Fuel
Fuel type:
Premium unleaded gasoline, Octane Rat-
ing 91 (Research Octane Number 96)
or higher for optimum engine perfor-
mance. However, if such premium type
cannot be obtained, you may temporarily
use unleaded gasoline with an Octane
Rating as low as 87 (Research Octane
Number 91).
Fuel tank capacity, L (gal., Imp. gal.):
70 (18.5, 15.4) Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
Intake 0.15Ð0.25 (0.006Ð0.010)
Exhaust 0.25Ð0.35 (0.010Ð0.014)
Spark plug type:
2JZ- GE engine
DENSO PK16TR11
NGK BKR5EKPB11
2JZ- GTE engine
DENSO PK20R11
NGK BKR6EP11
Spark plug gap, mm (in.):
1.1 (0.043)
ENGINE LUBRICATION
Oil capacity (drain and ref
ill),
L (qt., Imp. qt.):
2JZ- GE engine
With filter 5.2 (5.5, 4.6)
Without filter 4.9 (5.2, 4.3)
2JZ- GTE engine
With filter 5.0 (5.3, 4.4)
Without filter 4.7 (5.0, 4.1)
Oil grade:
API grade SH, ºEnergy- Conserving IIº or
SJ, ºEnergy- Conservingº multigrade engine
oil or ILSAC multigrade engine oil is rec-
ommended. Recommended oil viscosity (SAE):
2JZ- GE engine
2JZ- GTE engine

SUPRA (U)187
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
2JZ-GE engine 8.0 (8.5, 7.0)
2JZ- GTE engine
With manual transmission
8.9 (9.4, 7.8)
With automatic transmission
8.8 (9.3, 7.7)
Coolant type:
With ethylene- glycol antifreeze
(Do not use alcohol type.)
BATTERY
Open voltage
*
at 20 C (68 F):
12.6Ð12.8 V Fully charged
12.2Ð12.4 V Half charged
11.8Ð12.0 V Discharged
* : Voltage that is checked 20 minutes after
the key is removed with all the lights
turned off
Charging rates:
5 A max. CLUTCH
Pedal freeplay, mm (in.):
5Ð15 (0.2±0.6)
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3
MANUAL TRANSMISSION
Oil capacity, L (qt., Imp. qt.):
1.8 (1.9, 1.6)
Oil type:
ESSO ATF DEXRON
D- 21065,
TOYOTA GEAR OIL V160 or
equivalent
AUTOMATIC TRANSMISSION
Fluid capacity (drain and ref ill),
L (qt., Imp. qt.):
2JZ- GE engine Up to 1.6 (1.7, 1.4)
2JZ- GTE engine Up to 1.9 (2.0, 1.7)
Fluid type: Automatic transmission fluid TYPE
T - IV or equivalent DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.):
1.35 (1.43 1.19)
Oil type:
Hypoid gear oil API GL- 5
Recommended oil viscosity:
Above ±18
5C (0 5F)
SAE 90
Below ±18 5C (0 5F)
SAE 80W or 80W- 90 BRAKES
Minimum pedal clearance when depressed
with the pressure of 490 N (50 kgf, 110
lbf) with the engine running, mm (in.):
2JZ-GE engine 72 (2.8)
2JZ- GTE engine 70 (2.8)

SUPRA (U)
188
Pedal freeplay, mm (in.):
1Ð6 (0.04±0.24)
Pad wear limit, mm (in.):
1.0 (0.04)
Lining wear limit, mm (in.):
1.0 (0.04)
Parking brake adjustment when pulled with
the foce of 196 N (20 kgf, 44 lbf):
5Ð8 clicks
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel freeplay:
Less than 30 mm (1.2 in.)
Power steering fluid type:
Automatic transmission fluid DEXRON
II
or III Tires
Tire size:
Spare tire
T145/70 R 17 Except spare tire
2JZ- GE engine
225/50R 16 92V (for front use only)
245/45R 16 94V (for rear use only)
2JZ- GTE engine
235/45ZR 17 (for front use only)
255/40ZR 17 (for rear use only)
Tire pressure, kPa (kgf/cm 2
or bar, psi):
Spare tire 420 (4.2, 60)
Except spare tire 230 (2.3, 33)
Wheel size: 225/50R 16 92V 16 y 8JJ
245/45R 16 94V 16 y 9JJ
235/45ZR 17 17 y 8JJ
255/40ZR 17 17 y 9.5JJ
T145/70R 17 17 y 4T
Wheel nut torque, N´m (kgf´m, ft´lbf): 103 (10.5, 76) Fuses
80050F09

