1998 TOYOTA SUPRA Owners Manual

SUPRA (U)49
2. To remove the child restraint system,press the buckle- release button and al-
low the belt to retract.If your child restraint system requires
the use of a top strap, latch the hook
onto the anchor bracket and tighten the
top strap.
Twist the top strap half a turn: make a
twist at front top of the rear seatback, not
behind it. Then pass the top strap through
the cutout in the carpet on the rear cargo
floor.
See the following instructions to install the
anchor bracket.On the rear cargo floor
a. Roll back the carpet on the rear cargo
floor to find the anchor location you wish
to use.
b. Insert a 5 mm (0.5 in.) spacer and
tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5Ð24.7 N Vm (1.68Ð2.52
kgf Vm, 12.2Ð18.2 ft Vlb.).
To make a cutout for the top strap pas-
sage, push open the carpet along the per-
foration with finger pressure. (The perfora-
tion can easily be seen from the back
side of the carpet.)
ÐTop strap anchors and
locations

SUPRA (U)
50
d. After installing the anchor, put the car-
pet back in place.
If your child restraint system does not
provide any of the necessary parts, ask
your Toyota dealer. (See ºÐChild restraint
systemº.) Tilt steering wheelTo change the steering wheel angle,
hold the steering wheel, pull up the
lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
When the steering wheel is in a low posi-
tion, it will spring up as you release the
lock release lever.
CAUTION

Do not adjust the steering wheel
while the vehicle is moving.
After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
Outside rear view mirrorsÐ
Adjust the mirror so you can just see
the side of your vehicle in the mirror.
Be careful when judging the size or dis-
tance of any object seen in the outside
rear view mirror on the passenger 's side.
It is a convex mirror with a curved sur-
face. Any object seen in a convex mirror
will look smaller and farther away than
when seen in a flat mirror.
On some models, when you push the rear
window defogger switch, the heater panels
in the outside rear view mirrors will quick-
ly clear the surface.

SUPRA (U)51
CAUTION
Do not adjust the mirror while the
vehicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting in
personal injuries.
Since the mirror surfaces can get
hot, keep your hands off them when
the defogger switch is on.
To adjust a power rear view mirror, first
place the master switch at ºLº (left) or
ºRº (right) depending on which mirror
needs adjusting, then push the control
switch in the desired direction.
If the engine is not running, the key must
be in the ºACCº position.
NOTICE
If ice should jam the mirror, do not
operate the control or scrape the mir-ror face. Use a spray de- icer to free the mirror.
ÐFolding rear view mirrors
To fold the rear view mirror, push back-
ward.
The rear view mirrors can be folded back-
ward for parking in restricted areas.
CAUTION
Do not drive with the mirrors folded
backward. Both the driver and pas-
senger side rear view mirrors must
be extended and properly adjusted
before driving.
ÐPower rear view mirror
control

SUPRA (U)
52
Pull the lever toward you to reduce
glare from the headlights of the vehicle
behind you during night driving.
Before adjusting the mirror to the position
with most clarity, push the day- night
change lever away from you (daylight driv-
ing position).
Remember that by reducing glare you also
lose some rear view clarity.
Anti- glare inside rear view
mirror

SUPRA (U)53
Part 1
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1- 4
Lights, Wipers and Defogger
Headlights and turn signals
Emergency flashers
Instrument panel light control
Front fog lights
Interior lights
Ignition switch light
Luggage compartment light
Windshield wipers and washer
Rear window wiper and washer
Rear window and outside rear view
mirror defoggers
Headlights and turn signals
To turn the lights on, twist the knob on
the end of the lever.
FIRST CLICKSTOP: Only the parking, tail,
license plate, side marker and instrument
panel lights turn on.
SECOND CLICKSTOP: The headlights also
turn on.
The lights automatically turn off when the
driver 's door is opened with the ignition
key turned off. To turn them on again, turn
the key to the ºONº position or actuate
the headlight switch. If you are going to
park for over one week, make sure the
headlight switch is off.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights onfor a long period when the engine is not running.

SUPRA (U)
54
For high beam, push the lever away
from you. Pull it toward you for low
beam. For the headlight flasher, pull it
further back.
A blue light in the instrument panel indi-
cates high beam is on.
The headlight flasher works even when
the headlight switch is off.For signaling turns, move the lever up
or down in the conventional manner.
The key must be in the ºONº position.
The turn signal is self- cance lling after a
turn, but after a lane change, you may
have to cancel it by hand. You can also
signal a lane change by moving the turn
signal lever partway and holding it there.
If the green light in the instrument panel
flashes faster than normal, it indicates
that the front or rear turn signal bulb has
burned out. Emergency flashersTo turn on the emergency flashers,
push the switch.
All the turn signal lights will flash.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.

SUPRA (U)55
NOTICE
To prevent the battery from being dis-charged, do not leave the switch onfor a long period when the engine isnot running.
Instrument panel light control
To adjust the brightness of the instru-
ment panel lights, turn the knob. Front fog lightsTo turn on the front fog lights, twist
the knob of the headlight and turn sig-
nal switch lever. They will come on
when the headlights are turned on low
beam.

SUPRA (U)
56
Interior lights
To turn on the interior light, push the
switch.
With the central switch pushed on the
ºDOORº side, both lights come on when
either of the side doors is opened. The
lights remain on for a certain time after
both doors are closed.
Ignition switch lightFor easy access to the ignition switch,
the ignition switch light comes on when
either side door is opened.
The light remains on for a certain time
after both side doors are closed.
Luggage compartment lightTo turn the luggage compartment light
on, open the back door and push the
switch. Closing the back door will turn
the light off.
