Speedometer
Indicates the current vehicle
speed.
Engine coolant temperature
gauge
Indicates the temperature of the
engine coolant. At normal
operating temperature, the needle
remains within the normal area
(the area between the ªHº and
ªCº). If it travels past the ªH,º the
engine is overheating. Stop the
vehicle as soon as safely possible,
switch off the ignition and let the
engine cool. Refer toEngine
coolantin theMaintenance and
carechapter.
Never remove the coolant
recovery cap while the
engine is running or hot.
This gauge indicates the
temperature of the engine coolant,
not the coolant level. If the coolant
is not at its proper level or
mixture, the gauge indication will
not be accurate.
10
2030405060
70
80
90
100
120206080
40100
120
160 140
180
MPHkm/h
110
H
Instrumentation
15

ELECTRONIC MESSAGE
CENTER
The electronic message center only
works when the ignition is in the
ON position.
The message center allows you to:
²see problems such as door ajar
and trunk ajar.
²see the compass direction.
²check the on/off status of
traction control, air suspension
and speed control systems.
²see how many kilometers/miles
you can drive before running
out of fuel.
²see how many liters/gallons of
fuel remain in the fuel tank.
²monitor the average fuel
economy.
²monitor the instantaneous fuel
economy.
²monitor the average speed.
²check the distance traveled
during a trip on either Trip A or
Trip B.
²check the distance remaining
from a set value during a trip.
You can select different features
for the message center to display
by using the message center
controls located in the center of
the instrument panel.
TRUNK AJAR DOOR AJAR
TRAC OFF AIR SUSPENSION
O/D OFF TRAC ACTIVE
SPEED CONTROL COMPASSkmCIRCLE
SLOWLY
WASHER
LTR/100km
km MILES/GALFUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
Instrumentation
16

toCompass calibration
adjustment.
Most geographic areas (zones)
have a magnetic north compass
point that varies slightly from the
northerly direction on maps. This
variation is four degrees between
adjacent zones and will become
noticeable as the vehicle crosses
multiple zones. A correct zone
setting will eliminate this error.
Refer toCompass zone
adjustment.
Compass zone adjustment
1. Determine which magnetic zone
you are in for your geographic
location by referring to the zone
map.
2. Locate the compass module
mounted on the center rear view
mirror post.
3. Turn ignition to the ON position.
4. Press and hold the reset control
located on top of the compass
module until the message center
display changes to show the
current zone setting.
5. Release the reset control, then
slowly press down again. Press the
control repeatedly until the correct
zone setting for your geographic
location is displayed on the
message center.
6. To exit the zone setting mode,
release pressure from the switch
for greater than ten seconds.
1
2
3
4
5
6
7891011121314 15
Instrumentation
18

3. Press the RESET control to
clear the system memory.
²Actual highway fuel economy
is now displayed.This current
average measure will change as
the speed control system
changes the engine speed to
maintain a constant vehicle
speed. This is most noticeable in
hilly environments.
4. Drive the vehicle at least 8 km
(5 miles) with the speed control
system engaged to display a
stabilized average.
5. Record the highway fuel
economy for future reference.
It is important to press the RESET
control after setting the speed
control to get accurate highway
fuel economy readings.
FUEL REMAIN
This function shows how many
liters (gallons) of fuel you have left
in the fuel tank. If the fuel level is
above 71.9 liters (19 gallons), the
letter ªFº (full) will appear on the
display. If the fuel level is below 4
liters (1 gallon), the letter ªEº will
appear in the display.
DIST TO EMPTY (DTE)
This function estimates
approximately how far you can
drive with the fuel remaining in
your tank under normal driving
conditions. Remember to turn the
ignition OFF when refueling your
vehicle. Otherwise, the display will
SELECT
RESET
FUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
FUEL ECON AVG
FUEL REMAIN
DIST TO EMPTY
AVG SPEED
TRIP A B
E/M
Instrumentation
21

PANEL DIMMER CONTROL
Use to adjust the brightness of the
instrument panel during headlight
and parklamp operation.
²Push up to brighten.
²Push down to dim.
AUTOLAMP CONTROL
The autolamp system provides
light sensitive automatic on-off
control of the exterior lights
normally controlled by the
headlamp control.
The autolamp system also keeps
the lights on for a preselected
period of time after the ignition
switch is turned to OFF.
²To turn autolamps on, rotate the
control counterclockwise. The
preselected time lapse is
adjustable up to approximately
three minutes by continuing to
rotate the control
counterclockwise.
²To turn autolamps off, rotate the
control clockwise to OFF.
HEADLAMP CONTROL
Rotate the headlamp control
clockwise to the first position to
turn on the parking lamps only.
Rotate to the second position to
also turn on the headlamps.
PANEL
DIM
OFF
AUTO
LAMPP
OFF
P
Controls and features
24

Flash to pass
Pull toward you to activate and
release to deactivate.
CLIMATE CONTROL SYSTEM
Electronic Automatic
Temperature Control (EATC)
system
The EATC system will maintain a
selected temperature and
automatically control airflow. You
can override automatic operation
with any of the override controls,
the fan speed control or steering
wheel controls.
Turning the EATC on
Press AUTO, any of the override
controls or the fan speed control.
The EATC will only operate when
the ignition is in the ON position.
Turning the EATC off
Press OFF. The Outside
Temperature (EXT) function will
continue to operate until the
ignition is turned off.
HI
LO
F
S
OFF
EXT OFF AUTOMAX
A/CFRONT
REAR
˚F
AUTO
EXT OFF AUTOMAX
A/CFRONT
REAR
EXT OFF AUTOMAX
A/C
Controls and features
26

reduce your ability to see
through your windshield. Also,
avoid placing small objects on
top of your instrument panel.
These objects can fall down into
the defroster outlets and block
airflow and possibly damage
your climate control system.
REAR WINDOW DEFROSTER
The rear defroster control is
located on the climate control
panel.
Press the defroster control to clear
the rear window of thin ice and
fog.
²The small LED will illuminate
when the defroster is activated.
The ignition must be in the ON
position to operate the rear
window defroster.
The defroster turns off
automatically after 10 minutes or
when the ignition is turned to the
OFF position. To manually turn off
the defroster before ten minutes
have passed, push the control
again.
CLOCK (IF EQUIPPED)
Press the right control to increase
the time displayed.
Controls and features
34

Press the left control to decrease
the time displayed.
AUDIO SYSTEM
Refer to the ªAudio Guideº in your
owner portfolio.
POSITIONS OF THE IGNITION
1. ACCESSORY, allows the
electrical accessories such as the
radio to operate while the engine
is not running.
2. LOCK, locks the steering wheel,
automatic transmission gearshift
lever and allows key removal.
3. OFF, shuts off the engine and all
accessories without locking the
steering wheel.
4. ON, all electrical circuits
operational. Warning lights
illuminated. Key position when
driving.
5. START, cranks the engine.
Release the key as soon as the
engine starts.
Key system
The vehicle is equipped with a
master key and valet key lock
system. The master key will
actuate doors, trunk, glove box,
ignition and remote trunk release.
3
1
2
5
4
