1997 FORD ASPIRE service

177
gasolines, the performance of the emission
control devices and systems may be adversely
affected. Repair of damage caused by using a
fuel that your vehicle was not designed for may
not be covered by your warranty.
%*
[MC43870(ALL)08/96]
Octane recommendation
*
[MC43876(ALL)05/96]
Your vehicle is designed to use regular gasoline
with an (R+M)/2 octane rating of 87.We do not
recommend gasolines labeled as ªregularº in
high altitude areas that are sold with octane
ratings of 86 or even less.
*
[MC43880(ALL)05/96]
one inch art:0060001-C
Typical octane rating label
*
[MC43891(ALL)08/96]
Do not be concerned if your vehicle sometimes
knocks lightly. However, if it knocks heavily
under most driving conditions on the
recommended octane fuel, see your dealer or a
qualified service technician to prevent any
engine damage.
%*
[MC43895(ALL)05/96]
Fuel quality
*
[MC43901(ALL)05/96]
If you are experiencing starting, rough idle or
hesitation problems try a different brand of fuel.
If the condition persists, see your dealer or a
qualified service technician.
*
[MC43904(ALL)08/96]
The American Automobile Manufacturers
Association (AAMA) issued a gasoline
specification to provide information on high
quality fuels that optimize the performance of
your vehicle. We recommend the use of
gasolines that meet the AAMA specification if
they are available.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

181
*
[MC44130(ALL)01/96]
q
Underinflated tires
*
[MC44135(ALL)01/96]
q
Heavy loads
*
[MC44140(ALL)01/96]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
[MC44145(ALL)01/96]
NOTE: During extended periods of vehicle
storage (60 days or more) fuel may
deteriorate due to oxidation. This can
damage rubber and other polymers in
the fuel system and may also clog
small orifices.
%
*
[MC47600(ALL)01/96]
Emission Control System
*
[MC47700(ALL)01/96]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[MC47750(ALL)05/96]
WARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
*
[MC47800(ALL)01/96]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[MC47900(ALL)01/96]
q
Use only unleaded fuel.
*
[MC48000(ALL)01/96]
q
Avoid running out of fuel.
*
[MC48100(ALL)01/96]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[MC48200(ALL)07/96]
q
Have the services listed in yourMaintenance
Schedulebooklet performed according to the
specified schedule.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

182
*
[MC48300(ALL)01/96]
WARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[MC48400(ALL)01/96]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
*
[MC48500(ALL)01/96]
Do not make any unauthorized changes to your
vehicle or engine. Changes that cause more
unburned fuel to reach the exhaust system can
increase the temperature of the engine or
exhaust system.
*
[MC48550(ALL)01/96]
In general, maintenance, replacement, or service
of the emissions control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
those which your vehicle or engine was
originally equipped.
*
[MC48575(ALL)01/96]
If other than Ford or Motorcraft or Ford
authorized remanufactured parts are used for
maintenance, replacement, or for the service of
components affecting emissions control, the
owner should be assured that such parts are
warranted by their manufacturer to be
equivalent to genuine Ford Motor Company
parts in performance and durability. Please
consult your warranty information booklet for
complete warranty information.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

183
*
[MC48600(ALL)01/96]
By law, anyone who manufactures, repairs,
services, sells, leases, trades vehicles, or
supervises a fleet of vehicles is not permitted to
intentionally remove an emission control device
or prevent it from working. In some of the
United States and in Canada, vehicle owners
may be liable if their emission control device is
removed or is prevented from working.
*
[MC48700(ALL)08/95]
Never use a metal exhaust collector when you
service your vehicle. If the metal collector
contacts any of your vehicle's plastic trim or
bumper parts they could melt or deform.
*
[MC48800(ALL)01/96]
Do not drive your vehicle if it does not operate
properly. See your dealer if the engine runs on
for more than five seconds after you shut it off
or if it misfires, surges, stalls, or backfires.
%*
[MC48900(ALL)01/96]
Information about your vehicle's emission
control system is on the Vehicle Emission
Control Information decal located on or near the
engine. This decal identifies engine displacement
and gives some tune-up specifications.
%*
[MC48910(ALL)03/96]
How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) Testing
[MC48920(ALL)02/97]
In some localities it may become a legal
requirement to pass an
Inspection/Maintenance (I/M) test of the
On-Board Diagnostic (OBD) II system. If your
ªCheck Engineº light is on, reference the ªCheck
Engineº light description under the Warning
Lights and Gauges section. Your vehicle may not
pass an I/M test with the Check Engine light on.
If the vehicle's powertrain system or its battery
has just been serviced, the OBD II system is
reset to a not ready for for I/M testing
condition. To prepare for I/M testing, additional
mixed city and highway driving to complete the
check of the OBD II system is necessary.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

