1997 FORD ESCORT Owners Manual

Sounding a panic alarm
Press once to sound an alarm
(with either the driver-door only or
all-door system).
²Sedan
²Wagon
The parking lamps flash, the horn
sounds, and the illuminated entry
system turns on.
Press a second time to turn off the
alarm.
Illuminated entry
Interior lamps illuminate when the
UNLOCK button is pressed on the
remote entry transmitter (if
equipped). The illuminated entry
function illuminates the interior
overhead lamp for approximately
20 seconds, until the key is
inserted into the ignition and
turned to ON, or until the LOCK
button is pressed on the remote
entry transmitter. The interior
overhead lamp must be set to the
DOOR position in order for the
UN
LOCK
LOCK
PANIC
UN
LOCKLOCK
TRUNK
PANIC
Controls and features
49

illuminated entry system to
activate.
Anti-theft system (if equipped)
The anti-theft system protects
against unauthorized entry into an
armed and locked vehicle. When
an unauthorized entry occurs, the
system activates and:
²flashes the parking lamps and
anti-theft indicator light
²sounds the horn
The horn and parking lamps shut
off after approximately three
minutes. The lights and horn will
remain off unless another
unauthorized entry is attempted.
Arming the system
The anti-theft system can be
armed when:
²the ignition is in the LOCK
position and the key is removed
²the panic alarm is off
²all doors are closed
Controls and features
50

Press once to arm the anti-theft
system.
The THEFT light in the instrument
cluster illuminates until the arming
procedure is complete. After the
arming procedure is complete, the
THEFT light flashes.
Disarming an untriggered
system
Press once to disarm the
untriggered anti-theft system.
If the driver armed the system but
did not exit the vehicle, the system
can also be disarmed by inserting
the key and turning the ignition to
ON.
The system will not disarm by
using the key in any door/trunk
lock cylinder.
UN
LOCK
LOCK
PANIC
UN
LOCKLOCK
TRUNK
PANIC
UN
LOCK
LOCK
PANIC
UN
LOCKLOCK
TRUNK
PANIC
Controls and features
51

Disarming a triggered system
Press either the UNLOCK or
PANIC button to disarm a
triggered anti-theft system.
A triggered system can also be
disarmed by inserting the key and
turning the ignition to ON.
This device complies with Part 15
of the FCC rules. Operation is
subject to the two following
conditions: (1) this device may not
cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause
undesired operation.
Replacement batteries for the
remote entry and/or anti-theft
system transmitters can be
purchased at pharmacies, watch
stores, or at authorized dealers.
If a transmitter is lost, a new one
may be programmed by your
dealer. Take any remaining
transmitters with you to the dealer
so they may be reprogrammed.
The system will work with up to
four transmitters. Your vehicle
comes equipped with two
transmitters; additional
transmitters can be ordered from
your dealer. It will be necessary to
have all of the transmitters
programmed to the remote entry
system by the dealer at the same
time.
UN
LOCK
LOCK
PANIC
UN
LOCKLOCK
TRUNK
PANIC
Controls and features
52

FRONT SEATS
Lift handle to slide the seat
forward or backward
Lift to adjust the seatback
Seating and safety restraints
53

Head restraints
Push the release button to lower
the head restraint
To raise the head restraint, pull
without pushing the release
button.
REAR SEATS
Stow the built-in child seat (if
equipped) in order to fold the rear
seatback down. Refer toBuilt-in
child seatin this chapter for more
information.
Push the seatback back to a raised
position and latch for normal
seating.
The full rear seat bench is shown.
The split-folding rear seat (if
equipped) operates in a similar
manner.
Press to unlock the seatback:
Seating and safety restraints
54

SAFETY RESTRAINTS
PRECAUTIONS
The use of safety belts helps to
restrain you and your passengers
in case of a collision. In most
states and in Canada, the law
requires the use of safety belts.
To reduce the risk of
serious injury in a
collision, always drive and ride
with your seatback upright and
the lap belt snug and low across
the hips.
Safety belts must be worn
by all vehicle occupants to
be properly restrained and help
reduce the risk of injury in a
collision.
To prevent the risk of
injury make sure children
sit where they can be properly
restrained.
It is extremely dangerous
to ride in a cargo area,
inside or outside of a vehicle. In
a collision, people riding in these
areas are more likely to be
seriously injured or killed.
Do not allow people to
ride in any area of your
vehicle that is not equipped with
seats and safety belts.
Seating and safety restraints
55

Be sure everyone in your
vehicle is in a seat and
using a safety belt properly.
USING THE SAFETY
RESTRAINTS PROPERLY
Combination lap and shoulder
belts
Insert the tongue into the slot to
fasten.
Push the red release button and
remove the tongue from the slot to
unfasten.
The lap belts should fit
snugly and as low as
possible around the hips, not
around the waist.
The outboard safety restraints in
the vehicle are combination lap
and shoulder safety belts. The
front and rear seat passenger
outboard safety belts have the two
types of locking modes.
Seating and safety restraints
56
