1999 PONTIAC BONNEVILLE Owners Manual

yellowblue
2-53 Convenience Net (Option)
Your vehicle may have a convenience net. You'll see it
just inside the back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over during sharp turns or
quick starts and stops. For heavier loads, store them in
the trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
Ashtrays and Cigarette Lighter
Lift the cover to reveal the front ashtray.
To clean the ashtray, lift it out by pulling on the snuffer.
On models without a console, there's an
ashtray/cupholder under the instrument panel. To clean
the ashtray, lift it out by pulling up on the tabs on either
side. It snaps back into place.
To open the rear ashtrays, lift the cover.
NOTICE:
Don't put papers and other things that burn into
your ashtrays. If you do, cigarettes or other
smoking materials could set them on fire,
causing damage.

yellowblue
2-54
To use a lighter, just push the center in all the way and
let it go. When it is ready, the center will pop back by
itself. Pull out the entire unit to use it.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
Sun Visors
To block out glare, you can swing down the visors. You
can also remove them from the center mount and swing
them to the side, while the auxiliary sunshade remains to
block glare from the front.
Visor Vanity Mirror
Open the cover to expose the vanity mirror.
If your vehicle has the optional lighted vanity mirrors,
the lamps come on when you open the cover. You can
adjust the brightness of the lamps by moving the switch
up or down.

yellowblue
2-55
Air Inflator System (Option)
Some vehicles have an air inflator for use in maintaining
proper air pressure for the tires. The air inflator is
located in the trunk. The ON switch will work only with
the ignition on.
CAUTION:
Inflating something too much can make it
explode, and you or others could be injured. Be
sure to read the inflator instructions, and inflate
any object only to its recommended pressure.
The air inflator comes with a kit that includes a 20-foot
(6.1 m) hose and an air pressure gage, as well as
instructions and special adapters for inflating things like
an air mattress or a basketball.

yellowblue
2-56
Accessory Power Outlet
On models with the overhead console, there is a 12-volt
ignition
-fed outlet. Slide the cover aside to access the outlet.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything
requiring more than 15 amps.
OnStar System (Option)
Your vehicle may be equipped with the OnStar
communications service. The following services are
available 24 hours a day from an OnStar
representative:

Roadside Service with Location

Emergency Services Button

Remote Door Unlock

Theft Detection/Notification and Stolen
-Vehicle
Tracking

Automatic Notification of Air Bag Deployment

Concierge/Customer Conveniences Services
NOTE: Installation of aftermarket equipment is
possible, however, the features described above will not
be compatible with any portable phone other than the
OnStar cellular phone available from your dealer.
For more information about the OnStar System, contact
your dealer.

yellowblue
2-57
Sunroof (Option)
Your vehicle may be
equipped with an
express
-open sunroof. Press
the control switch rearward
and release it to open the
glass panel and sunshade.If you want to stop the sunroof in a partially open
position, lightly press the switch again. To completely
open the sunroof, press the switch rearward again. The
sunshade can also be opened by hand.
To close the sunroof, press and hold the control switch
forward to close the glass panel. Then, close the
sunshade by hand.
When the sunroof is in the closed position, press the
control switch forward to the vent position. Open the
sunshade by hand.
Press the switch rearward to close the rear vent.
The control switch will work only when the ignition is
on or during retained accessory power, if you have that
option. See ªRetained Accessory Powerº in the Index.

yellowblue
2-58
The Instrument Panel - Your Information System

yellowblue
2-59
A. Twilight Sentinel/Headlamp Switch
B. Turn Signal/Multifunction Lever
C. Tilt Steering Wheel Lever
D. Instrument Cluster/Gages
E. Audio System Steering Wheel Controls
F. Ignition SwitchG. Air Outlet
H. Climate Control System
I. Glove Box
J. Audio System
K. Hazard Warning Flashers Switch
L. Hood Release

yellowblue
2-60
Instrument Panel Clusters
Your instrument panel clusters are designed to let you know at a glance how your vehicle is running. You'll know how
fast you're going, how much fuel you're using, and many other things you'll need to drive safely and economically.
Your vehicle is equipped with one of these instrument panel clusters, which includes indicator warning lights and
gages that are explained on the following pages.
Cluster with Gages
