1999 DODGE RAM stop start

Fig. 20: Underhood Power Distribution Center
Courtesy of Chrysler Corp.
WARNING: Always disconnect battery ground cable before servicing
"high-current fuses. It is recommended that "high-current"
fuses be replaced by a qualified technician.
Power Distribution Center Relay & Fuse Identification
A - Starter Relay
B - Trailer Lights Relay
C - Auto Transmission Relay
D - Anti-Lock Brake System Relay
E - Auto Shutdown Relay
F - Air Conditioning Clutch Relay
G - Horn Relay
H - Fuel System Relay
J - ABS Warning Light Relay
K - Fog Lamp 2 Relay
L - Fog Lamp 1 Relay
1 - 30 Amp (Pink)
Engine Control
2 - 40 Amp (Green)
Ignition Run/Accessory
3 - 40 Amp (Green)
Ignition Run
4 - 50 Amp (Red)
Instrument Panel, Horn, Parking Lights
5 - 20 Amp (Blue)
Fuel Pump
6 - 30 Amp (Pink)
Trailer Lights
7 - 40 Amp (Green)
Stop/Headlight
8 - 40 Amp (Green)
ABS Pump
9 - 20 Amp (Yellow)
Hazard Lights
10 - 20 Amp (Yellow)
Horn/AC
11 - 15 Amp (Blue)

Normal Maximum Time-Out
Component Draw Draw (Minutes)
Anti-Theft System ................ 0.4 .... 1.0 ....... ...
Auto Door Lock ................... 1.0 .... 1.0 ....... ...
Body Control Module .............. 3.6 ... 12.4 ........ 20
Central Processing System ........ 1.6 .... 2.7 ........ 20
Electronic Control Module ........ 5.6 ... 10.0 ....... ...
Electronic Level Control ......... 2.0 .... 3.3 ........ 20
Heated Windshield Module ......... 0.3 .... 0.4 ....... ...
HVAC Power Module ................ 1.0 .... 1.0 ....... ...
Illuminated Entry ................ 1.0 .... 1.0 ......... 1
Light Control Module ............. 0.5 .... 1.0 ....... ...
Oil Level Module ................. 0.1 .... 0.1 ....... ...
Multi-Function Chime ............. 1.0 .... 1.0 ....... ...
Pass Key Decoder Module ......... 0.75 .... 1.0 ....... ...
Power Control Module ............. 5.0 .... 7.0 ....... ...
Retained Accessory Power ......... 3.8 .... 3.8 ....... ...
Radio ............................ 7.0 .... 8.0 ........ 15
Twilight Sentinel Module ......... 1.0 .... 1.0 ....... ...
Voltage Regulator ................ 1.4 .... 2.0 ....... ...









\









\









\









\









\









\









\


INTERMITTENT PARASITIC LOAD PROBLEMS
Intermittent parasitic lad can occur because of a memory
device that does not power down with ignition off. With an
intermittent parasitic load, battery draw can be greater than 1.0 amp.
To find and intermittent problem requires that an ammeter and
Disconnect Tool (J-38758) test switch be connected and left in the
circuit. See Fig. 1. Road test vehicle. After road test, turn ignition
off and remove key.
Monitor the milliamps scale for 15-20 minutes after ignition
is turned off. This allows monitoring memory devices to determine if
they time out and stop drawing memory current. The test switch is
needed to protect ammeter when the vehicles is started.
DIODE CHECK & SOLENOID TEST (GENERAL MOTORS)

Procedure For Programming PCM & Clearing DTCs From ABS & SRS
Modules
Connect scan tool to Data Link Connector (DLC). DLC is
located under left side of instrument panel. Using scan tool, enter
correct VIN and mileage into PCM. Using scan tool manufacturer's
instructions, clear DTCs from ABS and SRS modules.
Procedure For Updating Secret Key Data
1) Connect scan tool to Data Link Connector (DLC). DLC is
located under left side of instrument panel.
2) Go to ENGINE and then MISC menus on scan tool. Place the
SKIM in SECURED ACCESS MODE by using the appropriate Personal
Identification Number (PIN) for this vehicle. PIN may be obtained from\
the owner, vehicle's invoice, or from the manufacturer. Select UPDATE
THE SECRET KEY DATA. The data will be transferred from Smart Key
Immobilizer Module (SKIM) to the PCM, allowing the vehicle to start.
NOTE: On Ram Van and Ram Wagon, if 3 attempts are made to enter the
SECURED ACCESS MODE using the incorrect Personal
Identification Number (PIN), the SECURED ACCESS MODE will be
locked out for one hour. To exit this locked out mode, leave
ignition switch in the ON position for one hour with all
accessories turned off. It may be necessary to monitor
battery state and connect a battery charger if necessary.
ENGINE SENSORS & SWITCHES
BATTERY TEMPERATURE SENSOR
Removal & Installation
Battery temperature sensor is snapped into center of battery
tray, directly below the battery. Remove battery. Disconnect
electrical connector for battery temperature sensor. Pry battery
temperature sensor straight upward from battery tray. To install,
reverse removal procedure.
BRAKE SWITCH
NOTE: Brake switch may also be referred to as brakelight switch or
stoplight switch.
Removal (Dakota, Durango & Ram Pickup)
1) Brake switch is located near top of brake pedal. Remove
lower instrument panel cover for access to brake switch if necessary.
Disconnect electrical connector from brake switch. Depress and hold
brake pedal downward.
2) Rotate brake switch counterclockwise approximately 30
degrees so alignment tab on brake switch aligns with opening on
mounting bracket. Pull brake switch rearward from mounting bracket.
NOTE: Before installing brake switch, plunger on brake switch must
be pulled outward to fully extended position and then pushed
inward 4 detent positions to ensure proper brake switch
adjustment.
Installation
1) Pull plunger on brake switch outward to the fully extended
position. Push plunger on brake switch inward 4 detent positions. The
brake switch will click at each detent position when pushing plunger
inward.
2) Install electrical connector on brake switch. Depress
brake pedal as far as possible. Install brake switch in mounting

