CLEANING AND
STORAGE
EAK01302*A. CLEANING
Frequent, thorough cleaning of your mo-
torcycle will not only enhance its appear-
ance but will improve its general perfor-
mance and extend the useful life of many
components.
1. Rinse the dirt and degreaser off with a
garden hose.EUU34602cCExcessive hose pressure may cause water
seepage and deterioration of wheel bear-
ings, front fork, brakes, transmission seals
and electrical parts.2. After cleaning the motorcycle, dry all
surfaces with a chamois, clean towel,
or soft absorbent cloth.3. Dry the chain and lubricate it to pre-
vent rust.
4. Automotive-type wax may be applied
to all painted and chrome-plated sur-
faces. When finished, start the engine
and let it idle for several minutes.
EAK00700B. STORAGE
Long term storage (60 days or more) of
your motorcycle will require some preven-
tive procedures to guard against deteriora-
tion. After thoroughly cleaning the motor-
cycle, prepare for storage as follows:
1. Drain the fuel tank, fuel lines, and car-
buretor float bowl(s).
2. Remove the empty fuel tank, pour a
cup of SAE 10W30 or 20W40 motor oil
in the tank, shake the tank to coat the
inner surfaces thoroughly and drain
off the excess oil. Reinstall the tank.
64
T105(E) O/M-3 9/11/01 11:17 AM Page 64 (1,1)

3. Remove the drive chain. Thoroughly
clean the chain with solvent and lubri-
cate it. Reinstall the chain or store it in
a plastic bag (tied to frame for safe-
keeping).
4. Lubricate all control cables.
5. Block up the frame to raise both
wheels off the ground.
6. Tie a plastic bag over the exhaust pipe
outlet to prevent moisture from enter-
ing.
7. If storing in a humid or salt-air atmos-
phere, coat all exposed metal surfaces
with a light film of oil. Do not apply oil
to any rubber parts or the seat cover.
8. Remove the battery and charge it.
Store it in a dry place and recharge it
once a month. Do not store the bat-
tery in an excessively warm or cold
place (less than 0°C (32°F) or more
than 30°C (86°)).
EUU05800NOTE:
Make any necessary repairs before storing
the motorcycle.
65
T105(E) O/M-3 9/11/01 11:17 AM Page 65 (1,1)

66
Model
Dimensions:
Overall length 1,870 mm
Overall width 655 mm
Overall height 1,050 mm
Seat height 755 mm
Wheelbase 1,190 mm
Minimum ground clearance 130 mm
Basic weight:
With oil and full fuel tank 96 kg
Minimum turning radius: 1,800 mm
Engine:
Type Air cooled 4 stroke, SOHC
Cylinder arrangement Forward inclined single cylinder
Displacement 101.8 cm
3
Bore
×stroke 49.0
×54.0 mm
Compression ratio 9.0 : 1
Starting system Electric and kick starter
Lubrication system: Wet sump
SPECIFICATIONS
T105(E) O/M-3 9/11/01 11:17 AM Page 66 (1,1)

67
Model
Engine oil (4-cycle):
Type Yamalibe 4 (20W40) or equivalent
SAE 20W40 type SE motor oil
Capacity
Periodic oil change 0.8 L
Total amount 1.0 L
Air filter: Wet type element
Fuel:
Type Regular gasoline
Tank capacity 4.3 L
Reserve amount
Carburetor:
Type/manufacturer VM16SH/MIKUNI
T105(E) O/M-3 9/11/01 11:17 AM Page 67 (1,1)

68
Model
Spark plug:
Type/manufacturer CR7HSA/NGK
Gap 0.6~0.7 mm
Clutch type: Wet, centrifugal, automatic
Transmission:
Primary reduction system Spur gear
Primary reduction ratio 67/18 (3.722)
Secondary reduction system Chain drive
Secondary reduction ratio 37/15 (2.467)
Transmission type Constant mesh 4 speed
Operation Left foot operation
Gear ratio:
1st 38/12 (3.167)
2nd 33/17 (1.941)
3rd 29/21 (1.381)
4th 23/21 (1.095)
T105(E) O/M-3 9/11/01 11:17 AM Page 68 (1,1)

69
Model
Chassis:
Frmae type Steel Tube underbone
Caster angle 27°
Trail 78 mm
Tire:
Type With tube
Size – Front 2.25-17-4PR
Rear 2.50-17-4PR
Brake:
Front brake type Drum brake
Operation Right hand operation
Rear brake type Drum brake
Operation Right foot operation
Suspension:
Front Telescopic fork
Rear Swing arm
Shock absorber:
Front Coil spring/oil damper
Rear Coil spring/oil damper
T105(E) O/M-3 9/11/01 11:17 AM Page 69 (1,1)

70
Model
Wheel travel:
Front 80 mm
Rear 65 mm
Electrical:
Ignition system C.D.I
Generator system Flywheel magneto
Battery type/capacity 12V5AH
Headlight type: Krypton bulb
Bulb wattage/quantity:
Headlight 12V30W/30W
Tail/brake light 12V/5W/21W
Flasher light 12V10W ×4
Meter light 12V1.7W ×1
Indicator light wattage/quantity:
“NEUTRAL” 12V3.4W ×1
“HIGH BEAM” 12V3.4W ×1
“TURN” 12V3.4W ×1
“TOP” 12V3.4W ×1
T105(E) O/M-3 9/11/01 11:17 AM Page 70 (1,1)

YAMAHA MOTOR CO., LTD.
