EN G IN E C O OLIN G S PEC IF IC ATIO NS

1999 D odge P ic ku p R 1500
1998-99 ENGINE COOLING
CHRY - Specifications - All Models
1998 Talon
1998-99 Avenger, Breeze, Caravan, Cirrus, Concorde, Dakota,
Durango, Intrepid, Neon, Ram Pickup, Ram Van/Wagon, Sebring
Convertible, Sebring Coupe, Stratus, Town & Country, Voyager
1999 LHS, 300M
BELT ADJUSTMENT
NOTE: For belt routing on models not covered in this article,
information was not available. See underhood label for proper
belt routing.
Belts should be adjusted to proper tension using belt tension
gauge. See appropriate BELT ADJUSTMENT SPECIFICATIONS table. Some
models may be equipped with an automatic belt tensioner. Ensure
serpentine belts are routed properly. See Figs. 5 through 14.
4-CYLINDER BELT ADJUSTMENT SPECIFICATIONS - CARS









\









\









\









\









\









\









\







Application New Belt (1) Used Belt
Lbs. (kg) Lbs. (kg\
)
Avenger & Sebring Coupe
2.0L
Generator ................... 110-160 (50-73) .. 90-110 (41-50\
)
Power Steering
With A/C .................. 137-159 (62-72) .. 93-115 (42-52\
)
Without A/C ............... 110-160 (50-73) .. 90-110 (41-50\
)
Breeze, Cirrus & Stratus
2.0L & 2.4L
A/C & Generator .................. 150 (68) ............ 80 (36\
)
Power Steering .................. 130 (59) ............ 80 (36\
)
Neon
2.0L (DOHC & SOHC)
A/C & Pwr. Steering ............. 135 (61) ........... 100 (45\
)
Generator ....................... 135 (61) ........... 100 (45\
)
Sebring Convertible
2.4L .......................... 150 (68) ............ 80 (36\
)
Talon
2.0L Non-Turbo
Generator ................... 110-160 (50-73) .. 90-110 (41-50\
)
Power Steering
With A/C .................. 137-159 (62-72) .. 93-115 (42-52\
)
Without A/C ............... 110-160 (50-73) .. 90-110 (41-50\
)
2.0L Turbo
A/C ........................... 86-99 (39-45) ... 57-75 (26-34\
)
Generator ..................... 110-154 (50-70) ........ 88 (40\
)
Power Steering ............... 110-154 (50-70) .. 77-92 (35-42\
)
( 1) - Belt is considered used after 15 minutes of service.









\









\









\









\









\









\









\







V6 BELT ADJUSTMENT SPECIFICATIONS - CARS








\









\









\









\









\









\









\







Application New Belt (1) Used Belt
Lbs. (kg) Lbs. (kg\
)

Avenger & Sebring Coupe
2.5L
A/C ......................... 110-132 (50-60) ... 66-86 (30-39\
)
Generator & P/S ............. 143-187 (65-85) .. 99-121 (45-55\
)
Cirrus & Stratus 2.5L
A/C & Generator ................. 150 (68) ............. 80 (36\
)
Power Steering .................. 130 (59) ............. 80 (36\
)
Concorde, Intrepid, LHS & 300M
2.7L
All Belts ................... 180-200 (78-91) ........ 120 (54\
)
3.2L & 3.5L
A/C ......................... 140-160 (64-73) ........ 120 (54\
)
Generator & Power Steering ..... 180-200 (78-91) ........ 120 (54\
)
Sebring Convertible
2.5L .......................... 150 (68) ............ 80 (36\
)
(1) - Belt is considered used after 15 minutes of service.









\









\









\









\









\









\









\







BELT ADJUSTMENT SPECIFICATIONS - TRUCKS








\









\









\









\









\









\









\







Application New Belt (1) Used Belt
Lbs. (kg) Lbs. (kg\
)
Dakota & Durango
2.5L ........................ 180-200 (82-91) .. 140-160 (64-73\
)
3.9L, 5.2L & 5.9L ................. ( 2) .................... ( 2)
FWD Vans
Caravan & Voyager
2.4L
A/C & Generator .............. 190 (86) ............ 115 (52\
)
Power Steering ............... 140 (64) ............. 90 (41\
)
3.0L
A/C .......................... 150 (68) ............. 80 (36\
)
Generator & P/S ................ ( 2) .................... ( 2)
3.3L & 3.8L ...................... ( 2) .................... ( 2)
Town & Country
3.3L & 3.8L ...................... ( 2) .................... ( 2)
Ram Pickup & Ram Van/Wagon
All Engines ....................... ( 2) .................... ( 2)
( 1) - Belt is considered used after 15 minutes of service.
( 2) - Automatic belt tensioner is used. Belt tension adjustment is not
required.









