1999 CADILLAC CATERA Owners Manual

yellowblue
2-51
NOTICE:
Don't put papers or other flammable items into
the ashtrays. Hot cigarettes or other smoking
materials could ignite them, causing a
damaging fire.
The cigarette lighter is located next to the ashtray. Press
it all the way in and release. It will pop back by itself
when it's ready to light. You also have a lighter on the
back of the center console near the rear seat air outlet.
These lighters (receptacles) work at all times, even when
your vehicle's ignition has been turned off.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
Sun Visors
Illuminated Visor Vanity Mirror
Turn the sunshade down and lift the cover to see the
mirror. Lighting is automatic.
Rear Sunshade (Option)
The power rear sunshade helps reduce the amount of
heat and light from the sun entering through the rear
window. The sunshade increases the comfort level of the
rear seat passengers as well as keeping your vehicle a
little cooler when it's parked in a sunny area.
This button is located to the
right of the shift lever on
the center console.
To use, slide the button
rearward
-- the button
returns to its original
position when released.
The rear sunshade
automatically raises. To
lower the sunshade, slide
the button rearward again.

yellowblue
2-52
Cellular Telephone (Option)
Your vehicle has been prewired for dealer installation of
a dual
-mode (analog/digital) cellular portable telephone.
Voice activation and hands
-free operation are standard
features. For more information, contact your dealer.
A user's guide is provided with the telephone.
OnStar
System (Option)
OnStar is a vehicle communications service which may
be ordered through your dealer. The following OnStar
services are available 24 hours a day:

Roadside Service with Location

Emergency Services Button

Remote Door Unlock

Theft Detection/Notification and
Stolen
-Vehicle Tracking

Automatic Notification of Air Bag Deployment

Concierge/Customer Convenience Services
For more information, contact your dealer.
Assist Handles
A handle above each door can be used when getting out
of your vehicle.
Garment Hooks
For convenience, you will find garment hooks attached
to each assist handle.
Floor Mats
Your vehicle is equipped with rubber-backed front and
rear floor mats. Keep them clean by vacuuming and
using a spot cleaner, if necessary. Do not machine wash.
Sunroof (Option)
The express-open sunroof
can increase ventilation and
it includes a sliding glass
panel and a sliding
sunshade. Power is supplied
to the sunroof when the
ignition key is turned
to ON.

yellowblue
2-53
When you stop your vehicle and turn the ignition key to
LOCK, you can still use the sunroof. The electrical
power to operate the sunroof will not shut off until a
door is opened
-- there is no time limit to this feature.
As soon as a door is opened, sunroof movement will
stop immediately. See ªRetained Accessory Powerº in
the Index.
A. Fully Open
B. About 80% Open
C. About 50% Open
D. About 25% OpenE. Fully Closed
F. About 40% Tilted
G. Fully TiltedTurning the control dial to position A fully opens the
glass panel and sunshade. The sunshade can also be
opened by hand. If you want to stop the roof in a
partially opened position, turn the control dial to any
position between A and E. The positions range from
about 25 percent open to approximately 80 percent
open. Turn the dial to position E to fully close the glass
panel. To close the sunshade, pull it forward manually.
To raise the glass panel, turn the control dial
counterclockwise to one of the three tilt positions. The
positions range from about 40 percent tilted (F) to fully
tilted (G). To close the vent, turn the dial clockwise to
position E.

yellowblue
2-54 Anti-Pinch Feature
If a hand, an arm or another object is in the way of the
power sunroof closing, the glass panel will stop at the
obstruction and open to a preset factory position.
CAUTION:
Pressing and holding the power sunroof control
dial in the up position will turn off the anti
-pinch
feature. If this happens, the sunroof won't stop if
something gets in the way. You or others could be
injured, and your sunroof could be damaged. Be
careful not to press and hold the power sunroof
control dial in the up position.
Manual Operation
If a failure in the power supply system occurs, the
sunroof can be manually closed by inserting a
screwdriver into the slot as shown. Turning the
screwdriver counterclockwise will close the sunroof.
The screwdriver is provided in the tool kit in the trunk
(with the jack).

