1998 LINCOLN TOWN CAR ignition

The valet key (marked ªvaletº) will
actuate doors and ignition only.
TILT STEERING
Pull the tilt steering control toward
you to move the steering wheel up
or down. Hold the control while
adjusting the wheel to the desired
position, then release the control.
Never adjust the steering
wheel when the vehicle is
moving.
TURN SIGNAL CONTROL
²Push down to activate the left
turn signal.
²Push up to activate the right
turn signal.
HI
LO
F
S
OFF
Controls and features
36

To turn speed control off
²Press OFF or
²Turn off the vehicle ignition.
Once speed control is switched off,
the previously programmed set
speed will be erased.
To set a speed
²Press SET ACC/SET ACCEL.
For speed control to operate,
the speed control must be ON
and the vehicle speed must be
greater than 48 km/h (30 mph).
If you drive up or down a steep
hill, your vehicle speed may vary
momentarily slower or faster than
the set speed. This is normal.
Speed control cannot reduce the
vehicle speed if it increases above
the set speed on a downhill. If
your vehicle speed is faster than
the set speed while driving on a
downhill, you may want to shift to
the next lower gear or apply the
brakes to reduce your vehicle
speed.
ON
OFF
RES
SET
ACCEL
COAST
Controls and features
38

Pressing OFF will erase the
previously programmed set speed.
To return to a previously set
speed
²Press RES/RSM/RESUME. For
RES/RSM/RESUME to operate,
the vehicle speed must be faster
than 48 km/h (30 mph).
Indicator light
Indicator message
This message is displayed in the
Message Center when either the
SET ACC/SET ACCEL or
RES/RSM/RESUME controls are
pressed. It turns off when the
speed control OFF control is
pressed, the brake is applied or
the ignition is turned to the OFF
position.
STEERING WHEEL CONTROLS
(IF EQUIPPED)
These controls allow you to
operate some radio and climate
control features.
ON
OFF
RES
SET
ACCEL
COAST
SPEED CONTROL
Controls and features
41

POWER WINDOWS
Express down
To make the driver window open
fully without holding the window
control, press the driver window
control completely down and
release quickly. Depress again to
stop window operation.
Window lock
The window lock feature allows
only the driver to operate the
power windows.
To lock out all the window controls
except for the driver's press the
right side of the control. Press the
left side to restore the window
controls.
Accessory delay (if equipped)
With accessory delay, the window
switches may be used for up to ten
minutes after the ignition switch is
turned to the OFF position or until
any door is opened.
POWER DOOR LOCKS
Press U to unlock all doors and L
to lock all doors.
WINDOW LOCK
WINDOW LOCK
DOOR LOCK
Controls and features
49

POWER SIDE VIEW MIRRORS
The ignition key must be in ACC
or ON to adjust the power side
view mirrors.
To adjust your mirrors:
1. Select L to adjust the left mirror
or R to adjust the right mirror.
2. Move the control in the
direction you wish to tilt the
mirror.
3. Return to the center position to
lock mirrors in place.
Heated outside mirrors
(if equipped)
Both mirrors are heated
automatically to remove ice, mist
and fog when the rear window
defrost is activated.
Do not remove ice from the
mirrors with a scraper or attempt
to readjust the mirror glass if it is
frozen in place. These actions
could cause damage to the glass
and mirrors.
LR
LR
Controls and features
50

POSITIVE RETENTION FLOOR
MAT
Position the floor mat so that the
eyelet is over the pointed end of
the retention post and rotate
forward to lock in. Make sure that
the mat does not interfere with the
operation of the accelerator or the
brake pedal. To remove the floor
mat, reverse the installation
procedure.
REMOTE ENTRY SYSTEM
The remote entry system allows
you to lock or unlock all vehicle
doors without a key.
The remote entry features only
operate with the ignition in the
OFF position.
Unlocking the doors
Press this control to unlock the
driver door. The interior lamps will
illuminate.
Press the control a second time
within five seconds to unlock all
doors.
Controls and features
53

Locking the doors
Press this control to lock all doors.
The horn will chirp and the
parklamps/taillamps will flash to
confirm that the control was
pressed. This feature can be
turned on/off through the following
procedure:
You must complete steps 1-5
within 30 seconds or the
procedure will have to be
repeated. If procedure needs to be
repeated, you must wait 30
seconds.
1. Turn ignition key to ON.
2. Press power door unlock control
3 times.
3. Turn ignition key from ON to
OFF.
4. Press power door unlock control
3 times.
5. Turn ignition key back to ON.
The doors will lock and unlock.
6. Press unlock control twice
within 5 seconds. The horn will
chirp twice upon successful
toggling of the horn chirp feature.
7. Turn ignition to OFF.
Controls and features
54

Opening the trunk
Press the control once to open the
trunk.
Be certain the trunk is closed
before driving your vehicle. The
trunk may appear closed, but it
may not be latched. Failure to do
so may cause objects to fall out of
the trunk or block rear view vision.
Sounding a panic alarm
Press this control to activate the
alarm.
To deactivate the alarm, press the
control again or turn the ignition
to ACC or ON.
This device complies with part 15
of the FCC rules and with RS-210
of Industry Canada. Operation is
subject to the following two
conditions: (1) This device may
not cause harmful interference,
and (2) This device must accept
any interference received,
including interference that may
cause undesired operation.
Changes or modifications not
expressly approved by the
party responsible for
compliance could void the
user's authority to operate the
equipment.
Replacing the batteries
The transmitter is powered by one
coin type three-volt lithium battery
CR2032 or equivalent. Typical
Controls and features
55
