1998 TOYOTA SUPRA Owners Manual

SUPRA (U)17
1. Get the tool bag out of the console
box.
In the tool bag, you will find a special kit
consisting of: Wrench and handle
ÐFor turning the center lock and the
front and rear bolts
Caps
ÐFor covering the front bolts
Plugs
ÐFor stopping up the rear holes
2. Face the ºLOOSENº side of the han-
dle toward you and insert the
wrench into the handle.3. Unlock the center lock by insertingthe wrench and turning it a 1/4 turn
counterclockwise.
Before detaching the sport roof from the
vehicle, fully open both of the side doors
and windows, and clear the seats.

SUPRA (U)
18
4. Loosen the bolts in the order shown by turning the wrench counterclock-
wise. Then lift up the front edge of
the sport roof and lift off the roof
forward.
CAUTION
Be careful not to get your hands or
fingers caught between the sport roof
and the vehicle body when detaching
the roof.
NOTICE
Take care not to hit the sport roof
against the vehicle body to avoiddamage to the roof when detaching the roof.
5. After removing the roof, put the caps on the front bolts and insert
the plugs into the rear holes.
CAUTION
Do not stick your head, arms or
any objects out of the opening
while the vehicle is moving.
Never attempt to remove the roof
while driving.
Do not sit on top of the vehicle
around the opening.

SUPRA (U)19
1. Open the back door and set up therear holders as shown above.
Before stowing the roof in the luggage
compartment, be sure to remove the lug-
gage cover. (See ºLuggage coverº in
Chapter 1- 8.)
2. Put in the roof from the left side as shown. Then insert the front edge of
the roof in the front holders, and
engage the rear edge with the rear
holders.
Put the front edge on the triangle marks
of the front holders.
To engage the rear edge of the roof with
the rear holders, put the rear edge on
the holders while pushing the front edge
fully forward against the front holders.
CAUTION
To minimize the risk of personal inju-
ry, make sure all four corners of the
roof are securely locked in the hold-
ers after installation.
NOTICE
To avoid damage the roof panel, do not press on the center of the stowedroof panel and do not put anyting on the stowed roof panel.
ÐStowing in luggage
compartment

SUPRA (U)
20
ÐReinstalling on vehicle
1. Lift up the rear edge while pushing
the roof fully forward, then pull the
front edge out of the holders. Re-
move the roof from the right side as shown.
After removing the roof, put back the rear
holders by pulling up the lock release
knob.
NOTICE
Do not operate the knob until the roof
has been removed.

SUPRA (U)21
2. Place the rear edge on first and thenthe front edge.
Before installation, be sure to take the
caps and plugs off.
CAUTION
To minimize the risk of personal inju-
ry, make sure all four corners are
securely fixed on the brackets after
installation.
3. Tighten the bolts and lock the center lock in the order shown. (See ºÐDe-
taching from vehicleº for details.)
Note that all five connections need to be
tight to secure the sport roof.
Reverse the wrench handle so the
ºTIGHTENº side faces toward you and
turn it clockwise.
Check that the roof is correctly installed
by lightly trying to move the roof.
Put the wrench, handle, caps and plugs
back in the tool bag in the console box.
CAUTION
Make sure to tighten all four bolts
and to lock the center lock when
installing the sport roof.

SUPRA (U)
22

SUPRA (U)23
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 3
Seats, Seat belts,
Steering wheel
and Mirrors
Seats
Front seats
Fold- down rear seat
Seat belts
SRS driver and front passenger
airbags
Child restraint
Tilt steering wheel
Outside rear view mirrors
Anti- glare inside rear view
mirror
Seats
While the vehicle is being driven, all ve-
hicle occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belts provided.
CAUTION

Do not drive the vehicle unless the
occupants are not properly seated.
Do not allow sitting on top of a
folded- down seatback, or in the
luggage compartment. Persons not
properly seated and not properly re-
strained by seat belts can be se-
verely injured in the event of emer-
gency braking or a collision.
During driving, do not allow pas-
sengers to stand up or move
around between seats. Severe inju-
ries can occur in the event of emer-
gency braking or a collision.
Adjust the driver's seat so that the foot
pedals, steering wheel and instrument
panel controls are within easy reach of
the driver.
CAUTION
Adjustments should not be made
while the vehicle is moving, as the
seat may unexpectedly move and
cause the driver to lose control of
the vehicle.
When adjusting the seat, be careful
not to hit the seat against a pas-
senger, luggage or rear seat.
After adjusting the seat position,
try sliding it forward and backward
to make sure it is locked in posi-
tion.
After adjusting the seatback, exert
body pressure to make sure it is
locked in position.
Do not put objects under the seats.
The objects may interfere with the
seat- lock mechanism or unexpect-
edly push up the seat position ad-
justing lever; the seat may suddenly
move, causing the driver to lose
control of the vehicle.
Front seatsÐ
ÐSeat adjustment precautions

SUPRA (U)
24
While adjusting the seat, do not put
your hands under the seat or near
the moving parts. You may catch
and injure your hands or fingers.
ADJUSTING SEAT POSITION
Pull the lock release lever up. Then
slide the seat to the desired position
with slight body pressure and release
the lever.
ADJUSTING SEATBACK ANGLE
Lean forward and pull the lock release
lever. Then lean back to the desired
angle and release the lever.
CAUTION
To reduce the risk of sliding under
the lap belt during a collision, avoid
reclining the seatback any more than
needed. The seat belts provide maxi-
mum protection in a frontal or rear
collision when the driver and the pas-
senger are sitting up straight and
well back in the seats. If you are
reclined, the lap belt may slide past
your hips and apply restraint forces
directly to the abdomen. Therefore, in
the event of a frontal collision, the
risk of personal injury may increase
with increasing recline of the seat- back.
ÐAdjusting front seat
(manual seat)
