Anti-lock brake system (ABS)
Illuminates when the ABS needs
service. The light will also briefly
illuminate when the ignition key is
turned to ON and the engine is off.
Turn signal
Illuminates when the left hand or
right hand turn signal or the
hazard lamps are illuminated.
High beams
Illuminates when the headlamp
high beams are on.
Anti-theft (if equipped)
Illuminates when the anti-theft
system is arming and flashes when
the anti-theft system is armed.
Charging
Illuminates when there is a
problem with the alternator or
charging system and the electrical
system requires service. The light
will also briefly illuminate when
the ignition key is turned to ON
and the engine is off.
Oil pressure
Illuminates when the oil pressure
is low, not the low oil level.
However, if your engine's oil level
is low, it could affect the oil
pressure. Stop the vehicle and
check the oil level as soon as
possible. Do not drive the vehicle if
the light remains on. The light will
also briefly illuminate when the
ignition key is turned to ON and
the engine is off.
ABS
THEFT
Instrumentation
9

Engine coolant
Illuminates when there is low
coolant level or a problem with the
engine coolant system. Stop the
vehicle and check the engine
coolant level as soon as possible.
The light will also briefly illuminate
when the ignition key is turned to
ON and the engine is off. For more
information on engine coolant,
refer toChecking and adding
engine coolantin the
Maintenance and carechapter.
Liftgate ajar (if equipped)
Illuminates when the ignition is in
the ON position and the liftgate is
open.
Many of the lights illuminate
briefly when you start the vehicle.
For more information on warning
light illumination, refer to
Preparing to start the vehiclein
theStartingchapter.
Warning chimes
Safety belt warning chime
For information on the safety belt
warning chime, refer to the
Seating and safety restraints
chapter.
Supplemental restraint system
(SRS) warning chime
For information on the SRS
warning chime, refer to the
Seating and safety restraints
chapter.
CHECK
COOLANT
Instrumentation
10

Key-in-ignition warning chime
A warning chime sounds when the
key is left in the ignition and any
door is opened.
Headlamps-on warning chime
A warning chime sounds when the
headlamps are on, the ignition is
off, and a door is opened.
Instrumentation
11

Instrument cluster gauges
Base cluster gauges
Sport cluster gauges
0000
000000
MPH
km/h
10 2030405060
70
80
90
10 0
12 011 020 4060
8010 0
12 0
16 0
18 0 140
200
FUEL FILLEF1/2CH
0000
000000
MPH
km/h
10 2030405060
70
80
90
10 0
12 011 020 4060
8010 0
12 0
16 0
18 0 140
200
FUEL FILLCHEF1/22
134
5
6
7
8RPM x 1000
Instrumentation
12

Speedometer
Fuel gauge
When the fuel gauge needle is on
the E (empty) portion of the
gauge, there are between
approximately 2 L (.6 gallons) and
4 L (1 gallon) of usable fuel left in
the tank.
Engine coolant temperature
gauge
If the engine coolant temperature
gauge moves into the H zone:
1. Pull off the road as soon as is
safely possible.
2. Turn off the engine and let it
cool.
3. Check and add engine coolant
as necessary. Refer toChecking
and adding engine coolantin the
Maintenance and carechapter. If
the coolant level and mixture is
not properly maintained, the
engine coolant temperature gauge
will not read properly.
0000
000000
MPH
km/h
10 2030405060
70
80
90
10 0
12 011 020 4060
8010 0
12 0
16 0
18 0 140
200
EF1/2
CH
Instrumentation
13

Odometer
The odometer gives a six digit
reading of how many kilometers
(miles) your vehicle has traveled.
Trip odometer
The trip odometer gives a four
digit reading of how many
kilometers (miles) your vehicle has
traveled in an individual trip.
Press the reset button to begin an
individual trip odometer record.
Tachometer
0000
000000
MPH
km/h
10 2030405060
70
80
90
10 0
12 011 020 4060
8010 0
12 0
16 0
18 0 140
200
2
134
5
6
7
8RPM x 1000
Instrumentation
14

INSTRUMENT PANEL DIMMER
SWITCH
To adjust the instrument panel
dimmer switch:
²Rotate the switch to the right to
dim the instrument panel
lighting.
²Rotate the switch to the left to
brighten the instrument panel
lighting.
HI LOOFF*A/C*MAX
A/C
TUNE
DISCS

SEEK
TUNE
SCAN
EJ REW FF
BAL BASSTREBFADE TAPE
CD AM
FM
–+1
SIDE 1-22
345
COMP1
SIDE 1-2VOL–
PUSH ON
LMIRRORR
00000000002030405060
70
80
90
10 0
11 020 40608010 0
12 0
16 0
18 0 140
200FUEL FILLCHEF1/22
13RPM x 1000
RSM
SET
ACC
CST OFF ON
OFFINT
1 OFF MIST
HI LOOFF*A/C*MAX
A/C
TUNE
DISCS

SEEK
TUNE
SCAN
EJ REW FF
BAL BASSTREBFADE TAPE
CD AM
FM
–+1
SIDE 1-22
345
COMP1
SIDE 1-2VOL–
PUSH ON
LMIRRORR
0000000002030405060
70
80
90
10 0
11 020 40608010 0
12 0
16 0
18 0 140FUEL FILLCHEF1/22
13RPM x 1000
RESET
SET
ACC
SET XXXX XXXOFF2INT
1 OFF MIST
Controls and features
15

POWER OUTSIDE MIRRORS (IF
EQUIPPED)
To adjust the outside mirrors:
1. Select the mirror you want to
adjust.
LDriver side mirror
RPassenger side mirror
2. Move the mirror control in the
desired direction.
3. Lock the mirror by moving the
switch to the center position.
R LMIRRORS
HI LOOFF*A/C*MAX
A/C
TUNE
DISCS

SEEK
TUNE
SCAN
EJ REW FF
BAL BASSTREBFADE TAPE
CD AM
FM
–+1
SIDE 1-22
345
COMP1
SIDE 1-2VOL–
PUSH ON
LMIRRORR
0000000002030405060
70
80
90
10 0
11 020 40608010 0
12 0
16 0
18 0 140FUEL FILLCHEF1/22
13RPM x 1000
RESET
SET
ACC
SET XXXX XXXOFF2INT
1 OFF MIST
Controls and features