\









\









\









\









\









\









\







Fig. 1: Belt Routing (2.0L Avenger, Sebring Coupe & Talon Without
Turbo)
Courtesy of Chrysler Corp.

COOLING SYSTEM BLEEDING
GASOLINE ENGINES
Air in system will collect under radiator cap. As engine
reaches operating temperature, coolant and any trapped air will enter
reserve tank. As engine cools, a vacuum will be created which will
draw only coolant into cooling system. After engine has gone through a
warm-up and cooling cycle, run engine until it again reaches operating
temperature. Ensure coolant in reserve tank is at warm coolant mark on
reserve tank or dipstick.
5.9L DIESEL ENGINE
For bleeding procedures on 5.9L diesel, see appropriate 12-
valve or 24-valve engine article in ENGINES. DO NOT operate engine
while filling cooling system.
SPECIFICATIONS
COOLING SYSTEM SPECIFICATIONS
COOLING SYSTEM SPECIFICATIONS - CARS








\









\









\









\









\









\









\







Application Specification
Avenger & Sebring Coupe
Coolant Replacement Interval ........... 30,000 Miles Or 24 Months
Coolant Capacity ................................. 7.4 Qts. (7.0L)\
Pressure Cap .............................................. 16 psi
Thermostat
DOHC
Starts To Open ................................... 195
F (91C)
Fully Opens ..................................... 216F (102C)
SOHC
Starts To Open ................................... 180
F (82C)
Fully Opens ...................................... 203F (95C)
Breeze, Cirrus, Sebring Convertible & Stratus
Coolant Replacement Interval ........... 45,000 Miles Or 36 Months
Coolant Capacity
2.0L ............................................ 8.5 Qts. (8.0L)\
2.4L ............................................ 9.0 Qts. (8.5L)\
2.5L .......................................... 10.5 Qts. (10.0L)\
Pressure Cap ........................................... 14-18 psi
Thermostat
Starts To Open .............................. 192-199
F (88-93C)
Fully Opens ....................................... 220F (104C)
Concorde, Intrepid, LHS & 300M
Coolant Replacement Interval ....................... 120,000 Miles
Coolant Capacity ................................. 9.4 Qts. (8.9L)\
Pressure Cap ........................................... 14-18 psi
Thermostat
Starts To Open .............................. 192-199
F (88-93C)
Fully Opens ....................................... 220F (104C)
Neon
Coolant Replacement Interval ........... 45,000 Miles Or 36 Months
Coolant Capacity ................................. 7.4 Qts. (7.0L)\
Pressure Cap ........................................... 14-18 psi
Thermostat
Starts To Open .............................. 192-199
F (88-93C)
Fully Opens ....................................... 220F (104C)

Talon
Coolant Replacement Interval ........... 30,000 Miles Or 24 Months
Coolant Capacity ................................. 7.4 Qts. (7.0L)\
Pressure Cap
VIN F ................................................. 11-15 psi
VIN Y ................................................. 14-18 psi
Thermostat
Starts To Open
VIN F ............................................ 180
F (82C)
VIN Y ............................................ 195F (91C)
Fully Opens
VIN F ............................................ 203
F (95C)
VIN Y ........................................... 216F (102C)








\









\









\









\









\









\









\







COOLING SYSTEM SPECIFICATIONS - TRUCKS








\









\









\









\









\









\









\







Application Specification
Coolant Replacement Interval ............. 45,000 Miles Or 36 Months
Coolant Capacity ( 1)
Caravan, Town & Country, & Voyager
2.4L ...................................... ( 2) 11.2 Qts. (10.6L)
3.0L ...................................... ( 2) 13.0 Qts. (12.3L)
3.3L & 3.8L ............................... ( 2) 13.2 Qts. (12.5L)
Dakota
2.5L ............................................ 9.8 Qts. (9.3L)\
3.9L .......................................... 14.0 Qts. (13.2L)\
5.2L .......................................... 14.3 Qts. (13.5L)\
5.9L ................................................. 14.6L (13.7L)\
Durango
3.9L .......................................... 14.0 Qts. (13.2L)\
5.2L & 5.9L ...................................... 14.3 Qts. (13.5L)\
Ram Pickup
3.9L, 5.2L & 5.9L (Gasoline) .................. 20.0 Qts. (18.9L\
)
5.9L (Diesel) ................................. 24.0 Qts. (22.7L\
)
8.0L .......................................... 26.0 Qts. (24.6L)\
Ram Van/Wagon
3.9L ........................................... 10.4 Qts. (9.8L)\
5.2L .......................................... 13.1 Qts. (12.4L)\
5.9L
With Rear Heater ............................ 14.1 Qts. (13.3L)\
Without Rear Heater ......................... 13.1 Qts. (12.4L)\
Pressure Cap ............................................. 14-16 psi
Thermostat
Diesel Engines
Starts To Open ..................................... 181
F (83C)
Fully Open ............................................ 203F (95C)
Gasoline Engines
Starts To Open ..................................... 192
F (89C)
Fully Opens ....................................... 220F (104C)
( 1) - Capacities listed are approximate.
( 2) - Capacity includes heater and coolant recovery tank. Add 2 qts.
(1.9L) for models equipped with rear heater.









