1997 FORD TAURUS Owners Manual

Cleaning the wiper blades
If the wiper blades do
not wipe properly,
clean both the
windshield and wiper
blades using undiluted
windshield wiper
solution or a mild
detergent. Rinse
thoroughly with clean
water. To avoid
damaging the blades,
do not use fuel,
kerosene, paint thinner
or other solvents.
Cleaning the instrument panel
Clean instrument panel with a damp cloth, then dry
with a dry cloth.
Any cleaner or polish that increases the gloss of the
upper portion of the instrument panel should be
avoided. The dull finish in this area is to help
protect the driver from undesirable windshield
reflection.
Cleaning the interior fabric
Remove dust and loose dirt with a whisk broom or a
vacuum cleaner. Remove fresh spots immediately.
Follow the directions that come with the cleaner.
BASSTREBBALFADEREWFFEJECT1234
56wTAPE SIDETAPE
R-DEFTUNESEEKSCAN AM
FMMH
LO
HIOFF
A/C
MAX
A/CVENTVOL
PUSH-ONwSTFM 12
AMCBLRFEFC HFUEL DOOR>SERVICE
ENGINE
SOONLOW
COOLANTTHEFT102030405060
70
80
90
100
1202060100
140
180P R N D 2 1MPH km/h0000000000P!
BRAKE+ –110CRUISERPMx1000ABSO/D
OFFREAR
LAMP
OUTPREMIUM UNLEADED
FUEL RECOMMENDED0 1234
5
6
78
Maintenance and care
154
ProCarManuals.com

Cleaning leather seats (if equipped)
For routine cleaning, wipe the surface with a soft,
damp cloth. For more thorough cleaning, wipe the
surface with a leather and vinyl cleaner or a mild
soap.
Cleaning and maintaining the safety belts
Clean the safety belts with a mild soap solution
recommended for cleaning upholstery or carpets. Do
not bleach or dye the belts, because these actions
may weaken the belt webbing.
Check the safety belt system periodically to make
sure there are no nicks, wear or cuts. If your vehicle
has been involved in an accident, have all the safety
restraints examined by a qualified technician.
Cleaning the built-in child seat (if equipped)
Clean the built-in child seat with mild soap and
water. Do not use household cleaning products
because they may weaken the safety belt webbing or
damage the vinyl parts of the seat.
The child seat liner is removable and may be
machine-washed and air dried.
Maintenance and care
155
ProCarManuals.com

MOTORCRAFT PART NUMBERS
3.0L Vulcan engine
Component Part number
Air filter FA-1630
Fuel filter FG-800-A
Battery (standard) BXT-58R
Battery (optional) BXT-36R
Fuel filter FG-800-A
Passenger
compartment air filter
(if equipped)FP-6
Oil filter FL-400-S
PCV valve EV-228
Spark plug* AWSF-32PP**
* Refer to Vehicle Emissions Control Information
(VECI) decal for spark plug and gap information.
** If a spark plug is removed for inspection, it
must be reinstalled in the same cylinder. Cylinders
No. 1, 2 and 3 have a PG suffix. Cylinders No. 4, 5
and 6 have a P suffix. If a spark plug needs to be
replaced, use only spark plugs with the service
part number suffix letter9PP9as shown on the
engine decal.
3.0L Duratec engine
Component Part number
Air filter FA-1630
Fuel filter FG-800-A
Battery BXT-36R
Fuel filter FG-800-A
Capacities and specifications
156
ProCarManuals.com

Component Part number
Passenger
compartment air filter
(if equipped)FP-6
Oil filter FL-820-S
PCV valve EV-152
Spark plug AWSF-32F
3.4L SHO engine
Component Part number
Air filter FA-1630
Battery BXT-36R
Fuel filter FG-800-A
Passenger
compartment air filter
(if equipped)FA1628
Oil filter FL-400A
PCV valve EV-234
Spark plug AWSF-32FM
REFILL CAPACITIES
3.0L Vulcan engine
Fluid Ford Part
NameVehicle
TypeCapacity
Brake
fluidHigh
performance
DOT 3
brake fluidAll Fill to line
in reservoir
Engine
coolantPremium
cooling
system fluidAll 11.0 (11.6)
Capacities and specifications
157
ProCarManuals.com

