WORKSHOP MANUAL
SUPPLEMENT
FOREWORD
This Workshop Manual contains procedures for
service mechanics, including removal, disassembly,
inspection, adjustment, reassembly and
installation. Use the following manuals in
combination with this manual as required.
TECHNICAL INFORMATION MANUAL
N9806CNCP9
N9806CNCP9-A
WORKSHOP MANUAL
S9806CNCP9
All information, illustrations and product
descriptions contained in this manual are current
as at the time of publication. We, however, reserve
the right to make changes at any time without prior
notice or obligation.
The EVOLUTION -VI is sold exclusively through
RALLIART Inc. Since the EVOLUTION-VI is a rally-
based model, it will not be warranted and will not be
homologated for general production. Therefore, any
service matters on the EVOLUTION-VI should be
inquired to RALLIART Inc. as usual.
EVOLUTION-VI

Mitsubishi Motors Corporation March 1999
Interior and Supplemental
Restraint System (SRS) . . . . . . . . .
.
Heater, Air Conditioner and
Ventilation . . . . . . . . . . . . . . . . . . . . .
.

GENERAL – Precautions Before Service00-15
PRECAUTIONS BEFORE SERVICE
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
1. Items to follow when servicing SRS
(1) Be sure to read GROUP 52B – Supplemental Restraint System (SRS).
For safe operations, please follow the directions and heed all warnings.
(2) Always use the designated special tools and test equipment.
(3) Wait at least 60 seconds after disconnecting the battery cable before doing any further work.
The SRS system is designed to retain enough voltage to deploy the air bag even after the battery
has been disconnected. Serious injury may result from unintended air bag deployment if work
is done on the SRS system immediately after the battery cable is disconnected.
(4) Never attempt to disassemble or repair the SRS components. (SRS air bag control unit, air bag
module and clock spring.) If faulty, replace it.
(5) Warnings labels must be needed when servicing and handling SRS components. Warning labels
are located in the following locations.
Sun visor
Glove box
SRS air bag control unit
Steering wheel
Steering gear and linkage
Air bag module
Clock spring
(6) Store components removed from the SRS in a clean and dry place.
The air bag module should be stored on a flat surface and placed so that the pad surface is
facing upwards.
(7) Be sure to deploy the air bag before disposing of air bag module or disposing of a vehicle equipped
with an air bag. (Refer to GROUP 52B – Air Bag Module Disposal Procedures.)
(8) Whenever you finish servicing the SRS, check the SRS warning lamp operation to make sure
that the system functions properly.
2. Observe the following when carrying out operations on place where SRS components are installed,
including operations not directly related to the SRS air bag.
(1) When removing or installing parts do not allow any impact or shock to the SRS components.
(2) SRS components should not be subjected to heat over 93C, so remove the SRS components
before drying or baking the vehicle after painting.
After re-installing them, check the SRS warning lamp operation to make sure that the system
functions properly.

ENGINE – Specifications11-5
ItemsLimit Standard value
Alternator
Rotor coil resistance ΩApprox. 3 – 5–
Protrusion length of brush mm–2
Starter motor
Commutator runout mm0.050.1
Commutator outer diameter mm32.031.4
Commutator undercut mm0.5–
TORQUE SPECIFICATIONS
ItemsNm
Alternator and ignition system
Oil level gauge guide13
Water pump pulley9
Alternator brace (Alternator side)21
Alternator brace (Tightened with water pump)23
Alternator pivot bolt44
Crankshaft pulley25
Center cover3
Spark plug25
Ignition coil10
Timing belt
Timing belt cover (Flange bolt)11
Timing belt cover (Washer bolt)9
Power steering pump bracket49
Tensioner pulley49
Tensioner arm24
Auto tensioner24
Idler pulley48
Crank angle sensor9
Oil pump sprocket54
Camshaft bolt11 8
Tensioner “B”19
Counterbalance shaft sprocket45

