1998 YAMAHA T105 Owners Manual

4. Once the motorcycle has reached a
high enough speed to change gears,
close the throttle.
5. Shift into SECOND gear.
6. Open the throttle gradually.
7. Follow the same procedure when
shifting to the next higher gear.
8. The speed can be adjusted by opening
and closing the throttle grip. Turning it
toward you increases the speed, and
turning it in the opposite direction de-
creases the speed.
Recommend shift point
32
Gear position Recommend speed
1 st 0~20 km/h
2 nd 20~40 km/h
3 rd 30 km/h~
4 th (Top) 40 km/h~
T105(E) O/M-2 9/11/01 11:17 AM Page 32 (1,1)

To decelerate
1. Close the throttle and apply both the
front and the rear brakes at the same
time to slow the motorcycle.
2. Downshift through the gears and
when the motorcycle is almost com-
pletely stopped, shift into nutral.
Recommend shift point:
33
Gear position Recommend speed
4th
3rd 0~40 km/h
3rd 2rd 0~30 km/h
2nd 1st 0~15 km/h
T105(E) O/M-2 9/11/01 11:17 AM Page 33 (1,1)

EAF30000*Engine break-in
There is never a more important period in
the life of your motorcycle than the period
between zero and 1,000 km. Because the
engine is brand new, prolonged full throttle
operation, or any condition which might
result in excessive heating of the engine
must be avoided during this period.EAF308001. 0~150 km:
Avoid prolonged operation above 1/3
throttle. Vary the speed of the motor-
cycle from time to time. Do not oper-
ate it at one set throttle position.
2. 150~500 km:
Avoid prolonged operation above 1/2
throttle. Rev the engine freely through
the gears, but do not use full throttle
at any time.
34
0~500Km
1/21/3
0~150Km
T105(E) O/M-2 9/11/01 11:17 AM Page 34 (1,1)

3. 500~1,000 km:
Avoid cruising speeds in excess of 3/4
throttle.EUU40400cCAfter 1,000 km of operation, be sure to re-
place the engine oil.4. 1,000 km and beyond:
Avoid prolonged full-throttle opera-
tion. Vary speed occasionally.EUU32200cCIf any engine trouble should occur during
the break-in period, consult a Yamaha
dealer immediately.
35
500~1000Km
3/4
1000Km~
T105(E) O/M-2 9/11/01 11:17 AM Page 35 (1,1)

EAF40000Parking
When parking the motorcycle, stop the en-
gine and remove the ignition key.EUU63000wThe muffler and exhaust pipe are hot.
Park the motorcycle in a place where
pedestrians or children are not likely to
touch the motorcycle. Do not park the mo-
torcycle on a slope or soft ground; the mo-
torcycle may overturn.
36
T105(E) O/M-2 9/11/01 11:17 AM Page 36 (1,1)

EAH00000
PERIODIC
MAINTENANCE AND
MINOR REPAIR
EAH00400Periodic inspection, adjustment and lubri-
cation will keep your motorcycle in the
safest and most efficient condition possi-
ble. Safety is an obligation of the motorcy-
cle owner. The maintenance and lubrica-
tion schedule chart should be considered
strictly as a guide to general maintenance
and lubrication intervals.EUU63200wIf you are not familiar with motorcycle ser-
vice, this work should be done by a
Yamaha dealer.
37
T105(E) O/M-2 9/11/01 11:17 AM Page 37 (1,1)

EAH10101*Tool kit
The tools provided in the owner’s tool kit
are to assist you in the performance of pe-
riodic maintenance. However, some other
tools such as a torque wrench are also nec-
essary to perform the maintenance correct-
ly.EUU67100wModifications to this motorcycle not ap-
proved by Yamaha may cause loss of per-
formance, and render it unsafe for use.
Consult a Yamaha dealer before attempt-
ing any changes.
38
1Tool kit
T105(E) O/M-2 9/11/01 11:17 AM Page 38 (1,1)

39
* Valve(s)Check valve clearance. Adjust if necessary.2222Spark plug Check condition. Clean or replace if necessary.2222Air filterClean. Replace if necessary.22
* CarburetorCheck idle speed/stater operation.
2222
Adjust if necessary.
*
Fuel lineCheck fuel hose and vacuum pipe for cracks or
22damage. Replace if necessary.
Engine oilReplace (Warm engine before draining).22EVERY 2,000 km* Engine oil filterCheck/clean/replace if necessary2222BrakeCheck operation/Adjust if necessay22
Check rear arm assembly for looseness.
* Rear arm pivotCorrect if necessary. Moderately repack every.2
16,000 km***
* WheelsCheck balance/damage/runout/spoke tightness.
22Replace if necessary.
* Wheel bearingsCheck bearing assembly for looseness/damage.
22 2
Replace if damaged.
INITIAL EVERY
ITEM REMARKS
500 km 2,000 km 4,000 km 8,000 km
PERIODIC MAINTENANCE/LUBRICATION
T105(E) O/M-2 9/11/01 11:17 AM Page 39 (1,1)
