 101: The Powertrain
Control Module (PCM) has detected a problem within
the fuel system when this message appears. See your
dealership for service.
SERVICE IDLE CONTROL
- 107: A problem with
the idle control has occurred when this message displays.
Take your vehicle to your dealership for service.
SERVICE STABILITY SYS
- 54 : If you ever see
the SERVICE STABILITY SYS message, it means
there may be a problem with your stability enhancement
system. If you see this message, try to reset the system
(stop; turn off the engine; then start the engine again).
If the SERVICE STABILITY SYS message still
comes on, it means there is a problem. You should see
your dealer for service. Reduce your speed and drive
accordingly. A single chime will also sound when this
message is displayed.STABILITY SYS ENGAGED
- 55: You may see
the STABILITY SYS ENGAGED message on the
Driver Information Center. It means that an advanced,
computer
-controlled system has come on to help your
vehicle continue to go in the direction in which you're
steering. This stability enhancement system activates
when the computer senses that your vehicle is just
starting to spin, as it might if you hit a patch of ice or
other slippery spot on the road. When the system is on,
you may hear a noise or feel a vibration in the brake
pedal. This is normal.
When the STABILITY SYS ENGAGED message is on,
you should continue to steer in the direction you want to
go. The system is designed to help you in bad weather or
other difficult driving situations by making the most of
whatever road conditions will permit. If the STABILITY
SYS ENGAGED message comes on, you'll know that
something has caused your vehicle to start to spin, so
you should consider slowing down.
SERVICE STEERING SYS
- 127: This message
is displayed when a problem has been detected in
the Magnasteer

variable effort steering system.
Service is required.

2-86
SERVICE SUSPENSION SYS - 84: This message is
displayed to indicate that the suspension system is not
operating properly. To correct this problem, have your
vehicle serviced at your dealership.
SERVICE THEFT SYSTEM
- 34: This message
means there is a problem in the Personalized Automotive
Security System (PASS
-Key
III). A fault has been
detected in the system which means that the PASS
-Key
III system is disabled and is not protecting the vehicle.
The vehicle usually restarts, however, you may want to
take your vehicle to a proper service center before turning
off the engine.
SERVICE TRANSMISSION
- 100: See your dealer
for repair.
SERVICE VEHICLE SOON
- 3: This message is
displayed when a non
-emissions related powertrain
malfunction occurs. Have your vehicle serviced by a
technician as soon as possible.
SPEED LIMITED TO 90
- 113: A failure in the
suspension control system has occurred when this
message appears. The Powertrain Control Module (PCM)
determines the speed to which your vehicle is limited.
Have your vehicle serviced if this message appears.STARTING DISABLED REMOVE KEY
- 33: This
message will appear when the Personalized Automotive
Security System (PASS
-Key
III) senses that an
improper ignition key is being used to try to start the
vehicle. Check the ignition key for damage. If it is
damaged, it may need to be replaced. If you see no
damage, remove the key and try to start the vehicle
again. If it still does not start, try another ignition key.
THEFT ATTEMPTED
- 40: This message is
displayed if the theft system has detected a break
-in
attempt while you were away from your vehicle.
TOP SPEED FUEL CUT
-OFF - 111 : This message
will appear when the Powertrain Control Module (PCM)
senses that the maximum speed for your vehicle has
been reached. The speed of your vehicle will surge as
the fuel supply is cut off. This allows your vehicle to
stay in a safe tire operating range. The top speed is set
based on the top speed rating of the tires.
TRACTION ENGAGED
- 91 : When your traction
control system is limiting wheel spin, the TRACTION
ENGAGED message will be displayed. Slippery road
conditions may exist if this message is displayed, so
adjust your driving accordingly. This message will stay
on for a few seconds after the traction control system
stops limiting wheel spin.

2-87
TRACTION OFF - 89: This message will be displayed
after the traction control has been turned off by the
button on the center console.
TRACTION READY
- 90: This message informs
the driver that the traction control system is available.
This occurs when the traction control switch on the
console has been returned to ON (pressing the button
once turns the traction control system off: pressing the
button again turns the system back on). This message
will automatically disappear from the display after
five seconds.
TRACTION SUSPENDED
- 56: This message
displays when the traction control system has been
temporarily shut off because your vehicle's brakes
have overheated. This message does not indicate a
problem with your vehicle's traction control system.
After a few minutes, the traction control system will be
available again and the TRACTION READY message
will appear.TRANS HOT IDLE ENGINE
- 112: This message
indicates that the transaxle fluid in your vehicle is too
hot. Stop and allow your vehicle to idle until it cools
down or until this message is removed.
TRUNK OPEN
- 24: This message indicates that the
trunk is open when the ignition is on.
TURN SIGNAL ON
- 20: This message is a reminder,
after driving about a mile, that you have the turn signal
on. A multiple chime will also sound when this message
is displayed.
VEHICLE OVERSPEED
- 52: This message is
displayed when the vehicle speed exceeds a certain limit
as required by some export countries. A continuous
chime will also sound when this message is displayed.

