1999 CADILLAC SEVILLE Owners Manual

yellowblue
2-53
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Curb View Assist Mirror (If Equipped)
If your vehicle is equipped with memory mirrors, it will
also be equipped with the curb view assist mirror
feature. This feature will cause the passenger's mirror to
tilt when the vehicle is in REVERSE (R). This feature is
especially useful in allowing you to view the curb when
you are parallel parking. If further adjustment is needed
after the mirror is tilted, the power mirror controls may
be used to adjust the mirror. If the mirror control is
pressed while the passenger's mirror is tilted, the mirror
will move in that direction, but will return to its original
position once the vehicle is shifted out of REVERSE (R)
and a five
-second delay has occurred.
To program the feature, see ªCurb View Assist Mirror
Programmingº in the Index.
Storage Compartments
Glove Box
The glove box is located in front of the passenger's seat.
To lock the glove box door, insert the master key into
the lock cylinder and turn it clockwise. Turn the key
counterclockwise to unlock the door.
Map Pocket
The map/storage pockets are located on each front door as
well as on the passenger's and driver's front seatbacks.

yellowblue
2-54 Center Console Storage
The center console comes with a storage tray, a storage
compartment for CDs or tapes, a dual cupholder that
unfolds, a coinholder, an optional phone and an armrest.
The cupholder can be opened by pressing on the surface
panel located in front of the armrest and unfolding it.
Close the lid to secure.
Rear Storage Armrest
Your vehicle is equipped with a rear seat armrest which
includes an open storage compartment and a dual
cupholder that unfolds for use. Pull the armrest down by
using the attached handle. Push in the lever located at
the end of the armrest to open the storage compartment
and access the cupholder.
Wastebasket
The wastebasket is located on the passenger's side near
the footwell. To remove, pull the bottom portion
outward to release the velcro and slide the basket toward
you. Reverse the steps to reinstall.
Convenience Net
The convenience net is inside the back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over during sharp turns or
quick starts and stops.
The net is not for larger, heavier loads. Store them in the
trunk as far forward as you can. When not using the net,
hook the net to the tabs securing it to the sill plate.

yellowblue
2-55
Ashtrays and Cigarette Lighter
(Option)
The ashtrays and cigarette lighters may be ordered
through your dealer.
NOTICE:
Don't put papers or other flammable items into
your ashtrays. Hot cigarettes or other smoking
materials could ignite them, causing a
damaging fire.
Front Ashtray
Press on the lower edge of the cover of the console
located below the climate control system to reveal the
front ashtray. To clean the ashtray, lift it out by pulling
on the snuffer.
Rear Ashtray
To use the rear ashtray, lift the lid. For more
information, see your dealer.
Cigarette Lighter
The front cigarette lighter is located near the ashtray.
Press it all the way in and release. It will pop back by
itself when it's ready to light. You may also have a
lighter on the back of the center console near the rear
seat air outlet.
Note: Power to the cigarette lighter will shut off 10
minutes after the ignition is turned off. This helps to
prevent battery drainage. For more information, see
ªInadvertent Power Battery Saverº in the Index.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.

yellowblue
2-56
Sun Visors
Swing down the visor to block out glare. It can be
detached from the center mount and moved to the side.
When moved to the side, the sun visor will also move
forward and rearward. The sun visors are equipped with
a storage flap that can be used for small items such as
toll tickets.
There is also a secondary visor attached separately to
the headliner.
Lighted Visor Vanity Mirror
Turn the sunshade down and lift the cover to see the
mirror. Move the slide switch up or down to brighten or
dim the lamp.
Cellular Telephone (Option)
Your vehicle has been prewired for dealer installation of
a dual
-mode (analog/digital) cellular telephone. A fixed
mobile or a portable hand
-held system are available.
Either system has steering wheel telephone controls and
information output through the Driver's Information
Center (DIC). Voice activation and hands
-free operation
are standard features. For more information, contact
your dealer. A user's guide is provided with
the telephone.
OnStar
System (Option)
OnStar is a vehicle communications service which may
be ordered through your dealer. The following OnStar
services are available 24 hours a day:

Automatic Notification of Front and Side
Air Bag Deployment

Emergency Services

Theft Detection/Notification and
Stolen
-Vehicle Tracking

Remote Door Unlock

Roadside Assistance with Location

Route Support

Convenience Services

Remote Diagnostics

Hands
-Free, Voice-Activated Cellular Telephone
For more information, contact your dealer.
Assist Handles
An assist handle above each door can be used when
getting out of your vehicle.

