1997 TOYOTA T100 Owners Manual

16
While adjusting the seat, do not put
your hands under the seat or near
the moving parts. You may catch
and injure your hands or fingers.
ÐAdjusting front seats

17
ADJUSTING SEAT POSITION
Pull the lock release lever up. Then
slide the seat to the desired position
with slight body pressure and release
the lever.
ADJUSTING SEATBACK ANGLE(except non-split bench seat)
Lean forward and pull the lever up.
Then lean back to the desired angle
and release the lever.
CAUTION!
To reduce the risk of sliding under
the lap belt during a collision, avoid
reclining the seatback any more
than needed. The seat belts provide
maximum protection when the driv-
er and the passenger are sitting up
straight and well back in the seats. If
you are reclined, the lap belt may
slide past your hips and apply re- straint forces directly to the abdo-
men. Therefore, in the event of a
frontal collision, the risk of personal
injury may increase with increasing recline of the seatback. ADJUSTING DRIVER'S SEAT CUSH-
ION ANGLE (separate seat only)
Turn the knob either way.
ADJUSTING DRIVER'S SEAT LUM-
BAR SUPPORT (separate seat only) Pull the lever forward and rerlease. Repeat this until you have a comfortable support.For easy access to the rear seat, do this.
1. Lift the seatback lock release lever or
press the release pedal.
The seat will slide forward slightly.
2. Move the seat to the front-most posi- tion.
After passengers are in, lift up on the seat-
back and return the seat until it locks.
ÐMoving passenger's seat for rear seat entry (Xtra-cab models)

18
CAUTION!
After putting back the seat, try
pushing the seat forward and rear-
ward to make sure it is secured inplace.
Never allow anyone to rest their
foot on the release pedal while the
vehicle is moving.
Unlock the seatback, and fold it down.
Hold the lock release lever until you have
swung the seatback forward slightly.
CAUTION!
When returning the seatback to the
upright position: Make sure the seat belts are not
twisted or caught in the seatback
and are arranged in their proper
position for ready use.
Make sure the seatback is secure-
ly locked by pushing forward and rearward on the top of the seat- back.
BEFORE RAISING REAR SEAT
Stow the rear seat belts as shown in
the illustration.
This prevents the belts from falling out
when you raise the bottom cushion.
NOTICE
The seat belts must be stowed before you raise the bottom
cushion.
ÐFolding seatback (non-split
bench seat) ÐRear seats (jump seats)

19
RAISING REAR SEAT
To raise the bottom cushion, pull it up.
To lower the bottom cushion, push it down. See Luggage stowage precautionsº in
Part 2 for precautions to observe in load- ing luggage.
CAUTION!
When returning the bottom cushion
to its original position, make sure
the seat belts are not twisted or
caught under the bottom cushion
and are arranged in their proper
position for ready use.
Bench seatÐ
To raise the head restraint, pull it up.
To lower it, press the lock release but-
ton and push the head restraint down. Separate the seatÐ
To raise the head restraint, pull it up.
To lower it, press the lock release but-
ton and push the head restraint down.
To move the head restraint forward orbackward, pull it or push it.
The head restraint is most effective when
it is close to your head. Therefore, using a cushion on the seatback is not recom-mended.
CAUTION!
Adjust the top of the head restraint
so that it is closest to the top of
your ears.
After adjusting the head restraint,
make sure it is locked in position.
Do not drive with the head re-
straints removed.
Head restraints

20
To use the armrest, pull it out as shown above. When you fold the seatback, the armrest retracts to avoid hitting the manual trans-
mission gear shift lever.
NOTICE
To prevent damage to the armrest, avoid putting heavy loads on it.
Toyota strongly urges that the driver and passengers in the vehicle be properly re- strained at all times with the seat belts
provided. Failure to do so could increase
the chance of injury and/or the severity of
injury in accidents. Child. Use a child restraint system ap-
propriate for the child until the child be-
comes large enough to properly wear the
vehicle's seat belts. See Child restraintº
for details. NORMAL-CAB MODELSÐ
If a child is too large for a child restriant
systemn, the child should sit in the seat
and must be restrained using the vehicle's
seat belt. XTRA-CAB MODELSÐ
If a child is too large for a child restraint
system, the child should sit in the rear seat
and must be restrained using the vehicle's
seat belt. According to accident statistics,the child is safer when properly restrained
in the rear seat than in the front seat. If a
child must sit in the front seat, the seat
belts should be worn properly. Do not allow the child to stand up or kneel
on either rear or front seats. An unre-
strained child could suffer serious injury
during emergency braking or a collision.
Also, do not let the child sit on your lap. It
does not provide sufficient restraint.
If the shoulder belt falls across the child's neck or face, move the child to the center
position and use the center lap belt.
Small-framed person or youth in a
3-point type seat belt.
On models with
a bench seat, have a small-framed per-
son or youth sit slightly closer to the center
of the vehicle (so the shoulder belt does
not cross over the neck). On models with separate seats, move the seat fully back- ward.
Pregnant woman. Toyota recommends
the use of a seat belt. Ask your doctor for
specific recommendations. The lap belt
should be worn securely and as low as
possible over the hips and not on thewaist.
Injured person. Toyota recommends the
use of a seat belt. Depending on the injury,
first check with your doctor for specific recommendations.
Seat beltsÐ ÐSeat belt precautions
Armrest