ENGINE – Timing Belt11-15
TIMING BELT
REMOVAL AND INSTALLATION
1
2
3
4
5 67
8
9
1011
12 1314
1516
17 1819
20212223
24
2526
27
28 2930
31
32
9 Nm
9 Nm 49 Nm 11 N m
11 N m
19 Nm 3.5 Nm
30 Nm
45 Nm 49 Nm 11 8 N m
88 Nm
48 Nm 49 Nm 11 N m
24 Nm
24 Nm
54 Nm
Removal steps
1. Timing belt front upper cover
2. Timing belt front center cover
3. Rubber plug
4. Timing belt front lower cover
5. Power steering pump bracket
AL6. Timing belt
K7. Tensioner pulley
8. Tensioner arm
J9. Auto tensioner
10. Idler pulley
11. Crank angle sensor
BI12. Oil pump sprocket
CH13. Crankshaft sprocket bolt
D14. Crankshaft sprocket
15. Crankshaft sensing blade
16. Tensioner BEG17. Timing belt B
FF18. Counterbalance shaft sprocket
E19. Crankshaft spacer
G20. Crankshaft sprocket B
21. Crankshaft key
22. Oil filler cap
D23. Rocker cover
24. Rocker cover gasket A
25. Rocker cover gasket B
C26. Semi-circular packing
B27. Engine support bracket
HA28. Camshaft sprocket bolt
29. Camshaft sprocket
30. Timing belt rear right cover
31. Timing belt rear left upper cover
32. Timing belt rear left lower cover

MPI – General13-3
MPI System Diagram
1 Injector
2 ISC servo
3 Fuel pressure control valve
4 Waste gate solenoid valve
5 Secondary air control solenoid valve

Control relay

Fuel pump relay

A/C relay

Ignition coil

Exhaust temperature warning lamp

Engine warning lamp

Diagnosis output

Alternator G terminal

Fan motor relay

Tachometer

Fuel pump relay No.2 1 Oxygen sensor
2 Air flow sensor
3 Intake air temperature sensor
4 Throttle position sensor
5 Idle switch
6 Camshaft position sensor
7 Crank angle sensor
8 Barometric pressure sensor
9 High temperature sensor
10 Engine coolant temperature sensor
11 Detonation sensor

Power supply voltage

Ignition switch-IG

Ignition switch-ST

Vehicle speed sensor

A/C switch

Power steering fluid pressure switch

Alternator FR signalEngine ECU
1 Oxygen sensor
2 Air flow sensor3
Intake air tem-
perature sensor
4,
5
6 Camshaft position
sensor
7 Crank angle sensor 8 Barometric
pressure sensor
9 High temperature
sensor 10 Coolant temperature sensor
11 Detonation sensor1 Injector 2 ISC servo
3 Fuel pressure
control valve
4 Waste gate
solenoid valve 5 Secondary air
control solenoid
valveCanister
Check valveFrom
fuel
tank
Throttle position
sensor (with a
built-in
idle
switch)
Secondary
air valve
AirTo fuel
tankFuel
pressure
regulatorFrom
fuel
pump
Waste gate
actuator
Catalytic converter

MPI – Troubleshooting
Vehicle
speedInitial accel-
erator pedal
depression
NormalHesitation
Sag
Time
(Figure 1)(Figure 2)
Normal
Initial accel-
erator pedal
depression
IdlingStumble
TimeVehicle
speed
13-19
PROBLEM SYMPTOMS TABLE (FOR YOUR INFORMATION)
ItemsSymptom
StartingWon’t startThe starter is used to crank the engine, but there is no combustion within the
cylinders, and the engine won’t start.
Fires up and diesThere is combustion within the cylinders, but then the engine soon stalls.
Hard startingEngine starts after cranking a while.
Idling
stability
HuntingEngine speed doesn’t remain constant; changes at idle.
stability
Rough idleUsually, a judgement can be based upon the movement of the tachometer
pointer, and the vibration transmitted to the steering wheel, shift lever, body, etc.
This is called rough idle.
Incorrect idle speedThe engine doesn’t idle at the usual correct speed.
Engine stall
(Die out)The engine stalls when the foot is taken from the accelerator pedal, regardless
of whether the vehicles is moving or not.
Engine stall
(Pass out)The engine stalls when the accelerator pedal is depressed or while it is being
used.
DrivingHesitation, Sag“Hesitation” is the delay in response of the vehicle speed (engine speed) that
occurs when the accelerator is depressed in order to accelerate from the speed
at which the vehicle is now traveling, or a temporary drop in vehicle speed
(engine speed) during such acceleration. Serious hesitation is called “sag”.
(Refer to Figure 1.)
Poor accelerationPoor acceleration is inability to obtain an acceleration corresponding to the
degree of throttle opening, even though acceleration is smooth, or the inability
to reach maximum speed.
StumbleEngine speed increase is delayed when the accelerator pedal is initially
depressed for acceleration. (Refer to Figure 2.)
ShockThe feeling of a comparatively large impact or vibration when the engine is
accelerated or decelerated.
SurgeThis is repeated surging ahead during constant speed travel or during variable
speed travel.
KnockingA sharp sound like a hammer striking the cylinder walls during driving and which
adversely affects driving.
StoppingRun on
(“Dieseling”)The condition in which the engine continues to run after the ignition switch is
turned to OFF. Also called “Dieseling”.