yellowblue
2-55 Programming the Sunroof
If the battery on your vehicle has been recharged,
disconnected or is not working, you will need to
reprogram the sunroof following these steps. Refer to
the illustration under ªSunroofº for control
dial positions.
With your vehicle's ignition on:
1. If the sunroof is closed, turn the control dial to
position E. Hold the dial in position for about
five seconds.
If the sunroof is open, turn the control dial to E and
hold until the glass panel has closed. Now continue
holding the dial for approximately five
more seconds.
2. Turn the control dial to position G and hold until the
sunroof is fully tilted (about three seconds after the
motor has stopped).
3. Now turn the control dial to position E and keep
holding until the sunroof is fully closed (about three
seconds after the motor has stopped).4. Turn the control dial to position A and hold until the
sunroof is fully open (about three seconds after the
motor has stopped).
5. Turn to position E and keep holding the control dial
until the sunroof has fully closed (about three
seconds after the motor has stopped).
The sunroof is now programmed.
Note: If the sunroof keeps opening after you attempt to
close it once it has been programmed, you will need to
repeat Steps 2 through 5 (up to three times if needed).
If you are still having problems, consult your dealer
for service.
Also keep in mind that if something is in the way of the
sunroof closing during programming and you continue
to program the sunroof, the sunroof will only open or
close to the spot where the obstruction occurred. You
will need to reprogram the sunroof again, making sure
that the object has been removed.

yellowblue
2-56
Universal Transmitter (If Equipped)
This transmitter allows you to consolidate the functions
of up to three individual hand
-held transmitters. It will
operate garage doors and gates, or other devices
controlled by radio frequency such as home/office
lighting systems.The Universal Transmitter will learn and transmit the
frequencies of most current transmitters and is powered
by your vehicle's battery and charging system.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of
the device.
Changes and modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.

yellowblue
2-57 Programming the Universal Transmitter
Do not use the Universal Transmitter with any garage
door opener that does not have the ªstop and reverseº
safety feature. This includes any garage door opener
model manufactured before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming.
Your vehicle's engine should be turned off while
programming the transmitter. Follow these steps to
program up to three channels:
1. If you have previously programmed a transmitter
channel, proceed to Step 2. Otherwise, hold down
the two outside buttons on the Universal Transmitter
until the indicator light begins to flash rapidly (after
20 seconds). Then release the buttons. This
procedure initializes the memory and erases any
previous settings for all three channels.
2. Decide which one of the three channels you want to
program. Hold the end of the hand
-held transmitter
about 2 to 5 inches (5 to 13 cm) away from the
surface of the Universal Transmitter so that you can
still see the indicator light.3. Using both hands, press the hand
-held transmitter
button and the desired button on the Universal
Transmitter. Continue to press both buttons through
Step 4.
4. Hold down both buttons until you see the indicator
light on the Universal Transmitter flash slowly and
then rapidly. The rapid flashing indicates that the
Universal Transmitter has been programmed.
Release both buttons once the indicator light starts to
flash rapidly.
If you have trouble programming the Universal
Transmitter, make sure that you have followed the
directions exactly as described. The Universal
Transmitter may not work with older garage door
openers that do not meet current Federal Consumer
Safety Standards. If you cannot program the transmitter
after repeated attempts, refer to ªRolling Code
Programmingº later in this section or contact the
Universal Transmitter manufacturer at 1
-800-355-3515.
Be sure to keep the original hand
-held transmitter
in case you need to erase and reprogram the
Universal Transmitter.

yellowblue
2-58
Note to Canadian Owners: During programming, the
hand
-held transmitter may automatically stop
transmitting after one or two seconds. In this case, you
should press and re
-press the button on the hand-held
transmitter every two seconds without ever releasing the
button on the Universal Transmitter. Release both
buttons when the indicator light on the Universal
Transmitter begins to flash rapidly.
Operating the Universal Transmitter
Press and release the appropriate button on the Universal
Transmitter. The indicator light comes on while the
signal is being transmitted.
If the hand
-held transmitter appears to program the
Universal Transmitter but does not open your garage
door, and if the garage door opener was manufactured
after 1996, the garage door opener may have a ªrolling
codeº system. A rolling code system changes the code
of the garage door opener every time you open or close
the garage door.To determine if you have this system, press the button
on the Universal Transmitter that you have programmed
already. If the indicator light on the Universal
Transmitter flashes rapidly for two seconds and then
turns solid, the garage door opener has a rolling code
system. In a rolling code system, the garage door motor
head unit must be trained to the Universal Transmitter.
ªRolling Codeº Programming (If Equipped)
If you have not previously programmed the hand-held
transmitter to the Universal Transmitter, see
ªProgramming the Universal Transmitterº listed
previously. If you have completed this programming
already, you now need to train the garage door opener
motor head unit to recognize the Universal Transmitter.
Refer to your garage door opener owner's manual for
the proper transmitter training procedure for your garage
door opener brand.