NOTE: Before testing, check fluid level, belt tension, pump pulley,
tire pressure and engine idle speed.
HYDRAULIC SYSTEM PRESSURE TEST
NOTE: Replacement fittings are required on Pressure Test Gauge(C
-3309E) for adapting to "O" ring type hose tube ends.
Idle Pressure Test
1) Remove high pressure hose at steering pump and connect a
spare hose to pump fitting. Connect opposite end of spare hose to
Pressure Test Gauge (C-3309E). Connect pressure hose from valve side
of steering gear to valve side of gauge. Valve must be installed on
outlet side of gauge. See Fig. 2.
2) Fully open shutoff valve on test gauge. With a thermometer
in fluid reservoir, start engine and warm fluid to 150-170
F (66-
77C). Turning wheels from stop-to-stop will aid in warming fluid. DO
NOT hold wheels against stop.
3) With engine at idle and gauge valve open, check initial
pressure. See POWER STEERING PUMP PRESSURE TEST SPECIFICATIONS table.
If pressure is greater than 125 psi (8.8 kg/cm

), check for restricted
hoses or crimped lines.
Fig. 2: Installing Pressure Gauge
Courtesy of Chrysler Corp.
POWER STEERING PUMP PRESSURE TEST SPECIFICATIONS
\
\
\
\
\
\
\

Application psi (kg/cm
FD)
Idle Pressure ...................................... 50-80 (3.5-5.6)\
Relief Pressure
Dakota (4WD) ........................................ 1450 (101.9\
)
Ram Pickup .......................................... 1450 (101.9)\
Ram Van/Wagon ........................................ 1400 (98.4)\
\
\
\
\
\
\
\

CAUTION: DO NOT leave shutoff valve closed more than 5 seconds, or
pump damage could result.

Relief Pressure Test
1) Close gauge shutoff valve completely 3 times. Record
highest pressure attained each time. All 3 readings must be greater
than specifications and within 50 psi (3.5 kg/cm

) of each other. See
POWER STEERING PUMP PRESSURE TEST SPECIFICATIONS table. If pressures
are not as specified, replace pump. See POWER STEERING PUMP (GASOLINE)\
or VACUUM/POWER STEERING PUMP (DIESEL) under REMOVAL & INSTALLATION.
CAUTION: DO NOT hold steering wheel against stops more than 4 seconds,
or pump damage may result.
2) Open test valve and turn steering wheel to left and right
stops. Record highest pressure attained at each stop. If output
pressures are not equal against each stop, gear is leaking internally
and must be replaced. See STEERING GEAR under REMOVAL & INSTALLATION.
Shut off engine, remove test gauge, and connect pressure hose.
LUBRICATION
CAPACITY
CAPACITY\
\
\
\
\
\
\

Models Pts. (L)\
Dakota (4WD) ............................................. 2.5 (1.2\
)
Ram Pickup & Ram Van/Wagon ............................... 2.7 (1.3)\
\
\
\
\
\
\
\

FLUID TYPE
CAUTION: DO NOT use Automatic Transmission Fluid (ATF).
Use Mopar Power Steering Fluid (4318055).
FLUID LEVEL CHECK
Check fluid level with engine cold and not running. Remove
fluid level dipstick on pump reservoir. Dipstick should indicate FULL
COLD with fluid temperature of 70-80
F (21-27C). If needed, add fluid
through dipstick opening, and recheck. DO NOT overfill.
HYDRAULIC SYSTEM BLEEDING
Fill power steering pump reservoir to specified level. Start
engine and slowly turn steering wheel to left and right, but DO NOT
contact steering stops in either direction. Stop engine. Inspect
reservoir fluid level and add fluid if necessary. Bleeding process may
have to be repeated several times to completely purge all air from
system.
ADJUSTMENTS
POWER STEERING PUMP BELT
Vehicles are equipped with dynamic tensioner. No adjustment
is required.
POWER STEERING PUMP PULLEY

