1997 HONDA ODYSSEY Owners Manual

Child Safety

If you are using a toddler seat in the
front passenger's seat, move the
passenger's seat as far back as possible before installing the child
seat. If the passenger's bag inflates,
it could seriously hurt a toddler who
is not in the proper position or

properly restrained.
Restraining a Child Who Weighs

Over 40 lbs (18 kg)

We recommend that, whenever
possible, a child who has outgrown a
toddler seat ride in one of the outside positions of the second or
third seat and use a lap/shoulder
belt. Put the lap/shoulder belt on your
child and check its fit. The shoulder
belt should fit over the collarbone and across the chest. The lap belt
should sit low on your child's hips,
not across the stomach.
If the shoulder belt crosses the neck,
while sitting in the second or third bench seat, have your child move
toward the center of the seat until
the belt fits properly. If the belt still
crosses the child's neck, you shoulduse a booster seat.
Several styles of booster seats are
available. We recommend a design
that allows the child to use the car's lap/shoulder belt.
Whichever style you select, follow
the booster seat manufacturer's instructions.

Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Child Safety

Securing a Child Seat with a Lap/
Shoulder Belt
The lap/shoulder belt retractors in the passenger seating positions have
a built-in locking mechanism in-
tended to secure a child seat. When
you are placing a child seat in one of these outside seating positions, do
the following: 1. Place the child seat in the desired
seating position. Route the lap/
shoulder belt through the seat
according to the seat manufac-
turer's instructions.
2. Insert the latch plate into the buckle. Make sure it is fully

latched.

3. Slowly pull the shoulder portion of the belt out of the retractor until it
stops.

4. Allow the belt to slowly feed back into the retractor. You should heara clicking noise that indicates the
locking mechanism has engaged.
5. After the belt has retracted fully, pull up on the shoulder portion to
remove any slack.
6. Push and pull on the child seat to
verify that it is held firmly in place.If not, unlatch the seat belt, allow
it to retract fully, and repeat these
steps.

To unlatch the seat belt, push the red PRESS button on the buckle.Guide the belt across to the door
pillar. If the belt doesn't retract easily, pull it out and check for twistsor kinks.
Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Child Safety

Using Child Restraints with
Tethers
Your Honda has several attachment points that allow a tether-style childseat to be installed.

Tethers do not replace the use of seat

belts. Even if a tether is used, a child
seat must always be secured
properly with the vehicle's seat belts.

U.S. Models

Two tether attachment points are located on the tailgate sill that allowa tether-style child seat to be
installed on the third seat. Use the
dimensions in the illustration to
locate the attachment point you want to use. Cut a 7/8 inch (22 mm)diameter hole.
Install the tether hardware that came
with the child seat.
Tighten the bolt to: 16 lbf.ft (2.2 kgf.m, 22 N.m)
If you are not sure how to install the
hardware, have it installed by your authorized Honda dealer.
If you need an anchor plate and
mounting hardware, contact your
Honda dealer.
Canadian Models
Your Honda has attachment points for a tether-style child seat to be
installed on the second or third seat
as shown.
Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Child Safety

Second Seat Installation:

There are three attachment points available for the seven-passenger
model, and two attachment points
available for the six-passenger model.
To use a tether-style child seat in the second seat, the third seat must be
stored in the floor recess (see page 60). You will find a U-shaped slit in
the carpeting at each attachment
point. Select the attachment point
you want to use, and pull up the carpeting at the slit. Attach the
tether strap to the mounting hook and make sure it is secure.

Important Safety Information

Keep the third seat in the floor while
using a tether-style child seat in the second seat. If you attempt to return
the third seat to the upright position,
you may damage the vehicle or
tether, even though the damage may not be obvious. If this happens, the
child seat may not be properly restrained in a crash.

Third Seat Installation:

There are two attachment points on
the tailgate sill. Select the attach-

ment point you want use, and

remove the plug with a small flat-

tipped screwdriver or a fingernail file.

Install the tether hardware that came

with the child seat.

Tighten the bolt to:
16 lbf.ft (2.2 kgf.m , 22 N.m)
If you are not sure how to install the

hardware, have it installed by your
authorized Honda dealer.

The anchor plate and mounting hardware for a top tether are
supplied with the car. When install-

ing, make sure the toothed washer is
on the bottom of the bolt.
TOOTHED WASHER
The supplied anchor plate is designed only for mounting a child
restraint. Do not use it for any other

purpose.

Storing a Child Seat
When you are not using an infant seat or other child restraint, either
remove it or make sure it is properlysecured so it cannot be thrown
around the car during a crash.

Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Alcohol and Drugs

Driving a car requires your full at-
tention and alertness. Traffic condi-
tions change rapidly. You must be able to react just as rapidly. Alcohol
or drugs directly affect your alert-
ness and ability to react. Even pre-
scription and non-prescription medi-

cines can have this effect.
There are laws that deal with drunken driving. These laws define
how much alcohol it takes in your system to be legally "drunk." How-
ever, your judgment and reaction
time get worse with every drink — even the first one. The safest thing you can do is never
drink and drive. This can be done if
you plan ahead. If you know you are
going to be drinking, make plans to
ride with a friend who will not be drinking.
What if you find that you've been drinking and cannot get a ride from a
friend? Find alternative transpor-
tation. Call a taxi. Take a bus. Many communities have transportation
services devoted to shuttling people
who have been drinking. If you have no choice but to drive,
stop drinking and give yourself lots
of time to sober up. Time is the only
thing that can make you sober.
Things like coffee or a cold shower don't speed up the process.
If you see friends trying to get
behind the wheel after drinking, stop
them. Drive them yourself or arrange other transportation. If you
think you are interfering, remember
that your interference will keep them
from sharing the road with you.
Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Carbon Monoxide Hazard
Your car's exhaust contains carbon monoxide gas. You should have no
problem with carbon monoxide
entering the car in normal driving if
you maintain your car properly. Have the exhaust system inspected
for leaks whenever: The car is raised for an oil change.
You notice a change in the sound
of the exhaust. The car was in an accident that
may have damaged the underside. High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
car out of the garage. With the tailgate open, air flow can
pull exhaust gas into your car's
interior and create a hazardouscondition. If you must drive with the
tailgate open, open all the windows and set the heating and cooling
system as shown below.
If you must sit in your parked car,
even in an unconfined area, with the
engine running, adjust the heating
and cooling system as follows: 1. Push the button.
2. Select the mode.
3. Turn the fan on high speed.
4. Set the temperature control to a comfortable setting.

Driver and Passenger Safety

Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.ProCarManuals.comMain Menu Table of Contents s t

Safety Labels

These labels are in the locations shown. They warn you of potential
hazards that could cause serious injury. Read these labels carefully
and don't remove them.
If a label comes off or becomes hard
to read, contact your Honda dealer
for a replacement.

Driver and Passenger Safety
RADIATOR CAP
BATTERYProCarManuals.comMain Menu Table of Contents s t

Instruments and Controls

This section gives information about the controls and displays thatcontribute to the daily operation of
your Honda. All the essential controls are within easy reach.
Control Locations............................ 32
Indicator Lights................................ 33 Gauges.............................................. 37
Speedometer................................ 37
Trip Meter.................................... 37
Odometer...................................... 37

Temperature Gauge.................... 38 Fuel Gauge................................... 38
Maintenance Required Indicator.................................... 38
Controls Near the Steering
Wheel........................................ 39

Headlights.................................... 40
Daytime Running Lights............. 40
Instrument Panel Brightness..... 41
Turn Signals................................. 41
Windshield Wipers...................... 42
Windshield Washers................... 43 Rear Window Wiper and Washer......................................
43

Hazard Warning...........................
43

Rear Window Defogger.............. 44
Steering Wheel Adjustment....... 44
Steering Wheel Controls ................ 46 Cruise Control.............................. 46
Keys and Locks................................ 49
Keys...............................................49

Ignition Switch............................. 49
Power Door Locks....................... 50
Remote Transmitter....................

51

Childproof Door
Locks............... 52
Tailgate......................................... 52 Glove Box..................................... 53

Seats.................................................. 54
Passenger Seating....................... 54

Seat Adjustments......................... 54

Driver's Seat Power Height Adjustment............................... 55
Head Restraints........................... 56
Third Seat Access........................ 56

Removing the Second Seats
in the Six-Passenger Model.... 57
Folding the Second Seats in the Seven-PassengerModel.................................... 58
Reclining the Second Seat.......... 59
Folding the Third Seat in All Models............................ 60

Power Windows............................... 62

Sunroof.............................................. 63
Mirrors.............................................. 64
Adjusting the Power Mirrors..... 64

Parking Brake.................................. 65

Digital Clock..................................... 66
Beverage Holder.............................. 66

Dashboard Compartment............... 68
Center Pocket.................................. 68

Vanity Mirror................................... 68
Cigarette Lighter............................. 69

Ashtrays............................................ 69
Interior Lights.................................. 70
Ceiling Lights............................... 70
Spotlights...................................... 70

Tailgate Light............................... 71
Courtesy Lights........................... 71

Instruments and ControlsProCarManuals.comMain Menu s t