Fluid Ford Part
NameVehicle
TypeCapacity
Engine oil
(with
filter
change)Motocraft
motor oil
5W30 super
premiumAll 4.25 (4.5)
Fuel tank
capacityN/A All 60.6 (16.0
gallons)
Power
steering
fluidMotorcraft
MERCONt
AT FAll Fill to line in
reservoir
Automatic
transaxle
- AX4NMotorcraft
MERCONt
AT FAll 12.8 (13.5)
Automatic
transaxle
- AX4SMotorcraft
MERCONt
AT FAll 11.6 (12.2)
Windshield
washer
fluid -
FrontUltra-clear
windshield
washer
concentrateAll
Wagon2.7 (90 oz.)
2.1 (70 oz.)
3.0L Duratec engine
Fluid Ford Part
NameVehicle
TypeCapacity
Brake
fluidHigh
performance
DOT 3
brake fluidAll Fill to line
in reservoir
Engine
coolantPremium
cooling
system fluidAll 10.0 (10.6)
Capacities and specifications
158
ProCarManuals.com

Fluid Ford Part
NameVehicle
TypeCapacity
Engine oil
(with
filter
change)Motocraft
motor oil
5W30 super
premiumAll 5.2 (5.5)
Fuel tank
capacityN/A All 60.6 (16.0
gallons)
Power
steering
fluidMotorcraft
MERCONt
AT FAll Fill to line in
reservoir
Automatic
transaxle
- AX4NMotorcraft
MERCONt
AT FAll 12.7 (13.4)
Windshield
washer
fluid -
FrontUltra-clear
windshield
washer
concentrateAll 2.7 (90 oz.)
Windshield
washer
fluid -
RearUltra-clear
windshield
washer
concentrateWagon 2.1 (70 oz.)
3.4L SHO engine
Fluid Ford Part
NameVehicle
TypeCapacity -
Liters
(Quarts)
Brake
fluidHigh
performance
DOT 3
brake fluidAll Fill to line
in reservoir
Engine
coolantPremium
cooling
system fluidAll 10.0 (10.6)
Capacities and specifications
159
ProCarManuals.com

Fluid Ford Part
NameVehicle
TypeCapacity -
Liters
(Quarts)
Engine oil
(with
filter
change)Motocraft
motor oil
5W30 super
premiumAll 6.1 (6.5)
Fuel tank
capacityN/A All 60.6 (16.0
gallons)
Power
steering
fluidMotorcraft
MERCONt
AT FAll Fill to line in
reservoir
Automatic
transaxle
- AX4NMotorcraft
MERCONt
AT FAll 12.7 (13.4)
Windshield
washer
fluidUltra-clear
windshield
washer
concentrateAll 2.7 (90 oz.)
LUBRICANT SPECIFICATIONS
FluidFord Part
Name or
EquivalentFord Part
NumberFord
Specification
Brake
master
cylinderC6AZ-
19542-ABFord high
performance
DOT 3
brake fluidESA-
M6C25-A
Door latch,
hood latch,
auxiliary
latch, trunk
and liftgate
latchesD0AZ-
19584-AAMulti-
purpose
greaseESR-
M1C159-A
and ESA-
M1C93-A
Capacities and specifications
160
ProCarManuals.com

FluidFord Part
Name or
EquivalentFord Part
NumberFord
Specification
Lock
cylindersE8AZ-
19A501-BPenetrating
lubricantN/A
Automatic
transaxleXT-2-QDX Motorcraft
MERCONt
AT FMERCONt
Engine oil
(Gasoline
engines)XO-5W30-
QSPMotorcraft
5W30 super
premiumWSS-
M2C153-F
and API
Certification
Mark
Constant
velocity
jointsE43Z-19590-
ACV joint
grease -
high temp.ESP-
M1C207-A
Engine
coolantE2FZ-
19549-AAFord
premium
cooling
system
fluidESE-
M97B44-A
Power
steering
pump
reservoirXT-2-QDX Motorcraft
MERCONt
AT FMERCONt
ENGINE DATA
Engine data
Engine 3.0L SOHC
V63.0L DOHC
V63.4L DOHC
V8
Cubic
inches182 183 207
Horsepower 145 @ 5250
rpm200 @ 5750
rpm235 @ 6100
rpm
Capacities and specifications
161
