Read the sectionClimate Control Systemsfor instructions on
bringing fresh outside air into your vehicle. Refer to the Index.
Removing the Key From the Ignition
OFF/LOCK is the only position that allows you to remove the
key from the ignition. The LOCK feature helps to protect your
vehicle from theft, because it also locks the steering wheel
and the gearshift lever when the key is removed.
If your key is stuck in the LOCK position, and you are unable to
turn it, move your steering wheel left or right until the key
turns freely in the lock.
To remove your key from the ignition:
1. Put the gearshift lever in P (Park).
2. Set the parking brake fully.
3. Turn the ignition key to LOCK.
4. Remove the key.
WARNING
When you leave your vehicle, place the gearshift lever in
P (Park). Set the parking brake fully, and shut off the
engine. Never park your vehicle in N (Neutral). If you do
not take these precautions, your vehicle may move
suddenly and injure someone.
WARNING
Do not leave children, unreliable adults, or pets
unattended in your vehicle.
Starting
213

Notes
214

Brakes
When the foot (service) brake pedal is depressed, the high-mount
brake lamp should illuminate.
Occasional brake noise is normal and often does not indicate a
performance concern with the vehicle's brake system. In normal
operation, automotive brake systems may emit occasional or
intermittent squeal or groan noises when the brakes are applied.
Such noises are usually heard during the first few brake
applications in the morning; however they may be heard at any
time while braking and can be aggravated by environmental
conditions such as cold, heat, moisture, road dust, salt or mud. If
a ``metal-to-metal'', ``continuous grinding'' or ``continuous
squeal'' sound is present while braking, the brake linings may be
worn-out and should be inspected by a qualified service
technician.
Front Disc Brakes
The front disc brakes are self-adjusting. They do not require
service other than periodic lubrication of the caliper slide rails
and inspection for pad wear.
Rear Drum Brakes
The rear drum brakes are self-adjusting. Automatic adjustment
occurs through normal use of the brakes.
Four-Wheel Anti-lock Brakes (If Equipped)
The Anti-lock Brake System (ABS) prevents wheels from
completely locking up by automatically releasing and re-applying
the brakes. During ABS braking, slight brake pedal pulsations
may be felt on the driver's foot. These pulsations represent the
rapid cycling of the ABS valves. The pedal pulsations are
considered normal ABS operation, and will stop when normal
braking is resumed or when the vehicle comes to a stop.
Driving
215

During ABS activation, a mechanical noise may be heard as the
ABS cycles. This is normal ABS operation.
Anti-lock brake system (ABS)
On vehicles equipped with an anti-lock braking system (ABS), a
noise from the hydraulic pump motor and pulsation in the
pedal may be observed during ABS braking events. Pedal pulsation
coupled with noise while braking under panic conditions or on
loose gravel, bumps, wet or snowy roads is normal and indicates
proper functioning of the vehicle's anti-lock brake system. If
the vehicle has continuous vibration or shudder while braking,
felt mainly in the steering wheel, the vehicle most likely needs
service.
The ABS system has self-check capabilities. The system turns on
the ABS warning light each time you start the engine. After
the engine is started and the ABS warning light turns off, the system
performs another test the first time the vehicle reaches 4 mph
(6 km/h). A mechanical noise may be heard as the ABS system
performs a self test. This is a normal part of the self test
feature. If a malfunction is found during this check, the ABS
warning light will come on.
You should always be careful when braking, even if your vehicle
has the ABS system. Heavy braking on roads with loose
surfaces such as snow or gravel, or roads with severe pavement
irregularities could also cause you to lose control of your
vehicle.
WARNING
If the anti-lock brake system warning light remains on or
comes on while driving, have the braking system
checked by a qualified service technician as soon as
possible.
216

NOTE: If a fault occurs in the anti-lock system, and the brake
warning light is not lit, the anti-lock system is disabled
but normal brake function remains operational.
Ford Motor Company has not found any negative effects of
mobile radio transmitting equipment installed on vehicles with
the ABS providing that the radio is installed according to the radio
manufacturer's instructions. However, if you have had a
mobile radio transmitter installed and the check ABS light comes
on (at any time other than immediately after turning the key
to the ON position) have your mobile radio dealer inspect the
installation. Also, if the ABS system is activated other than during
maximum braking, have your mobile radio installation
checked.
If Brakes Do Not Grip Well or Pedal is ``Low''
If the brake pedal seems ªlowº it may indicate the need for a
brake system inspection and/or service. Apply your parking brake
several times. If the condition has not improved, you should
have your brakes checked as soon as possible.
Occasional brake squeal during light to moderate stops does not
affect the function of the brake system and is normal.
However, if the squeal becomes very loud or if it becomes more
frequent, return the vehicle to your dealer for inspection.
WARNING
Modifications to the suspension spring rates and/or
vehicle ride height may adversely affect vehicle stopping
ability.
Driving
217

Stopping Distances
Stopping distances vary with different loads and driving
conditions. Use caution when you drive under new conditions
and acquaint yourself with your vehicle's performance.
Applying the Brakes
Apply the brake pedal evenly. Use the ªsqueezeº technique. Push
on the brake pedal with a steadily increasing force. This allows
the wheels to continue to roll while you are slowing down, which
lets you steer properly. In the event of a sudden stop with ABS
equipped vehicles, do not pump the brakes. Pumping the brakes
during an anti-lock stop will diminish braking effectiveness.
Do not drive with your foot resting on the brake pedal. This will
increase your vehicle's stopping distance and may also cause
brake damage.
WARNING
If you are driving down a long or steep hill, shift to a
lower gear. Do not apply your brakes continuously, as they
may overheat and become less effective.
Using the Parking Brake
The parking brake pedal is suspended just below the bottom of
the instrument panel to the left of the brake pedal. To set the
parking brake, press the brake pedal with your right foot and
hold it while you push the parking brake pedal down firmly with
your left foot.
218

WARNING
When parking, do not use the gearshift in place of the
parking brake. Always set the parking brake fully and make
sure that the gearshift is securely latched in Park (P).
Turn off the ignition whenever you leave your vehicle.
Never leave your vehicle unattended while it is running. If
you do not take these precautions, your vehicle may
move unexpectedly and injure someone.
To release the parking brake, press the brake pedal with your
right foot and hold it while you lift up on the parking brake release
handle.
WARNING
If the parking brake is fully released, but the Brake
System light remains on, have the brakes checked
immediately. They may not be working properly.
The parking brake
Driving
219

The parking brake is not designed to stop a moving vehicle, but
you can use the parking brake to stop your vehicle in an
emergency if the service brakes fail. However, since the parking
brake does not stop your vehicle as quickly as the normal
brakes, the stopping distance will increase greatly.
Steering Your Vehicle
Your vehicle has power steering. Power steering uses energy
from the engine to help steer your vehicle.
If the amount of effort needed to steer your vehicle changes at a
constant vehicle speed, have the power steering system
checked. If the power steering system breaks down (or if the
engine is turned off), you can steer the vehicle manually but it takes
more effort.
Never hold the steering wheel in the extreme right or left
position for more than five seconds if the engine is running. This
can damage the power steering pump.
NOTE: After any severe impact such as striking large potholes,
sliding into curbs on icy roads, or a collision involving
the front end, have the front suspension and
steering checked for possible damage.
