1999 CADILLAC SEVILLE Owners Manual

yellowblue
2-5 Power Door Locks
Press the top of the power
door lock switch to unlock
all of the doors at once.
Press the down arrow to
lock the doors.
The rear power door lock switches only provide a lock
function as a safety feature. They will not unlock
the doors.
Automatic Door Locks
Close your doors and turn on the ignition. Every time
you move the shift lever out of PARK (P), all of the
doors will lock. The doors will unlock every time you
stop the vehicle and move the shift lever back into
PARK (P). If someone needs to get out while your
vehicle is not in PARK (P), have that person use the
manual or power door locks. When the door is closed
again, it will not lock automatically. Use the manual or
power door locks to lock the door again. If you need to
lock the doors before shifting out of PARK (P), use the
manual or power door locks.
Programmable Automatic Door Locks
With the vehicle in PARK (P) and the ignition in ON,
the door locks can be programmed through prompts
displayed by the Driver Information Center (DIC).
These prompts allow the driver to choose various lock
and unlock settings. For programming information, see
ªMemory and Personalization Featuresº in the Index.

yellowblue
2-6 Rear Door Security Lock
Your vehicle is equipped
with rear door security
locks that help prevent
passengers from opening
the rear doors of your
vehicle from the inside.
To Use One of These Locks
1. Move the lever on the door all the way up to the
ENGAGED position.
2. Close the door.
3. Do the same thing to the other rear door lock.
The rear doors of your vehicle cannot be opened from
the inside when this feature is in use.
To Open a Rear Door with the Security Lock
1. You may unlock the door by using the remote
keyless entry transmitter, the front door power lock
switch or by lifting the rear door lock knob.
2. Then open the door from the outside.To Cancel the Rear Door Lock
1. You may unlock the door by using the remote
keyless entry transmitter, the front door power lock
switch or by lifting the rear door manual lock. Open
the door from the outside.
2. Move the lever all the way down.
3. Do the same for the other rear door.
The rear door locks will now work normally.
Anti-Lockout Feature
Leaving your key in any ignition position with any door
open will disable the use of the power door locks and
the Remote Keyless Entry (RKE) lock function. If you
close the doors, you can lock them using the power door
locks or the (RKE) system. It is always recommended
that you remove the ignition key when locking
your vehicle.
The anti
-lockout feature can be overridden by holding
the power door lock switch for three seconds or longer.
Leaving Your Vehicle
If you are leaving the vehicle, open the door, set the
locks from the inside, get out and close the door.

yellowblue
2-7
Remote Keyless Entry (RKE) System
With this feature, you can
lock and unlock the doors,
unlock the trunk, open the
fuel door and turn on your
vehicle's interior lamps
from about 10 feet (3 m) up
to 30 feet (9 m) away using
the RKE transmitter
supplied with your vehicle.
Your remote keyless entry (RKE) system is intended to
be used as an added vehicle entry device. It is not
intended to replace a door key. It operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause
undesired operation.This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation of
the device.
Changes or modifications to this system by other than an
authorized service facility could void authorization to
use this equipment.
The range of this system is from about 10 feet (3 m) up
to 30 feet (9 m). At times you may notice a decrease in
range. This is normal for any RKE system. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:

Check to determine if battery replacement is
necessary. See the instructions that follow.

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.

If you're still having trouble, see your dealer or a
qualified technician for service.

yellowblue
2-8 Operation
When you press this button to unlock the driver's
door, the parking lamps on your vehicle will flash twice.
(You can program your vehicle so the parking lamps
will not flash. For more information, see ªRemote
Confirmationº in the Index.) Pressing this button again
within one to five seconds will unlock the other doors.
Pressing this button will also disarm the theft
-deterrent
system and turn on the interior lamps at night.
When you press this button to lock the doors, the
parking lamps will flash once and the horn will sound
once. (You can program your vehicle so the parking
lamps will not flash and/or the horn will not sound. For
more information, see ªRemote Confirmationº in the
Index.) This also arms the theft
-deterrent system when
the ignition is turned off.
Press this button to open the trunk. (The valet lock
switch must be in the OFF position.)
Press this button to open the fuel door. (The valet
lock switch must be in the OFF position.)
The numbers on the back of the RKE transmitter
correspond to Driver 1 and Driver 2. See ªMemory Seat
and Personalizationº in the Index. Remote confirmation
is not operational if any door is open.
The RKE transmitter can also be used to recall the
memory seats for up to two drivers. For more
information, see ªMemory Seat and Mirrorsº in
the Index.
Matching Transmitter(s) To Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Once your dealer has
coded the new transmitter, the lost transmitter will not
unlock your vehicle. Each vehicle can have only up to
four transmitters matched to it.
All transmitters must be present when replacement or
additional transmitters are being programmed.

yellowblue
2-9 Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about four years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
NOTICE:
When replacing the battery, use care not to touch
any of the circuitry. Static from your body
transferred to these surfaces may damage
the transmitter.
1. Use a coin (or a similar object) to pry open
the transmitter.

yellowblue
2-10
2. Once the transmitter is separated, use a pencil (or a
similar object) to remove the old battery. Do not use
a metal object.
3. Insert the new battery as the instructions under the
cover indicate.
4. Snap the transmitter back together tightly to be sure
no moisture can enter.
5. Resynchronize the transmitter. See the instructions
that follow.
Resynchronization
Pressing the transmitter buttons numerous times
(approximately 250 times) out of the vehicle's operating
range may cause the transmitter not to work. Replacing
the battery and pressing the transmitter buttons out of
range will also cause the transmitter not to work. If only
the fuel door button works, the transmitter needs to be
resynchronized to the receiver. Do this by pressing and
holding both the lock and unlock buttons on the
transmitter for about eight seconds. You must be within
range of the vehicle.
Once the transmitter has been resynchronized, the horn
will sound and the exterior lamps will flash once. The
system should now operate properly. See your dealer for
service if your transmitter still doesn't work properly.

yellowblue
2-11
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on AUTO and the temperature between
65F (18C) and 85F (29C). That will
force outside air into your vehicle. See
ªComfort Controlsº in the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock Release
The trunk lock release button
is located on the left side of
the instrument panel below
the lamp controls. To use this
feature, your vehicle must
be in PARK (P) or
NEUTRAL (N) and the
VALET lockout button must
be in the OFF position.
To open the trunk, press the trunk lock release
button upward.
You can also press the trunk release button on the
Remote Keyless Entry (RKE) transmitter to access the
trunk compartment.

yellowblue
2-12 Trunk Storage System (Option)
The trunk storage system can be used to organize many
different items inside the trunk. The storage
compartment (A) is located on top of the spare tire
cover (B).To install the storage system:
1. Remove the mat from the floor of the trunk. Remove
the handle from the spare tire panel and store it with
the spare tire.
2. Place the trunk storage system on the center of the
trunk floor (the cut
-out portion of the storage system
should be facing the front of the vehicle). Slide the
storage system fully forward.
3. Center the storage system access hole over the area
where the spare tire panel handle was located.
Position the storage system as needed and then
secure it with the retainer.
4. Attach the removable net to the slots located on the
side and front of the divider walls.
Once in place, the storage system can be moved forward
or rearward for convenience and easy accessing of
stored items.