yellowblue
2-57
Garment Hooks
For your convenience, a garment hook is attached to
each rear assist handle.
Umbrella Holder (If Equipped)
The driver's front seat cushion may come equipped with
an umbrella holder. Gently slide the umbrella into the
slot located under the front portion of the driver's
seat cushion.
Floor Mats
Your vehicle is equipped with rubber-backed front and
rear floor mats. Keep them clean by vacuuming and
using a spot cleaner, if necessary. Do not machine wash.
Sunroof (Option)
There are two control switches to operate the
sunroof
-- one to open/close or express-open the
sunroof and the other to vent the sunroof. The control
switches work only when the ignition is on or when the
ignition is off and the Retained Accessory Power (RAP)
is active.
Press and hold the ROOF
switch rearward to the first
position to open the glass
panel and sunshade. The
sunshade can also be
opened or closed by hand.
To close the glass panel,
press and hold the ROOF
switch forward.
Press and release the ROOF switch rearward to the
second position to express
-open the glass panel. If you
want to stop the glass panel in a partially
-open position,
press either the ROOF or VENT switch in any direction.
Note: If you press and hold the ROOF switch in the
express
-open position for more than one second, the
sunroof will operate manually.

yellowblue
2-58
To vent the sunroof, press
and hold the upper part of
the VENT switch. The
sunshade must be opened by
hand. To close, press and
hold the lower part of the
VENT switch.Universal Transmitter (Option)
K1±62±1116±W
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation.

yellowblue
2-59
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device
must accept any interference, including interference that
may cause undesired operation of the device.
Changes and modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
Programming the Universal Transmitter
Do not use the Universal Transmitter with any garage
door opener that does not have the ªstop and reverseº
safety feature. This includes any garage door opener
model manufactured before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming.
Your vehicle's engine should be turned off while
programming the transmitter. Follow these steps to
program up to three channels:
1. If you have previously programmed a transmitter
channel, proceed to Step 2. Otherwise, hold down
the two outside buttons on the Universal Transmitter
until the indicator light begins to flash rapidly (after
20 seconds). Then release the buttons. This
procedure initializes the memory and erases any
previous settings for all three channels.2. Decide which one of the three channels you want to
program. Hold the end of the hand
-held transmitter
about 2 to 5 inches (5 to 13 cm) away from the
surface of the Universal Transmitter so that you can
still see the indicator light.
3. Using both hands, press the hand
-held transmitter
button and the desired button on the Universal
Transmitter. Continue to press both buttons
through Step 4.
4. Hold down both buttons until you see the indicator
light on the Universal Transmitter flash slowly and
then rapidly. The rapid flashing indicates that the
Universal Transmitter has been programmed.
Release both buttons once the indicator light starts
to flash rapidly.
If you have trouble programming the Universal
Transmitter, make sure that you have followed the
directions exactly as described. The Universal
Transmitter may not work with older garage door
openers that do not meet current Federal Consumer
Safety Standards. If you cannot program the transmitter
after repeated attempts, refer to ªRolling Code
Programmingº later in this section or contact the
Universal Transmitter manufacturer at 1
-800-355-3515.

yellowblue
2-60
Be sure to keep the original hand-held transmitter
in case you need to erase and reprogram the
Universal Transmitter.
Note to Canadian Owners: During programming, the
hand
-held transmitter may automatically stop
transmitting after one or two seconds. In this case, you
should press and re
-press the button on the hand-held
transmitter every two seconds without ever releasing the
button on the Universal Transmitter. Release both
buttons when the indicator light on the Universal
Transmitter begins to flash rapidly.
Operating the Universal Transmitter
Press and release the appropriate button on the Universal
Transmitter. The indicator light comes on while the
signal is being transmitted.
The Universal Transmitter is disabled when the valet
lock switch inside the glove box is activated. For more
information, see ªValet Lockº in the Index.
If the hand
-held transmitter appears to program the
Universal Transmitter but does not open your garage
door, and if the garage door opener was manufactured
after 1996, the garage door opener may have a ªrolling
codeº system. A rolling code system changes the code
of the garage door opener every time you open or close
the garage door.To determine if you have this system, press the button
on the Universal Transmitter that you have programmed
already. If the indicator light on the Universal
Transmitter flashes rapidly for two seconds and then
turns solid, the garage door opener has a rolling code
system. In a rolling code system, the garage door motor
head unit must be trained to the Universal Transmitter.
ªRolling Codeº Programming (If Equipped)
If you have not previously programmed the hand-held
transmitter to the Universal Transmitter, see
ªProgramming the Universal Transmitterº listed
previously. If you have completed this programming
already, you now need to train the garage door opener
motor head unit to recognize the Universal Transmitter.
Refer to your garage door opener owner's manual for
the proper transmitter training procedure for your garage
door opener brand.
1. Find the training button on the garage door opener
motor head unit. The exact location and color of the
button may vary by garage door opener brand. If you
have difficulty finding the training button, refer to
your garage door opener owner's manual.