MPI – Troubleshooting13-39
INSPECTION PROCEDURE 28
Power steering fluid pressure switch system
Probable cause
The presence or absence of power steering load is input to the engine-ECU.
The engine-ECU controls the idle speed control (ISC) servo based on this input.
Malfunction of power steering fluid pressure switch

Improper connector contact, open or short-circuited
harness wire

Malfunction of the engine-ECU
Check the power steering fluid pressure switch.NG
Replace
OK
Measure at the power steering fluid pressure switch connector
A-101.

Disconnect the connector, and measure at the harness side.

Voltage between 1 and earth (Ignition switch: ON)
OK:System voltageNGCheck the following
connectors: A-28, B-60NG
Repair
OK
Check trouble symptom.
NG
Check harness wire be-
tween engine-ECU and
power steering fluid pres-
sure switch connector.NG
Repair
OK
Replace the engine-ECU.
OK
Check the following
connector: A-101NG
Repair
OK
Check trouble symptom.
NG
Replace the engine-ECU.
INSPECTION PROCEDURE 29
A/C switch and A/C relay system
Probable cause
When an A/C ON signal is input to the engine-ECU, the engine-ECU carries out
control of the idle speed control (ISC) servo, and also operates the A/C compressor
magnetic clutch.
Malfunction of A/C control system

Malfunction of A/C switch

Improper connector contact, open or short-circuited
harness wire

Malfunction of the engine-ECU
Check the A/C compressor relay.
(Refer to GROUP 55 – On-vehicle Service.)NG
Replace
OK
Measure at the engine-ECU connectors B-59, B-60.

Disconnect the connector, and measure at the harness side.

Voltage between 22 and earth, and 45 and earth
(Ignition switch: ON, A/C switch: ON)
OK:System voltage

Short-circuit between 22 and earth
(Ignition switch: ON, A/C switch: ON)
OK:A/C compressor clutch turns on.NGCheck the A/C system. (Refer to GROUP 55 – On-vehicle Service.)
OKCheck the following
connectors: B-59, B-60NG
Replace
OK
Check trouble symptom.
NG
Replace the engine-ECU.

MPI – Troubleshooting13-49
INSPECTION PROCEDURE 41
MUT-II: Check if idling speed is unstable.
OK
MUT-II Data list
45 ISC servo position (Refer to P.13-60.)NGAdjust the basic idle speed. (Refer to P.13-30.)*
MUT-II Data list
28 A/C switch (Refer to P.13-58.)NGCheck the A/C switch and A/C relay system.
(Refer to P.13-39. INSPECTION PROCEDURE 29.)
OK
OK
MUT-II Data list
27 Power steering fluid pressure switch (Refer to P.13-58)NGCheck the power steering fluid pressure switch system.
(Refer to P.13-39, INSPECTION PROCEDURE 28.)
1. Inspect the intake of air into the air intake system.

Broken intake manifold gasket

Broken vacuum hose

PCV valve does not operate.

Broken air intake hose
2. Check the injector for clog.
OK
OK
MUT-II Data list
11 Oxygen sensor
OK:Changes between 0–400 mV and 600–1,000 mV during
idlingNGCheck the fuel pressure. (Refer to P.13-30.)*
OK
MUT-II Data list
11 Oxygen sensor
OK:600–1,000 mV during sudden racingNGCheck the oxygen sensor system. (Refer to P.13-42, INSPECTION
PROCEDURE 31.)
OK
MUT-II Data list
21 Engine coolant temperature sensor (Refer to P.13-21.)NGCheck the engine coolant temperature sensor system.
(Refer to P.13-10, INSPECTION PROCEDURE FOR DIAGNOSIS
CODE 21.)
OK
MUT-II Data list
25 Barometric pressure sensor (Refer to P.13-58.)NGCheck the barometric pressure sensor system. (Refer to P.13-14,
INSPECTION PROCEDURE FOR DIAGNOSIS CODE 25.)
OK
MUT-II Data list
13 Intake air temperature sensor (Refer to P.13-56.)NGCheck the intake air temperature sensor system. (Refer to P.13-9,
INSPECTION PROCEDURE FOR DIAGNOSIS CODE 13.)
MUT-II Data list
26 Idle position switch (Refer to P.13-58.)NGCheck the idle position switch system.
(Refer to P.13-38, INSPECTION PROCEDURE 26.)
NOTE
*: Refer to Workshop Manual for LANCER EVOLUTION-IV and EVOLUTION-V (Pub. No. S9806CNCP9).
