2000 CADILLAC SEVILLE Owners Manual

2-45
When the Twilight Sentinel
switch is on and it's dark
enough outside, the high
-beam headlamps (at reduced
intensity) will turn off and normal low
-beam headlamp
operation will occur. When the Twilight Sentinel switch
is on and it's bright enough outside, the regular lamps
will go off, and the high
-beam headlamps at reduced
brightness will take over.
If it's dark outside and the Twilight Sentinel control
is off, a HEADLAMPS SUGGESTED message will
display on the Driver's Information Center (DIC). This
message informs the driver that turning on the exterior
lamps is recommended even though the DRL are still
illuminated. This message indicates that it has become
dark enough outside to require the headlamps and/or
other exterior lamps. Turning on the Twilight Sentinel
or the headlamps will deactivate the DRL and remove
the HEADLAMPS SUGGESTED message. If the
parking lamps or the fog lamps were turned on instead,
the DRL will still deactivate and the HEADLAMPS
SUGGESTED message will continue to be displayed.
To idle your vehicle with the DRL off, turn off the
Twilight Sentinel and shift the transaxle into PARK (P).
Placing your vehicle in PARK (P) disables the DRL.
The DRL will stay off until you shift out of PARK (P).To drive your vehicle with the DRL off, turn off the
Twilight Sentinel and manually turn on the parking
lamps or fog lamps (if equipped).
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Fog Lamps (STS Only)
Use the fog lamps for better vision in foggy or misty
conditions. When you push the fog lamp button located
next to the exterior lamps control, a small indicator light
in the fog lamp button and the LIGHTS ON and fog
lamp indicator lights on the instrument panel cluster will
tell you that the fog lamps and the parking lamps are on.
Pushing the fog lamp button again will turn them off.
If you turn on the high
-beam headlamps, the fog lamps
will turn off. They'll turn back on again when you
change to low
-beam headlamps. You can use the fog
lamp button to turn the fog lamps on or off when the
parking lamps or headlamps are on.
When the Twilight Sentinel

is on and the fog lamps are
turned on, the fog lamps, headlamps and parking lamps
will remain on.

2-46 Cornering Lamps
The cornering lamps come on when the headlamps
or parking lamps are on and you signal a turn.
They provide more light for cornering.
Twilight Sentinel

This control is located
below the exterior
lamps control knob.
It automatically turns
the lamps on and off
by sensing how dark
it is outside.To operate the Twilight Sentinel, leave the exterior
lamps control knob off and move the TWILIGHT lever
to any position but OFF.
If you move the lever all the way to the right, the lamps
will remain on for approximately three minutes after the
ignition has been turned to OFF or ACC. If you move
the lever so it is just on, the lamps will go off quickly
when you turn the ignition out of ON. You can adjust
the delay time from only a few seconds to three minutes.
If it's dark enough outside and Twilight Sentinel is
turned off, a HEADLAMPS SUGGESTED message
will display on the Driver's Information Center (DIC).
This message informs the driver that turning on the
exterior lamps is recommended (it has become dark
enough outside to require the headlamps and/or other
exterior lamps). Turning on the Twilight Sentinel,
the headlamps or the fog lamps will remove the
HEADLAMPS SUGGESTED message.

2-47
Light Sensor
The light sensor for the Daytime Running Lamps (DRL)
and the Twilight Sentinel is located on the driver's side
of the front defogger grille. If you cover the sensor,
it will read ªdarkº and the lamps will come on.
Exterior Lighting Battery Saver
If the manual parking lamps or headlamps have been
left on, the exterior lamps will turn off approximately
ten minutes after the ignition is turned to OFF. This
protects against draining the battery in case you have
accidentally left the headlamps or parking lamps on.
The battery saver does not work if the headlamps are
turned on after the ignition switch is turned to OFF.
If you need to leave the lamps on for more than
10 minutes, use the exterior lamps control knob to
turn the lamps back on. To delay the lamps from
turning off, see ªTwilight Sentinelº in the Index.

2-48
Interior Lamps
Instrument Panel Intensity/Brightness Control
With the parking lamps on, the instrument panel lighting
automatically dims when it becomes dark outside and
brightens when it becomes light outside. When it's dark,
and if the parking lamps are on, the brightness control
can be manually adjusted by using the instrument panel
brightness control.
The button is located to
the right of the Twilight
Sentinel control. Push the
button in to release it to
the outward position.
Turn the button counterclockwise to dim and clockwise
to brighten the lighting. Push the button in to return it to
the original storage position.
Interior Lamps Control
The interior lamps control,
located in the overhead
console, has three positions:
OFF, AUTO and ON.
With the control at AUTO and the front door opened,
the overhead console light, front hush panel lamps and
rear footwell lamps in the door will automatically come
on. When the rear door is opened, all the front door
lighting and rear overhead lamps will come on.
When the control is in ON, the courtesy lamps are
turned on. When the control is in OFF, the lamps are
turned off. (All automatic interior lighting functions are
terminated.) When the interior lamp control is in OFF,
only the driver's door controls and ignition switch
backlighting functions will operate.