SUPRA (U)189
80050F10
80050F08
Fuses (type A) 1. EFI NO.2 30 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
2. EFI NO.1 30 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
3. AM2 30 A: Starter system
4. FOG 15 A: Front fog lights
5. HAZ- HORN 15 A: Emergency flashers,
horns
6. TRAC 7.5 A: Traction control system
7. ETCS 15 A: Electronic Traction Control
System
8. ALT- S 7.5 A: Charging system 9. DOME 7.5 A:
Interior lights, personal
lights, door courtesy lights, luggage
compartment light, ignition switch light,
open door warning light, theft deterrent
system
10. RAD NO.1 20 A: Radio cassette tape
player
11. HEAD (RH) 15 A: Right- hand headlight
12. HEAD (LH) 15 A: Left- hand headlight
13. 30 A: Spare fuse
14. 7.5 A: Spare fuse
15. 15 A: Spare fuse
16. WIPER 20 A: Windshield wipers and
washer, rear window wiper and washer
17. HTR 7.5 A: Air conditioning system
18. ST 7.5 A: Starter system
19. IGN 7.5 A: Charging system, discharge
warning light, multiport fuel injection
system/s equential multiport fuel injec-
tion system, SRS airbag system
20. PANEL 10 A: Instrument panel lights,
instrument panel lights control
21. MIR- HTR 10 A: Mirror heaters
22. TURN 7.5 A: Turn signal lights
23. STOP 15 A: Stop lights, cruise control
system cancel device

SUPRA (U)
190
24. CIG 15 A:
Cigarette lighter, air condi-
tioning system, SRS airbag system,
theft deterrent system, shift lock con-
trol system
25. RAD NO.2 7.5 A: Radio, cassette tape
player, power antenna
26. TAIL 10 A: Tail lights, parking lights,
front side marker lights, rear side
marker lights, licence plate lights
27. ECU- IG 10 A: Cruise control system,
anti- lock brake system, power steering,
power antenna, theft deterrent system,
shift lock control system, traction con-
trol system
28. GAUGE 10 A: Gauges and meters, ser-
vice reminder indicators and warning
buzzers (except discharge and open
door warning lights), rear window de-
fogger, charging system, cruise control
system, electronically controlled auto-
matic transmission system, traction
control system
29. ECU- B 10 A: Air conditioning system,
cruise control system, anti- lock brake
system, SRS airbag system, traction
control system
30. OBD - II 7.5A: On- board diagnosis sys-
tem Fuses (type B)
31. DOOR 30 A: Power window, power
door lock system, theft deterrent sys-
tem
32. DEFOG 30 A: Rear window defogger
Fuses (type C)
33. ALT 120 A: Charging system
34. MAIN 50 A: Starter system, headlights
35. HTR 50 A: Air conditioning system
36. FAN 30 A: Electric cooling fans
37. ABS NO.1 60 A: Anti- lock brake sys-
tem, traction control system
38. AM1 50 A: Electronic ignition system/
distributor ignition system
39. POWER 60 A: ºPANELº, ºSTOPº,
ºTAILº, ºECU- Bº, ºDEFOGº and
ºDOORº fuses

SUPRA (U)191
Part 9
REPORTING SAFETY
DEFECTS FOR U.S.
OWNERS AND
UNIFORM TIRE
QUALITY GRADING
Reporting safety defects for U.S.
owners
Uniform tire quality grading
If you believe that your vehicle has
a defect whi ch coul d cause a cr ash
or could cause injury or death, you
should immediately inform the Na-
tional Highway Traffic Safety Ad-
ministration (NHTSA) in addition to
notifying Toyota Motor Sales,
U.S.A., Inc.
(Toll- free: 1- 800- 331- 4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety de-
fect exists in a group of vehicles, it
may order a recall and remedy
campaign. However, NHTSA cannot
become involved in individual prob-
lems between you, your dealer, or
Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may either
call the Auto Safety Hotline toll- free
at 1- 800- 424- 9393 (or 366- 0123 in
Washington.D.C. area) or write to:
NHTSA. U.S.Department of Trans-
portation. Washington.D.C. 20590.
You can also obtain other information
about motor vehicle safety from the
Hotline.
Reporting safety defects
for U.S. owners

SUPRA (U)
192
Uniform tire quality grading
This information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality gradesÐAll passenger ve-
hicle tires must conform to Federal
Safety Requirements in addition to
these grades. These quality grades are
molded on the sidewall.
Treadwear
ÐThe treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (1- 1/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate. Traction A, B, C
ÐThe traction grades,
from highest to lowest, are A, B, and C,
and they represent the tire's ability to stop
on wet pavement as measured under con-
trolled conditions on specified government
test surfaces of asphalt and concrete. A
tire marked C may have poor traction per-
formance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction.
Temperature A, B, C ÐThe temperature
grades are A (the highest), B, and C,
representing the tire's resistance to the
generation of heat and its ab ility to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No.109. Grades B
and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law. Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure.
