1997 FORD ESCORT Owners Manual

Cleaning the instrument panel
Any cleaner or polish that
increases the gloss of the upper
portion of the instrument panel
should be avoided. The dull finish
in this area is to help protect the
driver from windshield reflection.
Cleaning the exterior lamps
Do not use dry paper towels,
chemical solvents, or abrasive
cleaners to clean the lamps; these
products may cause scratches or
crack the lamps.
Cleaning the engine
A clean engine is more efficient
than a dirty one because a buildup
of grease and dirt acts as an
insulator and keeps the engine
warmer than normal. Follow these
guidelines to clean your engine:
²Take care when using a power
washer to clean the engine. The
high pressure fluid could
penetrate sealed parts and
cause damage.
²In order to avoid cracking the
engine block or fuel injection
pump, do not spray these
components with cold water.
²The alternator and air intake
must be covered to prevent
water damage when cleaning the
engine.
²Never wash or rinse the engine
while it is running; water in a
running engine may cause
internal damage.
Maintenance and care
177

Cleaning the wiper blades
If the blades do not wipe properly,
clean both the windshield and the
wiper blades using undiluted
windshield washer solution or a
mild detergent. Rinse thoroughly
with clean water. Do not use fuel,
kerosene, paint thinner, or other
solvents to clean the wiper blades;
these fluids will damage the
blades.
Cleaning the built-in child seat
Clean the built in child seat with
mild soap and water. Do not use
household cleaning products
because they may weaken the
safety belt webbing or damage the
vinyl parts of the seat.
The child seat liner is removable
and may be machine washed and
air dried.
Cleaning and maintaining the
safety belts
Clean the safety belts with a mild
soap solution recommended for
cleaning upholstery or carpets. Do
not bleach or dye the belts; this
may weaken the belt webbing.
Check the safety belt system
periodically to ensure there are no
nicks, wear, or cuts. If the vehicle
has been involved in an accident,
have all the safety belts and child
seat anchoring brackets (if
equipped) examined by a qualified
technician.
Maintenance and care
178

MOTORCRAFT PART NUMBERS
Component Ford part number Ð 2.0 liter
SPI engine
Air filter F7CX-9601-AA
Battery BX-58C
Fuel filter FG-862
Oil filter FL400-A
PCV valve EV-229
Spark plug* AGSF-34-E
* Refer to the Vehicle Emission
Control Information (VECI) decal,
located on the underside of the
hood, for gap specifications.
REFILL CAPACITIES
Your vehicle's fuel capacity
The fuel capacity for your vehicle
is 48.0 L (12.7 gallons).
²To avoid overspill from the filler
neck, stop fueling at the second
automatic shut off.
²For more information on fueling
your vehicle, refer toChoosing
the right fuelin the
Maintenance and carechapter.
Capacities and specifications
179

Capacities Ð liters (quarts) 2.0 liter SPI engine
Engine Oil Ð including filter /
excluding filter3.8 L (4.0 qt) / 3.3 L (3.5 qt)
Manual transaxle 3.35 L (3.55 qt)
Automatic transaxle Ð full torque
converter / empty torque
converter3.9 L (4.1 qt) / 6.3 L (6.7 qt)
Radiator filler cap 110 kPa (16 psi)
Engine coolant
Iautomatic transaxle
Imanual transaxle6.0 L (6.3 qt)
5.0 L (5.3 qt)
LUBRICANT SPECIFICATIONS
Item Ford part
nameFord part
numberFord
specification
Brake master
cylinderFord High
Performance
DOT 3 Motor
Vehicle Brake
FluidC6AZ-19542-AB ESA-M6C25-A,
DOT 3
Constant
velocity jointsCV Joint
Grease Ð High
TemperatureE43Z-19590-A ESP-MIC207-A
Door
weatherstripsSilicone
Lubricant
(tube)
(aerosol)COAZ-19553-AA
D7AZ-19553-AAESR-M13P4-A
ESR-M13P4-A
Engine coolant Ford Premium
Cooling System
FluidE2FZ-19549-AA,
-BESE-M97B44-A
Capacities and specifications
180

Item Ford part
nameFord part
numberFord
specification
Engine oil Motorcraft
5W-30 Super
Premium Motor
OilXO-5W-30 WSS-M2C153-F
Hinges and
latchesFord
Multi-Purpose
Grease Spray
(Aerosol)
F5AZ-19G209-AAESR-M1C159-A
and
ESB-M1C93A
Lock cylinders Penetrating
LubricantE8AZ-19A501-B N/A
Power steering
pumpPremium
Power Steering
FluidE6AZ-19582-AA ESW-M2C33-F
Automatic and
manual
transaxleMotorcraft
MERCONt
Multi-Purpose
(ATF)
Transmission
FluidXT-2-BDX,
-QDXMERCON
Wheel bearings,
rearMotorcraft
Premium
Long-Life
GreaseXG-1-C, -K ESA-M1C75-B
Windshield
washer fluid
reservoirUltra-Clear
Windshield
Washer
ConcentrateC9AZ-19550-AC
or
C9AZ-19550-BCESR-M17P5-A
Capacities and specifications
181

ENGINE DATA
Engine 2.0 liter; 121 CID; 4 cylinder (in-line);
compression ratio 9.2:1; single overhead cam;
split port induction (SPI)
Horsepower 110 at 5,000 rpm
Torque 169 Nm (125 lb ft at 3,750 rpm)
Required fuel grade 87 (R+M)/2
Firing order /
Injection timing1-3-4-2
Spark plug gap 1.3 to 1.4 mm / 0.052 to 0.056
Ignition system DIS
Valve clearances cold
inlet exhaust0: Maintenance free 0: Maintenance free
VEHICLE DIMENSIONS
Dimensions Ð cm
(inches)Sedan Wagon
V1Overall length 443.25 cm (174.5 in) 439.1 cm (172.9 in)
V2Overall width
(excluding exterior
mirrors)168.00 cm (66.2 in) 170 cm (67 in)
V3Maximum height 135.00 cm (53.2 in) 136.9 cm (53.9 in)
V4Wheelbase 250.00 cm (98.4 in) 250 cm (98.4 in)
V5Track Front
Rear143.5 cm (56.5 in),
143.5 cm (56.5 in)143.5 cm (56.5 in),
143.5 cm (56.5 in)
Capacities and specifications
182

5
2
3
5
2
3
Capacities and specifications
183

4
1
4
1
Capacities and specifications
184
