Page 9 of 424

yellowblue
1-3 Power Seat(s) (If Equipped)
If your vehicle has a power seat on the driver's or
passenger's side, you can adjust it with these controls at
the outside edge of the seat. The switch is located on the
side of the seat, next to the door.
You can use the round center knob to move the seat to
where you want it. To raise the seat, move the knob up.
To lower the seat, move the knob down. To move the
seat forward, move the knob toward the front of the
vehicle. To move the seat rearward, move the knob
toward the rear of the vehicle.
You can also raise and lower the front and rear of the seat.
To raise the front of the seat, move the front lever up. To
lower the front of the seat, move the front lever down. Toraise the rear of the seat, move the rear lever up. To lower
the rear of the seat, move the rear lever down.
The switch located at the front of this control panel
is for the power lumbar adjustment, which is
explained next.
Power Lumbar Adjustment (If Equipped)
If you have power lumbar
adjustment, you can
increase or decrease lumbar
support in an area of the
lower seatback.
To increase support, press and hold the front of the
rocker switch. Let go of the switch when the lower
seatback reaches the desired level of support.
To decrease support, press and hold the rear of the
rocker switch. Let go of the switch when the lower
seatback reaches the desired level of support.
Page 10 of 424
yellowblue
1-4 Heated Front Seats (If Equipped)
The control for the driver's side heated seat is located on
the left side of the seat. The control for the right front
passenger is located on the right side of the passenger's
seat. Move the switch forward to MED or HIGH
temperature to turn on the heating elements in the seat.
The right front passenger's safety belt must be buckled
before the heating elements in that seat will operate.
To turn the heated seats off, move the switch rearward
to OFF.
Reclining Front Seatbacks
To adjust the seatback, move the lever rearward.
Release the lever to lock the seatback where you want it.
Move the lever again rearward and the seatback will go
to an upright position.
Page 11 of 424
yellowblue
1-5
But don't have a seatback reclined if your vehicle
is moving.
CAUTION:
Sitting in a reclined position when your vehicle is
in motion can be dangerous. Even if you buckle
up, your safety belts can't do their job when
you're reclined like this.
The shoulder belt can't do its job because it
won't be against your body. Instead, it will be in
front of you. In a crash you could go into it,
receiving neck or other injuries.
The lap belt can't do its job either. In a crash the
belt could go up over your abdomen. The belt
forces would be there, not at your pelvic bones.
This could cause serious internal injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety
belt properly.
Page 12 of 424
yellowblue
1-6 Head Restraints
Slide the head restraint up or down so that the top of the
restraint is closest to the top of your ears. This position
reduces the chance of a neck injury in a crash.
Seatback Latches (2-Door Utility)
CAUTION:
If the seatback isn't locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
The front seatback folds forward to let you access the
rear of the vehicle.
To fold a seatback forward,
pull this lever forward and
tilt the seatback forward.
To return the seatback to the upright position, just push
the seatback rearward until it latches.
After returning the seatback to its upright position, pull
the seatback forward to make sure it is locked.
Page 13 of 424

yellowblue
1-7 Easy Entry Seat (2-Door Utility)
CAUTION:
If any easy entry seat isn't locked, it can move. In
a sudden stop or crash, the person sitting there
could be injured. And, even if there is no crash or
sudden stop, a driver sitting in an unlocked easy
entry seat could be startled by the sudden
movement and hit the wrong control or pedal,
causing an accident. After you've used it, be sure
to push rearward on any easy entry seat to be
sure it is locked.
The driver and passenger front bucket seat and the 60/40
split bench seat of your vehicle have an easy entry
feature. This makes it easy to get in and out of the
rear seat. On vehicles equipped with the power driver's
seat, only the passenger's front seat will have the easy
entry feature.
To operate the seat, pull
forward on the top of the
lever located at the side of
the seatback, and tilt the
seatback forward toward
the front of the vehicle.
When you do, the seat bottom will release. Just pull or
push the seat forward until it stops.
To return the seat to its regular position, return the
seatback to its upright position, then push the whole seat
rearward until it latches.
After returning the seat to its regular position, try to
move the seat with your body, to make sure the seat is
locked into place.
Page 14 of 424

yellowblue
1-8 Rear Seats
CAUTION:
If a head restraint is not installed on the seatback
or stored in the vehicle properly, it could be
thrown about the vehicle in a crash or sudden
maneuver. People in the vehicle could be injured.
Remove the head restraints only when you need
to fold the seat, and be sure that the head
restraints are stored securely in the storage bag
and placed under the rear seat. When the seat is
returned to the passenger position, be sure the
head restraints are installed properly.
Folding the Rear Seat (2-Door Models)
If your vehicle has a rear seat, the seat can be folded flat
for more cargo space. Before folding, make sure that
nothing is under or in front of the seat. When the seat is
folded, it will lay almost flat on the floor.
When folding the seat, first
remove the head restraints.
Push the button at the top of
the seatback and slide the
head restraint out of the
height
-adjust tubes.
Detach the storage bag from the back of the rear seat.
Then, put the head restraints in the storage bag and place
the bag in the rear seat footwell, under the seat.
Page 15 of 424
yellowblue
1-9
To fold the seat, pull on the release handle at the bottom
of the seat cushion marked RELEASE.When you release the seat cushion, the seatback is
automatically released. Pull the loop on the seatback
forward and fold the seatback onto the seat cushion.
To return the seat to the passenger position, just lift up
on the seatback and push it rearward until it latches.
After returning the seat to the passenger position, pull
forward on the seatback to make sure it is locked into
place. Also, return the safety belts and head restraints to
their original positions, so they will be available for rear
seat passengers to use.
Page 16 of 424

yellowblue
1-10
Folding Rear Seats (4-Door Models)
The rear seat of the 4
-Door Utility or the second seat of
a Suburban may have a 60/40 seat, either side may be
folded down to give you more cargo space.
Before folding, place the latch portion of the center
safety belt in the center armrest. That way, the center
safety belt will be out of the way when the seat is folded
and also will be easily available for passengers to use
when the seat is returned to the passenger position. Also,
make sure that nothing is under or in front of the seat.
When the seat is folded, it will lay flat on the floor.
When folding the seat,
first remove the head
restraints. Push the release
buttons at the bottom of
each head restraint
height
-adjust post and slide
the head restraint out of the
height
-adjust tubes.
Set the head restraints aside for now. You will store
them in their proper position after you are done folding
the seat.
To fold the seat, pull up on
the strap loop at the rear of
the outer edge of the seat
cushion. Then, pull the
seat cushion up and fold
it forward.
After folding the seat cushion fully forward, pull the
seatback forward and fold the seatback down until it
is flat.
Then, store the head
restraints by sliding them
into the rear of the seat
cushion. Make sure the
posts go in all the way.