\









\









\









\









\









\









\


3.9 L V 6, 5 .2 L & 5 .9 L V 8 - V IN [ T , X , Y , Z ]
1 999 D odge P ic ku p R 1500
1998-99 ENGINES
CHRY - 3.9L V6, & 5.2L & 5.9L V8
Chrysler Corp. Dakota, Durango, Ram Pickup, Ram Van/Wagon
Jeep Grand Cherokee
ENGINE IDENTIFICATION
Engine may be identified by eighth character of Vehicle
Identification Number (VIN) stamped on metal tab located near lower
left corner of windshield. See ENGINE IDENTIFICATION CODES table.
Engine serial number may be required when ordering
replacement parts. Engine serial number is located on left front
corner of cylinder block just below cylinder head.
ENGINE IDENTIFICATION CODES









\









\









\









\









\









\









\







Engine Code
3.9L PFI ......................................................... X
5.2L PFI ......................................................... Y
5.2L MFI CNG ..................................................... T
5.9L PFI
Light Duty Cycle ............................................... Z
Heavy Duty Cycle ( 1) ........................................... 5
( 1) - Heavy Duty Cycle (HDC) engine uses an engine mounted air
injection pump.









\









\









\









\









\









\









\







SPECIAL ENGINE MARKS
Information identifying undersize and oversize components is
found at various engine locations and is decoded as follows:
Crankshaft & Rod Journals
The letter "M" (main) or "R" (rod) followed by number
indicates which main or rod bearing journal is .001" (.02 mm)
undersize. The mark is stamped on No. 6 crankshaft counterweight on 3.
9L, No. 8 crankshaft counterweight on 5.2L and No. 3 crankshaft
counterweight on 5.9L engines.
Cylinder Block - Letter "A" following engine serial number
indicates .020" (.51 mm) oversize cylinder bores:
* A diamond-shaped stamp, located on top pad at front of engine
and stamped on flat area of each oversize lifter bore,
indicates .008" (.20 mm) oversize lifters.
* A stamp "X" indicates .005" (.13 mm) oversize valve stems.
The stamp is found on machined pad, near two 3/8" tapped
holes on each end of cylinder head.
ADJUSTMENTS
VALVE CLEARANCE ADJUSTMENT
Hydraulic valve lifters are used. No valve adjustment is
required.

TROUBLE SHOOTING
NOTE: To trouble shoot mechanical engine components, see
appropriate table in TROUBLE SHOOTING article in GENERAL
INFORMATION.
REMOVAL & INSTALLATION
CAUTION: When battery is disconnected, vehicle computer and memory
systems may lose memory data. Driveability problems may exist
until computer systems have completed a relearn cycle. See
COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION
before disconnecting battery.
NOTE: For installation reference, label all electrical connectors,
vacuum hoses and fuel lines before removal. Also place mating
marks on engine hood and other major assemblies before
removal.
FUEL PRESSURE RELEASE
CAUTION: Fuel system is under pressure. Pressure must be released
before servicing fuel system components.
Gasoline
1) Disconnect negative battery cable. Loosen fuel tank cap to
release tank pressure. Press on filler tube flap to relieve any
additional tank pressure.
NOTE: Fuel filler tube has spring-loaded flap located below fuel
fill cap to serve as secondary seal if fuel fill cap is not
tightened. It is part of EVAP monitor system when vehicle is
equipped with leak detection pump (LDP). Vehicle may be
equipped with flap installed into fuel filler tube even if
vehicle is NOT equipped with LDP and EVAP monitor system.
2) Remove fuel pump relay from Power Distribution Center
(PDC). For location of relay, refer to label on underside of PDC
cover. Start and run engine until it stalls. Attempt restarting engine
until it will no longer run.
3) Unplug connector from an injector. Attach one end of a
jumper wire (18 gauge or smaller) with alligator clips to either
injector terminal. Connect other end of jumper wire to positive side
of battery. Connect one end of a second jumper wire to remaining
injector terminal.
WARNING: Powering an injector for more than a few seconds will
permanently damage injector.
4) Touch other end of second jumper wire to negative terminal
of battery for no more than a few seconds. Place a rag below fuel
line. Disconnect quick-connect fitting at fuel rail. See FUEL LINE
DISCONNECT FITTINGS. Return fuel pump relay to PDC.
Compressed Natural Gas Fuel Tube Purging (5.2L)
1) Close control valve (clockwise) on all fuel cylinders.
Open manual shutoff valve (open when handle is parallel to fuel
tubes).
2) Start and operate engine until it runs out of fuel.
Attempt 3 more engine starts. If check valve or fuel fill receptacle