Removal
1) Place wheels in straight-ahead position. Place drain pan
under steering gear assembly. Disconnect and cap pressure and return
hoses from steering gear. Disconnect steering column shaft coupling
from steering gear stub shaft.
2) Raise and support vehicle. Disconnect steering linkage
(center link) from pitman arm. See Fig. 9. Disconnect stabilizer bar
(if necessary). Place reference mark on pitman arm and sector shaft.
Remove nut and pitman arm from sector shaft. Remove steering gear-to-
frame bolts. Remove steering gear.
Installation
1) Install steering gear with bolts finger tight. Center
steering gear and align stub shaft with steering column. Install
steering column shaft coupling bolt and tighten to specification. See
TORQUE SPECIFICATIONS.
CAUTION: Stake pitman arm nut against pitman arm to ensure proper
retention.
2) Reposition steering gear to eliminate binding, and tighten
bolts to specification. Install pitman arm on sector shaft with
reference marks aligned. Install lock washer and nut. Tighten nut to
specification.
3) To install remaining components, reverse removal
procedure. Fill pump reservoir. Bleed air from hydraulic system. See
HYDRAULIC SYSTEM BLEEDING under LUBRICATION.
SECTOR SHAFT OIL SEAL
Removal
1) Raise and support vehicle. Place wheels in straight-ahead
position. Disconnect steering linkage (center link) from pitman arm.
Disconnect stabilizer bar (if necessary).
2) Place reference mark on pitman arm and sector shaft.
Remove nut and pitman arm from sector shaft. Place drain pan under
steering gear. Remove retaining ring and steel washer. See Fig. 1.
CAUTION: DO NOT hold steering wheel in left-turn position for more
than 2 seconds.
3) Start engine and momentarily hold steering wheel in
extreme left-turn position. When pressure develops, this should force
upper oil seal, steel washer and lower oil seal from steering gear
housing. Stop engine and remove seals.
Installation
1) Ensure seal bore of steering gear is free of burrs and
sector shaft is free of pitting or roughness. Lubricate replacement
seals and steel washers with power steering fluid.
2) Wrap sector shaft with plastic tape or .005" (.13 mm)
thick shim stock. Install upper oil seal (single lip seal) and steel
washer first. Oil seal must be installed only deep enough to allow for
remaining oil seal, steel washer and retaining ring.
CAUTION: DO NOT install upper oil seal against inner bore surface of
steering gear housing. Oil seals must be installed so each
oil seal is separately seated in shaft bore.
3) Install lower oil seal (double lip seal) and steel washer\
.
Oil seal must be installed only deep enough to allow for steel washer
and retaining ring. Remove tape or shim stock and install retaining
ring.

converter lock-up. ECM uses various input signals such as transmission
temperature, output shaft speed, central module timer, engine speed,
APPS and brake switch position to determine operation of transmission
torque converter clutch solenoid. Transmission torque converter clutch
solenoid is located on transmission valve body.
FUEL SYSTEM
FUEL DELIVERY
Fuel Injection Pump
A camshaft-driven Bosch VP44 in-line fuel injection pump is
used to supply high pressure fuel to each fuel injector in precise
metered amounts at the correct time. See Fig. 2. The pump is timed to
camshaft gear. Pump output is controlled by integral Fuel Pump Control
Module (FPCM). Because of electronic control, idle speeds and pump
timing are not adjustable. See ON-VEHICLE ADJUSTMENTS - TRUCKS -
DIESEL article. FPCM can operate engine if crankshaft position sensor
signal does not exist. Fuel injection occurs near completion of
compression stroke for each cylinder.
Fuel injection pump contains an overflow valve which allows
excess fuel to return to the fuel tank. Overflow valve is located on
side of fuel injection pump and is used to attach the fuel return line
to the fuel injection pump.
Fuel Transfer Pump
Fuel transfer pump is located on driver's side of cylinder
block, above starter. See Fig. 2. A 12 volt, 12-amp electric vane-type
pump supplies low fuel pressure from fuel tank, through fuel
heater/fuel filter/water separator to fuel injection pump. Fuel
transfer pump contains internal check valves to prevent fuel from
bleeding back into fuel tank during engine shutdown. Pump will self
prime with ignition on for 2 seconds. Pump has 2 modes, 100 percent
duty cycle (10 psi) when engine is running and 25 percent duty cycle
(7 psi) when engine is cranking.
Fuel Filter/Water Separator
Fuel filter/water separator, located on left side of engine,
protects injection pump by removing water and contaminants from fuel.
See Fig. 2 . Assembly also includes fuel heater and Water-In-Fuel (WIF)
sensor.
In-Tank Fuel Filter
A separate in-tank fuel filter is attached to bottom of fuel
tank module. In-tank fuel filter does not require service under normal
conditions.
FUEL CONTROL
Fuel Injector
Fuel injector delivers atomized fuel into the cylinder.
During fuel injection, fuel pressure from fuel injection pump
increases to fuel injector opening pressure or pop pressure of 4500
psi (316 kg/cm

). This is the pressure required to lift fuel injector
needle valve from its seat, allowing fuel to be injected into the
cylinder. Once fuel pressure decreases to less then the opening
pressure, a spring forces needle valve closed and stops fuel injection
into the cylinders. Each fuel injector is connected to injection pump
by a high pressure (as much as 17,405 psi) line.
Fuel Injection Timing
Pump output is controlled by integral Fuel Pump Control
