1997 TOYOTA T100 Owners Manual

8
LOCKING WITH KEY
Turn the key towards the front of the
vehicle to lock and towards the back to
unlock.
Vehicles with power door lock sys-
temÐBoth doors lock and unlock simulta-
neously with either door. In the driver's
door l ock, turning the key once will unlock
the driver's door and twice in succession
will unlock the driver's door and passen-
ger's door simultaneously.LOCKING WITH INSIDE LOCK KNOB
Turn the lock knob forward to lock and
backward to unlock the door.
Closing the door with the lock knob in the
lock position will also lock the door. Be careful not to lock your keys in the vehicle.
Vehicles with power door lock systemÐ
The door cannot be locked if you leave the key in the ignition switch.LOCKING AND POWER DOOR LOCK SWITCH
To lock and unlock both doors simul-
taneously, push the power door lockswitch.
Side doors

9
CAUTION!
Before driving, be sure that the
doors are closed and locked, espe-
cially when small children are in the
vehicle. A long with the proper use of
seat belts, locking the doors helps
prevent the driver and passengers
from being thrown out from the ve-
hicle during an accident. It also
helps prevent the doors from being
opened unintentionally.
The windows can be operated with the
switch on each door.
The power windows work when the igni- tion switch is in the ONº position. Howev-
er, if both doors are closed, they work for 60 seconds even after the ignition switch
is turned off. They stop working when ei-ther door is opened.
OPERATING THE DRIVER'S WINDOW
Use the switch on the driver's door.
Normal operation: The window moves
as long as you hold the switch.
To open: Lightly push down the switch.
To close: Pull up the switch.Automatic operation (to open only):
Push the switch completely down and
then rel ease it. The window will fully open.
To stop the window partway, lightly pull the
switch up and then release it.
Power windows

10
OPERATING THE PASSENGERS' WIN-
DOWS
Use the switch on the passenger's
door or the switch on the driver's door
that controls the passenger's window.
The windows moves as long as you hold the switch.
To open: Push down the switch.
To close: Pull up the switch.
If you push in the WINDOWS LOCKº
button on the driver's door, the passen-
ger's windows cannot be operated.
CAUTION!
To avoid serious personal injury,
you must do the following. Always make sure the head, hands
and other parts of the body of all
occupants are kept completely in-
side the vehicle before you close
the power windows. If someone's
neck, head or hands gets caught in
a closing window, it could result in
a serious injury. When anyonecloses the power windows, be sure that they operate the win-
dows safely.
When small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the WINDOW LOCKº
button to prevent them from mak-
ing unexpected use of the switches.
Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the power window switches
and get trapped in a window. Unat-
tended children can become in-
volved in serious accidents.

11
To open the quarter window, pull the
latch handle toward you and swing it
fully out.
When closing the window, make sure it is completely closed.To unlock the rear window, pull the left
end of the latch handle toward you and
disengage the right end from thecatch.
When closing the window, make sure it is completely closed.OPENING
To open the tailgate, pull the handle up. See Luggage stowage precautionsº in
part 2 for precautions to observe in load- ing luggage.
After closing the tailgate, try pulling it to-
ward you to make sure it is securely locked.
Avoid driving with the tailgate open.
NOTICE
Tailgate
Quarter windows Rear window

12
REMOVAL
1. Open the tailgate to the anglewhere you can release the support
brackets from the lugs on bothsides.
2. Open the tailgate to about 30 5 from
vertical and pull up the right side of
the tailgate to unhook the rightside.
3. Slide the tailgate a little to the right to unhook the left side.
To install the tailgate, follow the removal
procedure in revers order.
After closing the tailgate, try pulling it to-
ward you to make sure it is securely closed.
We recommend you keep the tailgate
closed when not in use.

Before unhooking the tailgate,fold the support brackets.
Make sure the support brackets
are securely latched on both sidepanels when installing the tail-
gate.
NOTICE
To open the hood, do the following.
1. Pull the hood lock release lever.
The hood will spring up slightly.
Hood

13
2. In front of the vehicle, pull up on theauxiliary catch lever and lift the hood.3. Hold the hood open by insertingthe support rod into the slot.
Before closing the hood, check to see that
you have not forgotten any tools, rags,
etc. and return the support rod to its clip-
this prevents rattles. Then lower the hood
and make sure it locks into place. If neces-
sary, press down gently on front edge to lock it.
After inserting the support rod into
the slot, make sure the rod supports
the hood security.
CAUTION!
1. To open the fuel filler door, pull the
lever up.
CAUTION!
Do not smoke, cause sparks or al-
low open flames when refuelling.
The fumes are flammable.
When opening the cap, do not re-
move the cap quickly. In hot weath-
er, fuel under pressure could cause
injury by spraying out of the filler
neck if the cap is suddenly re- moved.
Fuel tank cap

14
CAUTION!
Do not fill a fuel container on a plas-
tic truck bed liner, a rubber truck
bed mat, or any other insulating
material. A static electricity charge
could cause a spark and fire haz-
ard. The proper procedure is to
place an approved fuel container
on the ground away from the truck for filling.
2. To remove the fuel tank cap, turn
the cap slowly counterclockwise,
then pause slightly before remov-
ing it. after removing the cap, hang
it on the cap hanger.
It is not unusual to hear a slight swoosh
when the cap is opened. When installing,
turn the cap clockwise till you hear a click.
5VZ-FE engineÐ
If the cap is not tightened securely, the malfunction indicator lamp comes on.
Make sure the cap is tightened securely. The indicator lamp goes off after driving several times. If the indicator lamp does
not go off, contact your Toyota dealer as soon as possible.
CAUTION!
Make sure the cap is tightened se-
curely to prevent fuel spillage in
case of an accident.
Use only a genuine Toyota fuel
tank cap for replacement. It has a
built in check valve to reduce fuel tank vacuum.

Part 1Seats Front seatsÐ
ÐSeat adjustment precautions
15
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-3 Seats, Seat belts, Steering wheel and Mirrors
Seats
Front seats
Rear seats
Head restraints
Armrest
Seat belts
SRS airbags
Child restraint
Tilt steering wheel
Outside rear view mirrors
Anti-glare inside rear view mirror
While the vehicle is being driven, all ve-
hicle
occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belt provided.
CAUTION
Do not drive with the vehicle occu-
pants not properly seated, such as
sitting on top of a folded-down
seatback, or in the luggage
compartment. Per sons not proper-
ly seated and not properly re-
strained by seat belts can be se-
verely injured in the event of emer-
gency braking or a collision.
During driving, do not allow pas-
sengers to stand up or move
around between seats. Balance
can be unsteady and severe inju- ries can ocur in the event of emer- gency braking or a collision.! Adjust the driver's seat so that the foot
pedals, steering wheel and instrument
panel
controls are within easy reach of the
driver.CAUTION
Adjustments should not be made
while the vehicle is moving, as the
seat may unexpectedly move and cause the driver to lose control of the vehicle.
When adjusting the seat, be care- ful not to hit the seat against lug- gage.
After adjusting the seat position,
try sliding it forward and back-
ward to make sure it is locked in position.
After adjusting the seatback, exert
body pressure to make sure it is
locked in position.
Do not put objects under the seats
as they may interfere with the seat-
lock mechanism or unexpectedly
push up the seat position adjust-
ing lever; the seat may suddenly
move, causing the driver to lose
control of the vehicle.!
