1999 CADILLAC CATERA Owners Manual

yellowblue
6-59
Fuse Usage
22 Headlamp Switch, LH
Low
-Beam Headlamp
23 LH Parking Lamp and Turn Signal
Lamps, LH Rear Sidemarker Lamp,
Multifunction Relay, LH Stoplamp
and Taillamp
24 Lifting Magnet, BCM, Gage Cluster
25 Sunroof Actuator
26 Headlamp Switch, RH and LH Front
Sidemarker Lamp, Middle Taillamp, RH
and LH Rear License Plate Lamp, Radio,
Automatic Transmission Control
Indicator, Heater and A/C Control
27 Automatic Level Control Sensor, Rear
Suspension Leveling Air Compressor
and RelayFuse Usage
28 Door Lock Relay, OnStar

Connector
29 Multifunction Relay
30 RH Parking Lamp and Turn Signal Lamp,
RH Rear Sidemarker Lamp, RH
Stoplamp and Taillamp
31 RH Low
-Beam Headlamp Turn
Signal Switch
32 RH High
-Beam Headlamp Relay
33 Blower Controller, A/C
Compressor Relay
34 Heated Rear Window Defogger Relay
35 Passenger Seat Adjuster Switch, Driver
Seat Adjuster Memory Module

yellowblue
6-60
Relay Box
The relay box is located on the lower part of the
instrument panel, to the right of the steering column.Relay Usage
I Daytime Running Lamps
II Automatic Level Control
III Rear Window Defogger, Heated Mirrors
IV Hazard Warning Flashers
V High
-Beam Headlamps II (RH)
VI Horn
VII Parking Lamps and Turn Signal Lamps
VIII Low
-Beam Headlamps
IX Not Used
X Not Used
XI High
-Beam Headlamps I (LH)

yellowblue
6-61
Engine Compartment Relay Center
The relay center is located next to the battery on the
driver's side of the engine. Lift the cover to access.
Fuse/Relay Usage
1 Secondary Air Injection Pump
(Relay K12)
2 Fan Control (Relay K67)
3 Auxiliary Water Pump (Relay K22)
4 Windshield Wiper Motor (Relay K8)
5 A/C Compressor Relay (K60)

yellowblue
6-62
Fuse/Relay Usage
6 Fan Control Relay (K87)
7 Fan Control Relay (K26)
8 Fuse 50
9 Fan Control Relay (K28)
10 Engine Controls Power Relay (K43)
12 Fuse 40
15 Fuse 52
16 Connector C110
17 Coolant Fan Test Connector
Fan Control
18 Fuse 42 (A), Fuse 49 (B)
19 Fan Control Relay (K52)
20 Fuel Pump Relay (K44)
29 Fuse 43Replacement Bulbs
Application Bulb Number
Composite Headlamps
Inner High Beam 90512338. . . . . . . . . . . . . . . . . . .
Outer Low Beam 90512338. . . . . . . . . . . . . . . . . . .
Front Turn Signal Lamp 90487485. . . . . . . . . . . . . . .
Rear Turn Signal Lamp and Taillamp 90002521. . . .
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions. Please refer to
ªRecommended Fluids and Lubricantsº in the
Maintenance Schedule booklet for more information.
Transmission 7.0 quarts (6.6 L). . . . . . . . . . . . . . . . .
Engine Crankcase
Oil Change With Filter 6.0 quarts (5.75 L). . . . . . .
Engine Cooling System 10.57 quarts (10.0 L). . . . . .
Fuel Tank 16.0 gallons (60.56 L). . . . . . . . . . . . . . . . .
R
-134a Refrigerant 2.09 lbs. (0.95 kg). . . . . . . . . . . .
NOTE: All capacities are approximate. When adding, be
sure to fill to the approximate level, as recommended in
this manual. Recheck fluid level after filling.

yellowblue
6-63 Wheel Bolt Torque
80 lb-ft (110 N´m)
Engine Specifications
Displacement 181 cubic inches (2 962 cc). . . . . . . . .
Type 3.0 L DOHC V6. . . . . . . . . . . . . . . . . . . . . . . . .
VIN Engine Code R. . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 200 (bhp) @ 6000 rpm. . . . . . . . . . . . . .
149 (kW) @ 6000 rpm
Torque 192 (lb
-ft) @ 3600 rpm . . . . . . . . . . . . . . . . .
260 (N´m) @ 3600 rpm
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Starts To Open 198
F (92
C) . . . . . . . . .
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Air Filter Element 90509318. . . . . . . . . . . . . . . . . . .
Fuel Filter Element 90542540. . . . . . . . . . . . . . . . . .
Engine Oil Filter 25010792. . . . . . . . . . . . . . . . . . . .
Passenger's Compartment Air Filter 90510338. . . . .
Spark Plugs 90541059 (Bosch Plug = FLR9LTE). . .
Thermostat 90502201. . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wiper Blades 9118382 (RH). . . . . . . . . . .
9118381 (LH)
Vehicle Dimensions
Wheel Base 107.5 inches (273.0 cm). . . . . . . . . . . . .
Length 194.0 inches (492.8 cm). . . . . . . . . . . . . . . . .
Height 56.4 inches (143.2 cm). . . . . . . . . . . . . . . . . . .
Width 70.3 inches (178.6 cm). . . . . . . . . . . . . . . . . . .
Front Tread 59.3 inches (150.6 cm). . . . . . . . . . . . . . .
Rear Tread 59.8 inches (152.0 cm). . . . . . . . . . . . . . .

yellowblue
6-64
-NOTES

7-
yellowblue
7-1
Section 7 Customer Assistance Information
Here you will find out how to contact Cadillac if you need assistance. This section also tells you how to obtain service
publications and how to report any safety defects.
7
-2 Customer Satisfaction Procedure
7
-3 Customer Assistance for Text Telephone
(TTY) Users
7
-4 Customer Assistance Offices
7
-5 GM Mobility Program for Persons
with Disabilities
7
-5 Roadside Service
7
-7 Roadside Service for the Hearing or
Speech Impaired
7
-8 Courtesy Transportation
7
-8 Transportation Options7
-10 Warranty Information
7
-10 Reporting Safety Defects to the United
States Government
7
-11 Reporting Safety Defects to the
Canadian Government
7
-11 Reporting Safety Defects to General Motors
7
-11 Ordering Service and Owner Publications
in Canada

yellowblue
7-2
Customer Satisfaction Procedure
Your satisfaction and goodwill are important to your
dealer and to Cadillac. Normally, any concerns with the
sales transaction or the operation of your vehicle will be
resolved by your dealer's sales or service departments.
Sometimes, however, despite the best intentions of all
concerned, misunderstandings can occur. If your
concern has not been resolved to your satisfaction, the
following steps should be taken:STEP ONE -- Discuss your concern with a member of
dealership management. Normally, concerns can be
quickly resolved at that level. If the matter has already
been reviewed with the sales, service or parts manager,
contact the owner of the dealership or the general manager.
STEP TWO -- If after contacting a member of
dealership management, it appears your concern cannot be
resolved by the dealership without further help, contact
the Cadillac Customer Assistance Center, 24 hours a day, by
calling 1-800-458-8006. In Canada, contact GM of Canada
Customer Communication Centre in Oshawa by calling
1-800-263-3777 (English) or 1-800-263-7854 (French).
We encourage you to call the toll-free number in order
to give your inquiry prompt attention. Please have the
following information available to give the Customer
Assistance Representative:

Vehicle Identification Number (This is available
from the vehicle registration or title, or the plate
at the top left of the instrument panel and visible
through the windshield.)

Dealership name and location

Vehicle delivery date and present mileage
