1999 CHEVROLET SUBURBAN Owners Manual

yellowblue
6-65
Replacement Bulbs
LAMP OR BULB TRADE NO. POWER RATING AT 12.8V, WATTS QTY
HEADLAMPS
2 Headlamp System (Sealed Beam)
Low/High Beam H6054 35/65 2
4 Headlamp System (Composite)
Low Beam 9006 55 2
High Beam 9005 65 2
LAMP OR BULB TRADE NO. QTY
EXTERIOR
Front Marker Lamp 194 2
Front Parking and Turn Lamp 2357NA 4
Rear Parking Lamp 3057 2
Rear Stop and Turn Lamp 3057 2
Back
-up Lamp3156 2
Roof Marker Lamp* 194 5
License Plate Lamp 194 2
Underhood Lamp 93 1
*Suburban Only

yellowblue
6-66
LAMP OR BULB TRADE NO. QTY
INTERIOR
Dome Lamps
211
-22
Reading Lamps
211
-24
Roof Console Lamps* 168 2
Door Courtesy Lamp 194 2/4*
Four
-Wheel-Drive Indicator**194 1
Four
-Wheel-Drive Shift Lever**194 1
Instrument Panel Compartment Lamp 194 1
Ashtray Lamp 194 1
Sunshade Vanity Mirror 74 4
*Suburban Only
**Manual Transfer Case

yellowblue
6-67
Capacities and Specifications
Please refer to ªRecommended Fluids and Lubricantsº in the Index for more information.
Engine Identification -- Gasoline Engines
EngineªVORTECº 5700 ªVORTECº 7400
Type V8 V8
RPO Code L31 L29
VIN Code R J
Fuel System SFI* SFI*
*Sequential Fuel Injection
Wheels and Tires
MODEL DESCRIPTION TORQUE
C 1500 5 bolts (14 mm)
140 lb
-ft (190 N´m)
K 1500, C
-K 25006 bolts (14 mm)
140 lb-ft (190 N´m)
C
-K 25008 bolts (14 mm)
140 lb-ft (190 N´m)
Tire Pressure See the Certification/Tire label
on the rear edge of the driver's
door or the incomplete vehicle
document in the cab.

yellowblue
6-68 Cooling System Capacity (Approximate)
After refill, the level must be rechecked. See ªCooling Systemº in the Index.
ENGINE VIN QTY Without Rear Heater QTY With Rear Heater
ªVORTECº 5700 V8 R 17.5 Quarts (16.5 L) 20 Quarts (19 L)
ªVORTECº 7400 V8 J 25 Quarts (23.5 L) 27.5 Quarts (26 L)
Crankcase Capacity (Approximate)
After refill, the level must be rechecked. Add enough engine oil so that the fluid is within the proper operating range.
See ªEngine Oilº in the Index.
ENGINE VIN
QUANTITY WITH FILTER

ªVORTECº 5700 V8 R 5 Quarts (4.8 L)
ªVORTECº 7400 V8 J 6.6 Quarts (6.3 L)

Oil filter should be changed at every oil change.
Fuel Tank Capacity (Approximate)
TYPE QUANTITY
Utility 30 Gallons (113 L)TYPE QUANTITY
Suburban
- Gasoline 44 Gallons (167 L)
Suburban
- Diesel 42 Gallons (159 L)
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same. If the air conditioning system in your vehicle needs refrigerant, be sure
the proper refrigerant is used. If you're not sure, ask your dealer.
See refrigerant charge label under the hood for charge capacity information and requirements.

yellowblue
6-69
Normal Maintenance Replacement Parts -- Gasoline Engines
Replacement part numbers listed in this section are based on the latest information available at the time of printing,
and are subject to change. If a part listed in this manual is not the same as the part used in your vehicle when it was
built, or if you have any questions, please contact your GM truck dealer.
EngineªVORTECº 5700 V8 ªVORTECº 7400 V8
VIN R J
Oil Filter
AC Type PF1218
AC Type PF1218
Air Cleaner Filter
AC Type A1300C

AC Type A1300C


PCV Valve AC Type CV769C AC Type CV774C
Spark Plugs
AC Type 41
-932 AC Type 41-932
Spark Plug Gap 0.060 in. (1.52 mm) 0.060 in. (1.52 mm)
Fuel Filter AC Type GF626 AC Type GF626
Wiper Blades (Front) GM Part No. 22154886 GM Part No. 22154886
Wiper Blade Type (Front) Trico Trico
Wiper Blade Length (Front) 18 inches (45.0 cm) 18 inches (45.0 cm)
Wiper Blade (Rear) GM Part No. 22154396 GM Part No. 22154396
Wiper Blade Type (Rear) Trico Trico
Wiper Blade Length (Rear) 14 inches (35.5 cm) 14 inches (35.5 cm)

Four
-Wheel-Drive Vehicles -- use a PF52 oil filter.


A1301C High
-capacity air cleaner filter.

yellowblue
6-70
-NOTES

7-
yellowblue
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-5 Short Trip/City
Definition
-- Gasoline Engines
7
-5 Short Trip/City Intervals -- Gasoline Engines
7
-6 Long Trip/Highway
Definition
-- Gasoline Engines
7
-7 Long Trip/Highway
Intervals
-- Gasoline Engines7
-8 Short Trip/City Scheduled
Maintenance
-- Gasoline Engines
7
-27 Long Trip/Highway Scheduled
Maintenance
-- Gasoline Engines
7
-38 Part B: Owner Checks and Services
7
-42 Part C: Periodic Maintenance Inspections
7
-44 Part D: Recommended Fluids and Lubricants
7
-46 Part E: Maintenance Record

yellowblue
7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet, or your
dealer for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
