1999 PONTIAC BONNEVILLE Owners Manual

yellowblue
2-13 Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about two years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
NOTICE:
When replacing the battery, use care not to
touch any of the circuitry. Static from your
body transferred to these surfaces may damage
the transmitter.
For battery replacement, use one Duracell
battery, type
DL
-2032, or a similar type.
To replace the battery:
1. Insert a coin into the notch near the key ring. Turn
the coin counterclockwise to separate the two halves
of the transmitter.
2. Once the transmitter is separated, use a pencil eraser
to remove the old battery. Do not use a metal object.
3. Remove and replace the battery. Replace it as the
instructions inside the cover indicate.

yellowblue
2-14
4. Snap the transmitter back together tightly to be sure
no moisture can enter.
5. Test the operation of the transmitter with your
vehicle. If the transmitter does not work,
resynchronize the transmitter.
Resynchronization
After you have changed the battery in your transmitter,
or if only the instant alarm button works, the transmitter
needs to be resynchronized to the receiver. Do this by
pressing and holding both the LOCK and UNLOCK
buttons at the same time for about eight seconds. You
must be within range of the vehicle.
When the system has been resynchronized, the horn will
chirp and the exterior lamps will flash once. The system
should now operate properly.
Trunk
Trunk Lock Release
To unlock the trunk from the outside, insert the door key
and turn it.
Remote Trunk Release (Option)
If you have this option,
press the trunk release
button located below the
driver's door armrest to
release the trunk lid.
The ignition may be on or off and the transaxle must be
in PARK (P). The system also works with the remote
keyless entry system.

yellowblue
2-15 Remote Trunk Release Lockout (Option)
The trunk release lockout
switch in the trunk allows
you to secure items in
the trunk.
By pressing the left side of the valet switch, the remote
trunk release button below the driver's door armrest will
be disabled. Push the right side of the valet switch to
enable the remote trunk release button to work again.
Trunk Security Override (Option)
Pressing the trunk symbol on the remote keyless entry
transmitter opens the trunk even if the remote trunk
release lockout switch is activated.
Trunk Lid
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:
1. Make sure all other windows are shut.
2. Turn the fan on your heating or cooling
system to its highest speed with the
setting on ECON or VENT. That will
force outside air into your vehicle. See
ªComfort Controlsº in the Index.
3. If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.

yellowblue
2-16
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make
it impossible to steal. However, there are ways you
can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
With the ignition off and the driver's door open, you'll
hear a tone reminding you to remove your key from the
ignition and take it with you. Always do this. Your
steering wheel will be locked, and so will your ignition
and transaxle. And remember to lock the doors.
Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
If you park in a lot where someone will be watching
your vehicle, it's best to lock it up and take your keys.
But what if you have to leave your ignition key?
1. If possible, park in a busy, well lit area.
2. Put your valuables in a storage area, like your
trunk or glove box. Be sure to close and lock the
storage area.
3. Close all windows.
4. Move the trunk release lockout switch to the
ON position.
5. Lock the glove box.
6. Lock all the doors except the driver's.
7. Then take the door key and remote keyless entry
transmitter with you.

yellowblue
2-17
Universal Theft-Deterrent (Option)
If your vehicle has this option, it has a theft-deterrent
alarm system. With this system, the SECURITY light
will flash as you open the door (if your ignition is OFF).
This light reminds you to
activate the theft
-deterrent
system when leaving
your vehicle.
Activating the system:
1. Open the door.
2. Lock the door with the power door lock switch while
the door is open, or use the remote keyless entry
transmitter. The SECURITY light should come on
and stay on.
3. Close all doors. The SECURITY light should go off after
about 30 seconds and the system will then be armed.
If the SECURITY light comes on for one minute and
then shuts off while the ignition is on, the security
system has detected a problem with itself. See your
dealer for service.If a door or the trunk is opened without the key or
remote keyless entry transmitter, or if the door key
cylinders are damaged, the alarm will go off. It will also
go off if the trunk lock is damaged. Your vehicle's lamps
will flash and the horn will sound for one minute, then
will go off in order to save battery power.
Remember, the theft-deterrent system won't activate if
you lock the doors with a key or manual door lock. It
activates only if you use a power door lock switch while
the door is open, or the remote keyless entry transmitter.
Avoid setting off the alarm by accident.
Always unlock a door with a key, or use the remote
keyless entry system transmitter. Unlocking a door any
other way will set off the alarm.
If you set off the alarm by accident, unlock any door
with your key. You can also turn off the alarm by
pressing UNLOCK on the remote keyless entry
transmitter. The alarm won't stop if you try to unlock a
door any other way.
Testing the Alarm
1. From inside the vehicle, roll down the window.
2. Activate the system by locking the doors with the
power door lock switch while the door is open, or
with the remote keyless entry transmitter.

