1997 FORD TAURUS Owners Manual

The high-current fuses are coded as follows:
Fuse/Relay
LocationFuse Amp
RatingCircuits
protected
1 40A* Fuse panel
2 30A* Constant
control relay
module
3 40A* Ignition switch,
starter relay
4 30A* Accessory delay
relay
5 40A* Ignition switch
6 30A* Power seats
7 40A* Rear window
defrost relay
8 30A* Thermactor air
bypass solenoid,
EAM solid state
relay
9 40A* Constant
control relay
module
10 20A* Constant
control relay
module
11 40A* Blower motor
relay
12 20A* Semi-active ride
control module
13 40A* Anti-lock motor
module
14 - Not used
Roadside emergencies
106
ProCarManuals.com

Fuse/Relay
LocationFuse Amp
RatingCircuits
protected
15 15A** Daytime
running lamps
(DRL) module
16 10A** Air bag
diagnostic
monitor
17 20A** Rear control
unit, CD
changer
18 30A** Anti-lock brake
module
19 15A** Horn relay,
powertrain
control module
20 15A** Headlamp
switch,
autolamp park
relay
21 - Not used
22 30A** Autolamps
relay,
multi-function
switch,
headlamp
switch
23 - N/A
24 - N/A
25 - N/A
26 30A** Generator/
Voltage
regulator
27 - N/A
Roadside emergencies
107
ProCarManuals.com

Fuse/Relay
LocationFuse Amp
RatingCircuits
protected
28 15A** Heated oxygen
sensors,
canister vent
29 - N/A
30 - N/A
31 - N/A
32 - N/A
33 - N/A
*Maxi fuses. **Mini fuses
Always disconnect the battery before
servicing high current fuses.
Always replace the cover to the Power
Distribution Box before reconnecting the
battery or refilling fluid reservoirs.
Relays
Relays are located in
the power distribution
box and should be
replaced by qualified
technicians.
Roadside emergencies
108
ProCarManuals.com

CHANGING THE TIRES
Temporary spare tire information
The temporary spare
tire for your vehicle is
labeled as such. It is
smaller than a regular
tire and is designed for
emergency use only.
If you use the temporary spare tire
continuously or do not follow these
precautions, the tire could fail, causing you to lose
control of the vehicle, possibly injuring yourself or
others.
When driving with the temporary spare tireDO
NOT:
²exceed 80 km/h (50 mph) under any
circumstances
²load the vehicle beyond maximum vehicle load
rating listed on the Safety Compliance Label
²tow a trailer
²use tire chains
²drive through an automatic car wash, because of
the vehicle's ground clearance
²try to repair the temporary spare tire or remove it
from its wheel
²use the wheel for any other type of vehicle
Roadside emergencies
109
ProCarManuals.com

Tire change procedure
1. Park on a level
surface, activate hazard
flashers and set
parking brake.
2. Place gearshift lever in P (Park), block the
diagonally opposite wheel, then remove the spare
tire, jack and lug wrench.
In the sedan, these are
located in the trunk
under the floor carpet.
In the wagon, they are
stored in the left side
rear trim panel.
BRAKE RELEASE
Roadside emergencies
110
ProCarManuals.com

3. Loosen each wheel
lug nut one-half turn
counterclockwise but
do not remove them
until the wheel is
raised off the ground.
4. Put the jack in the
jack notch next to the
door of the tire you are
changing. Turn the jack
handle clockwise until
the wheel is completely
off the ground.
5. Remove the lug nuts with the lug wrench.
6. Replace the flat tire with the spare tire, making
sure the valve stem is facing outward. Reinstall lug
nuts until the wheel is snug against the hub. Do not
fully tighten the lug nuts until the wheel has been
lowered.
7. Lower the wheel by turning the jack handle
counterclockwise.
8. Remove the jack and
fully tighten the lug
nuts in the order
shown.
1
4
2
5 3
Roadside emergencies
111
ProCarManuals.com

9. Put flat tire, jack
and lug wrench away.
Make sure jack is
fastened so it does not
rattle when you drive.
Unblock the wheels.
Removing and replacing wheel covers
Full wheel cover
Your vehicle may have wheel covers with a wire
retention system. To remove the wheel cover, pry it
loose by inserting the tapered end of the jack handle
between the wheel cover and wheel.
To replace the wheel cover:
1. One of the windows on the wheel cover is
identified with a valve stem logo on the back side of
the wheel cover. Install the wheel over the wheel
with the window at the valve stem.
2. Hold the wheel cover in this position and press
the cover onto the wheel with the palm of your
hand. Do not force or hammer the cover.
Center wheel cover
1. Pry the center
ornament off the wheel
cover with the lug
wrench. Pry only at the
notch. Do not use a
screwdriver or any
other tool as this may
damage the wheel
cover surface finish.
Roadside emergencies
112
ProCarManuals.com

2. Remove the center
bolt on the wheel cover
with the lug wrench
tip.
3. To remove the wheel
cover, pry it loose by
inserting the tapered
end of the lug wrench
between the wheel
cover and wheel.
To replace the wheel cover:
1. One of the windows on the wheel cover is
identified with a valve stem logo on the back side of
the wheel cover. Install the wheel over the wheel
with the window at the valve stem.
2. Hold the wheel cover in this position and press
the cover onto the wheel with the palm of your
hand. Do not force or hammer the cover.
3. Attach the bolt to the pedestal through the center
hole on the cover with the lug wrench.
4. Align the legs of the center ornament with the
slots of the wheel cover. Reinstall the ornament by
pressing with the palm of your hand. Do not
hammer or force the cover.
Anti-theft lug nuts (if equipped)
If your vehicle is
equipped with this
feature, one of the lug
nuts on each wheel
must be removed and replaced with a special key.
The key and registration card are attached to the lug
wrench and stored with the spare tire. If you lose
Roadside emergencies
