Brake system warning
Extinguishes when the parking
brake is released. Illumination after
releasing the parking brake
indicates low brake fluid level.
Safety belt
Illuminates when the ignition is
switched on to remind you to
fasten your safety belts. For more
information, refer toUsing the
safety restraints properlyin the
Seating and safety restraints
chapter.
Air bag readiness
Briefly illuminates when the
ignition is turned to On. If the light
fails to illuminate, continues to
flash or remains on, have the
system serviced. For more
information, refer to
Supplemental restraints system
(SRS)in theSeating and safety
restraintschapter.
Check engine warning light
This light illuminates when the
engine's Emission Control System
requires service. It will also
illuminate when the ignition key is
in the On position and the engine
is off. Refer toWhat you should
know about the on-board
diagnostic (OBD II) systemin the
Maintenance and carechapter.
!
BRAKE
CHECK
ENGINE
com_safety_belt.01
f12_air_bag_readiness
f12_check_engine
f12_tcil_light
Instrumentation
10

Transmission control indicator
light (TCIL)
The TCIL (OFF), located on the
end of the gearshift lever, may
flash steadily if a malfunction has
been detected. If the TCIL is
flashing, contact your Ford dealer
as soon as possible. If this
condition persists, damage to the
transmission could occur.
For more information, refer to the
Drivingchapter.
4x4 light (if equipped)
Illuminates when 4H (Four-Wheel
Drive) or 4L (Four-Wheel Drive
Low) is engaged.
4x4 low range (if equipped)
Illuminates when 4L (Four-Wheel
Drive Low) is engaged.
Anti-lock brake system (ABS)
Momentarily illuminates when the
ignition is turned on and the
engine is off. If the light stays on
or continues to flash, the ABS
needs to be serviced.
Fuel reset
Illuminates when the ignition key
is turned to the ON position and
the fuel pump shut-off switch has
been triggered. For more
information, refer toFuel pump
shut-off switchin theRoadside
emergencieschapter.
OVERDRIVE OFF
4x4
LOW
RANGE
ABS
FUEL
RESET
f12_4x4_light
f12_4x4_low
com_anti-lock_brake.01
com_fuel_reset.01
com_anti-theft_alarm.01
Instrumentation
11

Anti-theft system (if equipped)
Illuminates when the anti-theft
system is arming and flashes when
the anti-theft system is armed.
High beams
Illuminates when the headlamp
high beams are on.
Turn signal
Illuminates when the left or right
turn signal or the hazard lights are
turned on.
Testing warning lights
Turn the ignition key to On
without starting the vehicle. The
THEFT
!MPH 1050
3070
4080
120
140
18 0
40
20
0
10090 60
8060100
20 km/h
0010
000005CH
EF
DOOR
AJARLOW
FUEL
MPH
CHECK
ENGINEABS
L H18
8
BRAKE
!
LOW
FUEL
ABS
BRAKE
3
MPH 1050
3070
4080
120
140
18 0
40
20
0
10090 60
8060100
20 km/h
0010
0000052
4
5
6 01LH
CH
EF
818RPMx1000CHECK
ENGINE
com_high_beams.01
com_turn_signal.01
f12_testing_lights
Instrumentation
12

warning and indicator lights shown
above will illiminate for a brief
time. If any of these lights do not
illuminate, contact your dealer for
service.
Headlamps on warning chime
Sounds when the headlamps are
on, the key is out of the ignition
and any door is opened.
Key-in-ignition warning chime
Sounds when the key is left in the
ignition and any door is opened.
The chime is not active when the
ignition key is in the On position.
Safety belt warning chime
For information on the safety belt
warning chime, refer to the
Seating and safety restraints
chapter.
Supplemental restraint system
(SRS) warning chime
For information on the SRS
warning chime, refer to the
Seating and safety restraints
chapter.
f12_headlamps_on
f12_key_in_ignition
com_safety_chime.01
com_srs_chime.01
f12_gauges
Instrumentation
13

INSTRUMENT CLUSTER
GAUGES
Your vehicle has one of the
following instrument clusters:
Speedometer
Indicates the current vehicle road
speed.
1050
3070
4080
120
140
18 0
40
20
0
10090 60
8060100
20 km/h
0010
000005L HCH
18
8EFEF
3
1050
3070
4080
120
140
18 0
40
20
0
10090 60
8060100
20 km/h
0010
2
4
5
6 01LH
CH
EF
818
THEFT
RPMx1000
3
MPH 1050
3070
4080
120
140
18 0
40
20
0
10090 60
8060100
20 km/h
0010 000005
2
4
5
6 01LH
CH
EF
818
THEFT
RPMx1000
MPH
50
4080
120
140
18 0
4060100
20 km/h
0010
000005
MPH 1050
3070
4080
120
140
18 0
40
20
0
10090 60
8060100
20 km/h
0010
000005
f12_speedometer
com_tachometer.02
Instrumentation
14

Tachometer (if equipped)
Indicates the engine speed in
revolutions per minute.
Engine coolant temperature
gauge
Indicates the temperature of the
engine coolant. At normal
operating temperature, the needle
remains within the normal area. If
it enters the red section, the
engine is overheating. Switch off
the ignition and let it cool. Refer to
Checking and adding engine
coolantorWhat you should know
about fail safe coolingin the
Maintenance and carechapter.
Fuel gauge
Indicates the fuel level.
0RPMx1000
3
2
4
5
6 1
CHCH
EF
f12_engine_coolant
f12_fuel_gauge f12_voltage_gauge
Instrumentation
15

Voltage gauge
If the pointer moves and stays
outside of the normal range, it
indicates that the battery is not
being charged. Have the vehicle's
electrical system checked by your
dealer as soon as possible.
Engine oil pressure gauge
This shows the engine oil pressure
in the system. Sufficient pressure
exists as long as the needle
remains in the normal range. If the
gauge indicates constantly low
pressure at normal engine speed,
refer toChecking and adding
engine oilin theMaintenance
and carechapter. If the gauge
indicates a low pressure and the
engine oil level is correct, switch
off the engine immediately and
have your vehicle checked at your
dealer.
Odometer
Registers the total kilometers
(mileage) of the vehicle.
818818
LHLH
MPH
50
4080
120
140
18 0
4060100
20 km/h
0010
000005
MPH 1050
3070
4080
120
140
18 0
40
20
0
10090 60
8060100
20 km/h
0010
0
00
00
00
00
05
5
f12_oil_pressure
f12_odometer f12_trip_odometer
Instrumentation
16

Trip odometer
Registers the kilometers (miles) of
individual journeys. To reset,
depress the control.
MPH
50
4080
120
140
18 0
4060100
20 km/h
0010
000005
MPH 1050
3070
4080
120
140
18 0
40
20
0
10090 60
8060100
20 km/h
0
000005
001
Instrumentation