2-88
Vehicle Programming and
Personalization Features (If Equipped)
If your vehicle is equipped with personalization, you
can program certain features to a preferred setting
for up to two people. If your vehicle does not have
personalization, then some of the features on your
vehicle have been programmed for all drivers. On all
vehicles, certain features such as HVAC settings, radio
preset settings, exterior lighting at unlock, remote lock
and unlock confirmation and automatic door locks have
already been programmed for your convenience. If the
vehicle is equipped with Personalization, then the seat
position, steering column position (if equipped) and
the outside mirror positions can also be programmed.
The navigation screen preferences (if equipped) will
remain at the last set position.
If your vehicle is equipped with personalization, the
driver's preferences are recalled by pressing the unlock
button on the Remote Keyless Entry (RKE) transmitter
or by pressing the appropriate memory button ª1º or ª2º
located on the driver's door. Please note that certain
features can be programmed not to recall until the key is
placed in the ignition. To change feature preferences you
must enter FEATURE PROGRAMMING (see below).
All vehicles that have memory seats, have personalization.
Entering FEATURE PROGRAMMING
To begin programming, the ignition must be in ON
and your vehicle in PARK (P). If your vehicle has
memory, you must press the appropriate memory button
ª1º or ª2º, located on the driver's door panel before
programming. Press the INFO button one or more times
until the FEATURE PROGRAMMING prompt appears
on the DIC display. Press the ON/OFF button to enter
FEATURE PROGRAMMING. To exit, press the INFO
RESET button.
Remote Recall Memory (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the REMOTE
RECALL MEMORY prompt appears. To turn the
feature on, press the ON/OFF button until ON is
displayed on the DIC. The seat and mirror memory
settings that have been previously programmed can be
recalled by pressing the unlock button on the RKE
transmitter. The steering column will move when the
key is inserted in the ignition and turned to ON.
To turn the feature off, press the ON/OFF button
until OFF is displayed.

2-89 Key in Recall (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the KEY IN
RECALL prompt appears on the DIC display. To turn
the feature on, press the ON/OFF button until ON
appears. The seat and mirror memory settings that have
been previously programmed will be recalled when the
key is inserted in the ignition. The steering column
(if equipped) will move when the key is turned to ON.
To turn the feature off, press the ON/OFF button until
OFF appears.
Auto Exit Seat (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the AUTO
EXIT SEAT prompt shows on the DIC display. This
feature will move the seat to the driver's exit position
when the key is turned out of ON (away from START)
and the driver's door is opened. To turn this feature on,
press the ON/OFF button until ON appears on the DIC.
To turn this feature off, press the ON/OFF button until
OFF shows.
Auto Exit Steering Wheel (If Equipped)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the AUTO
EXIT STRG WHEEL prompt appears on the DIC
display. This feature will move the column to the
driver's exit position when the key is turned out of ON
(away from START) and the driver's door is opened.
Lights Flash at Unlock
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the LIGHTS
FLASH AT UNLOCK prompt appears. To turn this
feature on, press the ON/OFF button until ON is
displayed on the DIC. If all the doors are closed, the
parking lamps will flash twice when the unlock button
on the RKE transmitter is pressed. The lamps will not
flash if the manual parking lamps or headlamps are
active. To turn the feature off, press the ON/OFF
button until the OFF prompt appears.
This feature will not work if any door is open.