yellowblue
2-18
3. Get out of the car, close the door and wait for the
SECURITY light to go out.
4. Then, reach in through the window, unlock the door
with the manual door lock and open the door. This
should set off the alarm.
If the alarm does not sound when it should, check to
see if the horn works. The horn fuse may be blown. To
replace the fuse, see ªFuses and Circuit Breakersº in
the Index.
If the alarm does not sound, or the vehicle's lamps do
not flash, the vehicle should be serviced by an
authorized service center.
PASS-Key
II
Your vehicle is equipped with the PASS-Key II
(Personalized Automotive Security System)
theft
-deterrent system. PASS-Key II is a passive
theft
-deterrent system. It works when you insert or
remove the key from the ignition.
PASS
-Key II uses a resistor pellet in the ignition key
that matches a decoder in your vehicle.When the PASS
-Key II system senses that someone is
using the wrong key, it shuts down the vehicle's starter
and fuel systems. For about three minutes, the starter
won't work and fuel won't go to the engine. If someone
tries to start your vehicle again or uses another key
during this time, the vehicle will not start. This
discourages someone from randomly trying different
keys with different resistor pellets in an attempt to make
a match.
The ignition key must be clean and dry before it's
inserted in the ignition or the engine may not start. If the
engine does not start and the SECURITY light is on, the
key may be dirty or wet. Turn the ignition off.
Clean and dry the key. Wait about three minutes and try
again. If the starter still won't work, and the key appears
to be clean and dry, wait about three minutes and try
another ignition key. At this time, you may also want to
check the fuse (see ªFuses and Circuit Breakersº in the
Index). If the starter won't work with the other key, your
vehicle needs service. If your vehicle does start, the first
ignition key may be faulty. See your dealer or a
locksmith who can service the PASS
-Key II.

yellowblue
2-19
If you accidentally use a key that has a damaged or
missing resistor pellet, the starter won't work. The
SECURITY light will flash. But you don't have to wait
three minutes before trying another ignition key.
See your dealer or a locksmith who can service the
PASS
-Key II to have a new key made.
If you're ever driving and the SECURITY light comes
on and remains on, you will be able to restart your
engine if you turn it off. Your PASS
-Key II system,
however, is not working properly and must be serviced
by your dealer. Your vehicle is not protected by the
PASS
-Key II system.
If you lose or damage a PASS
-Key II ignition key, see
your dealer or a locksmith who can service PASS
-Key II
to have a new key made. In an emergency, call the Pontiac
Roadside Assistance Center at 1
-800-ROADSIDE or
1
-800-762-3743. In Canada, call 1-800-268-6800.
New Vehicle ªBreak-Inº
Your vehicle doesn't need an elaborate ªbreak-in.º
But it will perform better in the long run if you follow
these guidelines:
Don't drive at any one speed
-- fast or slow -- for the
first 500 miles (805 km). Don't make full
-throttle starts.
Avoid making hard stops for the first 200 miles (322 km) or
so. During this time your new brake linings aren't yet broken
in. Hard stops with new linings can mean premature wear
and earlier replacement. Follow this breaking
-in guideline
every time you get new brake linings.
Don't tow a trailer during break
-in. See ªTowing a
Trailerº in the Index for more information.

yellowblue
2-20
Ignition Positions
Leaving children in a vehicle with the ignition key is
dangerous for many reasons. A child or others could be
injured or even killed. They could operate power
windows or other controls or even make the vehicle
move. Don't leave the keys in the vehicle with children.
With the ignition key in the ignition switch, you can turn
the switch to five positions.NOTICE:
If your key seems stuck in LOCK and you can't
turn it, be sure you are using the correct key; if
so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. But turn the key only with your hand.
Using a tool to force it could break the key or the
ignition switch. If none of this works, then your
vehicle needs service.
Key Reminder Warning
If you leave your key in the ignition, in the OFF
position, you will hear a warning tone when you open
the driver's door.
