DI±200
± DIAGNOSTICSENGINE (1MZ±FE)
435 Author: Date:
(2) Connect the OBD II scan tool or TOYOTA hand±
held tester to DLC3 at the lower center of the instru-
ment panel.
(3) Turn the ignition switch ON and push the OBD II
scan tool or TOYOTA hand±held tester switch ON.
(4) Use the OBD II scan tool or TOYOTA hand±held
tester to check the DTC and freezed frame data and
note them down (For operating instructions, see the
OBD II scan tool's instruction book.).
(5) See page DI±197 to confirm the details of the DTC.
NOTICE:

When simulating symptoms with an OBD II scan tool
(excluding TOYOTA hand±held tester) to check the
DTC, use normal mode. For code on the DTC chart
subject to º2 trip detection logicº, performe the fol-
lowing either action.

Turn the ignition switch OFF after the symptom is
simulated the first time. Then repeat the simulation
process again. When the problem has been simulated
twice, the MIL lights up and the DTCs are recorded in
the ECM.

Check the 1st trip DTC using Mode 7 (Continuous Test
Results) for SAE J1979.
(c) Clear the DTC.
The DTCs and freezed frame data will be erased by either
action.

Operating the OBD II scan tool (complying
with SAE J1978) or TOYOTA hand±held tes-
ter to erase the codes. (See the OBD II scan
tool's instruction book for operating instruc-
tions.)

Disconnecting the battery terminals or EFI
fuse.
NOTICE:
If the TOYOTA hand±held tester switches the ECM from
normal mode to check mode or vice±versa, or if the ignition
switch is turned from ON to ACC or OFF during check
mode, the DTCs and freezed frame data will be erased.
3. INSPECT DIAGNOSIS (Check Mode)
HINT:
TOYOTA hand±held tester only:
Compared to the normal mode, the check mode has an in-
creased sensitivity to detect malfunctions.
Furthermore, the same diagnostic items which are detected in
the normal mode can also be detected in the check mode.

A00209
DLC1
TE1
E1
SST
DLC1
P12915
P12952
DI±204
± DIAGNOSTICSENGINE (1MZ±FE)
439 Author: Date:
5 Check idle speed.
PREPARATION:
(a) Warm up the engine to normal operating temperature.
(b) Switch off all accessories.
(c) Switch off air conditioning.
(d) Shift transmission into ºNº position.
(e) Connect the OBD II scan tool or TOYOTA hand±held tester to DLC3 on the vehicle.
CHECK:
Use CURRENT DATA to check the idle speed.
OK:
Idle speed: 650 ~ 750 rpm
NG Proceed to problem symptoms table on
page DI±221.
OK
6 Check ignition timing.
PREPARATION:
(a) Warm up the engine to normal operating temperature.
(b) Switch off all accessories.
(c) Switch off air conditioning.
(d) Shift transmission into ºNº position.
(e) Keep the engine speed at idle.
(f) Using SST, connect terminals TE1 and E1 of the DLC1.
SST 09843±18020
(g) Using a timing light, connect the tester to check wire.
CHECK:
Check ignition timing.
OK:
Ignition timing: 10° BTDC at idle
NG Proceed to page IG±1 and continue to
troubleshoot.
OK
Proceed to problem symptoms table on page
DI±221.

DI07B±07
± DIAGNOSTICSENGINE (1MZ±FE)
DI±211
446 Author: Date:
DIAGNOSTIC TROUBLE CODE CHART
1. SAE CONTROLLED
HINT:
Parameters listed in the chart may not be exactly the same as your reading due to the type of instrument
or other factors.
If a malfunction code is displayed during the DTC check in check mode, check the circuit for that code listed
in the table below. For details of each code, turn to the page referred to under the ''See page '' for the respec-
tive ''DTC No.'' in the DTC chart.
DTC No.
(See Page)Detection ItemTrouble AreaMIL*1Memory
P0100
(DI±222)Mass Air Flow Circuit
MalfunctionOpen or short in mass air flow meter circuit
Mass air flow meter
ECM

P0101
(DI±227)Mass Air Flow Circuit
Range/Performance
Problem
Mass air flow meter
P0110
(DI±228)Intake Air Temp. Circuit
MalfunctionOpen or short in intake air temp. sensor circuit
Intake air temp. sensor (built into mass air flow meter)
ECM

P0115
(DI±233)Engine Coolant Temp. Circuit
MalfunctionOpen or short in engine coolant temp. sensor circuit
Engine coolant temp. sensor
ECM

P0116
(DI±237)Engine Coolant Temp. Circuit
Range/Performance ProblemEngine coolant temp. sensor
Cooling system
P0120
(DI±239)Throttle/Pedal Position
Sensor/Switch ºAº Circuit
MalfunctionOpen or short in throttle position sensor circuit
Throttle position sensor
ECM

