1998 LINCOLN TOWN CAR ignition

The fuses are coded as follows.
Fuse/Relay
LocationFuse Amp
RatingDescription
1 10A Lighting Control Module (LCM)
2 30A EATC Blower Motor
3 10A Lighting Control Module (LCM)
4 7.5A Instrument Cluster
5 7.5A Lighting Control Module (LCM)
6 15A EATC, Heated Seats
7 15A Lighting Control Module (LCM),
Day/Night Sensor/Amplifier
8 10A Shift Lock, Speed Control, Air
Suspension, Steering Wheel Rotation
Sensor
9 20A Lighting Control Module (LCM),
Multi-Function Switch
10 20A Brake Pedal Position (BPP) Switch,
Brake Pressure Switch
11 10A Electronic Crash Sensor
12 15A Instrument Cluster, Anti-Theft, Ignition
Switch
13 10A Anti-Lock Brake Module, Traction
Control Switch
14 7.5A Transmission Control Switch, Lighting
Control Module (LCM)
15 20A Multi-Function Switch
16 30A Wiper Control Module (WCM),
Windshield Wiper Motor
17 10A Digital Transmission Range (DTR)
Sensor
18 7.5A Lighting Control Module (LCM), Front
Radio Control Unit, Cellular Telephone
Transceiver, Electronic Day/Night Mirror,
Compass Module
Roadside emergencies
118

The high-current fuses are coded
as follows.
Fuse/Relay
LocationFuse Amp
RatingDescription
1 50A** Ignition Switch
2 40A** Ignition Switch
3 50A** Cooling Fan
4 30A** PCM Power Relay
5 40A** I/P Fuse Panel, Fuses 10, 19, 21, 23, 25,
27, 32
6 30A** Starting System
7 50A** I/P Fuse Panel, Fuses 1, 3, 5, 7, 9, 31
8 30A** Power Seats, I/P Fuse Panel, Fuse 30
9 50A** Anti-Lock Brakes
10 40A** Rear Defrost
11 40A** Accessory Delay Relay, I/P Fuse Panel,
Fuse 29
12 30A** Air Suspension
13 15A* Charging System
14 20A* Fuel Pump
15 10A* Air Bags
16 30A* Heated Seats
17 10A* Air Suspension
18 15A* Horn
19 30A* Subwoofer, I/P Fuse Panel, Fuse 23
20 15A* Fuel Injectors
21 15A* Heated Oxygen Sensors
22 Ð Not Used
23 Ð Not Used
24 20A* Auxiliary Power Outlet
25 30A** Power Lumbar, Power Seats
26 30A CB Cooling Fan
27 Ð Not Used
Roadside emergencies
121

JUMP STARTING YOUR
VEHICLE
The gases around the
battery can explode if
exposed to flames, sparks, or lit
cigarettes. An explosion could
result in injury or vehicle
damage.
Do not push start your
vehicle. You could damage
the catalytic converter.
Batteries contain sulfuric
acid which burns skin,
eyes, and clothing.
Preparing your vehicle
Also see the label on the battery.
1. Use only a 12±volt supply to
start your vehicle. If you connect
your battery to a 24±volt power
supply you can damage your
starter, ignition system and other
electrical components.
2. Do not disconnect the battery of
the disabled vehicle as this could
damage the vehicle's electrical
system.
3. Park the booster vehicle close to
the hood of the disabled vehicle
making sure theydo nottouch.
Set the parking brake on both
vehicles and stay clear of the
engine cooling fan and other
moving parts.
Roadside emergencies
126

²Always dispose of automotive
batteries in a responsible
manner. Follow your
community's standards for
disposal. Call your local
recycling center to find out
more about recycling automotive
batteries.
WINDSHIELD WIPER BLADES
Check the wiper blades at least
twice a year or when they seem
less effective. Substances such as
tree sap and some hot wax
treatments used by commercial car
washes reduce the effectiveness of
wiper blades.
Checking the wiper blades
If the wiper blades do not wipe
properly, clean both the windshield
and wiper blades using undiluted
windshield wiper solution or a mild
detergent. Rinse thoroughly with
clean water. To avoid damaging the
blades, do not use fuel, kerosene,
paint thinner or other solvents.
Changing the wiper blades
When replacing wiper blade
assemblies, always use a
Motorcraft part or equivalent. To
make replacing the wipers easy,
turn the ignition to ACC, then turn
the wipers on. When the wipers
reach the vertical position, turn
the ignition to LOCK.
Maintenance and care
151