2-49 Illuminated Entry
The illuminated entry system turns on the courtesy
lamps and the backlighting to the driver's door switches
and to the ignition key when a door is opened or if you
press the Remote Keyless Entry (RKE) transmitter
unlock button. The illuminated entry system works with
the light sensor and it must be dark outside in order
for the courtesy lamps or backlighting to turn on. The
courtesy lamps turn off approximately 25 seconds after
the last door is closed or after the ignition key is turned
to RUN or if the RKE transmitter lock button is pressed.
The courtesy lamps turn off approximately 40 seconds
after the doors are unlocked with the RKE transmitter
if no door is opened.
Parade Dimming
This feature prohibits the dimming of the instrument
panel lights during daylight while the parking lamps are
on. This feature works with the light sensor and is fully
automatic. When the light sensor reads darkness outside,
the instrument panel lights can be adjusted by following
the steps under ªInstrument Panel Intensity/Brightness
Control.º Backlighting to the instrument panel will
also turn on.
Reading Lamps
The reading lamps are located in the roof. These lamps
and the interior courtesy lamps come on when any door
is opened and it is dark outside. The rear lamps come on
when a rear door is opened. Press the button near the
lamps to turn them on and off.
If the reading lamps are left on, they automatically shut
off 10 minutes after the ignition has been turned off.
Battery Load Management
The battery load management feature is designed to
monitor the vehicle's electrical load and determine when
the battery is in a heavy discharge condition. During
times of high electrical loading, the engine may idle
at a higher revolutions per minute (rpm) setting than
normal to make sure the battery charges. High electrical
loads may occur when several of the following are on:
headlamps, high beams, fog lamps, rear window
defogger, high blower fan, heated seats and engine
cooling fans.

2-50
If the battery continues to discharge, even with the
engine idling at a higher rpm setting, some electrical
loads will automatically be reduced. When this occurs,
the rear window defogger may take slightly longer to
clear the glass, the heated seats may not get as warm
as they usually do and the fan blower may cut back
to a lower speed. For more battery saving information,
see ªBattery Saver Active Messageº in the Index.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's
battery against drainage from the interior lamps,
trunk lamp, glove box lamp, cigarette lighters or the
garage door opener. When the ignition is turned off,
the power to these features will automatically turn
off after 10 minutes. Power will be restored for an
additional 10 minutes if any door is opened, the trunk
is opened or the courtesy lamp switch is turned on.
Mirrors
Electrochromic Day/Night Rearview Mirror
with Compass
Your vehicle has an electrochromic inside rearview
mirror with a compass.
By pressing the MIRROR side of the button located
at the bottom of the mirror, the mirror automatically
changes to reduce glare from headlamps behind you.

2-51
The mirror also includes an eight-point compass
display in the upper right corner of the mirror face.
When on, the compass automatically calibrates as the
vehicle is driven.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause
the liquid cleaner to enter the mirror housing.
Cleaning the Photocells
Use a cotton swab and glass cleaner to clean the
photocells when necessary.
Mirror Operation
The right side of the button, located at the bottom of
the mirror, turns the electrochromic mirror on and off.
To turn on the automatic dimming feature, press
MIRROR. To turn off the automatic dimming, press
MIRROR again. The indicator light will be illuminated
when this feature is active.Time Delay
The automatic mirror has a time delay feature which
prevents unnecessary changing from the night back to
the day position. This delay prevents rapid changing of
the mirror as you drive under lights and through traffic.
Compass Operation
Press the COMPASS side of the button to turn the
compass on or off.
While the ignition is on and the compass feature is
selected, the compass will show two character boxes
for approximately two seconds. After two seconds,
the mirror will display the compass heading.
Compass Calibration
If, after two seconds, the display does not show a
compass heading (ªNº for North, for example),
there may be a strong magnetic field interfering with the
compass. Such interference may be caused by a magnetic
antenna mount, magnetic note pad holder or a similar
magnetic item. If the letter ªCº should ever appear in
the compass window, the mirror needs calibration.

2-52
The mirror can be calibrated in one of two ways:

Drive the vehicle in circles at 5 mph (8 km/h) or less
until the display reads a direction, or

Drive the vehicle on your everyday routine.
Compass Variance
The mirror is set in zone eight upon leaving the factory.
It will be necessary to adjust the compass to compensate
for compass variance if you live outside zone eight.
Under certain circumstances, as during a long distance
cross
-country trip, it will be necessary to adjust for
compass variance. Compass variance is the difference
between earth's magnetic north and true geographic
north. If not adjusted to account for compass variance,
your compass could give false readings.
To adjust for compass variance:
1. Use the COMPASS side of the button located at the
bottom of the mirror. Press and hold COMPASS
until a zone number appears in the display.
2. Find your current location and variance zone number
on the following zone map.
3. Press COMPASS on the bottom of the mirror
until the new zone number appears in the display.
After you stop pressing the button, the display will
show a ªCº and will need recalibration.