20
To use the armrest, pull it out as shown above. When you fold the seatback, the armrest retracts to avoid hitting the manual trans-
mission gear shift lever.
NOTICE
To prevent damage to the armrest, avoid putting heavy loads on it.
Toyota strongly urges that the driver and passengers in the vehicle be properly re- strained at all times with the seat belts
provided. Failure to do so could increase
the chance of injury and/or the severity of
injury in accidents. Child. Use a child restraint system ap-
propriate for the child until the child be-
comes large enough to properly wear the
vehicle's seat belts. See Child restraintº
for details. NORMAL-CAB MODELSÐ
If a child is too large for a child restriant
systemn, the child should sit in the seat
and must be restrained using the vehicle's
seat belt. XTRA-CAB MODELSÐ
If a child is too large for a child restraint
system, the child should sit in the rear seat
and must be restrained using the vehicle's
seat belt. According to accident statistics,the child is safer when properly restrained
in the rear seat than in the front seat. If a
child must sit in the front seat, the seat
belts should be worn properly. Do not allow the child to stand up or kneel
on either rear or front seats. An unre-
strained child could suffer serious injury
during emergency braking or a collision.
Also, do not let the child sit on your lap. It
does not provide sufficient restraint.
If the shoulder belt falls across the child's neck or face, move the child to the center
position and use the center lap belt.
Small-framed person or youth in a
3-point type seat belt.
On models with
a bench seat, have a small-framed per-
son or youth sit slightly closer to the center
of the vehicle (so the shoulder belt does
not cross over the neck). On models with separate seats, move the seat fully back- ward.
Pregnant woman. Toyota recommends
the use of a seat belt. Ask your doctor for
specific recommendations. The lap belt
should be worn securely and as low as
possible over the hips and not on thewaist.
Injured person. Toyota recommends the
use of a seat belt. Depending on the injury,
first check with your doctor for specific recommendations.
Seat beltsÐ ÐSeat belt precautions
Armrest

21
CAUTION!
Persons should ride in their seats
properly wearing their seat belts whenever the vehicle is moving.
Otherwise, they are much more like-
ly to suffer serious bodily injury in
the event of sudden braking or a col- lision.
When using the seat belts, observe
the following: Use the belt for only one person at
a time. Do not use a single belt for
two or more peopleÐeven chil- dren.
Avoid reclining the seatbacks too
much. The seat belts provide maxi-
mum protection when the seat-backs are in the upright position.
(Refer to the seat adjustment in-structions.)
Be careful not to damage the belt
webbing or hardware. Take care
that they do not get caught or
pinched in the seat or doors.
Inspect the belt system periodical-
ly. Check for cuts, fraying, and
loose parts. Damaged parts should
be replaced. Do not desassemble
or modify the system
Keep the belts clean and dry. If they
need cleaning, use a mild soap
solution or lukewarm water. Never
use bleach, dye, or abrasive clean-
ers-they may severely weaken thebelts.
Replace the belt assembly (includ-
ing bolts) if it has been used in a se-
vere impact. The entire assembly
should be replaced even if damage
is not obvious.
Replace the seat belt if the warning
label under the sleeve can be seen.
The warning label, REPLACE
BELTº, will appear if the belt re-
ceives a severe impact or otherforce.

22
Adjust the seat as needed (front seats only) and sit up straight and well back
in the seat. To fasten your belt, pull it
out of the retractor and insert the tab
into the buckle.
You will hear a click when the tab locks into the buckle.
The seat belt length automatically adjusts
to your size and the seat position.
The retractor will lock the belt during a
sudden stop or on impact. It also may lock
if you lean forward too quickly. A slow, easy motion will allow the belt to extend,
and you can move around freely. If the seat belt cannot be pulled out of the
retractor,
firmly pull the belt and release it.
You will then be able to smoothly pull the
belt out of the retractor.
When a passenger's shoulder belt is com-
pletely extended and is then retracted
even slightly, the belt is locked in that posi-
tion and cannot be extended. This feature
is used to hold the child restraint system
securely. (For details, see Child restraintº
in this chapter.) To free the belt again, fully
retract the belt and then pull the belt out
once more.CAUTION!
After inserting the tab, make sure
the tab and buckle are locked and that the belt is not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and buckle.
If the seat belt does not function
normally, immediately contact
your Toyota dealer. Do not use the
seat until the seat belt is fixed. It cannot protect an adult occupant
or your child from injury.
Seat belts with an adjustable shoulder anchorÐ
Adjust the shoulder anchor position
to your size.
To raise the anchor position, push the an-
chor up. To lower the anchor position,
push the lock release button and slide the
anchor down. After the adjustment, make sure the anchor is locked in position.
ÐOutside seat belts
