AR46.40-P-0200GH
Removing and installing tie rod
12.3.97
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
P46.40-0262-12
10
Tie rod
10a
Tie rod joint
10i
Clamping nut
Modification notes
10.9.03
Reference to adjusting toe on front axle replaced by
reference to chassis alignment check
Step 5
Removing, installing
Danger!
Risk of fatal injury
if the vehicle slips or
topples off the lifting platform
Align vehicle between the columns of the
lifting platform and position the four support
plates
at the lifting platform support points
specified by the vehicle manufacturer.
AS00.00-Z-0010-01A
Notes on self-locking bolts and nuts
AH00.00-N-0001-01A
1
Remove front wheel
e
Removing and fitting wheels
AP40.10-P-4050GH
2
Press tie rod joint (10a) off steering knuckle
AR46.40-P-0200-02C
Installation:
Replace self-locking nut.
*BA46.40-P-1001-01C
Thrust piece
*140589006300
Puller
*202589023300
3
Slacken clamping nut (10i) and unscrew tie
rod (10)
Counter tie rod (arrow).
Installation:
On vehicles with speed-
sensitive power steering the tie rod is marked
with a "P". These tie rods are approx. 4 mm
shorter.
*BA46.40-P-1002-01C
4
Install in the reverse order
5
Check toe on front axle and adjust if necessary
See:
#
Performing chassis alignment check
AR40.20-P-0200A
Tie rod
Number
Designation
Model 163
BA46.40-P-1001-01C
Self-locking nut, tie rod to steering knuckle
Nm
55
BA46.40-P-1002-01C
Clamping nut, tie rod to inner tie rod
Nm
50
Copyright DaimlerChrysler AG 06.07.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