P0121
(DI±243)Throttle/Pedal Position
Sensor/Switch ºAº Circuit
Range/Performance Problem
Throttle position sensor
*2
P0125
(DI±244)
Insufficient Coolant Temp. for
Closed Loop Fuel Control
(Except California Spec.)
Fuel system
Injector
Ignition system
Gas leakage on exhaust system
Open or short in heated oxygen sensor circuit
(bank 1, 2 sensor 1)
Heated oxygen sensor (bank 1, 2 sensor 1)
ECM

*3
P0125
(DI±249)
Insufficient Coolant Temp. for
Closed Loop Fuel Control
(Only for California Spec.)
Fuel system
Injector
Ignition system
Gas leakage on exhaust system
Open or short in A/F sensor circuit (bank 1, 2 sensor 1)
A/F sensor (bank 1, 2 sensor 1)
ECM

*2
P0130
(DI±255)Heated Oxygen Sensor Circuit
Malfunction (Bank 1 Sensor 1)Heated oxygen sensor
Fuel trim malfunction
*1:


MIL lights up
*
2: Except California specification vehicles
*
3: Only for California specification vehicle

DI±214
± DIAGNOSTICSENGINE (1MZ±FE)
449 Author: Date:
DTC No.
(See Page)Detection ItemTrouble AreaMIL*Memory
P0440
(DI±311)Evaporative Emission Control
System Malfunction
Vapor pressure sensor
Fuel tank cap incorrectly installed
Fuel tank cap cracked or damaged
Vacuum hose cracked, holed, blocked, damaged or
disconnected ((1) or (2) in fig. 1)
Hose or tube cracked, holed, damaged or loose seal
((3) in fig. 1)
Fuel tank cracked, holed or damaged
Charcoal canister cracked, holed or damaged
Fuel tank over fill check valve cracked or damaged
*1
P0441
(DI±318)Evaporative Emission Control
System Incorrect Purge Flow
Open or short in VSV circuit for EVAP
Open or short in VSV circuit for vapor pressure sensor
Open or short in vapor pressure sensor circuit
VSV for EVAP
VSV for vapor pressure sensor
Vapor pressure sensor
Vacuum hose cracks, holed blocked, damaged or
disconnected ((1), (4), (5), (6) and (7) in fig.1)
Charcoal canister cracks, holed or damaged
Fuel tank over fill check valve cracked or damaged

P0446
(DI±318)Evaporative Emission Control
System Vent Control
Malfunction
Open or short in VSV circuit for EVAP
Open or short in VSV circuit for vapor pressure sensor
Open or short in vapor pressure sensor circuit
VSV for EVAP
VSV for vapor pressure sensor
Vapor pressure sensor
Vacuum hose cracks, holed blocked, damaged or
disconnected ((1), (4), (5), (6) and (7) in fig.1)
Charcoal canister cracks, holed or damaged
Fuel tank over fill check valve cracked or damaged

P0450
(DI±331)Evaporative Emission Control
System Pressure Sensor
MalfunctionOpen or short in vapor pressure sensor circuit
Vapor pressure sensor
ECM

P0451
(DI±331)Evaporative Emission Control
System Pressure Sensor
Range/PerformanceOpen or short in vapor pressure sensor circuit
Vapor pressure sensor
ECM

P0500
(DI±333)Vehicle Speed Sensor
Malfunction
Open or short in speed sensor circuit
Vehicle speed sensor
Combination meter
ECM

P0505
(DI±336)Idle Control System
Malfunction
IAC valve is stuck or closed
Open or short in IAC valve circuit
Open or short in A/C signal circuit
Air intake (hose loose)

*:


MIL lights up

P18349
DI±256
± DIAGNOSTICSENGINE (1MZ±FE)
491 Author: Date:
HINT:
If a malfunction exists, the MIL will light up during step (6).
NOTICE:
If the conditions in this test are not strictly followed, detection of the malfunction will not be possible.
If you do not have a TOYOTA hand±held tester, turn the ignition switch OFF after performing steps
(3) to (6), then perform steps (3) to (6) again.
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand±held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected, when troubleshooting it is useful for determining
whether the vehicle was running or stopped, the engine warmed up or not, the air±fuel ratio lean or rich, etc.
at the time of the malfunction.
1 Are there any other codes (besides DTC P0130, P0150) being output ?
YES Go to relevant DTC chart.
NO
2 Check the output voltage of heated oxygen sensors (bank1, 2 sensor1)
during idling.
PREPARATION:
Warm up the heated oxygen sensors (bank1, 2 sensor1) with the engine at 2,500 rpm for approx. 90 sec.
CHECK:
Use the OBD II scan tool or TOYOTA hand±held tester to read the output voltage of the heated oxygen sen-
sors (bank1, 2 sensor1) during idling.
OK:
Heated oxygen sensors (bank1, 2 sensor1) output voltage:
Alternates repeatedly between less than 0.4 V and more than 0.55 V (See the following table).
OK Go to step 8.
NG