2. Each time you fill the tank,
record the amount of fuel added
(in liters or gallons).
3. After at least three to five fuel
tank fill-ups, fill the fuel tank and
record the current mileage
reading.
4. Use one of the following
equations to calculate fuel
economy.
Liters used x 1004Total
kilometers traveled
Total miles traveled4Total
gallons used
Keep a record for at least one
month. This will provide an
accurate estimate of the vehicle's
fuel economy.
EMISSION CONTROL SYSTEM
Your vehicle is equipped with
various emission control
components and a catalytic
converter which will enable your
vehicle to comply with applicable
exhaust emission standards. To
make sure that the catalytic
converter and other emission
control components continue to
work properly:
²Use only unleaded fuel.
²Avoid running out of fuel.
²Do not turn off the ignition
while your vehicle is moving,
especially at high speeds.
Maintenance and care
163

ENGINE DATA
Engine 4.6L engine
Cubic inches 281
Horsepower-single exhaust
1200 @ 4250 rpm
Horsepower-single exhaust2205 @ 4250 rpm
Horsepower-dual exhaust1215 @ 4500 rpm
Horsepower-dual exhaust2220 @ 4500 rpm
Torque-single exhaust1265 lbs. ft. @ 3000 rpm
Torque-single exhaust2280 lbs. ft. @ 3000 rpm
Torque-dual exhaust1275 lbs. ft. @ 3000 rpm
Torque-dual exhaust2290 lbs. ft. @ 3500 rpm
Required fuel grade Refer to9Octane
recommendations9in the
Maintenance and Carechapter
Firing order 1-3-7-2-6-5-4-8
Spark plug gap 1.3-1.4 mm (0.052-.056 inch)
Ignition system Coil on plug
Compression ratio 10.0:1
1Vehicles sold in California, New
York, Massachusetts and
Connecticut only.
2Vehicles sold outside California,
New York, Massachusetts and
Connecticut.
VEHICLE DIMENSIONS
Vehicle dimensions mm (in)
(1) Overall length 5 469 (215.3)
(2) Overall width 1 987 (78.2)
(3) Overall height 1 472 (58.0)
(4) Wheelbase 2 990 (117.7)
(5) Track - Front 1 611 (63.4)
(5) Track - Rear 1 659 (65.3)
Capacities and specifications
182

Headlamps ...................................24
autolamp system .......................24
flashing ......................................26
high beam .................................25
Heating ........................................26
High beams
indicator light .............................9
Hood
release lever ............................133
Ignition
positions of the ignition ...........35
Instrument panel
lighting up panel and interior .24
Jump-starting
your vehicle ........................126,128
attaching cables ......................127
disconnecting cables ..............128
Keyless entry system
autolock .....................................57
Keys
key in ignition chime ...............13
Lamps
interior lamps .........................171
Lights, warning and indicator
air bag ..........................................8
anti-lock brakes (ABS) ..............9
brake ............................................8
charging system ..........................9
low coolant ................................10
oil pressure ...............................10
safety belt ...................................8
service engine soon .................6,7
traction control system ............10
turn signal indicator ...................9
Lubricant specifications ...........181
Message center ...........................16
reset button ..............................17
select button .............................17
Mirrors
automatic dimming rearview
mirror ........................................47
cleaning ...................................178heated ........................................50
side view mirrors (power) .......50
Moon roof ....................................46
Odometer .....................................14
Panic alarm feature, remote
entry system ................................55
Parking brake ..............................98
Parts (see Motorcraft parts) ....179
Power door locks ........................49
Power steering
fluid, checking and adding ....145
Refill capacities for fluids ........180
Relays ........................................115
Remote entry system .................53
illuminated entry ......................57
locking/unlocking doors ......53,54
replacement/additional
transmitters ...............................56
replacing the batteries .............55
Reporting safety defects ..........185
Safety restraints
automatic locking mode
(retractor) ............................71,72
extension assembly ..................74
for children ...............................81
lap and shoulder belts .............70
maintenance ..............................75
proper use .................................68
warning light and chime .....13,75
Safety seats for children
attaching with tether straps ....89
automatic locking mode
(retractor) .................................85
in rear seat ................................88
tether anchorage hardware .....89
Seats ............................................64
adjusting the seat, manual .......67
adjusting the seat, power ...64,66
head restraints ..........................64
heated seats ..............................66
lumbar support .........................67
Servicing your vehicle ..............131