184
*
[MC48950(ALL)07/96]
The driving modes required to reach the ready
condition consist of a minimum of 30 minutes of
city and highway driving as described below:
*
[MC48960(ALL)03/96]
q
20 minutes of driving in stop and go
city-type traffic with at least four idle periods.
*
[MC48970(ALL)03/96]
q
10 minutes of driving on an expressway or
highway.
*
[MC48980(ALL)05/96]
Before completing the above driving modes, the
engine must be warmed up and at operating
temperature. Once started, the vehicle must not
be turned off during the above driving modes. If
the vehicle owner is unable to meet the I/M
requirements by using these driving patterns, an
authorized service center can perform a detailed
OBD II drive cycle as it would any other type of
repair work.
%
*
[MC60000(ALL)03/96]
Lights and Bulb Replacement
*
[MC60100(ALL)01/96]
It is a good idea to check the operation of the
following lights frequently:
*
[MC60200(ALL)01/96]
q
headlamps
[MC60300(ALL)01/96]
q
high mount brakelamp
*
[MC60400(ALL)01/96]
q
tail lamps
*
[MC60500(ALL)01/96]
q
brakelamps
*
[MC60600(ALL)01/96]
q
hazard flasher
*
[MC60700(ALL)01/96]
q
turn signals
*
[MC60800(ALL)01/96]
q
side markers
*
[MC60900(ALL)05/96]
q
license plate lamps
*
[MC61000(ALL)01/96]
q
fog lamps
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

204
[CS55000(ALL)02/96]
Your Engine Type
[CS55100(ALL)02/96]
Your vehicle has a 1.3L (81 CID), fuel injected,
overhead cam, four-cylinder engine.
[CS55200(ALL)02/96]
The following page shows you a diagram of the
engine and where to find items you should
regularly service.
File:12iccsf.ex
Update:Tue Mar 4 08:57:46 1997

211
Customer Assistance
%*
[HS00205(ALL)06/94]
Roadside Assistance
*
[HS00210(ALL)11/95]
Ford Motor Company has set up a 24-hour,
seven-day-a-week hotline with trained operators
who put you in touch with the help you need if
you experience a problem with your vehicle.
This complimentary service is provided to you
throughout your warranty period of 3 years or
36,000 miles (60,000 km), whichever comes first.
To purchase Roadside Assistance coverages
beyond this period (available through Ford Auto
Club in the United States or Ford and
Lincoln-Mercury dealers in Canada), contact
your Ford or Lincoln-Mercury dealer. Additional
Roadside Assistance coverage is unavailable in
Puerto Rico and the Virgin Islands.
*
[HS00215(ALL)06/94]
Roadside Assistance will cover the following:
*
[HS00220(ALL)06/94]
q
Mount your spare if you have a flat tire.
*
[HS00225(ALL)06/94]
q
Jump-start your battery if it is dead.
*
[HS00230(ALL)06/94]
q
Unlock your vehicle if you are locked out.
*
[HS00235(ALL)06/94]
q
Bring you fuel if you run out.
*
[HS00240(ALL)06/94]
q
Tow your vehicle if you are stranded. Even
non-warranty related tows, like accidents or
getting stuck in mud or snow, are covered
(some exclusions apply, such as impound
towing and repossession).
File:14ichsf.ex
Update:Tue Mar 4 08:58:16 1997

212
*
[HS00245(ALL)06/94]
How to use Roadside Assistance
*
[HS00250(ALL)06/94]
Your Roadside Assistance identification card can
be found in the Owner Guide portfolio in your
glove compartment. Complete the card and place
it in your wallet for quick reference.
*
[HS00255(ALL)04/95]
To receive roadside assistance in the United
States call 1-800-241-FORD (in Canada call
1-800-665-2006).
*
[HS00260(ALL)04/95]
Should you need to arrange for roadside
assistance yourself, Ford Motor Company will
reimburse the reasonable cost. To obtain
information about reimbursement call
1-800-241-FORD (in Canada call 1-800-665-2006).
*
[HS00300(ALL)01/95]
If You Have a Service Problem
*
[HS00400(ALL)01/95]
Ford Motor Company has authorized Ford and
Lincoln-Mercury dealerships that can service
your vehicle for you. This chapter tells you how
to get service or maintenance for your vehicle.
%*
[HS00475(ALL)02/95]
Service/Maintenance Concerns
(U.S. or Canada)
*
[HS00600(ALL)04/95]
Ford recommends taking your vehicle to your
selling dealer who wants to ensure your
continued satisfaction. You may, however, take
your vehicle to any authorized Ford or
Lincoln-Mercury dealer. In most cases, your
dealer will be able to resolve your concern.
*
[HS00700(ALL)04/95]
If you are not satisfied with the service you
received from your dealership's service
department, talk to the service manager at the
dealership, or if you still are not satisfied, talk to
the owner or general manager of the dealership.
In most cases, you will have your concern
resolved at this level.