2-90 Lights Flash at Lock
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the LIGHTS
FLASH AT LOCK prompt appears on the DIC display.
To turn the feature on, press the ON/OFF button until
ON appears. If all the doors are closed, the parking
lamps will flash once when the lock button on the RKE
transmitter is pressed. The lamps will not flash if the
manual parking lamps are active. To turn the feature off,
press the ON/OFF button until OFF appears.
This feature will not work if any door is open.
Horn Sounds at Lock
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the HORN
SOUNDS AT LOCK prompt appears on the DIC
display. To turn the feature on, press the ON/OFF
button until ON appears. If all the doors are closed,
the horn will sound once when the lock button on the
RKE transmitter is pressed. To turn the feature off,
press the ON/OFF button until OFF appears.
This feature will not work if any door is open.
Exterior Lights at Unlock
This personalization feature enables the driver to
program the exterior lamps to turn on or to remain off
when using the RKE transmitter to unlock the vehicle.
During dark or night conditions, if exterior lighting is
selected, the parking lamps, taillamps, reverse lamps,
high
-beam headlamps, etc. will turn on for about
20 seconds or until a door is opened, the key is turned
out of OFF or the RKE transmitter is used to lock
the vehicle.
Enter FEATURE PROGRAMMING by following
the previous instructions and then press the INFO
button one or more times until the FEATURE
PROGRAMMING prompt appears on the DIC
display. Press the ON/OFF button to enter FEATURE
PROGRAMMING. To exit, press the INFO RESET
button. Press the down arrow on the INFO button one
or more times until the EXT LIGHTS AT UNLOCK
prompt appears.
To turn the feature on, press the ON/OFF button until
ON is displayed. To turn the feature off, press the
ON/OFF button until OFF is displayed.

2-91 Doors Lock in Gear
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the DOORS
LOCK IN GEAR prompt appears. This feature will
automatically lock all doors when the vehicle is shifted
out of PARK (P) and all the doors are closed. To turn
the feature on, press ON/OFF until ON is displayed on
the DIC. To turn the feature off, press ON/OFF until
OFF is displayed.
Driver Unlock in PARK (P)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the DRIVER
UNLOCK IN PARK (P) prompt appears. This feature
will automatically unlock only the driver's door when the
vehicle is shifted into PARK (P). To turn the feature on,
press ON/OFF until ON is displayed on the DIC. To turn
the feature off, press ON/OFF until OFF is displayed.
Driver Unlock Key Off
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the DRIVER
UNLOCK KEY OFF prompt appears. This feature will automatically unlock only the driver's
door when the ignition key is turned to OFF. To turn the
feature on, press ON/OFF until ON is displayed on the
DIC. To turn the feature off, press ON/OFF until OFF
is displayed.
Doors Unlock in PARK (P)
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the DOORS
UNLOCK IN PARK prompt appears. This feature
will automatically unlock all doors when the vehicle is
shifted into PARK (P). To turn the feature on, press
ON/OFF until ON is displayed on the DIC. To turn
the feature off, press ON/OFF until OFF is displayed.
Doors Unlock Key Off
Enter FEATURE PROGRAMMING by following the
previous instructions and then press the down arrow on
the INFO button one or more times until the DOORS
UNLOCK KEY OFF prompt appears. This feature will
automatically unlock all doors when the ignition key is
turned to OFF. To turn the feature on, press ON/OFF
until ON is displayed on the DIC. To turn the feature
off, press ON/OFF until OFF is displayed.

2-92 Mirror To Curb In Reverse (If Equipped)
Press the down arrow on the INFO button one or
more times until the MIRROR TO CURB IN REV
prompts appears on the DIC display. This feature will
move the passenger's outside rearview mirror to a curb
view position when the console shifter is placed in
REVERSE (R) and it will return the mirror to the last
known driving position when the console shifter is
moved out of REVERSE (R). To turn this feature on,
press the ON/OFF button until ON is displayed on the
DIC. To turn the feature off, press the ON/OFF button
until OFF is displayed. For more information, see
ªCurb View Assist Mirrorº in the Index.
Driver's Names Set/Recall (If Equipped)
After the FEATURE PROGRAMMING prompt is
displayed on the DIC and the ON/OFF button is pressed,
the prompts DRIVER NO 1 or DRIVER NO 2 will
appear. These prompts correspond to which RKE
transmitter button or memory recall button has been
pressed on the driver's door armrest. You may have
your name and a second driver's name displayed here, replacing the prompts DRIVER NO 1 and DRIVER
NO 2. A dealership can program your vehicle to display
the names you want. The names will appear whenever
the key is turned to ON only if RKE transmitters 1 or 2
are used to enter the vehicle or buttons 1 or 2 on the
driver's door are pressed.
Comfort Controls and Radio System
Personalization
These features allow both drivers to personalize their own
climate control settings as well as their radio settings. For
more information, see ªClimate Control Personalizationº
and ªRadio Personalizationº in the Index.
The outside temperature is always available for display
if it has been selected for a DIC display when your
vehicle is running unless an overriding DIC message
appears. You can change the temperature from
Fahrenheit to Celsius by pressing the ENG/MET
(English/metric) button on the instrument panel. For
more information on the DIC, see ªDIC Messagesº
in the Index.