DI±294
± DIAGNOSTICSENGINE (1MZ±FE)
529 Author: Date:
(1) Connect the OBD II scan tool or TOYOTA hand±held tester to the DLC3.
(2) Start and warm up the engine with all accessories switched OFF.
(3) Run the vehicle at 70 ~ 90 km/h (43 ~ 56 mph) for 3 min. or more.
(4) Idle the engine for about 2 min.
(5) Do steps (3) and (4) again.
(6) Stop at safe place and turn the ignition switch OFF.
(7) Do step (2) to (5) again.
(8) Check the READINESS TESTS mode on the OBD II scan tool or TOYOTA hand±held tester.
If COMPL is displayed and the MIL does not light up, the system is normal.
If INCMPL is displayed and the MIL does not light up, run the vehicle steps (2) to (6) from some times and
check it.
HINT:
INCMPL is displayed when either condition (a) or (b) exists.
(a) The system check is incomplete.
(b) There is a malfunction in the system.
If there is a malfunction in the system, the MIL light up after step (7) above is done.
(2trip detection logic)
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand±held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected, when troubleshooting it is useful for determining
whether the vehicle was running or stopped, the engine warmed up or not, the air±fuel ratio lean or rich, etc.
at the time of the malfunction.
TOYOTA hand±held tester
1 Connect TOYOTA hand±held tester, and read value of EGR gas temperature.
PREPARATION:
(a) Connect the TOYOTA hand±held tester to the DLC3.
(b) Warm up the engine.
CHECK:
Read EGR gas temperature on TOYOTA hand±held tester during idling.
OK:
EGR gas temperature : 55C (415F) ~ 1505C (3025F) (Not immediately after driving)
HINT:
If there is an open circuit, TOYOTA hand±held tester indicates 3.15C (37.65F).
If there is an short circuit, TOYOTA hand±held tester indicates 159.35C (318.75F).
OK Go to step 4.
NG

FI6514
OX Signal Waveform (Oscilloscope)
1 V
0 V
200 m sec./Division
DI±306
± DIAGNOSTICSENGINE (1MZ±FE)
541 Author: Date:
(a) Connect the TOYOTA hand±held tester to the DLC3, or connect the probe of the oscilloscope between
terminals OXR1, OXL1, OXS and E1 of the ECM connector.
(b) Start engine and warm it up with all accessories switched OFF until water temp. is stable.
(c) Race the engine at 2,500 ~ 3,000 rpm for about 3 min.
(d) After confirming that the waveform of the heated oxygen sensor, bank 1, 2 sensor 1 (OXR1, OXL1),
oscillate around 0.5 V during feedback to the ECM, check the waveform of the heated oxygen sensor,
bank 1 sensor 2 (OXS).
HINT:
If there is a malfunction in the system, the waveform of the
heated oxygen sensor, bank 1 sensor 2 (OXS), is almost the
same as that of the heated oxygen sensor, bank 1, 2 sensor 1
(OXR1, OXL1), on the left.
There are some cases where, even though a malfunction
exists, the MIL may either light up or not light up.
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand±held theater or OBD II scan tool. Because freeze frame re-
cords the engine conditions when the malfunction is detected, when troubleshooting it is useful for determin-
ing whether the vehicle was running or stopped, the engine warmed up or not, the air±fuel ratio lean or rich,
etc. at the time of the malfunction.
1 Are there any other codes (besides DTC P0420) being output?
YES Go to relevant DTC chart.
NO
2 Check gas leakage on exhaust system.
NG Repair or replace.
OK

A00364
Vehicle Speed
60 ~ 120 km/h
(38 ~ 75 mph)
Idling
IG SW OFF
3 ~ 5 min.
Time
(1) (2)(3)(4)
± DIAGNOSTICSENGINE (1MZ±FE)
DI±341
576 Author: Date:
CONFIRMATION DRIVING PATTERN
(a) Connect the TOYOTA hand±held tester to the DLC3.
(b) Switch the TOYOTA hand±held tester from normal mode to check mode (See page DI±197).
(c) Start the engine and warm it up with all accessory switches OFF.
(d) Drive the vehicle at 60 ~ 120 km/h (38 ~ 75 mph) and engine speed at 1,600 ~ 3,200 rpm for 3 ~ 5 min.
HINT:
If a malfunction exists, the MIL will light up during step (4).
NOTICE:
If the conditions in this test are not strictly followed, detection of the malfunction will not be possible.
If you do not have a TOYOTA hand±held tester, turn the ignition switch OFF after performing steps
(3) and (4), then perform steps (3) and (4) again.
INSPECTION PROCEDURE
HINT:

If DTC P1130 is displayed, check Bank 1 Sensor 1 circuit.

If DTC P1150 is displayed, check Bank 2 Sensor 1 circuit.

Read frame freeze data using TOYOTA hand±held tester or OBD II scan tool. Because freeze frame
records the engine conditions when the malfunction is detected, when troubleshooting it is useful for
determining whether the vehicle was running or stopped, the engine warmed up or not, the air±fuel
ratio lean or rich, etc. at the time of the malfunction.
1 Are there any other codes (besides DTC P1130, P1150) being output?
YES Go to relevant DTC chart.
NO