is to be serviced, slowly loosen inlet side of fuel fill tube fitting
at check valve. It is normal for approximately 25 psi of residual
natural gas pressure to flow from loosened fitting. At this point, all
fuel tubes are purged of natural gas between fuel cylinders and
engine. It is now okay to open fuel system.
WARNING: Fuel cylinders still contain high-pressure fuel.
Compressed Natural Gas Fuel Cylinder Purging (5.2L)
1) Open manual shutoff valve. Open only fuel control valve(s)\
(counterclockwise) on fuel cylinder(s) to be serviced. Close all oth\
er
control valve(s) (clockwise) on fuel cylinder(s) not being service\
d.
2) Start and operate engine until it runs out of fuel.
Attempt 3 more engine starts. At this point, all fuel tubes and opened
cylinders are purged of natural gas between fuel cylinders and engine.
It is now okay to open fuel system.
WARNING: Fuel cylinders not being serviced still contain high-pressure
fuel.
FUEL LINE DISCONNECT FITTINGS
Removal & Installation (Tab Type Fitting)
1) Release fuel pressure. See FUEL PRESSURE RELEASE.
Disconnect negative battery cable. Ensure area around fuel line and
disconnect fitting is clean. Place shop towel around fuel line.
2) On 2-tab connectors, squeeze retainer tabs together and
pull fuel tube/quick-connect fitting assembly off of fuel tube nipple.
On single-tab connectors, use screwdriver to pry up pull tab. See
Fig. 1 . Raise pull tab until it separates from quick-connect fitting.
Discard old pull tab. Disconnect quick-connect fitting from fuel line.
CAUTION: DO NOT install a quick-connect fitting without retainer being
either in fuel tube or already in quick-connect fitting.
After installing fuel line in disconnect fitting, pull on
fuel line and disconnect fitting to ensure fuel line is
locked in place.
3) To install, coat fuel tube nipple with clean 30W engine
oil. Insert quick-connect fitting into fuel tube until stop on fuel
tube rests against back of quick-connect fitting.
4) On single-tab connectors, obtain NEW pull tab. Push tab
down until it locks into quick-connect fitting. On 2-tab connectors,
firmly pull on fuel tube and fitting to ensure retainer and quick-
connect fitting are locked.
Removal & Installation (Retainer Type Fitting)
1) Release fuel pressure. See FUEL PRESSURE RELEASE.
Disconnect negative battery cable. Ensure area around fuel line and
disconnect fitting is clean. Place shop towel around fuel line.
2) Pull backward on disconnect fitting while depressing
plastic ring into disconnect fitting. See Fig. 2. Separate fuel line
from disconnect fitting.
NOTE: Plastic retainer ring must be pressed squarely into fitting
body. If retainer is cocked during removal, it may be
difficult to disconnect fitting. Use open-end wrench on
shoulder of plastic retainer to ease disconnection.
3) To install, ensure plastic ring is in outward position
(away from disconnect fitting). If plastic ring is in inward position
(toward disconnect fitting), disconnect fitting must be replaced.
4) Lubricate end of fuel line with 30W engine oil. Insert

fuel line into disconnect fitting until shoulder on fuel line locks in
place.
CAUTION: DO NOT install a quick-connect fitting without retainer being
either in fuel tube or already in quick-connect fitting.
After installing fuel line in disconnect fitting, pull on
fuel line and disconnect fitting to ensure fuel line is
locked in place.
5) Pull on fuel line and disconnect fitting to ensure fuel
line is locked in place. If fuel line is not locked in place, ensure
plastic ring is not causing locking retainer to remain in released
position. Reconnect negative battery cable. Start engine and check for
leaks.
Fig. 1: Identifying Tab Type Fuel Line Disconnect Fittings
Courtesy of Chrysler Corp.
